1. Disconnect negative cable from battery. 2. Drain cooling system (Refer to 7 - COOLING - STANDARD PROCEDURE). 3. Remove right and left cylinder head covers (Refer to 9 - ENGINE/CYLINDER HEAD/CYLINDER HEAD COVER(S) - REMOVAL). 4. Remove radiator fan shroud (Refer to 7 - COOL- ING/ENGINE/RADIATOR FAN - REMOVAL). 5. Rotate engine until timing mark on crankshaft damper (2) aligns with TDC mark on timing chain 6. Remove power steering pump (Refer to 19 - STEERING/PUMP - REMOVAL). 7. Remove access plug from left and right cylinder heads for access to chain guide fasteners. 8. Remove the oil fill housing to gain access to the right side tensioner arm fastener. 9. Remove crankshaft damper (Refer to 9 - ENGINE/ ENGINE BLOCK/VIBRATION DAMPER - REMOVAL) and timing chain cover (Refer to 9 - 9 - 2154 ENGINE - 3.7L - SERVICE INFORMATION DR/DH |
