Chery B11. Manual - part 20

Operation and Adjustment of Interior Devices

81

Tractive Force Control Switch

This switch is used for enable or disable

tractive force control function

The tractive force control system is helpful

for vehicle stability and steering

performance, especially driving in the

slippery (e.g. ice road) and sandy road.

When tractive force system is working, the

tractive force control light (TCS light) will

be turned on. Meanwhile, you can hear the

working sound of the electronic pump

from engine compartment. If you keep

stepping the accelerator pedal, the engine

speed will not be accelerated. This is

normal working situation, please do not

worry.

If the vehicle is caught in ice or snow, you

can try to close the tractive force control

system. The vehicle skidding can drag

vehicle out from the mud or ice and then

help the vehicle drive out by “ shaking ”

the vehicle.

If there is a malfunction in the system, the

TCS light will be on and the tractive force

control switch will not work. In that case,

this vehicle has to be repaired.

Storage Box

Storage box is on central armrest. Pressing

button on driver side can open the lower

box. Pressing front passenger side button

can only open the upper box.

Storage box

Operation and Adjustment of Interior Devices

82

Rear Ashtray

Rear Cup Holder

Rear cup holder is located on central

armrest of rear seat

Power Outlet

Power outlet locates in left-front of front

passenger side seat, or under right side of

central control panel.

It provide power for some equipments, e.g

vehicle-refrigerator

Rear
ashtray

Rear cup
holder

Operation and Adjustment of Interior Devices

83

The

voltage is 12V,

The

rated power is

120W. Please do not use any

equipment which its rated power is

over 120W. Unless it will cause fire

accident. Please also do not use

non-12 V equipment which can

damage the equipment and might

also cause fire accident.

The power derives

from

the vehicle storage

battery, Therefore, it can cause the

serious storage battery shortage if

the storage battery keep providing

power to electronic equipment,

through this outlet after the engine

flame out.

Door Lock and Anti-theft

84

Door Lock and
anti-theft

Key

The main key for this vehicle is able to

work for all locks in this vehicle. In case

you lost it, you can get a new one from

Cherry Special Service Center. You should

put the second key in a secure place for

any emergency.

Central locking system

This vehicle allows you to control all

doors at same time with key, remote

controller and the switches in driver and

front passenger side door.

It allows you locking / opening all doors in

the driver side door, using the key.

All doors are locked when pressing the

lock button in driver or front passenger

side door. All doors are unlocked when

pressing the unlock button in drive or front

passenger side door.

Under door opened, all safety buttons in

all doors move up. On door locked, all

safety buttons in all doors move down.

The door can be locked by pressing safety

button.

To avoid any attack from

outside, the vehicle should

be driven under all doors locked.

Door lock

Front door can be locked or unlocked from

outside by key. In vehicle,you can open

the door using the inside door handle.

You can press locked-pole to close rear

door ,when you leave your vehicle.
