P0335-CRANKSHAFT POSITION SENSOR CIRCUIT (CONTINUED) 6. CRANKSHAFT POSITION SENSOR NOTE: Inspect the slots on the flywheel for damage. If a problem is found repair as necessary. If there are no possible causes remaining, view repair. Repair Replace the Crankshaft Position Sensor. Perform the POWERTRAIN VERIFICATION TEST. (Refer to 9 - ENGINE - STANDARD PROCEDURE) 7. (K24) CKP SIGNAL CIRCUIT SHORTED TO BATTERY VOLTAGE Turn the ignition off. Disconnect the C2 PCM harness connector. Ignition on, engine not running. Measure the voltage on the (K24) CKP Signal circuit in the CKP Sen- Is the voltage above 0 volts? Yes >> Repair the short to battery voltage in the (K24) CKP Signal circuit. Perform the POWERTRAIN VERIFICATION TEST. (Refer No >> Go To 8 9 - 410 ENGINE - ELECTRICAL DIAGNOSTICS - 3.7L/4.7L/5.7L DR/DH |
