241

uu

Audio System Basic Operation

u

Playing AM/FM Radio

Features

■

HD subchannel

Displays the subchannel list when an HD Radio

TM

 station is selected.

1.

Press the

MENU

 button.

2.

Rotate

 to select

HD Subchannel

, then press

.

3.

Rotate

 to select a channel from a list, then press

.

Select the

 or

 when the subchannel number is displayed.

You can also select the channel by the following procedure.

1.

Select

More

.

2.

Select

HD Subchannel

.

3.

Select the channel number.

Interface Dial

On Demand Multi-Use Display

TM

242

uu

Audio System Basic Operation

u

Playing SiriusXM

®

 Radio

Features

Playing SiriusXM

®

 Radio

Audio/Information Screen

On Demand Multi-Use Display

TM

Category Up/Down Icons

Select

 or

 to display and select

an SiriusXM

®

 Radio category.

MENU Button

Press to display the menu items.

 (Power) Button

Press to turn the audio system
on and off.

Source

Select to change an audio source.

Tune

Select to switch to tune mode.

Preset Icons

Select to store a station.
To listen to a stored channel, select

1

-

12

.

More

Select to display the menu items.

BACK Button

Press to go back to the previous display.

VOL (Volume) Knob
(Pushed out)

Turn to adjust the volume.

Interface Dial/ENTER Button

Press and turn to select preset radio
stations.
Move up, down, right and left to
select secondary menu.

Scan

Select to sample each of the
strongest stations on the selected
band for 10 seconds.

Skip/Seek Icons

Select

 or

 to the previous

or next channel.
In channel mode, select and hold
to change the channel rapidly.

Continued

243

uu

Audio System Basic Operation

u

Playing SiriusXM

®

 Radio

Features

1.

Select the SiriusXM

®

 mode.

2

Audio Remote Controls

 P. 215

2

On Demand Multi-Use Display

TM

 P. 217

2.

Press the

MENU

 button.

3.

Rotate

 to select

Channel List

, then press

.

4.

Rotate

 to select a channel from a list, then press

.

2.

Select a channel using the

,

,

,

 icons on the tune mode screen or

the preset numbers (

1

-

12

) on the preset mode screen.

To change the tune mode:

1.

Press the

MENU

 button.

2.

Rotate

 to select

XM Tune Mode

, then press

.

3.

Rotate

 to select

Channel Mode

 or

Category Mode

, then press

.

1.

Select

More

.

2.

Select

XM Tune Mode

.

3.

Select

Channel Mode

 or

Category Mode

.

■

To Play the SiriusXM

®

 Radio

1

Playing SiriusXM

®

 Radio

You can control the SiriusXM

®

 radio using voice

commands.

2

Voice Control Operation

 P. 232

In the channel mode, all available channels are
selectable. In the category mode, you can select a
channel within a category (Jazz, Rock, Classical, etc.).

There may be instances when SiriusXM

®

 Radio does

not broadcast all the data fields (artist name, title).
This does not indicate a problem with your audio
system.

SiriusXM

®

 Radio stations load in ascending order,

which can take about a minute. Once they have
loaded you will be able to scroll up or down to make
your selections.

Interface Dial

On Demand Multi-Use Display

TM

Interface Dial

On Demand Multi-Use Display

TM

uu

Audio System Basic Operation

u

Playing SiriusXM

®

 Radio

244

Features

To store a station:

1.

Tune to the selected station.

2.

Move

 or

 to select the

Preset

 tab.

3.

Rotate

 to select the preset number you want to store the station.

4.

Press and hold

 for a few seconds.

You can also store that station by the following procedure.

1.

Tune to the selected station.

2.

Press the

MENU

 button.

3.

Rotate

to

select

Save Preset

, then press

.

4.

Rotate

 to select the preset number you want to store that station, then press

.

1.

Tune to the selected station.

2.

Change the display to the preset screen.

3.

Select and hold the preset number you want to store that station.

You can also store that station by the following procedure.

1.

Tune to the selected station.

2.

Select

More

.

3.

Select

Save Preset

.

4.

Select the preset number you want to store that station.

■

Preset Memory

1

Playing SiriusXM

®

 Radio

You can store 12 SiriusXM

®

 stations into the preset

memory.

Interface Dial

On Demand Multi-Use Display

TM

245

uu

Audio System Basic Operation

u

Playing a CD

Continued

Features

Playing a CD

Your audio system supports audio CDs, CD-Rs and CD-RWs in either MP3, WMA, or
AAC

*1

 format. With the CD loaded, select the CD mode.

*1:Only AAC format files recorded with iTunes are playable on this unit.

Audio/Information Screen

MENU Button

Press to display the menu items.

CD Slot

Insert a CD about halfway into the CD
slot.

 (CD Eject) Button

Press to eject a CD.

Folder Up/Down Icons

Select

 to skip to the next folder, and

 to skip to the beginning of the

previous folder in MP3, WMA, or AAC.

Source

Select to change an audio source.

Skip/Seek Icons

Select

 or

 to change tracks

(files in MP3, WMA, or AAC).
Select and hold to move rapidly within
a track/file.

More

Select to display the menu items.

BACK Button

Press to go back to the previous display.

Interface Dial/ENTER Button

Press and turn to select an item,
then press to set your selection.
Move up, down, right and left to
select secondary menu.

On Demand Multi-Use Display

TM

 (Power) Button

Press to turn the audio system
on and off.

VOL (Volume) Knob (Pushed out)

Turn to adjust the volume.

Scan

Select to use a scan feature.

Random

Select to use a random feature.

Repeat

Select to use a repeat feature.

uu

Audio System Basic Operation

u

Playing a CD

246

Features

1.

Press the

MENU

 button.

2.

Rotate

 to select

Music Search

, then

press .

3.

Rotate

, move

 or

, then press

 to

select a file from the

Music Search

 list.

You can also select a file by the following
procedure.

1.

Rotate

 or press

 to display the song

list.

2.

Rotate

, move

 or

, then press

 to

select a file from the list.

■

How to Select a File from the Music Search List
(MP3/WMA/AAC)

1

Playing a CD

NOTICE

Do not use CDs with adhesive labels. The label can
cause the CD to jam in the unit.

WMA and AAC files protected by digital rights
management (DRM) cannot be played.
The audio system displays

Unplayable File

, then

skips to the next file.

Text data appears on the display under the following
circumstances:

•

When you select a new folder, file, or track.

•

When you change the audio mode to CD.

•

When you insert a CD.

If you eject the CD but do not remove it from the slot,
the system reloads the CD automatically after several
seconds.

You can control a CD audio using voice commands.

2

Voice Control Operation

 P. 232

Folder Selection

File Selection

247

uu

Audio System Basic Operation

u

Playing a CD

Features

You can select scan, repeat, and random modes when playing a track or file.

1.

Press the

MENU

 button.

2.

Rotate

 to select

Scan

 or

Random/

Repeat

, then press

.

3.

Rotate

 to select a mode, then press

.

1.

Select

Scan

,

Random

 or

Repeat

.

2

Playing a CD

 P. 245

2.

Select a mode.

■

To turn off a play mode

1.

Press the

MENU

 button.

2.

Rotate

 to select the mode you want to turn off, then press

.

1.

Select

Scan

,

Random

 or

Repeat

.

2

Playing a CD

 P. 245

2.

Select the mode you want to turn off.

■

How to Select a Play Mode

1

How to Select a Play Mode

Play Mode Menu Items

Scan
Scan Folders

 (MP3/WMA/AAC): Provides a 10-

second sampling of the first file in each of the main
folders.

Scan Tracks

: Provides a 10-second sampling of all

tracks on the CD (all files in the current folder in MP3,
WMA, or AAC).

Random/Repeat
Repeat Folder

 (MP3/WMA/AAC): Repeats all files in

the current folder.

Repeat Track

: Repeats the current track/file.

Random in Folder

 (MP3/WMA/AAC): Plays all files

in the current folder in random order.

Random All Tracks

: Plays all tracks/files in random

order.

Random/Repeat

is selected.

Interface Dial

On Demand Multi-Use Display

TM

Interface Dial

On Demand Multi-Use Display

TM

248

uu

Audio System Basic Operation

u

Playing Hard Disk Drive (HDD) Audio

Features

Playing Hard Disk Drive (HDD) Audio

The Hard Disk Drive (HDD) Audio function plays tracks from music CDs that have
been recorded onto the built-in HDD. You can arrange the tracks in playlists or play
the tracks using various search methods.

Audio/Information Screen

MENU Button

Press to display the menu items.

CD Slot

Insert a CD about halfway into the CD
slot.

 (CD Eject) Button

Press to eject a CD.

Playlist/Album Up/Down Icons

Select

 to skip to the next playlist/

album, and

 to skip to the beginning

of the previous playlist/album.

Source

Select to change an audio source.

Skip/Seek Icons

Select

 or

 to change tracks.

Select and hold to move rapidly within
a track.

More

Select to display the menu items.

BACK Button

Press to go back to the previous display
or cancel a setting.

Interface Dial/ENTER Button

Press and turn to select an item,
then press to set your selection.
Move up, down, right and left to
select secondary menu.

SETTINGS Button

Press to go the

Setting menu

 screen.

On Demand Multi-Use Display

TM

 (Power) Button

Press to turn the audio system
on and off.

VOL (Volume) Knob (Pushed out)

Turn to adjust the volume.

Random

Select to use a random feature.

Scan

Select to use a scan feature.

Repeat

Select to use a repeat feature.

Continued

249

uu

Audio System Basic Operation

u

Playing Hard Disk Drive (HDD) Audio

Features

When

Recording from CD

 is set to

Auto

, the songs on music CDs are automatically

recorded to the HDD the first time you play each disc. You can then play the songs
directly from the HDD.

2

Customized Features

 P. 295

1.

Press the

MENU

 button.

2.

Rotate

 to select

Cancel Record to HDD

, then press

.

When

Recording from CD

 is set to

Manual

, the songs on music CDs can be

manually recorded to the HDD.

1.

Press the

MENU

 button.

2.

Rotate

 to select

Rec to HDD

, then press

.

■

Recording a Music CD to HDD

1

Recording a Music CD to HDD

You can add tracks to user playlists, where you can
mix and match tracks from other CDs recorded on
the HDD.

2

Editing an Album or Playlist

 P. 252

2

Editing Track Information

 P. 255

If you turn the power system off or the audio system
is turned off while recording a CD, there may be
pauses between songs when you play back from the
HDD.

Repeat, random, and scan functions are not available
during recording.

You can play music from other sources (e.g.,
SiriusXM

®

, HDD, etc.) while recording.

Please note that there is no compensation offered in
the case of unsuccessful recording of audio data or
the loss of audio data due to any cause whatsoever.

Clearing the HDD
Any music tracks stored on the HDD can be deleted.

2

Deleting all HDD Data

 P. 320

■

Stop Recording

■

Recording a CD Manually

Album AAA

Artist AAA

10

01’23”

Track AAA

01

Recording Indicator

Recording

Ready to record

uu

Audio System Basic Operation

u

Playing Hard Disk Drive (HDD) Audio

250

Features

1.

Press the

MENU

 button.

2.

Rotate

 to select

Music Search

, then

press .

3.

Rotate

, move

 or

, then press

 to

select a track from the

Music Search

 list.

u

Title information is displayed if found in
the Gracenote

®

 Album Info (Gracenote

®



Media Database) stored on the HDD.

u

The HDD has two types of playlists:
original playlists and user playlists. An
original playlist is automatically created
for each album when a music CD is
recorded. You can customize up to six
user playlists provided on the HDD by
adding tracks from your original playlists.

You can also select a track by the following
procedure.

1.

Rotate

 or press

 to display the song

list.

2.

Rotate

, move

 or

, then press

 to

select a track from the list.

■

How to Select a Track from the Music Search List

1

How to Select a Track from the Music Search List

You can control the HDD audio using voice
commands.

2

Voice Control Operation

 P. 232

2

Song By Voice

TM

 (SBV)

 P. 262

Music tracks recorded on HDD cannot be recorded
onto CDs or other devices.

Tracks are recorded at four times the playback speed
using ultra-efficient compression technology;
therefore, sound quality may vary slightly from the
original.

If the HDD is ever replaced, all music data is lost and
cannot be recovered.

If there is a problem, you may see an error message
on the display.

2

Hard Disk Drive (HDD) Audio

 P. 274

Continued

251

uu

Audio System Basic Operation

u

Playing Hard Disk Drive (HDD) Audio

Features

You can select scan, repeat, and random modes when playing a track.

1.

Press the

MENU

 button.

2.

Rotate

 to select

Scan

 or

Random/

Repeat

, then press

.

3.

Rotate

 to select a mode, then press

.

1.

Select

Scan

,

Random

 or

Repeat

.

2

Playing Hard Disk Drive (HDD) Audio



P. 248

2.

Select a mode.

■

To turn off a play mode

1.

Press the

MENU

 button.

2.

Rotate

 to select the mode you want to turn off, then press

.

1.

Select

Scan

,

Random

 or

Repeat

.

2

Playing Hard Disk Drive (HDD) Audio

 P. 248

2.

Select the mode you want to turn off.

■

How to Select a Play Mode

1

How to Select a Play Mode

Play Mode Menu Items

Scan
Scan Albums

: Provides a 10-second sampling of the

first track in each album.

Scan Tracks

: Provides a 10-second sampling of all

tracks on the HDD.

Random/Repeat

The following menu items vary depending on the
category you selected by the

Music Search

 list.

Repeat Artist

: Repeats all tracks in the current artist.

Repeat Album

: Repeats all tracks in the current

album.

Repeat Track

: Repeats the current track.

Random in Artist

: Plays all tracks in the current artist

in random order.

Random in Album

: Plays all tracks in the current

album in random order.

Random All Tracks

: Plays all tracks in random order.

Random/Repeat

is selected.

Interface Dial

On Demand Multi-Use Display

TM

Interface Dial

On Demand Multi-Use Display

TM

uu

Audio System Basic Operation

u

Playing Hard Disk Drive (HDD) Audio

252

Features

Change the playlist name, album name, genre, and track order of the current
playlist. You can also delete tracks, playlists, and albums.

■

Editing an album

1.

Press the

MENU

 button.

2.

Rotate

 to select

Edit/Delete

, then press

.

3.

Rotate

to

select

Albums

, then press

.

u

The pop-up menu appears on the screen.

4.

Rotate

 to select an album that you want

to edit or delete, then press

.

5.

To edit an album name:
Rotate

 to select

Edit Name

, then press

.

u

Enter the name using the interface dial or
the On Demand Multi-Use Display

TM

.

To delete an album:
Rotate

 to select

Delete

, then press

.

To edit track information or delete a track:
Rotate

 to select

List Tracks

, then press

.

2

Editing Track Information

 P. 255

■

Editing an Album or Playlist

1

Editing an Album or Playlist

The maximum number of songs in each of the six
user playlists is 999. Adding new songs overwrites
the oldest songs.

The maximum number of original playlists is 999 with
a maximum of 99 songs in each playlist.

Each album CD counts as an original playlist. Adding
a track from a user playlist into the same user playlist
will cause the track to appear twice in the playlist.

Deleting an album (original playlist) also deletes the
album tracks you have stored in any user playlists.

Deleting a user playlist or deleting all tracks from a
user playlist does not remove the playlist folder.
The folder retains the playlist name and artist
information.

Select

 to enter symbols.

 Icon

253

uu

Audio System Basic Operation

u

Playing Hard Disk Drive (HDD) Audio

Continued

Features

■

Editing a playlist

1.

Press the

MENU

 button.

2.

Rotate

 to select

Edit/Delete

, then press

.

3.

Rotate

 to select

Playlists

, then press

.

u

The pop-up menu appears on the screen.

4.

Rotate

 to select a playlist that you want

to edit or delete, then press

.

5.

To edit a playlist name:
Rotate

 to select

Edit Name

, then press

.

u

Enter the name using the interface dial or
the On Demand Multi-Use Display

TM

.

To delete a playlist:
Rotate

 to select

Delete

, then press

.

To edit track information or delete a track:
Rotate

 to select

List Tracks

, then press

.

2

Editing Track Information

 P. 255

254

uu

Audio System Basic Operation

u

Playing Hard Disk Drive (HDD) Audio

Features

■

Creating a new playlist

1.

Press the

MENU

 button.

2.

Rotate

 to select

Edit/Delete

, then press

.

3.

Rotate

 to select

Playlists

, then press

.

4.

Rotate

 to select

Create New Playlist

,

then press

.

u

Enter the name using the interface dial or
the On Demand Multi-Use Display

TM

,

then select tracks from the

Music

Search

 list.

255

uu

Audio System Basic Operation

u

Playing Hard Disk Drive (HDD) Audio

Continued

Features

Change the track title, artist name, genre and composer. You can also delete tracks.

1.

Press the

MENU

 button.

2.

Rotate

 to select

Edit/Delete

, then press

.

3.

Rotate

 to select

Tracks

, then press

.

4.

Rotate

 to select a track you want to edit

or delete, then press

.

u

The pop-up menu appears on the screen.

5.

To edit track information:
Rotate

 to select

Edit Name

, then press

.

u

Enter the track name, track artist, etc.
using the interface dial or the On
Demand Multi-Use Display

TM

. Move

,

rotate

 to select

OK

, then press

.

To delete a track:
Rotate

 to select

Delete

, then press

.

■

Editing Track Information

256

uu

Audio System Basic Operation

u

Playing Hard Disk Drive (HDD) Audio

Features

Music information (album name, artist name, genre) can be acquired by accessing
the Gracenote

®

 Album Info.

1.

Press the

MENU

 button.

2.

Rotate

 to select

Edit/Delete

, then press

.

3.

Rotate

to

select

Albums

, then press

.

4.

Rotate

 to select an album you want to

edit, then press

.

u

The pop-up menu appears on the screen.

5.

Rotate

 to select

Edit Name

, then press

.

6.

Move

 to select

Get Music Info

, then

press .

u

The system starts to access the
Gracenote

®

 Album Info.

■

Displaying Music Information
