PASSENGER SEAT BELT TENSIONER SHORT TO GROUND (CONTINUED) 2. CHECK FOR SHORTED PASSENGER SEAT BELT PRETENSIONER WARNING: To avoid personal injury or death, turn the ignition off, NOTE: Check connectors - Clean and repair as necessary. WARNING: To avoid personal injury or death, turn the ignition on, Does the scan tool display: PASSENGER SEAT BELT TEN- Yes >> Go To 3 No >> Replace the Passenger Seat Belt Pretensioner in accor- dance with the Service Information. Perform ORC VERIFICATION TEST - VER 1 3. CHECK (R56) PASSENGER SEAT BELT TENSIONER LINE 1 CIRCUIT AND (R54) PASSENGER SEAT WARNING: To avoid personal injury or death, turn the ignition off, Disconnect the ORC connectors. NOTE: Check connectors - Clean and repair as necessary. Measure the resistance of the (R56) Passenger Seat Belt Tensioner Measure the resistance of the (R54) Passenger Seat Belt Tensioner Is the resistance below 10K ohms on either circuit? Yes >> Repair the Passenger Seat Belt Tensioner circuits with a resistance below 10k ohms for a short to ground. Perform ORC VERIFICATION TEST - VER 1 No >> Go To 4 8O - 178 RESTRAINTS - ELECTRICAL DIAGNOSTICS DR/DH |
