Maintenance Manual for Chery·Oriental Son
Engine Section
Coolant temperature sensor
Manifold bracket
1.1
1.4
Exhaust Manifold
Screw bolt of emission manifold cover
Screw bolt of inflow duct joint
Exhaust manifold nut ( M8)
Exhaust manifold nut ( M10)
Screw bolt of coolant bypass duct joint
Screw bolt of coolant duct component
Thermostat housing
bolt
Water pump screw bolt
1.4
2.4
3.0
5.0
2.4
1.3
2.4
1.4
Rocker and Camshaft
Rocker cover screw bolt
Screw bolt of rocker and camshaft assembly
Trust bearing cover bolt
0.4
3.2
1.9
Cylinder Cover and Valve
Cylinder cover bolt
2.0＋90°＋90°
Front cover & Engine oil pump
Drain plug
Oil pan
Screw bolt and nut of oil strainer
Oil pressure switch
Pressure relief plug
Screw bolt of oil cleaner bracket
Front cover bolt
Plug
Flange bolt
Engine oil pump cover bolt
Engine oil pump cover screw
4.5
0.7
1.9
1.0
4.5
1.9
2.4
2.4
3.7
1.6
1.0
Piston and Connecting Rod Assembly
Connecting rod nut
2.0＋90°～100°
Crank, Cylinder Body, Flywheel
Flywheel screw bolt
Installation screw bolt of rear cover
Installation screw bolt of bell jar
Installation screw bolt of oil seal cover
Screw bolt of main bearing cover
13.5
1.1
0.9
1.1
2.5＋90°～100°
Throttle Body
Bracket screw bolt
0.5
Throttle Position Sensor
0.35
Screw bolt of idle speed air valve
0.35
