DAF CF65, CF75, CF85 Series . Manual - part 92

©

 200346

1-11

Internal and external cab components

TECHNICAL DATA

ΧΦ65/75/85 series

1

0

Adjustment dimensions of mirrors with dead
angle exterior mirror

D

C

B

A

C D

A

B

E

F

K1 01 333

Size

Normal (mm)

Normal adjustment angle

A

326

9

B

396

45

C

219

35

D

47

31

E (main mirror)

1379

F

1406

TECHNICAL DATA

1-12

©

 200346

Internal and external cab components

0

ΧΦ65/75/85 series

1

Dimensions of compulsory field of vision

B3

B4

B2

B1

A1

A3

D1

C1

C3

C4

C2

A2

B5

B

A

C

D

K100237

Mirror

size 1

size 2

size 3

size 4

size 5

Pavement mirror [A]

1 m

1 m

1.25 m

Wide-angle exterior mirror [B]

2.5 m

15 m

12.5 m

25 m

3 m

Main exterior mirror, co-driver side [C]

30 m

3.5 m

0.75 m

4 m

Main exterior mirror, driver side [D]

10 m

2.5 m

©

 200346

1-13

Internal and external cab components

TECHNICAL DATA

ΧΦ65/75/85 series

1

0

1.2 TIGHTENING TORQUES

The tightening torques specified in this section
are different from the standard tightening torques
cited in the overview of the standard tightening
torques. The other threaded connections not
specified must therefore be tightened to the
torque cited in the overview of standard
tightening torques.

When attachment bolts and nuts are replaced, it
is important that - unless stated otherwise - these
bolts and nuts are of exactly the same length and
property class as those removed.

Windscreen wiper motor

Roof hatch

Clutch pedal

(1) Use Loctite 243 to secure

Engine brake switch

Steering column

(1) Always replace the attachment bolt and nut

Doors

Exterior mirrors

Raised roof

Attachment on bulkhead

20 - 25 Nm

Motor shaft nut

40 - 50 Nm

Windscreen wiper arm nut

16 - 20 Nm

Fixing bolts for roof hatch edging

10 Nm

Sealant for end of clutch pedal spindle

silicone sealant

Locking bolt

according to standard

(1)

Sealant for bolts

silicone sealant

Attachment bolt for steering shaft universal joint

54 Nm

(1)

Attachments nuts at underside of steering column

23 Nm

Steering wheel attachment nut

65 Nm

Striker plate Torx screws

23 Nm

Lower pivoting point of D-shaped support, M8 nut

32 Nm

Pavement mirror adjusting nut

7.0 - 8.1 Nm

Attachment bolts for raised roof frame

30 Nm

TECHNICAL DATA

1-14

©

 200346

Internal and external cab components

0

ΧΦ65/75/85 series

1
