Daewoo Nubira. Manual - part 15

9S – 18

BODY REAR END

DAEWOO V–121 BL4

4. Install the floor carpet to its original position.
5. Install the lower B–pillar seat belt anchor with the

bolt.

Tighten

Tighten the lower B–pillar seat belt anchor bolt to 35
N

m (26 lb–ft).

6. Install the front seat and the rear seat. Refer to

Section 9H, Seats.

7. Connect the cable to the fuel filler door.
8. Install the luggage compartment wheelhouse trim

panels. Refer to Section 9G, Interior Trim.

BODY REAR END 9S – 19

DAEWOO V–121 BL4

GENERAL DESCRIPTION

AND SYSTEM OPERATION

FUEL FILLER DOOR

The fuel filler door attaches to the fuel tank pocket on the
right side of the vehicle. The door is opened by pulling on
the fuel filler door remote handle located on the floor in
front of the driver’s seat.

REAR DECK LID (NOTCHBACK)

The rear deck lid consists of an inner and outer panel that
is hemmed around the perimeter and bonded together
with structural adhesive. The deck lid springs assist in the
opening of the rear deck lid and hold it in the open position.

HATCHBACK DOOR

The hatchback door consists of the rear hatch glass within
a steel frame. The steel frame is made of an inner and out-
er panel hemmed around the perimeter and bonded to-
gether with structural adhesive. The gas support assem-
blies assist in the opening of the hatchback door and can
hold it in the open position.

TAILGATE (WAGON)

The tailgate is made of a steel frame which contains the
rear glass. The steel frame is made of an inner and outer
panel hemmed around the perimeter and bonded together
with structural adhesive. The gas support assemblies as-
sist in the opening of the tailgate and can hold it in the open
position.

TECHNICAL SERVICE BULLETIN

Description:

Reference:

Prod. Dates:

Bulletin No.:

Model(s):

Date:

VIN Range:

Group:

TSB-001-98

All 1998 & 1999 Models

November 18, 1998

ALL

Paint Codes

Paint

ALL

General Manager
Service Manager

Technician(s)
Service Advisor

Body Shop Manager
Parts Manager

Circulate To:

√

√
√

√

Daewoo

Color

Code

Color Name

Model Application

Paint Manufacturer Codes

Lanos

Nubira Leganza

Akzo

Dupont

PPG

Sherwin

Williams/

Martin

Senour

11U

Galaxy White

DAE11U

F3540

91694

56925

21U

Azurite Blue

DAE21U

F3133

190456

56926

24U

Regatta Blue Pearl

DAE24U

F3132

190079

56928

42U

Deep Bluish Green

DAE42U

F3017

48187

56930

62U

Khaki Beige

DAE62U

F3186

28495

56933

74U

Spinel Red Pearl

DAE74U

F3185

74842

56937

83L

Granada Black

DAE83L

F1648

95089

53380

92U

Poly Silver

DAE92U

F3130

36652

56939

93U

Olive SIlver

DAE93U

F7117

37211

56940

To ensure correct paint color matching and the ability to acquire 1998-1999 Daewoo paint
from your local supplier, we have compiled a list of paint codes for Daewoo paint colors from
a number of the most predominant U.S. paint suppliers.

When ordering paint from your local supplier, please use the corresponding paint code for the
Daewoo paint color and paint brand you are purchasing.

You may forward questions to the Daewoo Technical Assistance Center at

(877) DMA-1234

or to your paint manufacturer’s representative. A list of paint manufacturer contacts is
provided on page 3 of this bulletin.
