Citroen Jumpy Multispace (2014 year). Instruction - part 13

9.29

JUMPY-ATLANTE-VP_EN_CHAP09B_RT6-2-7_ED01-2014

Enter the same code on the telephone then accept

the connection.

Then accept automatic connection on the telephone to allow the

telephone to reconnect automatically every time the vehicle is

started.

The ability of the system to connect in only one mode depends on

the telephone. The two modes may both connect by default.

USING THE TELEPHONE

The "

Hands-free mode " should be used in preference if

"Streaming" is not desired.

The services available depend on the network, the SIM card and the compatibility of the Bluetooth telephone used. Check the telephone

manual and with your network provider for details of the services available to you.

Select a code for the connection then

conﬁ rm "

OK ".

Depending on the type of telephone, the system will ask you to

accept or not the transfer of your contacts.

On return to the vehicle,the last telephone connected

automatically reconnects, within around 30 seconds after

switching on the ignition (Bluetooth activated and visible).

To modify the automatic connection mode, remove the pairing

and pair the telephone again with the desired mode.

9.30

JUMPY-ATLANTE-VP_EN_CHAP09B_RT6-2-7_ED01-2014

USING THE TELEPHONE

DIRECTORY / SYNCHRONIZING CONTACTS

Press

PHONE then select " Contacts

management " and conﬁ rm.

Select "

New contact " to enter a new

contact.

Select "

Sort by Name/First name " to

choose the order in which they appear.

Select "

Delete all contacts " to delete

the contacts saved in the system.

Selection "

Synchronization options ":

No synchronization: only the

contacts saved in the system

(always present).

- Display telephone contacts: only the

contacts saved in the telephone.

- Display SIM card contacts: only the

contacts saved on the SIM card.

Display all phone contacts:

contacts on the SIM card and in the

telephone.

Select "

Import all the entries " to import

all the contacts in the telephone and

save them in the system.

Once imported, a contact remains visible

whatever telephone is connected.

Select "

Contact mem. status " to see the

number of contacts saved in the system

or imported, and the free memory.

9.31

JUMPY-ATLANTE-VP_EN_CHAP09B_RT6-2-7_ED01-2014

MANAGING CONTACTS

Press

PHONE then select " Directory of

contacts " and conﬁ rm.

Select the desired contact and conﬁ rm.

Select "

Import " to copy one contact to

the system.

Select "

Call " to start the call.

Select "

Open " to view an external contact

or modify a contact saved in the system.

Select

Select "

Delete " to delete a contact saved

in the system.

It is necessary to import an external contact to modify the record.

It will be saved in the system. It is not possible to modify or delete

contacts in the telephone or the SIM card via the Bluetooth

connection.

USING THE TELEPHONE

press the back button to exit this menu.

Delete the addresses saved in the directory of contacts:

Press on

PHONE .

Select "Directory of contacts".

- Select "Display contacts" and conﬁ rm, then select the address.

- Select "Delete" and conﬁ rm.

(This operation must be carried out contact by contact).

9.32

JUMPY-ATLANTE-VP_EN_CHAP09B_RT6-2-7_ED01-2014

Press

PHONE twice.

Select "

Dial " then conﬁ rm.

Select "

Directory of contacts " then

conﬁ rm.

Dial the telephone number using the

virtual keypad selecting each number

in turn.

Conﬁ rm "

OK " to make the call.

Press

TEL or twice on PHONE .

CALLING A NEW NUMBER

CALLING A CONTACT

Select the desired contact and conﬁ rm.

If access was via the

PHONE button,

select "

Call " and conﬁ rm.

Select the number and conﬁ rm to start

the call.

MAKING A CALL

Use of the telephone is not recommended while driving. We

recommended that you park safely or make use of the steering

mounted controls.

9.33

JUMPY-ATLANTE-VP_EN_CHAP09B_RT6-2-7_ED01-2014

USING THE TELEPHONE

CALLING A RECENTLY ENTERED NUMBER

Press

TEL , select " Call list " and

conﬁ rm,

Select the desired number and conﬁ rm.

To erase the calls log, press

PHONE twice, select " Phone

functions " and conﬁ rm then select " Delete calls log " and

conﬁ rm.

ENDING A CALL

Press

PHONE then select " OK " to end

the call.

Or make a long press on

TEL at the

steering mounted controls.

Or make two short presses on

TEL at

the steering mounted controls.

Or press the

MODE button, as many

times as necessary, until the telephone

screen is displayed.

Press

PHONE to display the calls log.

Press "

OK " to display the contextual

menu then select "

Hang up " and

conﬁ rm.

9.34

JUMPY-ATLANTE-VP_EN_CHAP09B_RT6-2-7_ED01-2014

USING THE TELEPHONE

RECEIVING A CALL

An incoming call is announced by a ring and a superimposed display

on the screen.

"Yes " to accept the call is selected by

default.

Press "

OK " to accept the call.

Select "

No " and conﬁ rm to reject the

call.

A short press on

TEL accepts an

incoming call.

A long press on

TEL rejects an incoming

call.

9.35

JUMPY-ATLANTE-VP_EN_CHAP09B_RT6-2-7_ED01-2014

USING THE TELEPHONE

OPTIONS DURING A CALL *

During a call, press the

MODE button

several times to select display of the

telephone screen, then press "

OK " to

open the contextual menu.

Select "

Private mode " and conﬁ rm to

take the call on the handset.

Or select "

Hands-free mode " and

conﬁ rm to take the call via the vehicle's

speakers.

Select "

Put call on hold " and conﬁ rm to

put the current call on hold.

Or select "

Resume the call " and

conﬁ rm to resume the call on hold.

Select "

DTMF ring tones " to use the

numerical keypad, so as to navigate

through the menu of an interactive vocal

server.

Select "

Hang up " to end the call.

* Depending on the compatibility of the phone and your service plan.

It is possible to hold a 3-way conference

call by making 2 calls in succession*.

Select "

Conference mode call " in

the contextual menu accessible using

this button.

Or make a short press on this button.

9.36

JUMPY-ATLANTE-VP_EN_CHAP09B_RT6-2-7_ED01-2014

Press

PHONE twice.

Select "

List of the paired peripherals "

and conﬁ rm.

It is possible to:

Connect " or " Disconnect " the

selected telephone,

- delete the pairing of the selected

telephone.

It is also possible to select all pairings.

USING THE TELEPHONE

MANAGING PAIRED TELEPHONES

CHANGING THE RING TONE

Press

PHONE twice.

Select "

Phone functions " and conﬁ rm.

Select "

Ring options " and conﬁ rm.

You can adjust the volume and the type

of ring tone.

Select "

Bluetooth functions ".

Select "

OK " and conﬁ rm to save the

changes.

9.37

JUMPY-ATLANTE-VP_EN_CHAP09B_RT6-2-7_ED01-2014

9.38

JUMPY-ATLANTE-VP_EN_CHAP09B_RT6-2-7_ED01-2014

RADIO

Access to the "RADIO" menu

" " " " " " " " " " " " " " " " " " "

FM / AM band

FM / AM band " " " " " " " " " " " " " " " " " " "

Press  or  or use the rotary control to select the

previous or next station in the list.

Go from the list to the menu (left/right).

Press

RADIO .

9.39

JUMPY-ATLANTE-VP_EN_CHAP09B_RT6-2-7_ED01-2014

RADIO

By alphabetical list

Press

RADIO , select the station of your

choice and conﬁ rm.

By automatic frequency search

Press  or  for the automatic search

for a lower or higher radio frequency.

Or turn the thumb wheel at the steering

mounted controls.

By manual frequency search

Press  or  to adjust the radio

frequency step by step.

SELECTING A STATION

The external environment (hill, building, tunnel, underground car park…) may interfere with the reception, including in RDS station tracking mode.

This phenomenon is a normal result of the way in which radio waves are transmitted and does not in any way indicate a fault with the audio system.

The quality of reception is represented by the number of

active waves in this symbol.

Press

RADIO or OK to display the

contextual menu.

CHANGING WAVEBAND

Select "

Change waveband ".

Select "

AM / FM " and conﬁ rm.

9.40

JUMPY-ATLANTE-VP_EN_CHAP09B_RT6-2-7_ED01-2014

Press the button on the numerical keypad to recall a

preset station.

Or press then turn the thumb wheel at the steering

mounted controls.

PRESETTING A STATION

After selecting a station, press one of the buttons

on the numerical keypad for 2 seconds to preset the

current station.

An audible signal conﬁ rms that the station has been preset.

Press

RADIO .

ACTIVATE / DEACTIVATE RDS

RDS, if activated, allows you to continue listening to the same

station by automatic retuning to alternative frequencies. However,

in certain conditions, coverage of an RDS station may not be

assured throughout the entire country as radio stations do not

cover 100 % of the territory. This explains the loss of reception of

the station during a journey.

Select "

Guidance options " then

conﬁ rm.

Activate or deactivate "

RDS " then

conﬁ rm.

RADIO

9.41

JUMPY-ATLANTE-VP_EN_CHAP09B_RT6-2-7_ED01-2014

9.42

JUMPY-ATLANTE-VP_EN_CHAP09B_RT6-2-7_ED01-2014

Access to the "MUSIC MEDIA PLAYER" menu

" " " " " " " " " " " " " " " " " " "

MEDIA

MEDIA " " " " " " " " " " " " " " " " " " "

Go from the list to the menu (left/right).

Press

MUSIC .

9.43

JUMPY-ATLANTE-VP_EN_CHAP09B_RT6-2-7_ED01-2014

CD, MP3 CD / USB PLAYER

The audio equipment will only play audio ﬁ les with ".wma, .aac, .ﬂ ac,

.ogg and .mp3" ﬁ le extensions and with a bit rate of between 32 Kbps

and 320 Kbps.

It also supports VBR (Variable Bit Rate) mode.

No other type of ﬁ le (.mp4, .m3u…) can be played.

WMA ﬁ les must be of the standard wma 9 type.

The sampling rates supported are 11, 22, 44 and 48 KHz.

It is advisable to restrict ﬁ le names to 20 characters, without using of

special characters (e.g.: " " ? ; ù) to avoid any playing and displaying

problems.

In order to be able to play a recorded CDR or CDRW, when recording

it is preferable to select the ISO 9660 level 1, 2 or Joliet standard.

If the disc is recorded in another format it may not be played correctly.

It is recommended that the same recording standard is always used

for an individual disc, with as low a speed as possible (4x maximum)

for optimum sound quality.

In the particular case of a multi-session CD, the Joliet standard is

recommended.

INFORMATION AND ADVICE

The system supports USB mass storage or iPod

devices via the USB port (suitable cable not supplied).

If a partitioned USB memory key is connected to the

system, only the ﬁ rst partition is recognised.

Control of the peripheral device is with the audio

system controls.

The number of tracks is limited to 2000 maximum,

999 tracks per folder.

If the current consumption at the USB port exceeds

500 mA, the system goes into protection mode and

deactivates the port.

Other peripherals, not recognised on connection, must

be connected to the auxiliary socket using a Jack cable

(not supplied).

In order to be read, a USB memory stick must be formatted FAT 16 or 32.

The system does not support the operation of an Apple

player and a

USB memory stick connected at the same time.

It is recommended that ofﬁ cial Apple

USB cables are used to ensure

correct operation.

9.44

JUMPY-ATLANTE-VP_EN_CHAP09B_RT6-2-7_ED01-2014

MUSIC MEDIA PLAYERS

Insert the CD in the player, insert the USB

memory stick in the USB player or connect the

USB peripheral to the USB port using a suitable

cable (not supplied).

The system builds playlists (in temporary

memory), an operation which can take from

a few seconds to several minutes at the ﬁ rst

connection.

Reduce the number of non-music ﬁ les and the

number of folders to reduce the waiting time.

The playlists are updated every time the ignition

is switched off or connection of a USB memory

stick. However, the system memorises these

lists and if they are not modiﬁ ed, the loading

time will be shorter.

Play starts automatically after a period which

depends on the capacity of the USB memory

stick.

SELECTION OF SOURCE

The

SOURCE button on the steering mounted controls allows a

direct change to the next media source.

CD / CD MP3 "

USB, iPod "

AUX "

STREAMING "

RADIO "

Press

MUSIC to display the " MEDIA "

menu.

Select "

Following media source " and

conﬁ rm.

Repeat the operation as many times as necessary to obtain the

desired media source (except for radio which is accessible either

with

SOURCE or RADIO ).

SOURCES

Content .. 11 12 13 14 ..
