There is a 3.2-second interim between two adjacent troubleshooting codes; the number
flashes for 0.4 second and stops for another 0.4 second by turns; there is an interim of 1.2
seconds between adjacent numbers;
Number 0 flashes ten times and other numbers will flash for the their own number of
times accordingly;
Take troubleshooting codes 0110 and 0443 as an example:
故障灯 0 1 1 0 0 4 4 3
Fault indicator light
Request for grounding
→ Turn on the ignition switch→Indicator light flashes
once
→Stop for 3.2s→Ten times→Stop for 1.2s→Once→
Stop for 1.2s
→Once→ Stop for 1.2s→Ten times→Stop for 3.2s→Ten times→Stop for
1.2s
→Four times→Stop for 1.2s→Four times→
Stop for 1.2s
→Three times→ Stop for 3.2s→if the request for troubleshooting is not
stopped, Troubleshooting Code 0110 will be reported again……
Note: after the fault is eliminated, it is proposed to use a diagnostic instrument to get
rid of the troubleshooting code to avoid interference with the judgment of faults
during the next maintenance.
2. Diagnostic instrument ADC2000
