Operation and Adjustment of Interior Devices

77

Electric
outside rear-view mirror

Electric outside rear –view mirror can be

adjusted by adjusted switch which is on

service door. The adjusted switch can

work only after ignition switch is on.

Turning adjusted switch clockwise can

adjust left side rear-view mirror; turning

adjusted switch anti-clockwise can adjust

right side rear- view mirror.

While adjusted switch turn left or right,

leaning the switch to front, back, left and

right can help adjust mirror’s position.

Having the mirror adjusted, put the switch

back to original position.

Folding Electric Vehicel
Rear-view Mirror

Turning adjusted switch of rear-view

mirror 180 degree and push it to left, the

mirror can be folded, while push it to right,

the mirror can be opened.

Manual folding Vehicle
Rear-View Mirror *

Some case like in a narrow space, we can

fold the rear-view mirror manually. If we

want it back, we can just open it outside

onto correct position.

Rear seat control switch

Storage stand

Rear power window
switch

Left side
rear-view

mirror

adjust

Right side
rear-view mirror
adjust

Operation and Adjustment of Interior Devices

78

In convex, the image is

smaller and further than

real objective. So please do not

over- estimate the actual objective

distance.

Electric power windows

Left front door

Right front door

Rear Door

The electric power windows are only

active when the ignition switch is on.

Each window can be controlled by

switches in respective doors.

You can press the rocker switch to

open/close windows. The window glass

stops if you release the switch while it is

up or down.

In driver’s side door, besides the control

switch in driver side, there are other

control switches for the rest three

windows.

Rear -Window Safety Switch

There is another switch for rear-window

security in driver’s side door. Pressing this

security switch can disable the

Right front passenger’s side control switch

Rear power window
switch

Rear seat control
switch

Storage stand

Left rear
window switch

Left front
window switch

Right rear
window switch

Right front
window switch

Operation and Adjustment of Interior Devices

79

rear-window switch in the back.

Meanwhile, only the driver can control the

rear-window switch in his/her side. This

function is helpful when children are

sitting in the back.

Attention:

Please be careful when close the vehicle

window! Please watch over the

surrounding in order to avoid any

incidents.

Switch in Central Control
panel

Heat Switch on Driver Seat

Pressing this switch, the heater in driver

seat will be active. And another press will

stop the heater.

Air Purification Switch

Press this switch down, the purifying

equipment will be working. The purifying

equipment will stop working if you press

this switch once again.

Front Ashtray

Open the cover for using the ashtray.

To clean it up, you can take out the

embeded bowel.

Front ashtray Cigarette lighter

Operation and Adjustment of Interior Devices

80

Cigarette lighter

  The lighter should not be in

inserted status to avoid any

incident. The lighter should be taken

away if there is child staying alone

in vehicle.

Press the lighter in, as soon as it pops out.

The cigarette lighter remains operational

even the ignition key has been turned off.

Front Cup Holder

The front cup holder locates in central

control panel. It can be used by opening its

blind flange.

While

driving, please do

not put any hot drink in front or rear

holder to avoid injury by spoiled hot

water.

Cruising Control Switch

If the speed is over 60km/h, pressing this

switch can set cruising speed. Meanwhile,

you can remove right leg from accelerator

pedal; speed will be still at this cruising

speed.

Press the switch once again,cruising

control will be cancelled out.

Please do not use this cruising

function in the traffic time;

Also,you should not use it in

the rough, winding, slippery road.
