9T – 6

I

REMOTE KEYLESS ENTRY AND ANTI–THEFT SYSTEM

DAEWOO V–121 BL4

2.  Remove the siren electrical connector.
3.  Remove the siren bracket mounting bolt.
4.  Remove the siren.

Installation Procedure

1.  Install the siren on the siren bracket with the mount-

ing screws.

Tighten

Tighten the siren bracket mounting bolts to 22 N

S

m

(16 lb–in).

2.  Connect the siren electrical connector.

REMOTE KEYLESS ENTRY AND ANTI–THEFT SYSTEM  9T – 7

DAEWOO V–121 BL4

FRONT DOOR TAMPER SWITCH

Removal Procedure

1.  Disconnect the negative battery cable.
2.  Remove the front door trim panel. Refer to Section

9G, Interior Trim.

3.  Disconnect the door tamper switch electrical con-

nector.

4.  Remove the front door lock and the integral door

tamper switch. Refer toSection 9P, Doors.

Installation Procedure

1.  Install the front door lock and the integral door tam-

per switch. Refer toSection 9P, Doors.

2.  Install the door tamper switch electrical connector.
3.  Install the front door trim panel. Refer to Section

9G, Interior Trim.

4.  Connect the negative battery cable.

REAR DECK LID TAMPER SWITCH

Removal Procedure

1.  Disconnect the negative battery cable.
2.  Disconnect the rear deck lid tamper switch electri-

cal connector from the tamper switch.

3.  Remove the rear deck lid tamper switch.

9T – 8

I

REMOTE KEYLESS ENTRY AND ANTI–THEFT SYSTEM

DAEWOO V–121 BL4

Installation Procedure

1.  Install the rear deck lid tamper switch.
2.  Connect the rear deck lid tamper switch electrical

connector to the tamper switch.

3.  Connect the negative battery cable.

HOOD OPEN SWITCH

Removal Procedure

1.  Disconnect the negative battery cable.
2.  Disconnect the electrical connector from the hood

open switch.

3.  Remove the mounting screw from the hood open

switch.

4.  Remove the hood open switch.

REMOTE KEYLESS ENTRY AND ANTI–THEFT SYSTEM  9T – 9

DAEWOO V–121 BL4

Installation Procedure

1.  Install the hood open switch with the mounting

screw.

Tighten

Tighten the hood open switch mounting screw to 8
N

S

m (71 lb–in).

2.  Connect the electrical connector to the hood open

switch.

3.  Connect the negative battery cable.
