DAF CF65, CF75, CF85 Series . Manual - part 90

©

 200346

1-3

Internal and external cab components

TECHNICAL DATA

ΧΦ65/75/85 series

1

0

Permissible cab weights, day and sleeper cab

Permissible cab weights, high sleeper:

Cab side members
Welding on cab side members is NOT permitted.

When repairing the cab side member, you must
use sheet-metal trimming panels.
These must be fitted by spot welding.

A

K1 00 997

25 kg

(2x)

B

C

D

Item

Description

Max. load

A

Roof loading above

150

kg

B

Roof console

15

kg

C

Bunk

100

kg

D

Under bunk storage box

50

kg

K1 00 998

A

D

E

F

G

H

B
C

Item

Description

Max. load

A

Roof loading above

40

kg

B

Roof console

20

kg

C

Below roof console

15

kg

D

Upper bunk

100

kg

E

Upper bunk (folded away)

50

kg

F

Bunk

100

kg

G

Under bunk storage box

50

kg

H

Tool storage

2 x 25 kg

TECHNICAL DATA

1-4

©

 200346

Internal and external cab components

0

ΧΦ65/75/85 series

1

Recommended dimensions

(1) Measurement area between the brackets
(2) Measurement area under the bracket

K1 01 645

A

A

,

B

B

,

I

O

O

P

P’

J

N

A’

B

J

J

I

O

I

A

N

P

P’

B

O

Recommended dimension between measuring points on the same side.

A - B

818 mm

I - I

2070 mm

J - J

2185 mm

O - O

2247 mm

Recommended dimension between measuring points on opposite sides.

Short cab

Long cab

A' - N

1367 mm

1797 mm

B' - P

1660 mm

(1)

B' - P'

2110 mm

(2)

©

 200346

1-5

Internal and external cab components

TECHNICAL DATA

ΧΦ65/75/85 series

1

0

F

,

F

H

G

K

F

,

,

G

K

G

F

H

F

K

K1 00 928

F

,

Recommended dimension between measuring points on the same side.
F - F'

1524 mm

F' - H

1419 mm

G - K

1662 mm

F' - G

708 mm

Recommended dimension between measuring points on opposite sides.
G' - G

2030 mm

G - F

2612 mm

G - K

2649 mm

TECHNICAL DATA

1-6

©

 200346

Internal and external cab components

0

ΧΦ65/75/85 series

1

Z

Z

X

X

R

Z

X

K1 01 012

T

L

S

R(D)

R(S)

X - X

1175 mm

Z - Z

1080 mm
R(D) (short cab)

R(S) (long cab)

L - R

1176 mm

1606 mm

S - R

621 mm

1051 mm

T - R

1604 mm

2034 mm
