Citroen C-Crosser Dag (2008 year). Instruction - part 14

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

206

HANDS-FREE TELEPHONE

What is the Bluetooth

hands-free

telephone with voice recognition?

The system uses wireless
communication

technology

referred to as Bluetooth

which  allows  you  to  make
hands-free  telephone  calls
in  your  vehicle  via  your
Bluetooth

compatible mobile

telephone.

It has a voice recognition function which
allows you to make telephone calls using
a  microphone,  located  in  the  courtesy
light,  and  also  by  means  of  easy  use
of  the  steering  wheel  controls  or  using
voice  commands.  Five  languages  are
available: English (by default), Spanish,
French, German and Italian.

SPEAK
Pressing activates the voice recognition (“Listening” is displayed).
During voice recognition, a brief press pauses this recognition.
An extended press deactivates the recognition.
A brief press will activate the recognition even if a telephone call is progress.

Decreasing of the audio volume.

PICK UP
Press to answer an incoming call.
If a second incoming call is received,

press this button to place the ﬁ rst

call on hold and speak to the second
caller.
In  this  case,  a  brief  press  switches
between callers.
To establish a three-way conversation,
press  the  SPEAK  button  to  switch
to  voice  recognition  mode  and  say
“Incorporate the call”.

HANG UP
Press to reject an incoming call.
During a call, pressing ends this call.

General notes

Increasing of the audio volume.

Audio system on/off.

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

207

Changing the language,
programming the voice

Changing the language of the voice
commands
By default, the recognition system is in
English.

  Programming the user’s voice
You can use the user’s voice programming
function to create a voice model for one
person per language.
The  characteristics  of  your  voice  and
your pronunciation are recorded in this
model for improved voice recognition.
It is essential that the vehicle is parked
in  a  safe  place,  with  the  handbrake
applied.
Switch  off  your  telephone  during  the
process to avoid any interruption.

1 - Press the SPEAK button.

5 - The system says the ﬁ rst of 45

typical phrases.

If you do not start the programming

process within approximately 3 min-

utes  after  pressing  the  SPEAK  but-
ton, the process is cancelled.
If you press the SPEAK button with-
in 5 seconds following the reading of
a  voice  command,  the  recording  of
this command is repeated.

1 - Press the SPEAK button.

2 - Say “Setup”.

3 - Say “Language”.

5 - Say the language of your

choice in English, example:

say “French” for French.

7 - Say “Yes” to start the change

of language process or say
“No” to return to steps 4 to 7.

8 - The system repeats the language

chosen and completes the change
of language process.

2 - Say “Word training”.

4 - When you are ready to start,

press and hold the SPEAK
button.

6 - Repeat each phrase in the

table on the next page.

The system records your voice and

moves on to the recording of the next

command.
Continue the process until all of the
phrases have been recorded.

4 - The system says “Select a language:

English, Spanish, French, German
or Italian”.

6 - The system then says “French

selected. Is this correct?”

3 - An explanation message is given.

7 - After reading all the voice commands,

the system says “The word enrolment
is complete” and ends the process.

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

208

Programming controls

# 790 (for # = “Hash”)

* 671 (for * = “Star”)

212 - 4 903

235 - 3 494

315- 5 657

456 - 7 930

793 - 5 462

794 - 1 826

826 - 3 145

10 962 - 7 305

11 (531) 742 - 9 860

12 (632) 807 - 4 591

13 (800) 222 - 5015

14 (888) 555 - 1 212

15 0 123 456 789

16 55 66 77 88 99

17 44 33 22 11 00

18 Call 293 - 5804

Call * 350

20 Call 1 (234) 567 - 8 901

21 Dial 639 - 1542

22 Dial # 780

23 Dial (987) 654 - 3210

24 1058# 3794# Send

25 27643# 4321# Send

26 Cancel

27 Continue

28 Emergency number

29 Clear all

30 Help

31 Home, Work, Mobile, Pager

32 List of names

33 No

34 Phone book: Delete

35 Phone book: New entry

36 Previous

37 Phone book: Clear all

38 Redial

39 Repeat the training

40 Conﬁ gure the conﬁ rmation

requests

Conﬁ gure the language

Conﬁ gure the matching options

43 Match a telephone

44 Transfer the call

45 Yes

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

209

Matching your Bluetooth

telephone

The system can register up to 7 Blue-
tooth

compatible mobile telephones.

The

telephone

which

has

the

highest level of priority is matched
automatically.
It is absolutely essential that the vehicle
is parked in a safe place with the
handbrake applied.

1 - Press the SPEAK button.

7 - Say a 4-digit number which

will be recorded as the match-
ing code.

12 - After the audible signal,

allocate a name to the
telephone by saying the
name of your choice.

13 - The system says “Allocate an order

of priority between 1 and 7. One is
the highest level of priority”.

If the system does not detect the
Bluetooth

compatible

mobile

telephone,  the  matching  process
stops  accompanied  by  an  audible
signal.
If you select a level of priority which
has  already  been  allocated  to
another telephone, the system asks
you  if  you  wish  to  replace  this  level
of priority.

You can choose any 4-digit number.
Remember  this  matching  code  as
you  must  enter  it  in  the  telephone
in  one  of  the  following  steps  of  the
matching procedure.

9 - The system says “Start the matching

procedure on the telephone. Consult
the instructions in the telephone
manual”.

2 - Say “Conﬁ gure”.

3 - Say “Matching options”.

5 - Say “Match a telephone”.

8 - The system conﬁ rms the

validity of the number spoken,
answer “Yes”. Say “No” to
return to step 7.

10 - Consult

your

mobile

telephone’s  user  manual
and  enter  the  matching
code  recorded  in  step  7
in the telephone.

11 - When it detects a Bluetooth

compatible mobile telephone, the
system says “Please say the name
of the telephone after the bleep”.

14 - Say a number between 1

and 7 to establish the level
of priority of the mobile
telephone.

15 - The system says and conﬁ rms the

<name of the telephone> and the
<number> of its priority.

16 - Answer “Yes” or say “No” to

return to step 13.

17 - The

systems

says

“Matching complete” then
emits

audible

signal

and deactivates the voice
recognition.

4 - The system says “Do you wish

to match a telephone, delete a
telephone or obtain the list of
matched telephones?”.

6 - The systems says “Please say the 4

digits of a matching code”.

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

210

Making a telephone call using a number, phone book

Bluetooth

compatible

mobile

telephone must be matched with the
system.

Using a telephone number

If your vehicle is ﬁ tted with the audio-

telematics  display,  you  can  use  the
press  buttons  to  dial  a  number  then
make a call.

  Recording a name in the system’s
phone book
The  system  has  its  own  phone  book,
independent  of  that  of  the  mobile
telephone.
It can contain up to 32 names for each
language.
Each  name  in  the  phone  book  is
associated  with  4  locations:  HOME,
WORK, MOBILE and PAGER.

1 - Press the SPEAK button.

7 - The system says “HOME, WORK,

MOBILE OR PAGER”.

2 - Day “Dial”.

4 - Say the telephone number.

5 - The system asks you to con-

ﬁ rm this number, answer

“Yes”. Say “No” to return to
the previous step.

2 - Say “Phone book”.

4 - Say “New entry”.

6 - Say the name of your choice.

8 - Say

the

location

which

corresponds to the number
that you wish to record.

10 - Answer “Yes” or say “No” to

return to step 7.

12 - If you do not wish to change

the

telephone

number,

repeat the original number
to retain it, otherwise say the
new number.

14 - Answer “Yes” or say “No” to

return to step 11.

1 - Press the SPEAK button.

3 - The system says “Number please”.

3 - The system says “Select one of the

following items: New Entry, Change,
List  of  names,  Delete  or  Clear  all,
or  say  Cancel  to  return  to  the  main
menu”.

5 - The system says “Name please”.

To enter a new number:

9 - The system asks you to conﬁ rm the

location.

11 - If a telephone number has already

been recorded for this location, the
system says “The current number
is <number>, number please”.

13 - The system asks you to conﬁ rm the

number.

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

211

Making a telephone call using a name in the phone book, receiving a call

Using a name in the system’s phone
book
The name must be recorded in the
system’s phone book.

8 - Answer “Yes” or say “No” to

return to step 4.

Redialling the last number

  Receiving a call
The telephone ring is transmitted on the
speaker by the front passenger’s seat.
If  an  audio  source  (CD,  radio,  ...)  is  in
operation when the call is received, it is
placed on mute and only the incoming
call is heard.
When the ignition switch is in the ACC
or  ON  position,  the  audio  system  is
activated  automatically  if  an  incoming
call is received, even if it was originally
off.

1 - Press the PICK UP button.

At the end of the call, the audio system
returns to its previous status.

1 - Press the SPEAK button.

2 - Say “Call”.

4 - Say the name of the person

that you wish to call.

6 - Say the location corresponding

to the number that you wish to
call.

1 - Press the SPEAK button.

2 - Say “Redial”.

3 - The system says “Name please”.

5 - If several telephone numbers have

been recorded for this person, the
system says “Do you wish to call
<name> {home}, {work}, {mobile} or
{pager}?”

7 - The system requests conﬁ rmation of

the name.

9 - The system says “Call to <name> at

<location>” and makes the call.

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

212

When the system is waiting for a voice command, say “Help” to obtain a list of commands which can be used in the cur-
rent situation.

Voice commands (1/2)

Press this button to start the voice recognition.

Conﬁ gure

Phone book

Dial

Call

Redial

Emergency number

Matching options

Match a telephone

Delete a telephone

List of matched telephones

Select a telephone

Divert the call

Add a location

Conﬁ gure the conﬁ rmation requests

Language

New entry

Delete

Change

Call this number

Change another entry

Try again

Clear all

List of names

Home, at home

Work, at work

Mobile, on mobile

Pager, on pager

Help

Continue

All

Cancel

Mute

Deactivate mute

Yes

A U D I O E Q U I P M E N T a n d T E L E M A T I C S

213

Voice commands (2/2)

Zero

One

Two

Three

Four

Five

Six

Seven

Eight

Nine

Star (*)

Hash (#)

Word training

Repeat training

Activate

Deactivate

Incorporate the call

<digits> Send

English

Phone book New entry

Phone book Change

Phone book Delete

Phone book Clear All

Phone book List of names

Conﬁ gure the conﬁ rmation requests

Conﬁ gure Select a telephone

Conﬁ gure the matching options

Delete a name

Conﬁ gure the language

Conﬁ gure the PIN

Press this button to start the voice recognition.

When the system is waiting for a voice command, say “Help” to obtain a list of commands which can be used in the
current situation.

Content .. 12 13 14
