Citroen C-Crosser Dag (2008 year). Instruction - part 11

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

159

RADIO

Selecting radio mode

Press  the  “PWR”  button
or  the  “AM/FM”  button  to
switch on the radio.

Disconnecting the battery terminals
clears the stored radio stations.

Selecting the waveband

Press  the  “AM/FM”  button
several times in succession
to  select  the  waveband;  it
changes  in  the  following
order:  FM1  /  FM2  /  FM3  /
MW / LW / FM1...

Automatic station search

Press the “SEEK 

” or

“SEEK  ” button to search
the lower frequencies or
the

higher

frequencies

respectively.

Manual station search

Turn

the

“TUNE”

dial

respectively to the left to
search the lower frequencies
or to the right to search the
higher frequencies.

Manual station storing

Press one of the six buttons “1” to “6”

until an audible signal is heard.
The  sound  cuts  out  then  becomes
audible  again  when  the  station  has
been stored.
The  number  of  the  button  and  the
associated  radio  frequency  appear  on
the display.

Automatic station storing

Press the “AM/FM” button
for more than two seconds.

Recalling stored stations

Press one of the six buttons “1” to

“6”. The station corresponding to the
waveband selected appears on the
display.

The search begins automatically and

stops at the ﬁ rst station found.

The six stations offering the best

reception are stored and classiﬁ ed from

the weakest to the strongest on the six

corresponding buttons.

You can store up to six stations on each

waveband.
Storing a new station replaces the
previous station.

Stations can only be stored automatically
on wavebands FM3, MW and LW.
Storing  new  stations  replaces  the
previous stations.
This  storing  can  be  activated  auto-
matically  irrespective  of  the  waveband
selected.

To recall the pre-set memory setting,
press the button and release it within
two seconds.

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

160

“RDS”

The “Radio Data System” (RDS)
function on the FM waveband permits:
-

access to the displaying of information,
such as the name of the station, ...

tuning to the same station while
travelling through different regions,

- temporary tuning to trafﬁ c information

announcements.

Most FM stations use the RDS. These
stations  transmit  non-audible  data  in
addition to their programmes.
The  data  transmitted  in  this  way
allows you access to various functions,
mainly  displaying  of  the  name  of  the
station,  automatic  station  following  or

temporary tuning to trafﬁ c information

announcements.
The RDS allows you to continue listening
to the same station by means of the
alternative frequency following. However, in
certain conditions, this RDS frequency
following cannot be provided throughout
the country. Radio stations do not cover

the whole country, which explains the

loss of reception of the station during
a journey.

Alternative frequencies “AF”

Your radio automatically checks and
selects the best frequency for the radio
station to which it is tuned (if the station
broadcasts on several transmitters or
frequencies).
The frequency of a radio station covers

approximately 30 miles (50 km). The

change from one frequency to another

explains the temporary loss of reception

during a journey.
If  the  station  to  which  you  are  listen-
ing  does  not  have  several  frequencies
in the region in which you are currently
located, you can deactivate the alterna-
tive frequency following.

Traffic information “TP”

The “Trafﬁ c Program” (TP) function

permits

automatic

and

temporary

switching to an FM station broadcasting

trafﬁ c information.
The radio station or the source that you
are listening to at this point is paused.
Once the trafﬁ c information has ended,

the system switches back to the radio
station or the source that you were
listening to initially.

Regional following mode “REG”

Some  stations  are  organised  in  a  net-
work.
In different regions, they broadcast dif-
ferent  or  shared  programmes  depend-
ing on the time of day.
You can follow:
   -

a regional station only,

the entire network, with the possibil-
ity that you will be listening to a dif-
ferent programme.

The  “AF”,  “REG”  and  “TP”
functions  can  be  deacti-
vated  or  activated  via  the
“TUNE” button functions set-
ting mode.

Press the “TP” button.
“TP” appears on the display.
If the station is compatible,
“RDS” also appears.

If the radio detects trafﬁ c information,

“TRAF INF” appears on the display,
followed by the frequency of the
broadcasting station, then its name.
The volume is different from that of the
previous source.
Following the broadcasting of the trafﬁ c

information, the volume returns to that
of the source prior to the interruption.

When “TP” appears on the display,
the radio stops solely at RDS stations

broadcasting trafﬁ c information.

On long distance journeys, when
the stored station becomes weak,

the radio searches ﬁ rst for another

frequency for the same station (AF).
Then,  if  this  fails,  it  searches  for  a
frequency broadcasting the regional
programme  (REG).  If  this  also  fails,
the  radio  returns  to  the  stored  sta-
tion.

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

161

Themed type of programme
“PTY”

Some stations offer the option of
listening to a themed type of programme
as a priority, selected from the list
available below:
NEWS, AFFAIRS, INFO, SPORT, EDUCATE,
DRAMA,

CULTURE,

SCIENCE,

VARIED, POP M, ROCK M, EASY M,
LIGHT M,

CLASSICS,

OTHER M,

WEATHER, FINANCE, CHILDREN,
SOCIAL,

RELIGION,

PHONE IN,

TRAVEL, LEISURE, JAZZ, COUNTRY,
NATION M, OLDIES, FOLK M, DOCUMENT.

Emergency broadcasts
“ALERT”

An emergency broadcast automatically
and temporarily interrupts the FM station
or the source that you are listening to.
The message “ALERT” appears on the
display and the volume is different from
that of the previous source.
Following the emergency broadcast, the
message disappears and the volume
returns to that of the source prior to the
interruption.

Search for a “PTY” broadcast

Press the “PTY” button.
Turn the “TUNE” dial to
select the type of programme
required.

Two seconds later, the radio searches
for a broadcast which corresponds to
your selection; the type of PTY selected

ﬂ ashes on the display.
Once the station has been found, its
name appears on the display.
You can press the “SEEK  ” or “SEEK


” buttons to ﬁ nd another station.

If no station is found corresponding
to your selected type of programme,
“NONE” appears on the display for

ﬁ ve seconds and the radio returns to

the previous station.

Each new programme stored replaces
the previous one.

Storing a “PTY” programme
You can store up to six PTY programmes.

To recall the pre-set memory setting,
press the button and release it within
two seconds.

Changing the display language of
the “PTY” programme

Press the “TUNE” button for
more than two seconds to
access the functions setting
mode.

Then, press this button several times in
succession; the functions setting mode
changes in the following order:
AF / CT / REG / TP-S / PTY (languages) /
SCV / PHONE / OFF.
Turn the “TUNE” dial to the left or to the
right to select the language (ENGLISH,
FRANCAIS,

DEUTSCH,

SVENSK,

ESPAGNOL, ITALIANO).

The  sound  cuts  out  then  becomes  au-
dible  again  when  the  programme  has
been stored.
The  number  of  the  button  and  the
associated PTY programme appear on
the display.

Turn the “TUNE” dial to set
the PTY programme to be
stored.
Press one of the six buttons

“1” to “6” for more than two
seconds.

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

162

CD PLAYER

Selecting CD mode

the

player

already

contains a disc, press the
“CD” button.
“CD”, the track number and

the playing time appear on the display.

Functions setting mode

This permits activation or deactivation
of the functions below.

Press the “TUNE” button for
more than two seconds to
access the functions setting
mode.
Then, press this button
several times in succession;

the functions setting mode changes in
the following order:
AF / CT / REG / TO-S / PTY (languages) /
SCV / PHONE / OFF.
Turn the “TUNE” dial respectively to the
left to deactivate the function (“OFF”) or
to the right to activate it (“ON”).
The “PHONE” is not operational at
present.

The functions setting mode is

deactivated after approximately

10 seconds without any action.

After inserting a disc, printed face up-
wards, the player starts automatically.

Ejecting a disc

Press this button to remove
the disc from the player.
The system automatically
switches to radio mode.

Fast search

  Press  and  hold  button  “    ”
or “  ” to carry out a rewind
or  fast  forwards  search
respectively.
Play begins when the button
is released.

Selecting a track

Press button “  ” or “  ” to

select the previous or next

track respectively.

Repeating a track

Press the “RPT” button to
repeat the playing of the
current track. “RPT” appears
on the display.
To exit this mode, press this

button again.

Random playing of a disc

Press  the  “RDM”  button  to
start  random  playing  of  the
tracks  on  the  disc.  “RDM”
appears on the display.
To exit this mode, press this

button again.

Insert circular compact discs only.
8 cm compact discs must be inserted
in the centre of the player slot.

Once ejected, if the compact disc is

not removed within ﬁ fteen seconds, it

is reloaded into the player.

Audio CDs

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

162

CD PLAYER

Selecting CD mode

the

player

already

contains a disc, press the
“CD” button.
“CD”, the track number and

the playing time appear on the display.

Functions setting mode

This permits activation or deactivation
of the functions below.

Press the “TUNE” button for
more than two seconds to
access the functions setting
mode.
Then, press this button
several times in succession;

The functions setting mode is

deactivated after approximately

10 seconds without any action.

After inserting a disc, printed face up-
wards, the player starts automatically.

Ejecting a disc

Press this button to remove
the disc from the player.
The system automatically
switches to radio mode.

Fast search

  Press  and  hold  button  “    ”
or “  ” to carry out a rewind
or  fast  forwards  search
respectively.
Play begins when the button
is released.

Selecting a track

Press button “  ” or “  ” to

select the previous or next

track respectively.

Repeating a track

Press the “RPT” button to
repeat the playing of the
current track. “RPT” appears
on the display.
To exit this mode, press this

button again.

Random playing of a disc

Press  the  “RDM”  button  to
start  random  playing  of  the
tracks  on  the  disc.  “RDM”
appears on the display.
To exit this mode, press this

button again.

Insert circular compact discs only.
8 cm compact discs must be inserted
in the centre of the player slot.

Once ejected, if the compact disc is

not removed within ﬁ fteen seconds, it

is reloaded into the player.

Audio CDs

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

163

MP3 / TAG ID3 CD

Playing the beginning of each track

Press the “SCAN” button to

start the playing of the ﬁ rst

ten seconds of each track
on the disc. “SCAN” appears

on the display and the corresponding

track number ﬂ ashes.

To exit this mode, press this button

again.

The CD player and the CD changer
are compatible with the playing of MP3

ﬁ les.
These must be recorded in ISO9660
Level 1 / Level 2, Joliet or Romeo format
on CD ROMs, CD-Rs or CD-RWs. The

CDs can contain a maximum of 255

ﬁ les and 100 folders on 16 levels.
The Tag ID3 version 1 can be displayed

while playing MP3 ﬁ les.

In the case of compact discs
containing both CD-DA and MP3

ﬁ les, play automatically begins with

the CD-DA ﬁ les.
To switch play between the two types

of ﬁ le, press the “CD” button for more

than  two  seconds  until  an  audible
signal is heard.
While  using  these  compact  discs,
the  “Repeat”,  Random  play”  and
“Playing  of  the  beginning  of  the
tracks”  functions  are  only  applied  to

ﬁ les of the same format.

Selecting an MP3 folder

Turn the “FOLDER” dial re-
spectively to the right to se-
lect a folder in ascending or-
der or to the left to select a
folder in descending order.

Press the “DISP” button
several times in succession;

the CD-Text information

appears in the following
order:

DISC NAME / TRACK NAME / NORMAL
DISPLAY MODE.

CD-TEXT DISPLAY

If the information exceeds

12 characters, press the
“PAGE” button to see the
rest.

In the absence of CD-Text information

to be displayed, “NOTITLE” appears on
the display.

The CD player and the CD changer are
compatible with the displaying of CD-

Text information.

On CD-R/RWs, the quality of the
playing sound depends on the
encoding

software,

the

burning

device and the burning speed used.

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

164

When play begins, “READING” appears
on the display then disappears to make
way for the folder number, the track
number, the playing time and “MP3”.

Playing the beginning of each track

Press the “SCAN” button

to start playing the ﬁ rst ten

seconds of each track in all of
the folders. “SCAN” appears

on the display and the corresponding

track number ﬂ ashes.

To exit this mode, press this button

again.

MP3 / Tag ID3 display

Press the “DISP” button
several times in succession;
the MP3 information appears
in the following order:

FOLDER NAME / TRACK NAME /
NORMAL DISPLAY MODE.

If the information exceeds

12 characters, press the
“PAGE” button to see the
rest.

In the absence of MP3 or Tag ID3
information to be displayed, “NOTITLE”
appears on the display.

Press  the  “DISP”  button
for  more  than  two  seconds
to  activate  the  Tag  ID3
information.  “TAG”  appears
on the display.

Press  the  “DISP”  button  several  times
in  succession;  the  Tag  ID3  information
appears in the following order:
ALBUM  NAME  /  TRACK  NAME  /
ARTIST  NAME  /  NORMAL  DISPLAY
MODE.

To deactivate this information, press
the “DISP” button again for more than
two seconds.

Repeating the tracks in a folder

Press  the  “RPT”  button  for
more  than  two  seconds  to
repeat  the  playing  of  the
tracks  contained  in  the

current folder. “D-RPT” appears on the
display.
To exit this mode, press this button

again.

Random playing of a folder

Press  the  “RDM”  button  to
start  random  playing  of  the
tracks  in  the  current  folder.
“RDM”

appears

the

display.
To exit this mode, press this

button again.

Random playing of a disc

Press  the  “RDM”  button  for
more  than  two  seconds  to
start  random  playing  of  the
tracks  in  all  of  the  folders.
“D-RDM”  appears  on  the
display.
To exit this mode, press this

button again.

On  CD-R/RWs,  the  quality  of  the
playing  sound  depends  on  the
encoding  software,  the  burning
device and the burning speed used.
Depending on the ﬂ ow chart of the

MP3 folders and ﬁ les on the disc,

play may not begin immediately.

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

165

Selecting changer mode

the

changer

already

contains a disc, press the
“CD” button.
“CD”, the disc and track

numbers and the playing time appear
on the display.

After inserting at least one disc, printed
face upwards, the changer starts
automatically.

Ejecting a disc

Press this button brieﬂ y to

remove the current disc
from the changer.

Once ejected, if the compact disc is

not removed within ﬁ fteen seconds it

is re-loaded into the changer.

Loading a disc

appears on the display.
When the changer is ready,
the indicator light on the
“LOAD” button comes on

and “LOAD DISC N° (1-6)” appears on
the display.
If several slots are empty, select one
using one of the “DISC” buttons.

The CD changer can hold up to 6 CDs.
Press the “LOAD” button brieﬂ y. “WAIT”

Insert circular compact discs only.
8 cm compact discs cannot be
played by the changer.

Loading all of the discs

Ejecting all of the discs

Press  this  button  for  more
than  two  seconds.  The
current disc is ejected.
Once  this  disc  has  been

removed, the next disc is ejected

automatically in its turn.
Repeat these steps until unloading is
complete.

Selecting a disc

Press  one  of  the  “DISC”
buttons  several  times  in
succession  until  you  reach
the

disc

required.

The

symbol of the disc selected
appears on the display.

See also “CD-Text display” and “MP3 /

Tag ID3 CD”.

Press the “LOAD” button for
more than two seconds.
The changer selects an
empty slot number from the

lowest  to  the  highest  and  switches  to
waiting for loading mode.
“LOAD  DISC  N°  (1-6)”  appears  on
the  display;  insert  the  disc  in  the
corresponding slot.
The  changer  automatically  selects  the

next empty slot number and returns to

waiting for loading mode.
Repeat these steps until loading is
complete. Play begins with the last disc
inserted.

CD CHANGER

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

166

Playing of the beginning of each track

Press the “SCAN” button to

start the playing of the ﬁ rst

ten seconds of each track
on the disc. “SCAN” appears

on the display and the corresponding

track number ﬂ ashes.

To exit this mode, press this button

again.

On  CD-R/RWs,  the  quality  of  the
playing  sound  depends  on  the
encoding software, the burning device
and the burning speed used.

Random playing on all of the discs

Press  the  “RDM”  button  for
more  than  two  seconds  to
start  random  playing  of  the
tracks on all of the discs. “D-

RDM” appears on the display.
To exit this mode, press this button

again.

Fast search

Press and hold button “ 

”

or “  ” to carry out a rewind
or fast forwards search
respectively.
Play begins when the button
is released.

Selecting a track

Press button “ 

” or “  ” to

select the previous track or

next track respectively.

Repeating a track

Press the “RPT” button to
repeat the playing of the
current track. “RPT” appears
on the display.
To exit this mode, press this

button again.

Random playing of a disc

Press  the  “RDM”  button  to
start  random  playing  of  the
tracks  on  the  disc.  “RDM”
appears on the display.

To exit this mode, press this button

again.

Repeating a disc

Press  the  “RPT”  button  for
more  than  two  seconds  to
repeat  the  playing  of  the
tracks  of  the  current  disc.

“D-RPT” appears on the display.
To exit this mode, press this button

again.

Audio CD

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

167

ERROR MESSAGES

If an error message appears on the display, refer to the table below to ﬁ nd out what it means and the solution to be applied

in order to rectify it.

TEXT

DESCRIPTION

SOLUTION

NO DISC

No disc present.
Disc not compatible.

Insert a disc.

ERROR 01

Disc inserted incorrectly.
Disc with condensation.

Insert the disc with the printed face upwards.
Clean the dampness off the disc.

ERROR 02

Disc dirty, scratched or distorted.
Excessive vehicle vibration.

Clean or replace the disc.
Try again when the vibration has stopped.

ERROR 03

Error on insertion or ejection.
Playing head misaligned.

Eject the disc and insert it again. If it is not ejected,
have the audio equipment checked.

ERROR HOT

Triggering of the internal protection against high
temperatures.

Wait approximately 30 minutes to allow the audio

equipment to cool.

ERROR

Communication error between the audio equip-

ment and the external system.

External system supply error.

Consult a CITROËN dealer.

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

168

AUXILIARY SOCKETS

A. Left-hand

audio

input

(RCA

white)

B. Right-hand audio input (RCA

red)

C. Video input (RCA yellow)

Connect an external audio system

to  sockets   A   or   B   to  use  the  vehicle’s
speakers.
Connect  the  rear  seat  display  (option)
to  the  additional  socket   C   (refer  to  the
user manual supplied with the rear seat
display).

Audio-CD system

Audio-telematics system

Selecting the AUX source

Press  the  “CD”  button  for
more  than  two  seconds.
“AUX  REAR”  appears  on
the display.

The connection to the external audio

system is activated.
To  deactivate  this  connection  and
change  source,  press  the  “AM/FM”  or
“CD” button.

After pressing “AUX”, the

connection to the external

audio and/or video system
is activated.

Selecting the AUX source

To  deactivate  the  connection  and
change  source,  press  another  button
on the display (FM, CD, ...).

After

pressing

“Rear

Display”, the connection to
the rear audio and/or video
system is activated.

For  safety  reasons,  the  video
is  not  displayed  while  driving,
however  the  audio  can  be
played.

To display the picture and watch
a DVD, park the vehicle in a safe
place.

Selecting the rear display source

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

169

YOUR AUDIO-TELEMATICS SYSTEM

  This consists of the following components:
   -   a tilting 7˝ LCD colour touch screen,
  -

a GPS aerial located in your fascia,

a radio aerial located at the rear, on the roof of the vehicle,

4 to 6 speakers (according to version),

controls around the screen and at the steering wheel plus touch buttons on the screen according to the display,

a voice synthesiser (male or female) giving the directions during navigation,

GPS aerial

  It allows you to:
   -   be guided to the destination of your choice (European map on 30 Gb hard disc) taking trafﬁ c conditions into account,
  -

listen to the radio,

- listen to audio CDs (CDDA, CD-Text, CD-R/RW) or CDs with MP3 and WMA ﬁ les,
-

copy audio CDs to a music server, up to 2,500 songs (coded in MP3/WMA) on 10 Gb available on the hard disc,

play DVDs (playing of video if the vehicle is stationary),

make hands-free telephone calls.

For maintenance of the display, we recommend the use of a non-abrasive soft cloth (spectacles cloth) without any additional
products.

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

170

AUDIO: selection of the Audio-
video (FM, CD, music server, ..)
or Navigation (map) display.

VOL: adjustment of the audio-
video volume.

OPEN:

tilts

the

display and permits

access to the CD/

DVD.

second

press closes the
display.

SCALE: changing of the scale of
the map.

ENTR: conﬁ rms the choice of the

item selected on the screen.
For certain operations, conﬁ rmation

is given by contact with the touch
screen.

Scrolling of the map displayed or
selection of an item.

For safety reasons, it is
imperative that the driver
carries out operations which

require prolonged attention with
the vehicle stationary.

DESCRIPTION OF THE CONTROLS

Changing

the

audio-

video source (FM, CD, music
server, ...).

Activation/deactivation

the

mute.
Next or previous selection for:
-

a radio station,

an audio track (CD),

a chapter (DVD).

Move a ﬁ nger over the screen to operate

the system.
Use the buttons offered on the screen.

POWER: audio system on/off
(only).

Setting of the audio volume.

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

171

DESCRIPTION OF THE CONTROLS - MENUS

MODE: Audio-video menu for:
-

the radio,

the audio, MP3 or WMA CD,

the music server,

the DVD.

MENU: Navigation-guidance menu
for selecting:
-

a destination,

a point of interest (POI),

an advanced search by POI,

one of the 20 previous destinations,

an address stored in the address
book,

the return home,

certain navigation settings,

a route demonstration.

NAVI: displaying of the current location
on the map .

SET: Settings menu for:
-

switching off the display,

selecting the sound setting,

selecting the picture quality,

selecting the language, the time
zone or the units,

selecting the size of the DVD
picture,

selecting the guidance voice,
the display colour ranges or the
displaying of the audio-video
icon,

setting certain equipment available
in your vehicle.

INFO: Information menu for the
consultation or setting of certain
parameters of your vehicle.

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

172

NAVIGATION-GUIDANCE

  What is the navigation system and
the GPS?
The  satellite  navigation  system  guides
the driver to the destination that he has
set in accordance with a chosen route.
Initially,  it  searches  for  the  destination
required  by  the  user,  then  it  calculates

the route and ﬁ nally it provides the visual

and audible guidance instructions.

  What precautions should be
observed in order to use the system
under good conditions?
Do  not  place  anything  on  or  near  the
GPS aerial.
Do  not  use  any  digital  communication
equipment  (personal  computers,  etc.)
near the GPS aerial.
Do not afﬁ x any reﬂ ective ﬁ lms or ﬁ lms

containing carbon to the window.

The GPS (Global Positioning
System) consists of several
satellites distributed around
the earth. They continuously
transmit

digital

signals

which travel at the speed of light, on 2
different frequencies.
At any given time, the system receives
its  position  in  relation  to  the  satellites
detected  and  the  time  of  transmission
of the signal.
This  enables  the  telematic  unit  to
deduce its position and therefore that of
the vehicle.
A  repositioning  process  using  the
map  database  stored  on  the  hard  disc
permits  repositioning  of  the  vehicle’s
position  on  the  road  network  in  order
to improve the accuracy of the locating
function.

What is a point of interest (POI)?

Up to 40 different icons may
be  displayed  (refer  to  the
section  “Points  of  interest
icon”).
They  are  classiﬁ ed  in

5 groups and identiﬁ ed by one colour

for each group:
- Shops, ﬁ nance and businesses

(Green),

Vehicles and travel (Dark blue),

Restaurants (Orange),

Public

places

and

emergency

services (Brown),

Entertainment

and

attractions

(Blue).

GPS

The system’s measurements may be
inaccurate if the vehicle is:
-

in a tunnel or underground car
park,

underneath a two-level motorway,

in an area with several very high
buildings,

surrounded

closely

planted

trees.

Depending on the vehicle’s situation and
the reception of the GPS information, the
displayed information may disappear
from the display temporarily.

A  point  of  interest  (POI)  is
represented  by  an  icon  on
the  map,  it  represents  an
airport,  a  station,  a  town
hall, ...

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

173

A. Manoeuvre icon: indicates whether

the driver should turn left or right at

the next junction indicated by the

guidance and the distance to this
junction.

B. Guidance route: indicates the route

to the destination.

C. Vehicle marker: indicates the position

of the vehicle while driving.

TMC icon: displays trafﬁ c information

such as trafﬁ c jams, road works, etc.

When the user passes over the
icon, detailed TMC information can
be consulted.

E. Orientation mark: indicates the

orientation of the map displayed.

F. Map scale: indicates the scale of

the map displayed.

G. Name of the street: indicates the

name of the current street.

H. Direction

frame:

displays

the

number of the next road or the

name of the next street which the

driver should turn into.

I. Destination/intermediate destina-

tion icon: indicates the direction
of the destination or intermediate
destination.

Two-map display.

Single map display.

Information displayed on the
map during navigation

J. Destination/intermediate destina-

tion  information:  indicates  the  dis-
tance  and  the  time  remaining  un-
til  the  destination  or  intermediate
destination is reached.

K. Pressing provides access to the

Route Menu in order to:

K1 - change the route in favour of an-

other making a detour through a

speciﬁ ed region,

K2 - change

the

position

the

destination, add an intermediate
destination and change the route
calculation conditions,

K3 - display

route

various

methods,

K4 - delete a route created,
K5 - search for points of interest (POI)

around the current location.

Content .. 9 10 11 12 ..
