Door Lock and Anti-theft

89

hood, or truck hood is delayed to be closed,

the alarm system will go to working status

after 20 second after closing.

Remote controller battery
replacement

If the remote controller working distance

get shorter and shorter, you should replace

its battery (battery model 3V CR 2032) by

the following steps:

1.Open the controller unit by using

screwdriver tool from the side buckle.

2. Take battery out carefully. Put new

battery in with its icon (+) upward.

3.Put controller unit back in reverse step

for disassembly.

Used lithium battery can not be

thrown   away as normal home rubbish. It

should be thrown ,according to the

respective environmental protection

guideline.

Driving

90

Seat and Protection

Seat

Correct sitting posture

The seats, head restraints, safety belts and

airbags are all helpful for protecting

passengers. Fully utilizing them can

benefit the passengers, thus please comply

with the following points:.

Ÿ

Seated upright, try to lean your back

bottom to backrest if possible,but

should not exceed 30 degrees.

Ÿ

Adjusting the head restraints to get

the same height as your head.

Ÿ

Front seat should not be too much

close to instrument panel. While

driving, the driver should bend a

little his/her arm to grasp the steering

wheel,the driver should also bend a

little his/her foot, so that he/she can

step entirely on the pedal.

Ÿ

The shoulder safety belt should cross

middle of shoulder and then closely

and tightly cross chest. Please do not

cross it through the neck. The lap

safety belt should close to hip rather

then stomach.

Please do not adjust seat

while  driving.

Max. 30

°

Driving

91

Front passenger seat
adjustment

Frontward and backward moving
the seat

Draw up the adjusted pole beside seat if

you want to move seat frontward and

backward ,until it is in the comfortable

position. Then  you can release the pole

and shake the seat to see if it is locked into

the track.

Adjusting Backrest gradient

Please lean your body to the backrest, and

then push the adjusted pole; you can adjust

the backrest gradient by adjusting your

body gradient.

Driver power seat adjustment

There is control panel on one side of the

driver seat. It can control to adjust the seat

in 8 different ways. (Come and back every

time is considered as two ways, there are

together 4 movements), there are two

operational switches on the panel, which

function is shown as the illustrations.

Switch 1: It is used to adjust backrest

gradient

Ÿ

Push the switch frontward by your

finger, the backrest can lean

frontward, push the switch reversed;

it can lean in opposite direction.

Switch 2: It is used to adjust backrest

front / back position, front/back part

of cushion going up/down.

Switch 2

Switch 1

Seat adjust pole

Backrest adjust
pole

Driving

92

Ÿ

Push the switch frontward, the seat

moves to the front. Push the switch

backward , the seat moves to the

back

Ÿ

Push up the front side of the switch,

the front side of the cushion moves

up. On the contrary, push down the

front side of the switch, the front side

of the cushion moves down.

Ÿ

Push up the back side of switch, the

back side of cushion moves up. On

the contrary, push down the back

side of switch, the back cushion

moves down.

The vehicle might

be out

of control if you

adjust all these switches while driving.

Thus, the adjustment can only be done

while it is stopped.

While driving, it

does

not allow

passengers to touch these switches ,in

order to avoid movement of driver

seat, which can cause vehicle out of

control or accident.

Adjusting waist-rests

The waist-rest adjusted pole is on one side

of backrest. Turning this pole can adjust

waist-rest.

The waist-rest is up if the pole points

frontward. If the pole points upward, the

waistrest comes back.

Waist-rest adiusted
