DESCRIPTION
N·m
Ft. Lbs.
In. Lbs.
Common Rail Diesel Injection
Bolt-Bango Bolt of Leak
Oil Line to Rail
20
-
177
Bolt-Bracket to High
Pressure Pump
9
-
80
Bolt-High Pressure Pump
to Cylinder Head
14
-
124
Bolt-Pre-delivery Pump to
Top Cover of Cylinder
Head
9
-
80
Bolt-Pressure Control
Valve to Rail (2 stage,
torque)
3, 5
-
26, 44
Bolt-Rail to Cylinder Head
14
-
124
Bolt-Shutoff Valve to
Cylinder Head
8
-
70
Nut-Pressure Line to
Rail/Injector (New,Reused)
22/25
16/18.5
-
Nut-Pressure Line to High
Pressure Pump/Rail
22
16
-
Screw-Tensioning Claw to
Injector (2 stage, 1 torque,
2 torque angle)
7, 90°
-
62, 90°
Rail- Pressure Sensor to
Rail
22
16
-
Pressure Pipe Connection
to Injector
42
31
-
Threaded Rail to Rail
22
16
-
Fuel Cooling System
Bolt-Fuel Cooler to
Charge Air Distribution
Pipe
14
-
124
Heater Booster, Heater Unit
Bolt- Temperature
Controlled Cut Out to
Heater Booster control
Module
12
-
106
Nut-Threaded Stud to
Electronic Heater Booster
18
-
159
9 - 12
ENGINE
PT
ENGINE - 2.2L DIESEL (Continued)
