DISASSEMBLY AND ASSEMBLY OF THE GEARSHIFT SHAFT
——It need not to break down the transmission
assembly.
Disassembly:
——Put transmission assembly on the shelf or
workbench.
— — Leave it on the neutral position. (The
gearshift shaft move smoothly on arrowhead
direction)
——Screw off the gearshift positioning holder
assembly.
——Unscrew the bolt cover by special tool and
take off gearshift shaft.
——See the picture, press the spring holder to the
arrowhead direction to compress the internal
spring. Keep at this position until disassemble
the snap ring No.2.
Assembly:
——The assemble process is opposite to above
process.
Main point:
——Make sure the fork system on neutral gear.
——Moment to fasten bolt cover is 50Nm.
——Moment of fastening the gearshift shaft
positioning holder is 40Nm.
Special Tool
J-32
