Citroen Jumpy Multispace (2014 year). Instruction - part 15

9.61

JUMPY-ATLANTE-VP_EN_CHAP09B_RT6-2-7_ED01-2014

FREQUENTLY ASKED QUESTIONS

QUESTION

ANSWER

SOLUTION

With the engine off, the

system switches off after

a few minutes of use.

When the engine is switched off, the system's operating time depends on

the battery charge.

The switch-off is normal: the system switches to economy mode and

switches off to prevent discharging of the vehicle's battery.

Start the vehicle's engine to increase the battery

charge.

Playback of my USB

memory stick starts only

after a very long wait

(around 2 to 3 minutes).

Some ﬁ les supplied with the memory stick may greatly slow down access

to reading the memory stick (multiplication by 10 of the catalogue time).

Delete the ﬁ les supplied with the memory stick

and limit the number of sub-folders in the ﬁ le

structure on the memory stick.

When I connect my

iPhone as telephone and

to the USB port at the

same time, I am unable

to play the music ﬁ les.

When the iPhone connects automatically as a telephone, it forces the

streaming function. The streaming function takes the place of the USB

function which is then not useable, there is a period without sound of the

track being played with Apple

players.

Disconnect and reconnect to the USB port

(the USB function takes priority over streaming).

9.62

JUMPY-ATLANTE-VP_EN_CHAP09B_RT6-2-7_ED01-2014

9.63

JUMPY-ATLANTE-VP_EN_CHAP09C_RD45_ED01_2014

Audio system

Your Audio system is coded in such a way that it will

only operate in your vehicle.

For safety reasons, the driver must carry out operations

which require prolonged attention while the vehicle is

stationary.

When the engine is switched off and to prevent

discharging of the battery, the audio equipment may

switch off after a few minutes.

AUDIO SYSTEM / BLUETOOTH

01 First steps

02 Steering mounted controls

03 Main menu

04 Audio

05 USB Box

06 Bluetooth functions

07 Configuration

08 Trip computer

CONTENTS

09 Screen menu map

Frequently asked questions

9.64
9.65
9.66
9.67
9.70
9.73
9.76
9.77
9.78
9.83

9.64

JUMPY-ATLANTE-VP_EN_CHAP09C_RD45_ED01_2014

FIRST STEPS

Eject CD.

Select source:

radio, audio CD / MP3 CD, USB,

Jack connection, Streaming,

AUX.

Select the screen display

mode:

Date, audio functions, trip

computer, telephone.

Automatic frequency search

down/up.

Select previous/next CD, MP3

or USB track.

Audio settings: front/

rear fader, left/right

balance, bass/treble,

loudness, audio

ambiences.

Display the list of

local stations.

Long press: CD

tracks or MP3 folders

(CD / USB).

TA (Trafﬁ c Announcements)

on/off.

Long press: PTY * (radio

Programme TYpe) mode.

Display main menu.

The DARK button changes the screen display

for improved driving comfort at night.

press: upper bar only illuminated.

press: black screen.

press: return to standard display.

On/off, volume setting.

Buttons 1 to 6:

Select a pre-set radio station.

Long press: pre-set a station.

Select next frequency down/up.

Select previous/next MP3 folder.

Select previous/next folder / genre /

artist / playlist (USB).

Conﬁ rm.

Select wavebands

FM1, FM2, FMast and

AM.

Abandon the current

operation.

* Available according to version.

9.65

JUMPY-ATLANTE-VP_EN_CHAP09C_RD45_ED01_2014

STEERING MOUNTED CONTROLS

Radio: select the previous/next pre-set

station.

USB: select genre / artist / folder from the

classiﬁ cation list.

Select the previous/next item in a menu.

Change audio source.

Conﬁ rm a selection.

Call/end call on the telephone.

Press for more than 2 seconds:

telephone main menu.

Radio: automatic search for a lower

frequency.

CD / MP3 / USB: selection of the

previous track.

CD / USB: continuous press: fast

reverse.

Move in the list.

Radio: automatic search for a higher

frequency.

CD / MP3 / USB: selection of the next

track.

CD / USB: continuous press: fast

forwards play.

Move in the list.

Volume increase.

Volume decrease.

Mute: press the volume

increase and decrease

buttons simultaneously.

The sound is restored by

pressing one of the two

volume buttons.

9.66

JUMPY-ATLANTE-VP_EN_CHAP09C_RD45_ED01_2014

AUDIO FUNCTIONS :

radio, CD, USB, options.

> MONOCHROME SCREEN C

For a detailed global view of

the menus available, refer to

the "Screen menu map" in this

section.

TELEPHONE :

Bluetooth hands-free,

pairing, management

of a call.

PERSONALISATION-

CONFIGURATION :

vehicle parameters,

display, languages.

TRIP COMPUTER : entering

of distances, alerts, status of

functions.

> MONOCHROME SCREEN A

9.67

JUMPY-ATLANTE-VP_EN_CHAP09C_RD45_ED01_2014

AUDIO

Press the SOURCE button several

times in succession and select

the radio.

Press the BAND AST button to select

a waveband: FM1, FM2, FMast, AM.

Brieﬂ y press one of the buttons to

carry out an automatic search of the

radio stations.

Press one of the buttons to carry out

a manual search up / down for radio

frequencies.

Press the LIST REFRESH button to

display the list of stations received

locally (30 stations maximum).

To update this list, press for more

than two seconds.

The external environment (hills, buildings, tunnels, basement car parks, ...)

may block reception, including in RDS mode. This is a normal effect of the

way in which radio waves are transmitted and does not indicate any failure

of the audio system.

RDS

RADIO

SELECTING A STATION

Press the MENU button.

Select AUDIO FUNCTIONS then

press OK.

Select the FM WAVEBAND

PREFERENCES function then press

OK.

Select ACTIVATE RDS then press

OK. RDS appears on the screen.

In radio mode, press OK directly to activate / deactivate RDS mode.

The RDS, if displayed, enables you to continue listening to the same

station by automatic retuning to alternative frequencies. However, in certain

conditions, coverage of an RDS station may not be assured throughout the

country as radio stations do not cover 100 % of the territory. Under conditions

of very weak reception, the system may change to a regional station.

9.68

JUMPY-ATLANTE-VP_EN_CHAP09C_RD45_ED01_2014

AUDIO

Insert circular compact discs only.

Some anti-pirating systems, on original discs or CDs copied using a

personal recorder, may cause faults which are no reﬂ ection on the

quality of the original player.

Without pressing the EJECT button, insert a CD in the player, play

begins automatically.

PLAYING A CD

To play a disc which has already been

inserted, press the SOURCE button

several times in succession and

select CD.

Press one of the buttons to select a

track on the CD.

Press the LIST REFRESH button to display the list of tracks on the CD.

Press and hold one of the buttons for

fast forwards or fast backwards.

RECEIVING TA MESSAGES

Press the TA button to activate or

deactivate trafﬁ c messages.

The TA (Trafﬁ c Announcement) function gives priority to TA alert

messages. To operate, this function needs good reception of a

radio station transmitting this type of message. When a trafﬁ c

report is transmitted, the current audio source (Radio, CD, ...) is

interrupted automatically to play the TA message. Normal playback

of the audio source resumes at the end of the transmission of the

message.

9.69

JUMPY-ATLANTE-VP_EN_CHAP09C_RD45_ED01_2014

The MP3 format, an abbreviation of MPEG 1.2 & 2.5 Audio Layer 3,

is an audio compression standard which permits the recording of

several tens of music ﬁ les on a single disc.

In order to be able to play a recorded CDR or CDRW, when

recording, the ISO 9660 level 1.2 or Joliet ﬁ le format is

recommended.

If the disc is recorded in another format, it may not be played

correctly.

It is recommended that the same recording format is always

used for an individual disc, with as low a speed as possible

(4x maximum) for optimum sound quality.

In the particular case of a multi-session CD, the Joliet format is

recommended.

The audio system will only play ﬁ les with the extension ".mp3" with

a sampling rate of 22.05 KHz or 44.1 KHz. No other type of ﬁ le

(.wma, .mp4, .m3u...) can be played.

It is advisable to restrict ﬁ le names to 20 characters without using

special characters (e.g. " ? ; ù) to avoid any playing or displaying

problems.

MP3 CD

INFORMATION AND ADVICE

AUDIO

Empty CDs are not recognised and may damage the system.

Insert an MP3 compilation in the player.

The audio equipment searches for all of the music tracks, which

may take anything between a few seconds and several tens of

seconds, before play begins.

MP3 CD

PLAYING AN MP3 COMPILATION

On a single disc, the CD player can read up to 255 MP3 ﬁ les

spread over 8 folder levels. However, it is advisable to keep to

a limit of two levels to reduce the access time before the CD is

played.

While the CD is being played, the folder structure is not followed.

All of the ﬁ les are displayed on a single level.

To play a disc which has already

been inserted, press the SOURCE

button several times in succession

and select CD.

Press one of the buttons to select a

folder on the CD.

Press the LIST REFRESH button to display the list of directories of

the MP3 compilation.

Press and hold one of the buttons for

fast forward or backward play.

Press one of the buttons to select a

track on the CD.

9.70

JUMPY-ATLANTE-VP_EN_CHAP09C_RD45_ED01_2014

USB BOX

The system puts together playlists (temporary memory) created

over a period which depends on the capacity of the USB device.

The other sources are available during this time.

The playlists are updated each time the ignition is switched off or

each time a USB memory stick is connected.

When connecting for the ﬁ rst time, the classiﬁ cation suggested

is by folder. When you reconnect, the classiﬁ cation selected

previously is retained.

Connect the memory stick to the port, directly or

using a lead. If the audio equipment is switched

on, the USB source is detected as soon as it

is connected. Play begins automatically after a

delay which depends on the capacity of the USB

memory stick.

The ﬁ le formats supported are .mp3 (mpeg1

layer 3 only) and .wma (standard 9 only,

128 kbits/sec compression).

Certain playlist formats are supported (.m3u, ...)

On reconnection of the previous memory stick

used, play is resumed automatically with the last

track played.

This unit consists of a USB port and an auxiliary

Jack socket * . The audio ﬁ les are transmitted

from a portable device - digital player or a USB

memory stick - to your Audio system and heard

via the vehicle's speakers.

USB memory stick (1.1, 1.2 and 2.0) or Apple

player of generation 5 or later:

- USB memory sticks should be formatted

FAT or FAT 32 (NTFS not supported),

the Apple

player lead is essential,

- navigation through the ﬁ le database is also

possible by means of the steering mounted

controls.

The list of compatible equipment and the compression rates supported

are available from CITROËN dealers.

The list of compatible equipment and the compression rates supported

USING THE USB BOX

CONNECTING A USB MEMORY STICK

Other Apple

players of earlier generations and

players using the MTP protocol * :

- play via Jack-Jack lead only (not supplied),

- navigation through the ﬁ le database is from

the portable device.

* According to vehicle.

9.71

JUMPY-ATLANTE-VP_EN_CHAP09C_RD45_ED01_2014

Press LIST brieﬂ y to display the

previously selected classiﬁ cation.

Navigate through the list using the left/

right and up/down buttons.

Conﬁ rm the selection by pressing OK.

The lists available are Artist, Genre and Playlist (as deﬁ ned in the

Apple

player).

Selection and Navigation are described in steps 1 to 4 above.

Do not connect a hard disk or USB connection device other

than audio equipment to the USB port. This could damage your

installation.

CONNECTING AN APPLE

CONNECTING AN APPLE PLAYER VIA THE USB PORT

Press one of these buttons to gain

access to the previous / next track on

the classiﬁ cation list currently being

played.

Press and hold one of the buttons for

fast forward or backward play.

Press one of these buttons to

gain access to the previous / next

Genre, Folder, Artist or Playlist on

the classiﬁ cation list currently being

played.

Press and hold LIST to display the

different classiﬁ cations.

Select by Folder / Artist / Genre / Playlist,

press OK to select the classiﬁ cation

required, then press OK again to conﬁ rm.

- by Folder: all folders containing audio

ﬁ les recognised on the peripheral

device.

- by Artist: all of the artist names

deﬁ ned in the ID3 Tags, classiﬁ ed in

alphabetical order.

- by Genre: all of the genres deﬁ ned in

the ID3 Tags.

- by Playlist: in accordance with the

playlists recorded on the USB device.

USB BOX

9.72

JUMPY-ATLANTE-VP_EN_CHAP09C_RD45_ED01_2014

The display and control is via the portable device.

First adjust the volume of your portable device.

Then adjust the volume of your audio

system.

USING THE AUXILIARY INPUT (AUX)

ADJUSTING THE VOLUME OF

THE AUXILIARY SOURCE

JACK socket or USB port (according to vehicle)

USB BOX

Do not connect a device to both the JACK socket and the USB

port at the same time.

Connect the portable device

(MP3 player…) to the JACK socket or

to the USB port, using a suitable cable

(not supplied).

Press the SOURCE button several

times in succession and select AUX.

The auxiliary input, JACK or USB, allows the connection of a

portable device (MP3 player...).

9.73

JUMPY-ATLANTE-VP_EN_CHAP09C_RD45_ED01_2014

BLUETOOTH FUNCTIONS

For safety reasons and because they require prolonged attention

on the part of the driver, the operations for pairing of the Bluetooth

mobile telephone with the Bluetooth hands-free system of your

audio equipment must be carried out with the vehicle stationary

and the ignition on.

Press the MENU button.

A window is displayed with a message that a search is in progress.

Activate the telephone's Bluetooth function

and ensure that it is "visible to all" (telephone

conﬁ guration).

In the menu, select:

Bluetooth telephone function -

Audio

- Bluetooth conﬁ guration

Perform a Bluetooth search

The services offered depend on the network, the SIM card and the

compatibility of the Bluetooth equipment used.

Consult your telephone's manual and your operator to ﬁ nd out which

services are available to you.

BLUETOOTH TELEPHONE

SCREEN C

The TELEPHONE menu permits access to the following functions

in particular: Directory * , Call list, Pairing management.

The ﬁ rst 4 telephones recognised are displayed in this window.

A virtual keypad is displayed in the screen:

enter a code with at least 4 digits.

Conﬁ rm by pressing OK.

A message that the pairing has been successful appears in

the screen.

Select the telephone to be connected from the list. Only one

telephone can be connected at a time.

A message is displayed in the screen of the

telephone chosen. To accept the pairing, enter the

same code on the telephone, then conﬁ rm with OK.

The automatic connection authorised is only active after the

telephone has been conﬁ gured.

The directory and the call list can be accessed after the

synchronisation period.

(Available according to model and version)

* If your telephone is fully compatible.

If pairing fails, the number of attempts is not limited.

Go to www.citroen.co.uk for more information (compatibility,

more help, ...).

PAIRING A TELEPHONE / FIRST CONNECTION

9.74

JUMPY-ATLANTE-VP_EN_CHAP09C_RD45_ED01_2014

RECEIVING A CALL

An incoming call is announced by a ring and a superimposed

display in the vehicle's screen.

Select the YES tab on the display

using the buttons and conﬁ rm by

pressing OK.

Press this button to accept the call.

MAKING A CALL

From the Bluetooth telephone function Audio menu, select Manage

the telephone call then Call, Call list or Directory.

Press this button for more than two seconds for

access to your directory, then navigate with the

thumb wheel.

To dial a number, use your telephone's keypad,

with the vehicle stationary.

During a call, press this button for more than

2 seconds.

Conﬁ rm with OK to end the call.

BLUETOOTH FUNCTIONS

ENDING A CALL

9.75

JUMPY-ATLANTE-VP_EN_CHAP09C_RD45_ED01_2014

Initiate the pairing between the telephone and

the vehicle. This pairing can be initiated from

the vehicle's telephone function menu or via the

telephone's keypad. See steps 1 to 9 on the

previous pages. During the pairing phase, the

vehicle must be stationary with the key in the

ignition.

Select the telephone to be connected from the telephone

function menu.

The audio system connects to a newly paired telephone

automatically.

BLUETOOTH AUDIO STREAMING *

Wireless transmission of the telephone's music ﬁ les via the audio

equipment. The telephone must be able to manage the appropriate

Bluetooth proﬁ les (Proﬁ les A2DP / AVRCP).

* Depending on the compatibility of the telephone.

** In certain cases, playing of the Audio ﬁ les must be initiated from

the keypad.

*** If the telephone supports the function.

Activate the streaming source by

pressing the SOURCE button ** .

The tracks to be played can be

controlled as usual via the buttons on

the audio system control panel and

the steering mounted controls *** .

The contextual information can be

displayed on the screen.

BLUETOOTH FUNCTIONS

9.76

JUMPY-ATLANTE-VP_EN_CHAP09C_RD45_ED01_2014

CONFIGURATION

Press the MENU button.

Using the arrows, select

PERSONALISATION

CONFIGURATION.

Press to conﬁ rm the selection.

Using the arrows, select DISPLAY

CONFIGURATION.

Press to conﬁ rm the selection.

Using the arrows, select ADJUST

DATE AND TIME.

Adjust the settings one by one

conﬁ rming by pressing the OK

button. Next select the OK tab on the

screen then conﬁ rm.

SETTING THE DATE AND TIME

SCREEN C

Content .. 13 14 15 16 ..
