Citroen C-Crosser Dag (2008 year). Instruction

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

190

General notes on the
Music Server

  What is the music server?
The  tracks  on  audio  CDs  (not  MP3  or
WMA)  can  be  recorded  onto  the  hard

disc at approximately 4x speed and

stored on the music server.
Refer to the “Recording a CD” section.
The music server then allows you to
manage groups and lists of tracks.

“Original” group, number 01:

This is the location of the
original playlist created

automatically (not manual) when a track
of an audio CD is recorded.
It is not possible to change its name or
delete it.
You can record up to 9999 playlists in
this group.

“Original Playlist” lists:

These are original playlists
created

automatically

(not manual) when an
audio CD is recorded.

The lists and the artists can be renamed
or deleted. The genres can also be set.

“My Best” group, number 02:

This is the location of the
playlists, etc ... created

automatically from the information read
on the music server.
It is not possible to change its name or
delete it.
The groups “My Favorites” and “My Fre-
quency” are stored here.

“New Group” group for the user,
numbers 03 to 99:

This is the location of the
user’s playlists.

You can record up to 9999 playlists in
this group.
The group can be created, renamed or
deleted.

“My Favorites” list:

This is the location for
storing your favourite
tracks.

They can be deleted from the list and
the order in which they are played can
be changed.

“My Frequency” list:

This is the location of
the playlists used most

frequently from the original list.
It is not possible to add tracks or change
their order.

“User Playlist” list:

This is the location of a
playlist of tracks selected

by the user from the  original  list.
If  you  delete  a  track  from  the  original
list, it will be deleted from the user list.
The list and the artist can be renamed
or deleted.
It  is  possible  to  add  tracks  or  change
their order.

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

191

Information displayed in Music Server mode

A. The number and the name of the

track currently being played are
displayed.

B. The number and the name of the

playlist currently being played are
displayed.

C. The name of the artist is displayed

for the playlist currently being
played.

D. The playing time of the track

currently being played is displayed.

E. The playing mode currently selected

is displayed.

F. Group lists: position of the cursor

and

total

number

groups.

Playlists: position of the cursor
and

total

number

playlists.

Track lists: position of the cursor
and total number of tracks.

G. To display the list of groups, the

playlist and the list of tracks.

H. To scroll up or down through the

tracks. Press and hold for rewind or
fast forwards playing of a track.

I. To scroll up or down through the

playlists.

J. Group lists: number and name of

the group.

Playlists: number and name of the
playlist.
Track lists: number and name of the
track.

K. To display the secondary menu.
L. Displays

the

item

currently

selected.

M. Move the cursor onto the track

currently being played.

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

192

Explanations

Result

Playing a track or a playlist on the Music Server

Press

Press the MODE button then Music Server.

The playlists are played in a loop.
The server can play a track while recording another track from a CD. You
must wait until recording is complete before playing the recorded track.

Selecting a track

Press these buttons to switch between groups, playlists and
tracks.
You cannot switch directly from groups to tracks.

Press [  Track] to select the previous track or return to the beginning of
the track currently being played.
Press and hold for rewind play.

Press [ Track 

] to select the next track.

Press and hold for fast forwards play.

Selecting a playlist

Press [  Playlist] to select the previous playlist.

Press [Playlist 

] to select the next playlist.

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

193

Creating a group and a playlist on the Music Server

Explanations

Result

Press [^] to access the secondary menu.

Creating a group

Press [New Group], enter the name of the group and conﬁ rm by pressing

[SET].
The group is stored on the server.

Creating a playlist

Press [^] to access the secondary menu then press [Function Settings].

Press [New Playlist].

Select the group to which the playlist is to be attached.
The group must be created ﬁ rst.

Enter the name of the playlist and conﬁ rm by pressing [SET].
Then select the search method attached to this new list (either from the
list or by conditions).
The list is stored on the server.

Press

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

194

General notes on MP3/WMA CDs

Playing an MP3/WMA CD

When the MP3/WMA CD is
inserted in the player, play-
ing of the tracks is automat-
ic.
The tracks cannot be recorded
onto the music server.
You can play up to 8 levels,

255 folders and 400 ﬁ les

maximum.

  Copyright
Your Audio equipment may allow you to
listen to music which is usually protected
by copyright in accordance with current
national  and  international  standards.
Please  consult  these  standards  and
comply with them.

  Acceptance of the ﬁ les
Some  burned  CDs  may  not  be  played
by  your  equipment  (quality,  recording
speed ...).
When  you  burn  a  CD-R  or  CD-RW,
select  the  ISO  9660  level  1.2  or  Joliet
burning standard.
To  obtain  the  best  acoustic  quality
possible,  select  the  lowest  burning
speed.
The  MPEG1  and  MPEG2  standards
are accepted.
Transmission  speeds  between  32  and
320 kbits/s and scans between 16 kHz
and 48 kHz are accepted.
To  display  the  title  information  (the
name of the artist, the title of the album,
etc...), the information contained in the
ID3  Tags  or  the  WMA  Tags  must  be

included in the MP3/WMA ﬁ les burned

onto the disc.

  What is the MP3/WMA ﬁ le format?
MP3  is  the  abbreviation  of  MPEG-1
Audio  Layer  3  and  MPG  is  the

abbreviation of Motion Pictures Experts

Group, a digital video data compression
standard used on media such as video
CDs.
The  MP3  compression  reduces  the
number of bytes in a song by eliminating
the  long  sound  waves  in  the  range  of
frequencies  which  are  imperceptible
to  the  human  ear,  so  producing  high

quality audio ﬁ les with a low volume of

data.
This compression divides the size of
the content of a conventional audio

CD by approximately 10, which means

that the content of 10 audio CDs can
be recorded onto a single CD-R or
CD-RW.

WMA is the abbreviation of Windows
Media Audio, another audio data
compression

standard

offered

Microsoft.
It can be used to create and save audio

ﬁ les at a compression rate higher than

that of the MP3 format.
Windows

Media

and

Microsoft

Corporation  are  trademarks  registered
in  the  United  States  and/or  other
countries.

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

195

Information displayed in MP3/WMA CD mode

A. The number and the name of the

track currently being played are
displayed.

B. The name of the album/folder is

displayed for the track currently
being played.

C. The name of the artist is displayed

for the track currently being played.

D. The playing time of the current track

is displayed.

E. The playing mode currently selected

is displayed.

F. Position of the cursor and total

number of folders or tracks on the
current level.

G. To display the list of folders of a

higher level.

H. Displays

the

item

currently

selected.

I. To scroll up or down through the

tracks. Press and hold for rewind or
fast forwards playing of a track.

J. To scroll up or down through the

folders.

K. Displays the folder number and

the folder name. Plus the lists and
numbers of tracks and the name of

the ﬁ le (without extension).

L. To display the secondary menu.
M. Move the cursor onto the track

currently being played.

N. Displays the type of medium, MP3

or WMA.

The CD button is only active if the play-
er contains a CD.

Press Open to return the display to the
vertical position.

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

196

Playing an MP3/WMA CD (1/2)

Press

Explanations

Result

Press the MODE button then CD, if the player already contains a CD.

Moving around the folders

Selecting a folder

Otherwise, insert a CD in the player, play begins automati-
cally.

You can move by one level at a time.
Press on the name of a folder and at each press the list of folders of the
level below is displayed.

Press on the folder above to move up and/or select a level.

Press [ 

Folder] to select the previous folder.

Press [ Folder 

] to select the next folder.

These displays indicate the current level:
CD: level 0, folder below: level 1, folder below that, level 2, etc ...
Up to 8 levels maximum.

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

197

Changing the playing mode

Press [ 

Track] to select the previous track or return to the beginning of

the track currently being played.
Press and hold for rewind play.

Selecting a track

Press [ Track 

] to select the next track.

Press and hold for fast forwards play.

Press [Repeat] to play the track selected in a loop (repetition).
Press [Repeat] again to play all of the tracks in the selected folder in a
loop.
Press again to stop.

Press [Scan] to play the beginning of each track in each folder for

approximately 10 seconds (scanning).
Press [Scan] again the play the beginning of each track in the selected
folder in a loop.
Press again to stop or press on the current track (during the 10 seconds)
and play begins.

Press [Random] to play all of the tracks in the selected folder in random
order.
Press [Random] again to play all of the tracks on the CD in random
order.
Press again to stop.

Press [^] to access the secondary menu.

Press

Explanations

Result

Playing an MP3/WMA CD (2/2)

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

198

Information displayed in DVD mode

The DVD button is only active if the
player contains a DVD.

Press Open to return the display to the
vertical position.

For  safety  reasons,  the  video
is  not  displayed  while  driving,
however  the  audio  can  be
played.

To  display  the  picture  and  watch
a  DVD,  park  the  vehicle  in  a  safe
place.

K. To display the DVD title menu.
L. To scroll up or down through the

chapters.

Press and hold for fast backwards
or forwards play.

M. To scroll up or down through the

titles.

  N.   To enter a title or chapter number.
  O.   To change the angle.
  P.   To  change  the  language  of  the

subtitles.

Q. To change the language.
R. To select a chapter or title or specify

a number.

A. This icon is displayed when the

operation requested cannot be
carried out.

B. The number of the chapter currently

being played is displayed.

C. The number of the title currently

being played is displayed.

D. Symbols display the current status

of the player.

E. The playing time is displayed.
F. To resume normal play when play is

paused or during slow-motion play.

G. To stop play temporarily.
H. To stop play. Press the screen to

access the menu.

I. For slow-motion play.
J. To play the previously selected zone

on the disc.

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

199

Playing a DVD

Result

Explanations

Selecting a chapter

Press the MODE button then DVD, if the player already contains a DVD.

Otherwise, insert a DVD in the player, the picture is displayed
automatically. Press the screen to access the menus.

While driving, the sound band alone is played and no picture is dis-
played.

Press [ 

Chapter] to select the previous chapter or return to the begin-

ning of the chapter currently being played.
Press and hold for rewind play.

Press [ Chapter 

] to select the next chapter.

Press and hold for fast forwards play.

Selecting a title

Press [  Title] to select the previous title.

Press [Title 

] to select the next title.

Press

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

200

A - Choose to switch off the display.

To switch it back on, touch the
screen or press any button.

B - Choose the settings of the sound

in the vehicle, if an audio source is
selected (FM, CD, ...), for:

B1 - the sound distribution or the volume

such as the front-rear balance, the
bass, the medium, the treble, the
volume adjustment in relation to
the vehicle speed,

B2 - the type of music (with surround

option) such as classic, jazz, pop,
rock, hip hop, country, normal, ...

- the sound ﬁ eld (with surround

option) such as stage, live, hall,
normal, ...

C - Choose the quality of the picture

for:

C1 - the colour (when playing DVDs),
C2 - the intensity of the colours (when

playing DVDs),

C3  - the brightness,
C4  - the contrast,
C5  - the level of black.

SETTINGS

Display, sound, picture

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

201

Time and date, language, unit,
picture size

E - Choose the size of the DVD picture

for:

E1 - normal 4/3,

E2 - extends the picture evenly to the right

and to the left in wide screen mode,

E3 - extends the right and left parts only

leaving the centre as it stands in wide

screen mode,

E4 - enlarges the picture in 4/3 format.The

top and the bottom are outside the

frame.

D - Choose the base settings of the

system for:

D1 - setting of the time by the RDS signal,

time zone, summer time,

D2 - the language (English, Français,

Deutsch, Nederlands, Portuguese,
Español, Svenska, Italiano, Dansk),

D3 - the units for calculation of the

distances (km or miles and °C or °F),

D4 - other settings such as:

- the voice guidance volume,
- the type of voice guidance voice

(female or male),

- the volume of the operation bleeps

(1 to 3 and 0=no bleep),

- the

type

inputting

keypad

(alphabet or PC),

- the range of menu colours (red or

blue),

- the displaying or not of the audio

playing icons on the map screen,

- the reinitialisation of the vehicle

sensor,

- the interruption or not of the display

when the air conditioning is used.

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

202

Equipment, contrast, traffic information (TP)

F - Choose to adjust or set the

parameters  of  certain  equipment
offered  in  your  vehicle  (e.g.:
unfolding/folding  of  the  mirrors,
raising

the

windows

locking, timing and sensitivity of
the automatic lighting, direction
indicators motorway function, ...):

F1 - to scroll up the list,
F2 - to scroll down the list,
F3 - to reinitialise all of the settings

(manufacturer’s settings).
Press each setting to select or
change the parameters.

G - Choose to adjust the contrast of the

display in relation to the exterior

light (day, night or automatic).

H - Choose to activate or deactivate

the trafﬁ c information (TP).

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

203

INFORMATION

A - Consult the system information:
A1 - the software version,
A2 - the map data version,
A3 - the system information database

version.

To  update  the  versions,  insert
the  DVD  containing  the  new  data
and  follow  the  instructions  on  the
screen.

B - Consult the GPS information:
B1 - the satellite positions diagram with

the direction of movement of the
vehicle. Plus the position of the
satellite signal receivers,

B2 - the name of the current location,
B3 - the longitude and latitude of the

current location,

B4 - the position measurement status

(2D=3 satellites or fewer, 3D=4
satellites or more),

B5 - the number of receiving satellites,
B6 - to have north at the top of the

map,

B7 - to have the direction of the vehicle

at the top of the map,

B8 - to pivot the map from overhead or

change the angle of the map.

System version, satellite

D10

D11

D12

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

204

Calendar, trip

These double arrows permit
access to the driving information

screen, previous or next.

- Consult the driving information:

D1  - the average speed,
D2  - the average consumption,
D3  - the current consumption,
D4  -  for  speed  and  consumption

graphs in 5 minute intervals,

D5 - choose

automatic

reini-

tialisation (key at off for more
than

hours)

manual

reinitialisation (press reset),

D6 - the distance which can still be

travelled (in relation to the fuel
remaining and the recent aver-
age consumption),

D7 - the distance travelled since the

fuel tank was last ﬁ lled (press

refuel to reinitialise),

D8 - the

driving

time

(dura-

tion between the key being
turned to on then to off).

- press

start

measure

intermediate times with:

D9  - the duration,
D10  - the distance,
D11  - the speed,
D12  - the consumption.

- Make a note on the calendar of

special days, birthdays, ...

Use the arrows to ﬁ nd a date

and press directly on the day
required to enter the event.

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

205

- Consult the air conditioning

conditions:

F1  - the fan speed indicator,
F2  - the air selection indicator,
F3  -  the windscreen demisting

indicator light,

F4 - the air conditioning indicator,
F5 - the rear screen demisting

indicator light,

F6 - the AUTO mode indicator.

- Consult the environment

information:

E1 - the altitude,
E2 - the atmospheric pressure,
E3

- the exterior temperature. The ice

symbol ﬂ ashes if there is a risk

of ice.

G - Make and receive telephone

calls:

G1  - enter the telephone number,
G2  - delete a character,
G3  - make the call.

Refer to the hands-free telephone
section to connect your Bluetooth

mobile telephone.

Environment, air conditioning,
telephone

Citroen C-Crosser Dag (2008 year). Instruction - part 13
