Chery Eastar Service Manual Body Dimension and Accessories
90
The clearance between the headlamp and engine increases gradually from 5 mm to 6±1.5 mm
corresponding to the points from a to c at Q-Q.
The clearance between the front bumper and the headlamp increases gradually from 4 mm to 5±2 mm
corresponding to the points from b to m at S-S Rotation.
Front bumper
Headlamp
In
cr
ea
se
g
ra
du
al
ly
fr
o
m
4
m
m
to
5
±2
mm
c
o
rr
es
pon
d
in
g
t
o
t
h
e
po
in
ts
f
ro
m
b
t
o
m
S-S Rotation
Headlamp
Engine hood
Increase gradually from 5 mm to 6±1.5 mm
corresponding to the points from A to C
