Daewoo Nubira. Manual - part 7

Description

Page

Remote Keyless Entry Programming

2 of 2

May, 2001

8.

From the CODING SYSTEM screen, select “Coding Only” by pressing #1 on the Key
Pad.

9.

From the SECRET NUMBER OF CODINGS screen, enter four (4) zero's (0-0-0-0) in the
four (4) boxes labeled “1-2-3-4”.

10. From the CODING SYSTEM SELECT screen, select “Keyless Entry” by pressing #2 on

the Key Pad.

Note:

A slight delay may occur and “PLEASE WAIT” may be displayed before the next
screen appears.

11. From the KEYLESS ENTRY CODING SYSTEM screen, select “Coding Transmitter” by

pressing #1 on the Key Pad.

12. When directed by the Scan 100 Scan Tool, press any Button on the first Transmitter to

be programmed.

CAUTION:

Ensure that Transmitters from other vehicles in the immediate area are not
activated during this procedure.

13. Continue programming Transmitters when directed by the Scan 100 Scan Tool until all

Transmitters have been programmed.

Note:

A maximum of five (5) Transmitters may be programmed to a vehicle.

14. Once all Transmitters have been programmed, press the “ESC” Button on the Key Pad.

The display will confirm the number of Transmitters programmed.  If the number
displayed does not match the number of Transmitters programmed, repeat the procedure.

15. Turn the Scan 100 Scan Tool “OFF” by pressing the “POWER” Button, then disconnect it

from the Data Link Connector.

16. Wait approximately 10 seconds, then test the operation of each programmed Transmitter

to ensure it operates properly.

If additional information is needed regarding this procedure, please contact your District Parts
& Service Manager or the Daewoo Technical Assistance Center toll free at (877) 362-1234,
selection 1.

SECTION : 9R

BODY FRONT END

TABLE OF CONTENTS

SPECIFICATIONS

9R–1

. . . . . . . . . . . . . . . . . . . . . . . . . .

FASTENER TIGHTENING SPECIFICATIONS

9R–1

.

MAINTENANCE AND REPAIR

9R–2

. . . . . . . . . . . . . . .

ON–VEHICLE SERVICE

9R–2

. . . . . . . . . . . . . . . . . . . . .

LUBRICATION

9R–2

. . . . . . . . . . . . . . . . . . . . . . . . . . . .

FASTENERS

9R–2

. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ANTICORROSION MATERIALS

9R–2

. . . . . . . . . . . . .

FRONT END SEALING

9R–2

. . . . . . . . . . . . . . . . . . . .

COWL VENT GRILLE

9R–2

. . . . . . . . . . . . . . . . . . . . . .

HOOD

9R–4

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

HOOD HINGES

9R–4

. . . . . . . . . . . . . . . . . . . . . . . . . . .

HOOD PROP ROD

9R–5

. . . . . . . . . . . . . . . . . . . . . . . .

HOOD SECONDARY LATCH

9R–6

. . . . . . . . . . . . . . .

HOOD LATCH RELEASE CABLE

9R–6

. . . . . . . . . . . .

RADIATOR GRILLE

9R–8

. . . . . . . . . . . . . . . . . . . . . . . .

FENDER

9R–9

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

GENERAL DESCRIPTION AND SYSTEM

OPERATION

9R–14

. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

BODY FRONT END

9R–14

. . . . . . . . . . . . . . . . . . . . . .

SPECIFICATIONS

FASTENER TIGHTENING SPECIFICATIONS

Application

N

S

m

Lb–Ft

Lb–In

A–Pillar Fender Bolt

8

–

71

Cowl Vent Grille Screws

4

–

35

Fender Bolt (Front of Fas-
cia)

4

–

35

Front Bumper Fascia–to–
Fender Bolt

1.5

–

13

Hinge Bolts

27

20

–

Hood–to–Hinge Bolts

27

20

–

Hood Latch Bolts

8

–

71

Hood Release Handle Nuts

4

–

35

Lower Fender Bolt

8

–

71

Radiator Grille Nuts

4

–

35

Splash Shield Bolts

1.5

–

13

Upper Fender Bolts

8

–

71

9R – 2

I

BODY FRONT END

DAEWOO V–121 BL4

MAINTENANCE AND REPAIR

ON–VEHICLE SERVICE

LUBRICATION

The hood hinges and the locking mechanisms require pe-
riodic lubrication for proper operation. Refer to Section 0B,
General Information for the specific types and intervals of
lubrication.

FASTENERS

Notice : Dissimilar metals in direct contact with each other
may corrode rapidly. Make sure to use the correct fasten-
ers to prevent premature corrosion.

Many aluminum components are used on current models.
Aluminum in contact with steel may corrode rapidly if it is
not protected by special finishes or isolators.

The fasteners used have a special finish which provides
adequate protection from corrosion. These special fasten-
ers differ in color in order to easily identify them from the
standard metric fasteners, which are medium blue.

When replacing fasteners, avoid substituting otherwise
similar fasteners in the same location.

ANTICORROSION MATERIALS

In order to provide rust resistance, anticorrosion materials
have been applied to the interior surfaces of most of the
metal panels. When you service these panels, properly re-
coat them with a service–type anticorrosion material if any
of the original material has been disturbed.

FRONT END SEALING

All locations where waterleaks may occur are sealed dur-
ing production with high quality, durable sealers. If it be-
comes necessary to reseal specific areas, use a highqual-
ity sealer of medium–bodied consistency which will retain
its flexible characteristics after curing and can be painted,
if necessary.

COWL VENT GRILLE

(Left–Hand Drive Shown, Right–Hand
Drive Similar)

Removal Procedure

1.  Raise the hood and support it with the hood prop.
2.  Remove the wiper arms. Refer toSection 9D, Wip-

ers/ Washer Systems.

3.  Remove the cowl vent grille screws and the two–

piece grille.

BODY FRONT END  9R – 3

DAEWOO V–121 BL4

4.  Disconnect the washer hoses.

Installation Procedure

1.  Connect the washer hoses.

Notice :  Dissimilar metals in direct contact with each other
may corrode rapidly. Make sure to use the correct fasten-
ers to prevent premature corrosion.

2.  Install the two–piece grille and the cowl vent grille

screws.

Tighten

Tighten the cowl vent grille screws to 4 N

S

m (35 lbin).

3.  Install the wiper arms. Refer to Section 9D, Wipers/

Washer Systems.
