Fig. 16: Flex Plate Inspection Cover & Fastener
Courtesy of CHRYSLER LLC

18. Remove the flex plate access plate (1).

Fig. 17: Removing P/S Pump
Courtesy of CHRYSLER LLC

19. Remove the P/S pump (2).



2007 Dodge Nitro R/T

2007 ENGINE 4.0L - Service Information - Nitro



Fig. 18: Removing/Installing Torque Converter Bolts
Courtesy of CHRYSLER LLC

20. Remove the torque converter bolts (2).

Fig. 19: Ground Strap & Transmission Housing Bolts
Courtesy of CHRYSLER LLC

21. Remove the transmission housing to engine mounting bolts (2).



2007 Dodge Nitro R/T

2007 ENGINE 4.0L - Service Information - Nitro



Fig. 20: Removing/Installing Engine Mounting To Frame Fasteners
Courtesy of CHRYSLER LLC

22. Remove the engine mounting to frame fasteners (1).

23. Remove the upper intake manifold (Refer to REMOVAL ).

24. Disconnect the heater hose.

Fig. 21: Disconnecting Coolant Temperature, Cam Position & Oil Pressure Sensor Electrical
Connectors
Courtesy of CHRYSLER LLC

25. Disconnect the coolant temperature, cam position (1), oil pressure sensor electrical connectors.



2007 Dodge Nitro R/T

2007 ENGINE 4.0L - Service Information - Nitro



Fig. 22: Ignition Coils
Courtesy of CHRYSLER LLC

26. Disconnect the left ignition coil (1) and fuel injector harness connectors and position the wiring harness

aside.

27. Remove the right intake manifold support braces.

28. Disconnect the capacitor and ground strap from the right cylinder head cover.

Fig. 23: Ignition Coils
Courtesy of CHRYSLER LLC

1 - Electrical Connector
2 - Mounting Bolt
3 - Coil

1 - Electrical Connector
2 - Mounting Bolt
