Chery B11. Manual - part 62
Chery·Maintenance Manual for Oriental Son
Manual Transmission
Tightening torque specifications
Item Torque
N.m(kgf)
Set bolt of bottom cover
6.9 (0.7)
Bolt of interlocking plate
30 (3.1)
Clutch cover – set bolt of gearbox cover
44 (4.5)
Set bolt of release bearing bracket of the clutch
9.8 (1.0)
Set bolt of controller cover
18 (1.9)
Set bolt of transmission cable bracket
18 (1.9)
Set bolt of speedometer gear
3.9 (0.4)
Set bolt of limiter bracket
22 (2.3)
Gear lever set bolt
18 (1.9)
Gear lever set nut
11 (1.2)
Set bolt of differential drive gear
132 (13.5)
Backup light switch
32 (3.3)
Set bolt of front bearing bracket
18 (1.9)
Miter valve spring
32 (3.3)
Set bolt of reverse idler gear
48 (4.9)
Set bolt of tossing limiter bracket
69 (7.0)
6
