Chery B11. Manual - part 23

Driving

93

Head restraints

Head restraints can limit the moving of

head and reduce the risk of injury to the

cervical vertebra, in the event of an

accident. But correct position is for

protection only.

Front headrests

There are height-adjustable headrests on

the front-seat backrests. Occupants should

adjust the headrest to an appropriate

height ,in orderto get maximum

protection ,based on his/her stature.

Ajusting method of headrest:

Holding both sides of headrests to move it

up and down, by your hand. Adjust the

head restraint, so that its center is

approximately at the height of your ears.

Disassembling method of
headrest:

When remove the headrests, please press

the outside spring tab of headrests to pull

out from oriented unit. When install the

headrests, please distinguish front /rear

seat headrest (the plug of front seat

headrest is curve, the rear one is straight),

and then push the headrest-plug into the

oriented unit until you can engage the

spring tab with plug correctly.

Rear headrests

The rear headrests are not able to be

adjusted.

Adjustment of headrests

Do not remove or move

the headrests too low ,in order to

avoid neck injury in the impact

event. Please move headrests to an

appropriate position.

Spring

Driving

94

Rear Seats

There is storage-stand on the center of

rear-seat backrest. It is able to be turned

out from backrests. There is a baffle

behind the storage-stand. It is able to be

connected with trunk if the baffle is put

down.

Conveyance of   luggage

Luggage and other stowage

should be placed in the trunk

as front as possible. It is very

dangerous to drive vehicle if the trunk

door is open. Excessive exhaust gas is

likely to enter inside of vehicle through

opened trunk door.

Objects must be put into the

vehicle, and fix them to

prevent moving.

Safety Belts

Fasten your safety belt and use child

safety seat at all times of every trip. Never

allow more than one person to wear a

single safety belt. You should make sure

Baffle

Rear
storage-stand

Rear cup holder

Driving

95

the safety belt is fastened, the safety belt is

not loose, twisted and blocked.

Fasten your safety belt

before every trip.

Avoid wearing bulky

clothing.In order to get the

maximum protection,the safety belt

should snugly fit your body.

Never allow infants or small children to sit

in a passenger's lap. This passenger is not

able to protect children from being

injured.

Seat belt warning light

The light should be on, when ignition

switch is turned on. This light remains on

to remind passengers of wearing seat belts.

Fasten your seat belt

Drag the safety belt out smoothly. If you

overexert or the vehicle is on the slope, the

safety belt is likely to be locked. Seat belts

should be put at the center of outside

shoulder. And the waist belts should be

close to hips (not stomachs).

Insert the tab in the belt buckle

and make sure you hear a

and make sure you hear a “click”.

Press the red button in the buckle to

release safety belts. Hold the belt and

guide it back to its reel.

You should make sure that every belt uses

correct buckle.

if you can’t drag belt out,

please exert to drag belt and

release it. Then belt can be dragged out

smoothly.

Driving

96

Two-point safety belts of rear
seat

This safety belt is not able to adjust length

automatically. Insert the tab in the belt

buckle and make sure you hear a “click”.

Then adjust length by your hand, and keep

belts close to your hip.

Do not lean front seats excessively, the

safety belts only provide maximum

protection for seats close to upright

position.

Adjusting safety belts height
of front seats

Never route the belt across your neck.

Press the locking button on height

adjustment device to adjust height, and

moving safety belts up/down can across

the center of outside shoulder. And then

release locking button and shake

adjustment device to make sure if it is

locked.
