Bluetooth® audio system

Select by "

Folder

" / "

Artist

" / "

Genre

" /

"

Playlist

".

Depending on availability and type of device

used.

Press

OK

 to select the desired

classification, then press

OK

 again to

confirm.

Playing files

Make a short press on this button to

display the chosen classification.

Navigate in the list using the left / right

and up / down buttons.

Confirm the selection by pressing

OK

.

Press one of these buttons to go to the

previous / next track in the list.

Press and hold one of these buttons for fast

forward or rewind.

Press one of these buttons to go to the

previous / next "

Folder

" / "

Artist

" /

"

Genre

" / "

Playlist

"* in the list.

Input AUX socket (AUX)

Depending on equipment

Connect a portable device (MP3 player,

etc.) to the auxiliary jack socket using an

audio cable (not supplied).

Any additional devices connected to the

system must comply with the standard

* Depending on availability and the type of device used.

applicable to the product and/or the standard

IEC 60950-1.

Press the

SOURCE

 button several times

in succession and select "

AUX

".

First adjust the volume on your portable device

(to a high level). Then adjust the volume on your

audio system. Controls are managed via the

portable device.

Do not connect the same device to both

the auxiliary jack socket and the USB

port at the same time.

CD player

Insert circular compact discs only.

Some anti-pirating systems, on original discs

or CDs copied using a personal recorder, may

cause faults which are no reflection on the

quality of the original player.

Insert a CD in the player, play begins

automatically.

External CD players connected via the

USB port are not recognised by the

system.

To play a disc which has already been

inserted, press the

SOURCE

 button

several times in succession and select "

CD

".

Press one of the buttons to select a track

on the CD.

Press the

LIST

 button to display the list of

tracks on the CD.

Press and hold one of these buttons for

fast forward or rewind.

Playing an MP3 compilation

Insert an MP3 compilation in the CD player.

The audio equipment searches for all of the

music tracks, which may take anything between

a few seconds and several tens of seconds,

before play begins.

On a single disc, the CD player can read

up to 255 MP3 files spread over 8

directory levels.

However, it is advisable to keep to a limit of

two levels to reduce the access time before

the CD is played.

The folder structure is not observed during

playback.

All of the files are displayed on a single level.

To play a disc which has already been

inserted, press the

SOURCE

 button

several times in succession and select "

CD

".

Press one of the buttons to select a folder

on the CD.

Press one of the buttons to select a track

on the CD.

Press the

LIST

 button to display the list of

directories of the MP3 compilation.

243

Bluetooth® audio system

10

Press and hold one of these buttons for

fast forward or rewind.

Bluetooth

®

 audio streaming

Streaming allows music files on the telephone to

be played via the vehicle's speakers.

Connect the telephone.

(Refer to the "

Pairing a Bluetooth® telephone

"

section).

Activate the streaming source by pressing

SOURCE.

In certain cases, playback of the audio files must

be initiated from the keypad.

Audio files can be selected using the buttons on

the audio system control panel and the steering-

mounted controls. The contextual information

can be displayed on the screen.

If the telephone supports the function. The audio

quality depends on the quality of transmission by

the telephone.

Connecting Apple

®

 players

Connect the Apple

®

 player to the USB socket

using a suitable cable (not supplied).

Play starts automatically.

Control is via the audio system.

The classifications available are those of the

portable device connected (artists / albums /

genres / playlists).

The version of software in the audio system may

not be compatible with the generation of your

Apple

®

 player.

Information and advice

The CD player can play audio files with “.mp3”,

“.wma”, “.wav” and “.aac” file extensions, with a

bit rate of 32 to 320 Kbps.

It also supports TAG mode (ID3 tag, WMA TAG).

No other file types (".mp4", etc.) can be read.

Files of the ".wma" type should be to the wma 9

standard.

The sampling rates supported are 11, 22, 44 and

48 kHz.

Via the USB socket, the system can play audio

files with the extension “.mp3”, “.wma”, “.wav”,

“.cbr”, “.vbr" with a bit rate of 32 to 320 Kbps.

No other file types (".mp4", etc.) can be read.

Files of the ".wma" type should be to the wma 9

standard.

The sampling rates supported are 11, 22, 44 and

48 kHz.

File names should have fewer than 20

characters, avoiding special characters (e.g.

« ? ; ù) so as to avoid any reading or display

problems.

In order to be able to play a burned CDR or

CDRW, select ISO 9660 standards level 1, 2, or

Joliet, if possible, when burning the CD.

If the disc is burned in another format, it may not

be played correctly.

It is recommended that the same burning

standard always be used on an individual disc,

with the lowest speed possible (4x maximum) for

the best acoustic quality.

In the particular case of a multi-session CD, the

Joliet standard is recommended.

To protect the system, do not use a USB hub.

Only use USB memory sticks formatted

to FAT 32 (File Allocation Table).

It is recommended that you use genuine

Apple

®

 USB cables to guarantee correct

operation.

Telephone

Pairing a Bluetooth

®



telephone

As a safety measure and because it

requires sustained attention by the driver,

the pairing of a Bluetooth

®

 mobile telephone

with the Bluetooth

®

 hands-free system of your

audio system must be done with the

vehicle

stationary

 and the ignition on.

Activate the telephone's Bluetooth

®



function and ensure that it is "visible to

all" (telephone configuration).

244

Bluetooth® audio system

The services available depend on the

network, the SIM card and the

compatibility of the Bluetooth

®

 devices used.

Refer to your telephone’s user guide and your

service provider to check which services you

are able to access.

Procedure from the telephone

Select the name of the system in the list

of detected devices.

If the pairing procedure fails, we

recommend deactivating and then

reactivating the Bluetooth

®

 function on the

telephone.

Procedure from the system

Press the

MENU

 button.

Select "

Connections

".

Confirm with

OK.



Select "

Search for a device

".

Confirm with

OK.



A window is displayed with a search in progress

message.

In the list of devices detected, select a telephone

to pair. Only one telephone can be paired at a

time.

Completing the pairing

To complete the pairing, whichever

procedure is used (from the telephone or

from the system), confirm that the code is the

same in the system and in the telephone and

validate.

If pairing fails, the number of attempts is not

restricted.

A message appears on the screen confirming

the pairing.

Information and advice

The "

Telephone

" menu provides access to the

following functions in particular: "

Directory

", if

your telephone is fully compatible, "

Calls list

",

"

Consult the paired devices

".

Depending on the type of telephone, you may be

asked to accept or confirm access by the system

to each of these functions.

Go to the Brand's website for more

information (compatibility, more help,

etc.).

Managing connections

The telephone connection automatically

includes hands free operation and audio

streaming.

The ability of the system to connect to just

one profile depends on the telephone. Both

profiles may connect by default.

Press the

MENU

 button.

Select "

Connections

".

Press

OK

 to confirm.



Select "Bluetooth

Connections

management

" and confirm. The list of

paired telephones is displayed.

Press

OK

 to confirm.



Indicates that a device is connected.

A number indicates the profile of the

connection with the system:

–  1 for media or 1 for telephone.

–  2 for media and telephone.

Indicates connection of the audio

steaming profile.

Indicates connection of the hands-free

telephone profile.

Select a telephone.

Press

OK

 to confirm.



Then select and confirm:



– "

Connect telephone

"/"

Disconnect

telephone

" : to connect/disconnect the

telephone or the hands-free kit only.

– "

Connect media player

"/"

Disconnect media

player

" : to connect/disconnect streaming only.

245

Bluetooth® audio system

10

– "

Connect telephone + media

player

"/"

Disconnect telephone + media

player

" : to connect/disconnect the telephone

(hands-free kit and streaming).

– "

Delete connection

": to delete the pairing.

When you delete a pairing in the system,

remember to delete it from your

telephone as well.

Press

OK

 to confirm.



Receiving a call

An incoming call is announced by a ring and a

superimposed display in the screen.

Select the "

YES

" tab in the screen using

the buttons.

Confirm with

OK.



Press this button at the steering mounted

controls to accept the call.

Making a call

In the "

Telephone

" menu.

Select "

Call

".

Select "

Dial

".

Or

Select "

Directory

".

Or

Select "

Calls list

".

Confirm with

OK.



Press this button for more than two

seconds for access to your directory, then

navigate using the thumb wheel.

Ending a call

In the "

Telephone

" menu.

Select "

End call

".

Confirm with

OK

 to end the call.

During a call, press one of these buttons

for more than two seconds.

The system accesses the telephone's

contacts directory, depending on its

compatibility, and while it is connected via

Bluetooth.

With certain telephones connected by

Bluetooth you can send a contact to the

directory of the audio system.

Contacts imported in this way are saved in a

permanent directory visible to all, whatever

the telephone connected.

The menu for the directory is not accessible if

it is empty.

Managing calls

During a call, press

OK

 to display the

contextual menu.

End call

In the contextual menu, select "

Hang up

"

to end the call.

Confirm with

OK.



Microphone off

(so that the caller cannot hear)

In the contextual menu:

–  select "

Micro OFF

" to switch off the

microphone.

–  deselect "

Micro OFF

" to switch the

microphone on.

Confirm with

OK.



Telephone mode

In the contextual menu:

–  select "

Telephone mode

" to transfer the

call to the telephone (for example, to leave the

vehicle while continuing a conversation).

–  deselect "

Telephone mode

" to transfer the

call to the vehicle.

Confirm with

OK.



If the contact has been cut off, when you

reconnect on returning to the vehicle,

the Bluetooth connection will be restored

automatically and sound returned to the

system (depending on the compatibility of the

telephone).

In some cases, the Telephone mode must be

activated from the telephone.

246

Bluetooth® audio system

Interactive voice response

From the contextual menu, select "

DTMF

tones

" and confirm to use the digital

keypad to navigate in the interactive voice

response menu.

Confirm with

OK.



Consultation call

From the contextual menu, select

"

Switch

" and validate to return to a call

left on hold.

Confirm with

OK.



Directory

To access the directory, press and hold

SRC/TEL

.

Select "

Directory

" to see the list of

contacts.

Confirm with

OK.



To modify the contacts saved in the

system, press

MENU

 then select

"

Telephone

" and confirm.

Select "

Directory management

" and confirm.

You can:

– "

Consult an entry

",

– "

Delete an entry

",

– "

Delete all entries

".

The system accesses the telephone's

contacts directory, depending on its

compatibility, and while it is connected via

Bluetooth.

With certain telephones connected by

Bluetooth you can send a contact to the

directory of the audio system.

Contacts imported in this way are saved in a

permanent directory visible to all, whatever the

telephone connected.

The menu for the directory is not accessible if it

is empty.

Voice recognition

This function allows you to use your

smartphone's voice recognition via the system.

To start voice recognition, depending on the type

of steering mounted controls:

Make a long press on the end of the lighting

control stalk.

OR

Press this button.

Voice recognition requires the use of a

compatible smartphone first connected to

the vehicle by Bluetooth.

Frequently asked

questions

The following information groups together the

answers to the most frequently asked questions

concerning your audio system.

With the engine off, the audio system

switches off after a few minutes of use.

When the engine is switched off, the audio

system operating time depends on the state of

charge of the battery.

The switch-off is normal: the audio system

switches to economy mode and switches off to

avoid discharging the vehicle's battery.

►  Start the vehicle’s engine to increase the

charge of the battery.

The message "the audio system is

overheated" is displayed onscreen.

To protect the installation if the ambient

temperature is too high, the audio system

switches to an automatic thermal protection

mode, in which the volume may be decreased or

the CD player stopped.

►  Switch the audio system off for a few minutes

to allow the system to cool.

Radio

There is a difference in sound quality

between the different audio sources (radio,

CD, etc.).

For optimal listening quality, the audio settings

(Volume, Bass, Treble, Ambience and Loudness)

can be adjusted to different audio sources,

resulting in audible differences when switching

between sources (radio, CD, etc.).

►  Check that the audio settings (Volume, Bass,

Treble, Ambience and Loudness) are appropriate

to the sources being listened to. We recommend

setting the audio functions (Bass, Treble, Fr-Re

247

Bluetooth® audio system

10

balance and Le-Ri balance) to the middle

position, setting the musical ambience to "None",

setting loudness correction to "Active" in CD

mode and "Inactive" in Radio mode.

The preset stations do not function (no

sound, 87.5 MHz is displayed, etc.).

The wrong waveband is selected.

►  Press the BAND button to return to the

waveband (FM, FM2, DAB, AM) on which the

stations are preset.

Traffic announcement (TA) is shown but I

receive no traffic information.

The radio station is not part of the regional traffic

information network.

►  Tune to a radio station that broadcasts traffic

information.

The reception quality of the tuned radio

station gradually deteriorates or the station

presets are inoperative (no sound, 87.5 MHz

is displayed, etc.).

The vehicle is too far from the selected station’s

transmitter, or no transmitter is present in the

geographical area.

►  Activate the RDS function to allow the system

to check for a more powerful transmitter in the

area.

The environment (hills, buildings, tunnels,

basement car parks, etc.) may block reception,

including in RDS mode.

This is a perfectly normal phenomenon, and is

not indicative of an audio system malfunction.

The aerial is absent or has been damaged (for

example when going through an automatic car

wash or in an underground car park).

►  Have the aerial checked by a dealer.

The sound intermittently cuts out for 1 or 2

seconds in radio mode.

During this brief sound cut-out, the RDS

searches for another frequency giving better

reception of the station.

►  Switch off the RDS function if the

phenomenon occurs too frequently and always

on the same route.

Media

The Bluetooth connection is cut.

The battery in the peripheral device may not be

sufficiently charged.

►  Charge the battery in the peripheral device.

The message "USB device error" is displayed

in the screen.

The USB stick has not been recognised, or may

be corrupted.

►  Reformat the USB memory stick.

The CD is systematically ejected or is not

played.

The CD is upside down, cannot be read, does

not contain audio files or contains audio files of a

format not recognised by the audio system.

The CD is protected by an anti-pirating system

not recognised by the audio system.

►  Check that the CD is inserted in the player

the right way up.

►  Check the condition of the CD: the CD cannot

be played if it is too badly damaged.

►  Check the content in the case of a burned

CD: read the recommendations in the "Audio"

section.

Due to poor quality, certain burned CDs will not

be played by the audio system.

The CD audio quality is is poor.

The CD is scratched or of poor quality.

►  Insert good quality CDs and store them in

suitable conditions.

The audio settings (bass, treble, ambience) are

unsuitable.

►  Return bass and treble settings to 0, without

selecting an ambience.

I am unable to play the music files on my

smartphone via the USB port.

Depending on the smartphone, access by the

audio system to music on the smartphone may

have to be approved on the latter.

►  Manually activate the MTP profile on the

smartphone (USB settings menu).

Telephone

I am unable to access my voicemail.

Few telephones or service providers allow the

use of this function.

►  Call your voicemail, via the telephone menu,

using the number provided by your operator.

I am unable to access my directory of

contacts.

►  Check the compatibility of your telephone.

248

Bluetooth® audio system

You did not grant access to your contacts when

pairing the telephone.

►  Accept or confirm access by the system to

the contacts on your telephone.

I am unable to continue a conversation when

getting into my vehicle.

Handset mode is activated.

►  Deselect handset mode to transfer the call to

the vehicle.

I am unable to pair my telephone by

Bluetooth.

Telephones (models, versions of operating

systems) have their own specificities in the

pairing procedure and some telephones are not

compatible.

►  Before starting the pairing procedure, delete

the telephone pairing from the system

and

 the

system pairing from the telephone, in order to

view the compatibility of the telephones.

249

MyCitroën Play

11

MyCitroën Play

Multimedia audio system -

Applications - Bluetooth

®



telephone

The functions and settings described

vary according to the vehicle version and

configuration, as well as the country of sale.

For safety reasons and because they

require sustained attention by the driver,

the following operations must be carried out

with the

vehicle stationary

 and the ignition

on:

–  Pairing the smartphone with the system via

Bluetooth.

–  Using the smartphone.

–  Connecting to the CarPlay

®

 or Android

Auto applications (certain applications stop

displaying when the vehicle is moving).

–  Changing the system settings and

configuration.

The system is protected so that it only

operates in the vehicle.

The message

Energy economy mode

 is

displayed when the system is about to go into

standby.

The system’s Open Source Software

(OSS) source codes are available at the

following addresses:

https://www.groupe-psa.com/fr/oss/

https://www.groupe-psa.com/en/oss/

First steps

With the engine running, a press mutes

the sound.

With the ignition off, a press turns the system on.

Increase or decrease the volume using

the wheel or the "plus" or "minus" buttons

(depending on the equipment).

Use the buttons on either side of or below the

touch screen to access the menus, then press

the virtual buttons on the touch screen.

Depending on the model, use the "Source" and

"Menu" buttons on the left of the touch screen to

access the menus, then press the virtual buttons

on the touch screen.

At all times it is possible to display the rolling

menus by pressing the screen briefly with three

fingers.

All touch-sensitive areas on the screen are

white.

On pages with multiple tabs at the bottom of the

screen, you can switch between pages either

by tapping the tab for the desired page or by

swiping the pages to the left or right with your

finger.

Press in the shaded area to go back up a level

or confirm.

Press the back arrow to go back a level or

confirm.

The touch screen is of the "capacitive"

type.

To clean the screen, use a soft, non-abrasive

cloth (e.g. spectacles cloth) with no additional

product.

Do not use sharp objects on the screen.

Do not touch the screen with wet hands.

Certain information is displayed permanently in

the upper bar of the touch screen:

–  Air conditioning status information (depending

on version), and direct access to the

corresponding menu.

–  Radio Media and Telephone menu status

information.

–  Privacy status information.

–  Access to the touch screen and digital

instrument panel settings.

Audio source selection (depending on

equipment):

–  FM/DAB/AM radio stations (depending on

equipment).

–  Telephone connected via Bluetooth and

Bluetooth multimedia broadcast (streaming).

–  USB Memory stick.

–  Media player connected via the auxiliary

socket (depending on equipment).



250

MyCitroën Play



In the "Settings" menu, it is possible to

create a profile for an individual or for a

group of people with shared interests, and

configure a wide range of settings (radio

presets, audio settings, ambiences, etc.).

Settings are applied automatically.

In very hot conditions, the volume may

be limited to protect the system. It may

enter standby mode (with the screen and

sound off) for 5 minutes or more.

The system will resume normal operation

when the temperature in the passenger

compartment has dropped.

Steering-mounted

controls

Steering mounted controls -

Type 1





Radio:

Select the previous/next preset radio

station.

Select the previous/next item in a menu or a list.

Media:

Select the previous/next track.

Select the previous/next item in a menu or a list.

Radio:

Short press: display the list of radio

stations.

Long press: update the list.

Media:

Short press: display the list of folders.

Long press: display the available sorting options.

Change audio source (radio; USB; AUX if

equipment connected; CD; streaming).

Confirm a selection.



Increase volume.

Decrease volume.

Mute/restore sound by simultaneously

pressing the increase and decrease

volume buttons.

Steering mounted controls -

Type 2





Voice control

:

This control is located on the steering

wheel or at the end of the lighting control stalk

(depending on equipment).

Short press: smartphone voice commands via

the system.

Increase volume.

Decrease volume.

Mute by pressing the volume increase

and decrease buttons simultaneously

(depending on equipment).

Restore the sound by pressing one of the two

volume buttons.

Media

 (short press): change the

multimedia source.

Telephone

 (short press): start telephone

call.

Call in progress

 (short press): access

telephone menu.

Telephone

 (long press): reject an incoming call,

end call; when no call is in progress, access

telephone menu.

251

MyCitroën Play

11

Radio

 (rotate): automatic search for the

previous/next station.

Media

 (rotate): previous/next track, move

through a list.

Short press

: confirm a selection; if nothing

selected, access presets.

Radio

: display the list of stations.

Media

: display the list of tracks.

Radio

 (press and hold): update the list of

detected stations.

Menus

Applications





Access configurable equipment.



Radio Media





Select an audio source or radio station.

Telephone





Connect a mobile phone via Bluetooth

®

.

Run certain applications from a

smartphone connected via CarPlay

®

 or Android

Auto.

Settings





Configure a personal profile and/or

configure the sound (balance, ambience,

etc.) and the display (language, units, date, time,

etc.).

Driving





Activate, deactivate or configure certain

vehicle functions.

252

MyCitroën Play

Navigation





Configure the navigation and select your

destination via CarPlay

®

 or Android Auto.

Air conditioning



21,5

18,5



Manage various temperature and air flow

settings.

Applications

Viewing photos

Insert a USB memory stick in the USB port.

To protect the system, do not use a USB

hub.

The system can read folders and image files in

the formats: .tiff; .gif; .jpg/jpeg; .bmp and .png.

Press

Applications

 to display the main

page.

Press "

Photos

".

Select a folder.

Select an image to view.

Press this button to display the details of

the photo.

Press the back arrow to go back a level.

Managing messages

Press

Applications

 to display the main

page.

Press "SMS".

Select the "SMS” tab.

Press this button to select the display

settings for messages.

Press this button to search and select a

recipient.

Select the "Quick messages” tab.

Press this button to select the display

settings for messages.

Press this button to write a new message.

Press the bin alongside the selected

message to delete it.

Press this button alongside the selected

message to display the secondary page.

Press this button to edit and modify the

existing text.

Press this button to write a new message.

Press the bin to delete the message.

Radio

Selecting a station

Press

Radio Media

 to display the main

page.

Press one of the buttons to perform an

automatic search for radio stations.

Or

Move the slider to manually search for

frequencies up or down.

Or

Press the frequency.

253

MyCitroën Play

11

Enter the FM and AM waveband values

using the virtual keypad.

Press "

OK

" to confirm.



Radio reception may be affected by the

use of electrical equipment not approved

by the Brand, such as a USB charger

connected to the 12 V socket.

The exterior environment (hills, buildings,

tunnels, basement car parks, etc.) may

block reception, including in RDS mode.

This phenomenon is perfectly normal in the

context of radio wave transmission, and

in no way indicative of an audio system

malfunction.

Changing the waveband

Press

Radio Media

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Press "

Band

" to change waveband.

Press in the shaded area to confirm.



Presetting a station

Select a radio station or frequency.

Make a short press on the star outline. If

the star is solid, the radio station is

already preset.

Or

Select a radio station or frequency.

Press "

Preset

".

Make a long press on one of the buttons

to preset the station.

Activating/Deactivating RDS

RDS, if activated, allows you to continue

listening to the same station by automatically

retuning to alternative frequencies.

Press

Radio Media

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Activate/deactivate "

RDS

".

Press in the shaded area to confirm.



RDS station tracking may not be

available nationwide, as many radio

stations do not cover 100 % of the country.

This explains the loss of reception of the

station during a journey.

Displaying text information

The "Radio Text" function displays information

transmitted by the radio station relating to the

station or the currently playing song.

Press

Radio Media

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Activate/deactivate "

News

".

Press in the shaded area to confirm.



Playing TA messages

The TA (Traffic Announcement) function gives

priority to TA alert messages. To operate, this

function needs good reception of a radio station

that transmits this type of message. While traffic

information is being broadcast, the current

media is automatically interrupted so that the

TA message can be heard. Normal play of the

previously playing media resumes at the end of

the message.

Press

Radio Media

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Activate/deactivate "

TA

".

Press in the shaded area to confirm.



Audio settings

Press

Radio Media

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Press "

Audio settings

".

254

MyCitroën Play

Select the "

Tone

", "

Balance

", "

Sound

",

"

Voice

" or "

Ringtones

" tab to configure

the sound settings.

Press the back arrow to confirm.



In the "

Tone

" tab, the

Ambience

,

Bass

,

Medium

 and

Treble

 sound settings are

different and independent for each audio

source.

In the "

Balance

” tab, the

All passengers

,

Driver

 and

Front only

 settings are common

to all sources.

In the "

Sound

” tab, activate or deactivate

"

Volume linked to speed

", "

Auxiliary input

"

and "

Touch tones

".

The balance/distribution (or spatialisation

with the Arkamys

 system) uses audio

processing to adjust the sound quality

according to the number of passengers in the

vehicle.

Onboard audio: Arkamys Sound Staging



optimises the sound distribution inside

the passenger compartment.

DAB (Digital Audio

Broadcasting) radio

Terrestrial Digital Radio

Terrestrial Digital Radio

Digital radio provides higher quality sound.

The various "multiplexes/ensembles" offer a

choice of radio stations organised in alphabetical

order.

Press

Radio Media

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Press "

Band

" to select "

DAB band

".

Press in the shaded area to confirm.



FM-DAB Follow-up

"DAB" does not cover 100% of the territory.

When the digital radio signal is poor, the

"FM-DAB Follow-up" enables you to continue

listening to the same station by automatically

switching to the corresponding "FM" analogue

station (if there is one).

Press

Radio Media

 to display the main

page.

Press the "

OPTIONS

" button to go to the

secondary page.

Activate/deactivate "

FM-DAB Follow-up

".

Press in the shaded area to confirm.



If "FM-DAB Follow-up" is activated, there

may be a time offset of a few seconds

when the system switches to "FM" analogue

radio, and in some cases a change in volume.

When the digital signal quality is restored, the

system automatically changes back to "DAB".

To minimise this time lag, storing radio

stations in the "DAB" band is recommended.

If the "DAB" station being listened to is

not available on "FM", or if "FM-DAB

Follow-up" is not activated, the sound will cut

out when the digital signal becomes too weak.

Media

USB port

Insert the USB memory stick into the USB

port or connect the USB device to the

USB port using a suitable cable (not supplied).

To protect the system, do not use a USB

hub.

The system builds playlists (in temporary

memory); this operation can take from a

few seconds to several minutes at the first

connection.

255

MyCitroën Play

11

Reduce the number of non-music files and the

number of folders to reduce the waiting time.

Playlists are updated whenever the ignition

is switched off or a USB memory stick is

connected. The audio system memorises these

lists, which will subsequently load faster if they

have not been changed.

Auxiliary (AUX) jack socket

Depending on equipment

Connect a portable device (MP3 player,

etc.) to the auxiliary jack socket using an

audio cable (not supplied).

This source is only available if "Auxiliary input"

has been selected in the audio settings.

First adjust the volume on the portable device

(to a high level). Then adjust the volume of the

audio system.

Controls are managed via the portable device.

Selecting the source

Press

Radio Media

 to display the main

page.

Press the "

SOURCES

" button.

Select the source.

BluetoothStreaming

®

Streaming allows you to listen to the audio feed

from your smartphone.

The Bluetooth profile must be activated.

First adjust the volume on the portable device

(to a high level). Then adjust the volume of the

system.

If play does not start automatically, it may be

necessary to start the audio playback from the

smartphone.

Control is from the portable device or by using

the system's touch buttons.

Once connected in Streaming mode, the

smartphone is considered to be a media

source.

Connecting Apple

®

 players

Connect the Apple

®

 player to the USB socket

using a suitable cable (not supplied).

Play starts automatically.

Control is via the audio system.

The classifications available are those of

the portable device connected (artists/

albums/genres/playlists/audio books/

podcasts). It is also possible to use a

classification structured in the form of a

library.

The default classification used is by artist. To

modify the classification used, return to the

first level of the menu then select the desired

classification (playlists for example) and

confirm to go down through the menu to the

desired track.

The version of software in the audio system may

not be compatible with the generation of the

Apple

®

 player.

Information and advice

The system supports USB mass storage

devices, BlackBerry

®

 devices or Apple

®

 players

via the USB ports. The adapter cable is not

supplied.

Devices are managed using the audio system

controls.

Other devices, not recognised on connection,

must be connected to the auxiliary socket using

a jack cable (not supplied) or via Bluetooth

streaming, if compatible.

To protect the system, do not use a USB

hub.

The audio system will only play audio files with

".wav", ".wma", ".aac", ".ogg" and ".mp3" file

extensions, at bit rates between 32 Kbps and

320 Kbps.

It also supports VBR (Variable Bit Rate) mode.

No other file types (".mp4", etc.) can be read.

All ".wma" files must be standard WMA 9 files.

The supported sampling rates are 11, 22, 44 and

48 KHz.

To avoid reading and display problems, we

recommend choosing file names less than 20

characters long that do not contain any special

characters (e.g. “ ? . ; ù).

Use only USB memory sticks in FAT32 format

(File Allocation Table).

We recommend using the original USB

cable for the portable device.

256

MyCitroën Play

Telephone

USB sockets

Depending on equipment, for more information

on the USB sockets compatible with

CarPlay

®

 or

Android Auto

 applications, refer to the "Ease of

use and comfort" section.

For the list of compatible smartphones,

visit the Manufacturer's website in your

country.

Synchronising a smartphone enables

users to display applications that support

the smartphone’s CarPlay

®

 or Android Auto

technology on the vehicle’s screen. For

CarPlay

®

 technology, the CarPlay

®

 function

must first be activated on the smartphone.

Unlock the smartphone for the communication

process between the smartphone and the

system to work.

As principles and standards are constantly

changing,

we recommend keeping the

smartphone's operating system up-to-

date, together with the date and time on

the smartphone and the system

.

CarPlay

®

 smartphone

connection

Depending on country.

On connecting the USB cable, the

CarPlay

®

 function deactivates the

system's Bluetooth

®

 mode.

The "

CarPlay

" function requires the use of

a compatible smartphone and compatible

applications.

Connect the USB cable. The smartphone

charges when connected by the USB

cable.

From the system, press

Telephone

 to

display the CarPlay

®

 interface.

Or

If the smartphone has already connected

by Bluetooth

®

.

Connect the USB cable. The smartphone

charges when connected by the USB

cable.

From the system, press "

Telephone

" to

display the main page.

Press the "

PHONE

" button to go to the

secondary page.

Press "

CarPlay

" to display the CarPlay

®



interface.

When the USB cable is disconnected

and the ignition is switched off then back

on, the system will not automatically switch to

Radio Media mode; the source must be

changed manually.

The CarPlay

®

 navigation can be accessed

at any time by pressing the system's

Navigation

 button.

Android Auto smartphone

connection

Depending on country.

On the smartphone, download the

Android Auto application.

The "Android Auto" function requires the

use of a compatible smartphone and

applications.

Telephone not connected by

Bluetooth

®

Connect a USB cable. The smartphone

charges when connected by a USB cable.

From the system, press "

Telephone

" to

display the main page.

Press "

Android Auto

" to start the

application in the system.

Depending on the smartphone, it may be

necessary to activate the "

Android Auto

"

function.

During the procedure, several screen

pages relating to certain features are

displayed.

Accept to start and complete the connection.

When connecting a smartphone to the

system, we recommend enabling

Bluetooth

®

 on the smartphone.

Telephone connected by Bluetooth

®

From the system, press "

Telephone

" to

display the main page.

257

MyCitroën Play

11

Press the "

PHONE

" button to display the

secondary page.

Press "

Android Auto

" to start the

application in the system.

Access to the different audio sources remains

available in the margin of the Android Auto

display, using the touch buttons located in the

upper bar.

Access to the menus for the system is possible

at any time using the dedicated buttons.

There may be a pause before

applications become available,

depending on the quality of the network.

Pairing a Bluetooth

®



telephone

The services available depend on the

network, the SIM card and the

compatibility of the Bluetooth devices used.

Consult the telephone user guide and the

service provider to check which services are

available.

The Bluetooth function must be activated and

the telephone configured as "Visible to all” (in the

telephone settings).

To complete the pairing, whichever procedure is

used (from the telephone or from the system),

ensure that the code is the same in the system

and in the telephone.

If the pairing procedure fails, we

recommend deactivating and then

reactivating the Bluetooth function on the

telephone.

Procedure from the telephone

Select the name of the system in the list

of detected devices.

In the system, accept the connection request

from the telephone.

Procedure from the system

Press

Telephone

 to display the main

page.

Press "

Bluetooth search

".

The list of detected telephones is

displayed.

Select the name of the chosen telephone

in the list.

Connection sharing

The system offers to connect the telephone with

3 profiles:

– "

Telephone

" (hands-free kit, telephone only),

– “

Streaming

" (streaming: wireless playing of

audio files on the telephone),

– "

Mobile internet data

".

Select one or more profiles.



Press "

OK

" to confirm.



Depending on the type of telephone, you may by

prompted to accept the transfer of contacts and

messages.

The ability of the system to connect just

one profile depends on the telephone.

All three profiles may connect by default.

The profiles compatible with the system

are: HFP, OPP, PBAP, A2DP, AVRCP,

MAP and PAN.

Visit the Brand's website for more information

(compatibility, additional help, etc.).

Automatic reconnection

On returning to the vehicle, if the last telephone

connected is present again, it is automatically

recognised and within about 30 seconds

after switching on the ignition, the pairing is

established automatically (Bluetooth activated).

To modify the connection profile:

Press

Telephone

 to display the main

page.

Press the "

PHONE

" button to access the

secondary page.

Press "

Bluetooth connection" to

display the list of paired devices.

Press the "Details" button for a paired

device.

Select one or more profiles.
