Citroen C4 Aircross (2017 year). Instruction - part 18

271

C4-Aircross_en_Chap10b_Mitsu6_ed01-2016

Level 1

Level 2

Level 3

Comments

Repeat

Press to play the track repeatedly.

Scan

Press to play the start of each track for around 9 seconds.

Random

Press to play the tracks in random order.

Playback

Press to start play of the selected track.

Go Up 1 level

Press to go up one level.

Go to ROOT

Press to open the folder structure.

Repeat

Press to play the track repeatedly.

Scan

Press to play the start of each track for around 9 seconds.

Random

Press to play the tracks in random order.

Playback

Press to start play of the selected track.

Go Up 1 level

Press to go up one level.

Go to ROOT

Press to open the folder structure.

USB/iPod

Repeat

Press to play the track repeatedly.

Scan

Press to play the start of each track for around 9 seconds.

Random

Press to play the tracks in random order.

Playback

Press to start play of the selected track.

Bluetooth Audio

Repeat

Press to play the track repeatedly.

Scan

Press to play the start of each track for around 9 seconds.

Random

Press to play the tracks in random order.

Track

Press to start play of the selected track.

AUX

Manage play from the portable device.

272

C4-Aircross_en_Chap10b_Mitsu6_ed01-2016

What is RDS?

The Radio Data System (RDS) function on the FM waveband permits:
-

automatic retuning to alternative frequencies carrying the same station

while travelling through different regions (if the transmitters of this

station cover the area through which you are travelling),

temporary tuning to traffic information announcements,

display of the name of the station, etc...

Most FM stations use RDS.

These stations transmit non-audible data in addition to their programmes.

The data transmitted in this way allows you access to various functions,

mainly displaying of the name of the station, temporary tuning to

traffic information announcements or automatic retuning to alternative

frequencies.

RDS allows you to continue listening to the same station automatically by

means of alternative frequencies. However, alternative frequencies may not

be provided throughout the country. Radio stations do not cover the whole

country, which explains the loss of reception of the station during a journey.

RDS, AF, TP, PTY

RDS alternative frequencies

Your radio automatically checks and selects the best frequency for the radio station

to which it is tuned (if the station broadcasts on several transmitters or frequencies).

The frequency of a radio station covers approximately 30 miles (50 km). The

change from one frequency to another explains the loss of reception during a

journey.

If the station to which you are listening does not have several frequencies in the

region in which you are currently located, you can deactivate automatic alternative

frequencies.

Traffic information function

The Traffic Programme (TP) function permits automatic and

temporary switching to an FM station broadcasting traffic

information.

The radio station or the source that you are listening to at this point

is placed on hold.

Once the traffic information has ended, the system switches back to

the radio station or the source that you were listening to initially.

Programme types

Some stations offer the option of listening to a themed type of

programme as a priority, selected from the list available below:
NEWS, AFFAIRS, INFOS, SPORT, EDUCATE, DRAMA, CUlTURE,
SCIENCE, VARIED, POP M, ROCK M, EASY M, lIGHT M,
ClASSICS, OTHER M, WEATHER, FINANCE, CHIlDREN,

SOCIAL, RELIGION, PHONE IN, TRAVEL, LEISURE, JAZZ,

COUNTRY, NATION M, OLDIES, FOLK M, DOCUMENT.

RADIO

273

C4-Aircross_en_Chap10b_Mitsu6_ed01-2016

Press the AUDIO

button.

By default the screen displays the stations on FM1.

Selecting an FM station and presetting

Press SEEK TRACK

for a manual search up or

down. The frequency is modified in step of 0.1 MHz.

Press and hold to find a station automatically.

Press "Scan" to search for stations that can be

received in the current location, until a station is

found.

You can also start a search by type of programme by

pressing "PTY Filter".

Press "RDS Settings

Press "On" or "Off

" to activate or deactivate the

functions:
- "AF Check

": automatic search for the best

frequency,

- "Reg

": switch to the regional frequencies.

Once the frequency has been selected, a long press

on the station until a "Beep" is heard will preset it.

The name of the station is displayed if it is available.

RDS settings

Press the AUDIO

button.

By default the screen displays the stations on FM1.

Turn the FOLDER / TUNE SOUND

knob to select a

station.

RADIO

274

C4-Aircross_en_Chap10b_Mitsu6_ed01-2016

275

C4-Aircross_en_Chap10b_Mitsu6_ed01-2016

DAB (Digital Audio Broadcasting)

Digital radio

Digital radio provides a superior audio quality and also a display of

graphic current information concerning the radio station selected.

The different channels offer a choice of radio stations in alphabetical

order.

"DAB" does not have 100% coverage of the country.
If the current DAB station is not available on FM the "DAB-DAB
Link

" indicator disappears.

Press the MODE

button.

Press SEEK TRACK

for an ascending or descending

manual search. The frequency is changed in steps

of 0.1 MHz.
Maintain the pressure to tune to a station

automatically.

Press "Scan

" to search for transmitting stations, until

they are obtained.

You can also start a search by type of programme by

pressing "PTY Filter".

Once the frequency has been chosen, maintain the

pressure on the station until a "Beep" is heard in

order to store it.

If the name of the station is available, this is

displayed.

Turn the FOLDER / TUNE SOUND

thumbwheel to

select a station.

Select "DAB

When the digital signal is weak, "DAB" allows you to continue

listening to the same station, by automatically switching to the

corresponding analogue "FM" station (if it exists).

RADIO

276

C4-Aircross_en_Chap10b_Mitsu6_ed01-2016

Playing an MP3/WMA CD

When the MP3/WMA CD is inserted in the player,

playing of the tracks is automatic.

The tracks cannot be recorded onto the music server.

You can play CDs with up to 8 levels, 100 folders and 255 files

maximum.

Windows Media and Microsoft Corporation are trademarks

registered in the United States and/or other countries.

General notes on files

MP3 and WMA audio file formats

MP3 is the abbreviation of MPEG-1 Audio Layer 3 and MPEG is

the abbreviation of Motion Pictures Experts Group. This is a digital

audio compression standard that reduces the size of audio files by

eliminating frequencies that are inaudible to the human ear.

This compression divides the size of the content of a conventional

audio CD by approximately 10, which means that the content of

10 audio CDs can be recorded onto a single CD-R or CD-RW.

WMA is the abbreviation of Windows Media Audio, another audio

data compression standard offered by Microsoft.

It can be used to create and save audio files at a compression rate

lower than that of the MP3 format, with an equivalent file size.

File handling

Some blank CDs may not be played by your equipment (quality,

recording speed...).

When you burn a CD-R or CD-RW, select the ISO 9660 level 1.2

or Joliet burning standard.
To obtain the best acoustic quality possible, select the lowest

burning speed.

The MPEG1 and MPEG2 standards are accepted.

Transmission speeds between 32 and 320 kbits/s and scans

between 16 kHz and 48 kHz are accepted.

To display the title information (the name of the artist, the title of the

album, etc...), the information contained in the ID3 Tags or the WMA

Tags must be included in the MP3/WMA files burned onto the disc.

Copyright

Your audio system may allow you to listen to music which is usually

protected by copyright in accordance with current national and

international standards. Please consult these standards and comply

with them.

MUSIC

277

C4-Aircross_en_Chap10b_Mitsu6_ed01-2016

Press the MODE button then "CD", if the player

already contains a CD.

Otherwise, insert a CD in the player, play begins

automatically.

Playing a file

You can move by one level at a time.

Press on the name of a folder and at each press the

list of folders of the level below is displayed.

Press these buttons for fast forward or back in the

current track.

Press on "Go Up 1 Level

" to move up a level and/or

select a level.

Press these buttons to select the next or previous

track or return to the beginning of the track currently

being played.

Press "Random

" to play all of the tracks in the

selected folder in random order.
Press "Random

" again to play all of the tracks on the

CD in random order.

Press again to stop.

Press on "Go to ROOT

" to go up to the root level.

Press "Scan

" to play the beginning of each track in

each folder for approximately 10 seconds (scanning).
Press "Scan

" again the play the beginning of each

track in the selected folder in a loop.

Press again to stop or press on the current track

(during the 10 seconds) and play begins.

Press "Repeat

" to play the selected track repeatedly

in a loop.
Press "Repeat

" again to play all of the tracks in the

selected folder repeatedly in a loop.

Press again to stop.

Press this button for access to the secondary menu.

MUSIC

278

C4-Aircross_en_Chap10b_Mitsu6_ed01-2016

Using the USB port

With the vehicle stationary, ignition

switch in the LOCK position, connect

a suitable cable to the portable player.

The USB port is used to connect a

portable device (MP3 player, Apple

player, etc.). The files are sent from the

player to your audio system and heard

through the vehicle's speakers.

Then connect the cable to the

vehicle's USB port.

Use only USB memory sticks in the format FAT32 (File Allocation

Table).

File formats: MP3, WMA, AAC, WAV.

- Maximum number of levels (including root): 8.

- Number of folders: 100.

- Number of files: 255.

To protect the system, do not use a USB hub.

To disconnect the cable, the ignition switch must be in the LOCK

position.

Take care not to trap the cable when closing the armrest.

MUSIC

279

C4-Aircross_en_Chap10b_Mitsu6_ed01-2016

Connecting APPLE

players

Connect the Apple

player to the USB port using a suitable cable

(not supplied).

Play starts automatically.

Control is via the audio system.

The classifications available are those of the portable device

connected (artists / albums / genres / playlists / audiobooks /

podcasts).

The default classification used is by artist. To modify the classification

used, return to the first level of the menu then select the desired

classification (playlists for example) and confirm to go down through

the menu to the desired track.

The "Shuffle tracks" mode on an iPod

corresponds to the "Random"

mode on the audio system.

The "Shuffle albums" mode on an iPod

corresponds to the "Random

all" on the audio system.

"Shuffle tracks" is restored by default on each connection.

The version of software in the audio system may not be compatible

with the generation of your Apple

player.

MUSIC

Using the SD card reader

The SD card reader can play MP3, WMA, AAC and WAV audio

files.

Press the OPEN button to open the

screen panel.

Insert the SD card containing audio

files into the right-hand SD card

reader.

Push the SD card until it clicks into

place.
Press the OPEN button to close the

screen panel.

Press the MODE button, then on "SD

280

C4-Aircross_en_Chap10b_Mitsu6_ed01-2016

USB, iPod and SD player - Playing a track

Press the MODE button then on "USB/iPod" or "SD

you can display the sort by category at any time by

pressing "Playlist".

In USB or SD mode you can move up a level at the

same time.

Press on the name of a folder and at each press the

list of folders in the level below is displayed.

Press these buttons for fast forward or back in the

current track.

Press "Go Up 1 Level

" to go up one level and/or

select a level.

Press these buttons to select the next or previous

track or return to the beginning of the track currently

being played.

Press "Random

" to play all of the tracks in the

selected folder in random order.
Press "Random

" again to play all of the tracks in

random order.

Press again to stop.

Press "Go to ROOT

" to go up to the root level.

Press "Scan

" to play the beginning of each track in

each folder for approximately 10 seconds (scanning).
Press "Scan

" again to play the beginning of each

track in the selected folder in a loop.

Press again to stop or press on the current track

(during the 10 seconds) and play begins.

Press "Repeat

" to play the selected track repeatedly

in a loop.
Press "Repeat

" again to play all of the tracks in the

selected folder repeatedly in a loop.

Press again to stop.

Press this button for access to the secondary menu.

MUSIC

281

C4-Aircross_en_Chap10b_Mitsu6_ed01-2016

MUSIC

Using the auxiliary input (AUX)

The auxiliary input allows the

connection of a portable device

(MP3 player...).

Connect the portable device (MP3 player…) to the RCA sockets

(red and white) using a suitable cable, not supplied.

First adjust the volume of your portable device (to a high level).

Then adjust the volume of your audio system.

The operation and play is controlled on the portable device.

Press the MODE button, then on "AUX

282

C4-Aircross_en_Chap10b_Mitsu6_ed01-2016

SETTINGS

Level 1

Level 2

Level 3

283

C4-Aircross_en_Chap10b_Mitsu6_ed01-2016

Level 1

Level 2

Level 3

Comments

Display Off

Choose to switch off the screen.
To switch it back on, touch the screen or press any button.

System

Time

Choose adjustment of the time by the RDS signal, time zone, summer time.

Language

Select the language (English, Français, Deutsch, Nederlands, Português,

Español, Svenska, Italiano, Dansk, Vlaams, Polski, Norsk).

Pairing

Select an authorisation "Select Device to Connect", "Register Device", "Set

Passkey: Fixed", "Set Passcode".

Units

Select the units for the calculation of distances (km or miles and °C or °F).

Keyboard Layout

Select the type of input keyboard (alphabet or PC).

Reset all

Restore factory settings.
After reinitialisation, restart the system.

TP Standby

Select the traffic information (TP) setting: on or off.

Picture Control

Brightness

Adjust the image settings for: brightness, contrast, black level.

Contrast

Black Level

Clock Screen

284

C4-Aircross_en_Chap10b_Mitsu6_ed01-2016

INFORMATION

Level 1

Level 2

Level 3

285

C4-Aircross_en_Chap10b_Mitsu6_ed01-2016

Level 1

Level 2

Level 3

Comments

Calendar

Make a note on the calendar of special days, birthdays, ...

Use the arrows to find a date and press directly on the day required to

enter the event.

User SD

Check the capacity of the SD card and the free space.

Voice Control Help

Make a telephone call

Verify the use of voice commands.

Busy tone

Manage the directory

Pairing

GPS Information

Country

View GPS information:

- the satellite position chart with the direction and movement of

the vehicle,

- the name of the current location,

- the longitude and latitude of the current location,

- the status of location measurement (2D = 3 satellites or less,

3D = 4 satellites or more),

- the number of satellites visible.

286

C4-Aircross_en_Chap10b_Mitsu6_ed01-2016

INFORMATION

Level 1

Level 2

Level 3

Content .. 16 17 18 19 ..
