Acura ILX (2021 year). Manual in english - page 6

93

uu

Gauges and Multi-Information Display

u

Multi-Information Display

Continued

In

strum

ent Pa

nel

Multi-Information Display

The multi-information display shows the odometer, trip meter, outside temperature
indicator, and other gauges. It also displays important messages such as warnings
and other helpful information.

94

uu

Gauges and Multi-Information Display

u

Multi-Information Display

In

strum

ent Pa

nel

■

Main displays

Press the

 (information) button to change the display.

■

Switching the Display

ᵑᵐ

ᵑᵑ

ᵑᵐ

ᵑᵑ

 (information)

Button

Engine Oil Life

Vehicle Settings

Elapsed Time

Blank Screen

Average Speed

Range

Instant Fuel Economy/

Average Fuel Economy

Compass

*

Tire Pressure for

Each Tire

Turn-by-Turn

Directions

*

* Not available on all models

95

uu

Gauges and Multi-Information Display

u

Multi-Information Display

Continued

In

strum

ent Pa

nel

■

Lower displays

Press the

SEL/RESET

 button to change the display.

Odometer

Trip A

Trip B

Outside temperature

SEL/RESET

 Button

SEL/RESET



Button

SEL/RESET



Button

SEL/RESET

 Button

uu

Gauges and Multi-Information Display

u

Multi-Information Display

96

In

strum

ent Pa

nel

Shows the total number of miles or kilometers that your vehicle has accumulated.

Shows the total number of miles or kilometers driven since the last reset. Meters A
and B can be used to measure two separate trips.

■

Resetting a trip meter

To reset a trip meter, display it, then press and hold the

SEL/RESET

 button. The trip

meter is reset to

0.0

.

Shows the outside temperature in Fahrenheit (U.S.) or Celsius (Canada).

■

Adjusting the outside temperature display

Adjust the temperature reading up to ± 5°F (U.S.) or ± 3°C (Canada) if the
temperature reading seems incorrect.

Shows the estimated average fuel economy of each trip meter in mpg (U.S.) or
l/100 km (Canada). The display is updated at set intervals. When a trip meter is reset,
the average fuel economy is also reset.

■

Odometer

■

Trip Meter

■

Outside Temperature

■

Average Fuel Economy

1

Trip Meter

Switch between trip meter A and trip meter B by
pressing the

SEL/RESET

 button.

1

Outside Temperature

The temperature sensor is in the front bumper.
Road heat and exhaust from another vehicle can
affect the temperature reading when your vehicle
speed is less than 19 mph (30 km/h).

It may take several minutes for the display to be
updated after the temperature reading has stabilized.

Use the multi-information display’s customized
features to correct the temperature.

2

Customized Features

 P. 99, 315

1

Average Fuel Economy

You can change when to reset the average fuel
economy.

2

Customized Features

 P. 99, 315

Continued

97

uu

Gauges and Multi-Information Display

u

Multi-Information Display

In

strum

ent Pa

nel

Shows the instant fuel economy as a bar graph in mpg (U.S.) or l/100 km (Canada).

Shows the estimated distance you can travel on the remaining power and fuel. This
estimated distance is based on the vehicle’s current fuel economy.

Shows the time elapsed since the Trip A or Trip B was reset.

Shows the average speed in mph (U.S.) or km/h (Canada) since the Trip A or Trip B
was reset.

■

Compass

*

Shows the compass screen.

■

Turn-by-Turn Directions

When driving guidance is provided by the navigation system

*

 or Android Auto, turn-

by-turn directions to your destination appear.

2

Refer to the Navigation System Manual

2

Android Auto

 P. 275

■

Instant Fuel Economy

■

Range

■

Elapsed Time

■

Average Speed

■

Navigation

*

1

Elapsed Time

You can change when to reset the elapsed time.

2

Customized Features

 P. 99, 315

1

Average Speed

You can change when to reset the average speed.

2

Customized Features

 P. 99, 315

1

Navigation

*

You can select whether the turn-by-turn display
comes on or not during the route guidance.

2

Customized Features

 P. 99, 315

* Not available on all models

98

uu

Gauges and Multi-Information Display

u

Multi-Information Display

In

strum

ent Pa

nel

Shows each tire’s pressure.

2

Tire Pressure Monitor

 P. 447

Shows the remaining oil life and Maintenance Minder

TM

.

2

Maintenance Minder

TM

 P. 515

■

Tire Pressure Monitor

■

Engine Oil Life

Continued

99

uu

Gauges and Multi-Information Display

u

Multi-Information Display

In

strum

ent Pa

nel

Use the multi-information display to customize certain features.

■

How to customize

Press the

 button to select

Vehicle Settings

 and press the

SEL/RESET



button.

■

Customized Features

1

Customized Features

To customize other features, press the



button.

2

List of customizable options

 P. 102

2

Example of customization settings

 P. 106

Customization is possible when you see the driver’s
ID (

Driver 1

 or

Driver 2

) on the screen.

The driver’s ID indicates which remote transmitter
you have used to unlock the driver’s door. The
customized settings are recalled every time you
unlock the driver’s door with that remote.

Put the transmission into

(

P

 before you attempt to

change any customized setting.

Customizing is also available from the information
screen.
You cannot have

Vehicle Settings

 displayed on the

multi-information display while the information
screen shows the same menu.

2

Customized Features

 P. 315

Models with driving position memory system

Models with On Demand Multi-Use Display

TM

Multi-information Display: Goes to

Vehicle Settings

.

SEL/RESET

 Button:

Enters the selected item

 Button:

Changes the customize

menus and items

100

uu

Gauges and Multi-Information Display

u

Multi-Information Display

In

strum

ent Pa

nel

■

Customization flow

Press the

 button to select

Vehicle Settings

 and press the

SEL/RESET

 button.

Vehicle Settings

“Trip A” Reset Timing

Language Selection

Adjust Outside Temp. Display

Memory Position Link

Door Unlock Mode

Keyless Access Light Flash

Driver Assist System Setup

Meter Setup

Driving Position Setup

*

Keyless Access Setup

“Trip B” Reset Timing

Turn by Turn Display

*

Forward Collision Warning Distance

ACC Forward Vehicle Detect Beep

Lane Keeping Assist Suspend Beep

Blind Spot Info

*

Keyless Access Beep

ACC Display Speed Unit

Road Departure Mitigation Setting

SEL/RESET

SEL/RESET

SEL/RESET

SEL/RESET

SEL/RESET

SEL/RESET

Remote Start System On/Off

*

* Not available on all models

101

uu

Gauges and Multi-Information Display

u

Multi-Information Display

Continued

In

strum

ent Pa

nel

Exit

Door Setup

Maintenance Info.

Default All

Lighting Setup

Key And Remote Unlock Mode

Auto Door Lock

Auto Door Unlock

Keyless Lock Answer Back

Security Relock Timer

Interior Light Dimming Time

Headlight Auto Off Timer

Auto Light Sensitivity

*

Maintenance Reset

SEL/RESET

SEL/RESET

SEL/RESET

SEL/RESET

Walk Away Auto Lock

* Not available on all models

102

uu

Gauges and Multi-Information Display

u

Multi-Information Display

In

strum

ent Pa

nel

■

List of customizable options

*1:Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Driver Assist
System
Setup

Forward Collision
Warning Distance

Changes the distance at which CMBS

TM

 alerts.

Long

/

Normal

*1

/

Short

ACC Forward Vehicle
Detect Beep

Causes the system to beep when the system detects a
vehicle, or when the vehicle goes out of the ACC range.

On

/

Off

*1

ACC Display Speed Unit

Changes the speed unit for ACC on the multi-
information display.

mph

*1

/

km/h

 (U.S.)

mph

/

km/h

*1

 (Canada)

Road Departure
Mitigation Setting

Changes the setting for the road departure mitigation
system.

Normal

*1

/

Wide

/

Warning

Only

Lane Keeping Assist
Suspend Beep

Causes the system to beep when the LKAS is suspended.

On

/

Off

*1

Blind Spot Info

*

Changes the setting for the blind spot information.

Audible And Visual
Alert

*1

/

Visual Alert

/

Off

* Not available on all models

103

uu

Gauges and Multi-Information Display

u

Multi-Information Display

Continued

In

strum

ent Pa

nel

*1:Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Meter Setup

Language Selection

Changes the displayed language.

English

*1

/

Français

/

Español

Adjust Outside Temp.
Display

Adjusts the temperature reading by a few degrees.

-5°F

 ~

±0°F

*1

 ~

+5°F

(U.S.)

-3°C

 ~

±0°C

*1

 ~

+3°C

(Canada)

“Trip A” Reset Timing

Changes the setting of how to reset trip meter A,
average fuel economy A, average speed A, and elapsed
time A.

When Refueled

/

IGN Off

/

Manually Reset

*1

“Trip B” Reset Timing

Changes the setting of how to reset trip meter B,
average fuel economy B, average speed B, and elapsed
time B.

When Refueled

/

IGN Off

/

Manually Reset

*1

Turn by Turn Display

*

Selects whether the turn-by-turn display comes on
during the route guidance.

On

*1

/

Off

* Not available on all models

104

uu

Gauges and Multi-Information Display

u

Multi-Information Display

In

strum

ent Pa

nel

*1:Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Driving
Position
Setup

*

Memory Position Link

Turns the driving position memory system on and
off.

On

*1

/

Off

Keyless
Access
Setup

Door Unlock Mode

Changes which doors unlock when you grab the
driver’s door handle.

Driver Door Only

*1

/

All Doors

Keyless Access Light
Flash

Causes some exterior lights to flash when you
unlock/lock the doors.

On

*1

/

Off

Keyless Access Beep

Sets the beeper sound or not when you grab either
front door handle.

On

*1

/

Off

Remote Start System On/
Off

*

Turns the remote engine start feature on and off.

On

*1

/

Off

Lighting
Setup

Interior Light Dimming
Time

Changes the length of time the interior lights stay on
after you close the doors.

60sec

/

30sec

*1

/

15sec

Headlight Auto Off
Timer

Changes the length of time the exterior lights stay
on after you close the driver’s door.

60sec

/

30sec

/

15sec

*1

/

0sec

Auto Light Sensitivity

*

Changes the timing for the headlights to come on.

Max

/

High

/

Mid

*1

/

Low

/

Min

* Not available on all models

105

uu

Gauges and Multi-Information Display

u

Multi-Information Display

Continued

In

strum

ent Pa

nel

*1: Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Door Setup

Auto Door Lock

Changes the setting for when the doors
automatically lock.

With Vehicle Speed

*1

/

Shift

From P

/

Off

Auto Door Unlock

Changes the setting for when the doors
automatically unlock.

All Doors When Driver’s
Door Opens

*1

/

All Doors

When Shifted To Park

/

All

Doors When Ignition
Switched Off

/

Off

Key And Remote Unlock
Mode

Sets up either the driver’s door or all doors to unlock
on the first operation of the remote or built-in key.

Driver Door

*1

/

All Doors

Walk Away Auto Lock

Changes the settings for the automatic locking the
doors when you walk away from the vehicle while
carrying the keyless access remote.

On

/

Off

*1

Keyless Lock Answer
Back

LOCK/UNLOCK- The exterior lights flash.
LOCK (2nd push)- The beeper sounds.

On

*1

/

Off

Security Relock Timer

Changes the time it takes for the doors to relock and
the security system to set after you unlock the
vehicle without opening any door.

90sec

/

60sec

/

30sec

*1

Maintenance
Info.

Maintenance Reset

Resets the Maintenance Minder

TM

 display when you

have performed the maintenance service.

Cancel

/

Reset

Default All

—

Cancels customized changes you have made or
restores them to their default setting.

Cancel

/

Set

106

uu

Gauges and Multi-Information Display

u

Multi-Information Display

In

strum

ent Pa

nel

■

Example of customization settings

The steps for changing the

“Trip A” Reset Timing

 setting to

When Refueled

 are

shown below. The default setting for

“Trip A” Reset Timing

 is

Manually Reset

.

1.

Press and release the

 button to

select

Vehicle Settings

, then press the

SEL/RESET

 button.

2.

Press and release the

 button until

Meter Setup

 appears on the display.

3.

Press the

SEL/RESET

 button.

u

Language Selection

 appears first on

the display.

107

uu

Gauges and Multi-Information Display

u

Multi-Information Display

In

strum

ent Pa

nel

4.

Press and release the

 button until

“Trip A” Reset Timing

 appears on the

display, then press the

SEL/RESET

 button.

u

The display switches to the
customization setup screen, where you
can select

When Refueled

,

IGN Off

,

Manually Reset

, or

Exit

.

5.

Press and release the

 button select

When Refueled

, then press the

SEL/

RESET

 button.

u

The

When Refueled Setup

 screen

appears, then the display returns to the
customization menu screen.

6.

Press and release the

 button until

Exit

 appears on the display, press the

SEL/

RESET

 button.

7.

Repeat Step 6 until you return to the
normal screen.

109

Controls

This chapter explains how to operate the various controls necessary for driving.

Clock

.................................................. 110

Locking and Unlocking the Doors

Key .................................................. 112
Low Keyless Access Remote Signal

Strength......................................... 114

Locking/Unlocking the Doors from the

Outside .......................................... 115

Locking/Unlocking the Doors from the

Inside ............................................. 124

Childproof Door Locks ..................... 126
Auto Door Locking/Unlocking .......... 127

Opening and Closing the Trunk

....... 128

Security System

................................ 132

Immobilizer System .......................... 132

Security System Alarm...................... 132

Windows

........................................... 135

Moonroof

............................................. 138

Operating the Switches Around the

Steering Wheel

ENGINE START/STOP Button............. 139
Turn Signals ..................................... 142
Light Switches.................................. 143
Fog Lights

*

...................................... 146

Daytime Running Lights ................... 146
Auto High-Beam .............................. 147
Wipers and Washers ........................ 150
Brightness Control ........................... 152
Rear Defogger/Heated Door Mirror Button ..153

Adjusting the Steering Wheel .......... 153
Driving Position Memory System

*

.... 154

Mirrors

............................................... 156

Interior Rearview Mirror ................... 156
Power Door Mirrors ......................... 157

Adjusting the Seats

.......................... 158

Front Seats ...................................... 158

Interior Convenience Items

.............. 168

Interior Lights .................................. 168
Storage Items .................................. 170
Other Interior Convenience Items..... 173

Climate Control System

................... 175

Using Automatic Climate Control .... 175
Automatic Climate Control Sensors......178

* Not available on all models
