Acura RLX HYBRID (2020 year). Manual in english - page 10

160

uu

Operating the Switches Around the Steering Wheel

u

Auto High-Beam

Co
ntrols

Auto High-Beam

The front sensor camera detects the light sources ahead of the vehicle such as the
lights of a preceding or oncoming vehicle, or street lights. When you are driving at
night, the system automatically switches the headlights between low beam and high
beam depending on the situation.

When all of the following conditions have been met, the auto high-beam indicator
comes on and the auto high-beam is activated.

•

The power mode is in ON.

•

The light switch is in

AUTO

.

•

The lever is in the low beam position.

•

The headlights have been automatically
activated.

•

It is dark outside the vehicle.

If the auto high-beam indicator does not come on even when all the conditions have
been met, carry out the following procedure and the indicator will come on.

•

Pull the lever toward you for flashing the high beams then release it while driving.

1

Auto High-Beam

The auto high-beam system does not always operate
in every situation. This system is just for assisting the
driver. Always observe your surroundings and switch
the headlights between high beam and low beam
manually if necessary.

If you find the timing of beam changes inconvenient
for driving, change the headlight beams manually.

The range and the distance at which the camera can
recognize varies depending on conditions
surrounding your vehicle.

For the auto high-beam to work properly:

•

Do not place an object that reflects light on the
dashboard.

•

Keep the windshield around the camera clean.
When cleaning the windshield, be careful not to
apply the windshield cleanser to the camera lens.

•

Do not attach an object, sticker or film to the area
around the camera.

•

Do not touch the camera lens.

If the camera receives a strong impact, or repairing of
the area near the camera is required, consult a dealer.

■

How to Use the Auto High-Beam

Front Sensor Camera

Light Switch

Auto High-Beam
Indicator

Continued

161

uu

Operating the Switches Around the Steering Wheel

u

Auto High-Beam

Co
ntrols

■

Automatic switching between high-beam and low-beam

When auto-high beam is active, the headlights switch between high beam and low
beam based on the following conditions.

■

Manual switching between high-beam and low-beam

If you want to manually switch the headlights between high beam and low beam,
follow either of the procedures below. Note that when you do this, the auto high-
beam indicator will turn off and the auto high-beam will be deactivated.

Using the lever:

Pull the lever toward you for flashing the high beams then release it within about
one second while driving.

u

To reactivate the auto high-beam, pull the lever toward you for flashing the
high beams then release it while driving. The auto high-beam indicator will
come on.

Using the light switch:

Turn the light switch to

.

u

To reactivate the auto high-beam, turn the light switch to

AUTO

 when the

lever is in the low beam position, the auto high-beam indicator will come on.

1

How to Use the Auto High-Beam

In the following cases, the auto high-beam system
may not switch the headlights properly or the
switching timing may be changed. In case of the
automatic switching operation does not fit for your
driving habits, please switch the headlights manually.

•

The brightness of the lights from the preceding or
oncoming vehicle is intense or poor.

•

Visibility is poor due to the weather (rain, snow,
fog, windshield frost, etc.).

•

Surrounding light sources, such as street lights,
electric billboards and traffic lights are illuminating
the road ahead.

•

The brightness level of the road ahead constantly
changes.

•

The road is bumpy or has many curves.

•

A vehicle suddenly appears in front of you, or a
vehicle in front of you is not in the preceding or
oncoming direction.

•

Your vehicle is tilted with a heavy load in the rear.

•

A traffic sign, mirror, or other reflective object
ahead is reflecting strong light toward the vehicle.

•

The oncoming vehicle frequently disappears under
roadside trees or behind median barriers.

•

The preceding or oncoming vehicle is a motorcycle,
bicycle, mobility scooter, or other small vehicle.

The auto high-beam system keeps the headlight low
beam when:

•

Windshield wipers are operating at a high speed.

•

The camera has been detected a dense fog.

Switching to high beam:

All of the following conditions must
be met before the high beams turn
on.

•

Your vehicle speed is 25 mph (40
km/h) or more.

•

There are no preceding or
oncoming vehicle with headlights
or taillights turned on.

•

There are few street lights on the
road ahead.

Switching to low beam:

One of the following conditions
must be met before the low beams
turn on.

•

Your vehicle speed is 15 mph (24
km/h) or less.

•

There is a preceding or oncoming
vehicle with headlights or
taillights turned on.

•

There are many street lights on
the road ahead.

uu

Operating the Switches Around the Steering Wheel

u

Auto High-Beam

162

Co
ntrols

You can turn the auto high-beam system off. If you want to turn the system off or
on, set the power mode to ON, then carry out the following procedures while the
vehicle is stationary.

To turn the system off:

With the light switch is in

AUTO

, pull the lever

toward you and hold it for at least 40 seconds.
After the auto high-beam indicator light blinks
twice, release the lever.

To turn the system on:

With the light switch is in

AUTO

, pull the lever

toward you and hold it for at least 30 seconds.
After the auto high-beam indicator light blinks
once, release the lever.

■

How to Turn Off the Auto High-Beam

1

How to Use the Auto High-Beam

If the

Some Driver Assist Systems Cannot

Operate: Camera Temperature Too High

 message

appears:

•

Use the climate control system to cool down the
interior and, if necessary, also use defroster mode
with the airflow directed toward the camera.

•

Start driving the vehicle to lower the windshield
temperature, which cools down the area around
the camera.

If the

Auto High-Beam Cannot Operate: Clean

Windshield

 message appears:

•

Park your vehicle in a safe place, and clean the
windshield. If the message does not disappear after
you have cleaned the windshield and driven for a
while, have your vehicle checked by a dealer.

1

How to Turn Off the Auto High-Beam

If you turn the auto high-beam system off, the system
does not operate until you turn the system on.

Park in a safe place before turning the system off or
on.

AUTO

 Position

163

uu

Operating the Switches Around the Steering Wheel

u

Wipers and Washers

Continued

Co
ntrols

Wipers and Washers

The windshield wipers and washers can be
used when the power mode is in ON.

■

MIST

The wipers run at high speed until you release
the lever.

■

Wiper switch (OFF, AUTO, LO, HI)

Move the lever up or down to change the
wiper settings.

■

Washer

Sprays while you pull the lever toward you.
When you release the lever for more than one
second, the spray stops, the wipers sweep two
or three more times to clear the windshield,
then stop.

■

Windshield Wiper/Washer

1

Wipers and Washers

NOTICE

Do not use the wipers when the windshield is dry.
The windshield will get scratched, or the rubber
blades will get damaged.

NOTICE

In cold weather, the blades may freeze to the
windshield.
Operating the wipers in this condition may damage
the wipers. Use the defroster to warm the
windshield, then turn the wipers on.

Turn the washers off if no washer fluid comes out.
The pump may get damaged.

The wiper motor may stop motor operation
temporarily to prevent an overload. Wiper operation
will return to normal within a few minutes, once the
circuit has returned to normal.

If the wipers stop operating due to any obstacle such
as the build-up of snow, park the vehicle in a safe
place.
Rotate the wiper switch to

OFF

, and set the power

mode to ACCESSORY or VEHICLE OFF, then remove
the obstacle.

MIST

OFF

LO

: Low speed wipe

HI

: High speed wipe

Pull to
use
washer.

AUTO

uu

Operating the Switches Around the Steering Wheel

u

Wipers and Washers

164

Co
ntrols

When you push the lever down to

AUTO

, the

windshield wipers sweep once, and go into
the automatic mode.

The wipers operate intermittently, at low
speed, or at high speed and stops in
accordance with the amount of rainfall the
rainfall sensor detects.

■

AUTO sensitivity adjustment

When the wiper function is set to

AUTO

, you

can adjust the sensitivity of the rainfall sensor
(using the adjustment ring) so that wipers will
operate in accordance with your preference.

Sensor sensitivity

■

Automatic Intermittent Wipers

1

Automatic Intermittent Wipers

The rainfall sensor is in the location shown below.

AUTO

 should always be turned

OFF

 before the

following situations in order to prevent severe
damage to the wiper system:

•

Cleaning the windshield

•

Driving through a car wash

•

No rain present

You can change the automatic intermittent wiper
setting in the

AUTO

 position.

Rain Sensing

,

Intermittent

, and

Speed Sensitive



can be selected.

Rain Sensing

: Default setting.

Intermittent

: You can adjust the intermittent time

using the adjustment ring.

Speed Sensitive

: You can adjust the intermittent

time using the adjustment ring. In addition, the
intermittent time becomes a few seconds shorter
when the vehicle speeds up.

2

Customized Features

 P. 295

Rainfall Sensor

Adjustment Ring

Low sensitivity

High sensitivity

165

uu

Operating the Switches Around the Steering Wheel

u

Wipers and Washers

Co
ntrols

Turn the headlights on and press the
headlight washer button to operate.
The headlight washers also operate when you
turn the windshield washers for the first time
after the power mode sets to ON.

■

Headlight Washers

Canadian models

1

Headlight Washers

The headlight washers use the same fluid reservoir as
the windshield washers.

Headlight
Washer
Button

166

uu

Operating the Switches Around the Steering Wheel

u

Brightness Control

Co
ntrols

Brightness Control

When the power mode is in ON, you can use
the

(

+

 or

(

-

 button to adjust instrument

panel brightness.

Brighten:

 Press the

(

+

 button.

Dim:

 Press the

(

-

 button.

You will hear a beep when the brightness
reaches minimum or maximum. Several
seconds after you have adjusted the
brightness, you will be returned to the
previous screen.

■

Brightness level indicator

The brightness level is shown on the multi-
information display while you are adjusting it.

■

Adjusting the Instrument Panel Brightness

1

Adjusting the Instrument Panel Brightness

Instrument panel brightness varies, depending on
whether the exterior lights are on or off. The
instrument panel dims to reduce glare when they are
on.

When it is bright outside and the headlight
integration with the wiper

*

 is activated, the

instrument panel brightness does not change.

To cancel the reduced instrument panel brightness
when the exterior lights are on, press the

(

+

 button

until the brightness display is up to max, the beeper
sounds.

The brightness can be set differently for when the
exterior lights are on, and when they are off.

(

+

 Button

(

-

 Button

* Not available on all models

167

uu

Operating the Switches Around the Steering Wheel

u

Brightness Control

Co
ntrols

When the head-up display is on, press and
hold the

HUD

 button until its brightness level

indicator on the multi-information display.

Brighten:

 Press the

 button.

Dim:

 Press the

 button.

Several seconds after you have adjusted the
brightness, you will be returned to the
previous screen.

■

Brightness level indicator

The brightness level is shown on the multi-
information display while you are adjusting it.

■

Adjusting the Head-Up Display Brightness

 Button

3

 Button

4

HUD

 Button

3

4

168

uu

Operating the Switches Around the Steering Wheel

u

Rear Defogger/Heated Door Mirror/Heated Windshield Button

Co
ntrols

Rear Defogger/Heated Door Mirror/Heated
Windshield Button

Press the rear defogger, heated door mirror,
and heated windshield button to defog the
rear window and mirrors, and to deice the
windshield when the power mode is in ON.

The rear defogger, heated door mirrors, and
heated windshield automatically switch off
after 10-30 minutes depending on the outside
temperature.

However, if the outside temperature is 32°F
(0°C) or below, they do not automatically
switch off.

1

Rear Defogger/Heated Door Mirror/Heated Windshield Button

This system consumes a lot of power, so turn it off
when the window has been defogged or deiced.
Also, do not use the system for a long time while the
power system is stopped. This may weaken the 12-
volt battery, making it difficult to turn the power
system on.

When the power mode is set to ON and the outside
temperature is below 41°F (5°C), the heated door
mirror may automatically activate for 10 minutes.

When the outside temperate is below 39°F (4°C) and
the windshield defroster is turned on, the heated
windshield may automatically activate.
The heated windshield deactivates itself once the
windshield defroster is turned off or the outside
temperate reaches 43°F (6°C).

169

uu

Operating the Switches Around the Steering Wheel

u

Driving Position Memory System

Continued

Co
ntrols

Driving Position Memory System

You can store two driver’s seat (except for power lumbar), steering wheel and door
mirror positions with the driving position memory system.
When you unlock and open the driver’s door with a remote transmitter, or keyless
access system, door mirrors adjust to one of the two preset positions and the seat
adjusts to retracted positions of one of the two preset positions automatically.
The steering wheel and the seat will move to the stored position when you set the
power mode to ACCESSORY.

When you enter the vehicle, the multi-information display briefly shows you which
remote transmitter you used to unlock the vehicle.

•

DRIVER 1

 transmitter is linked to memory button 1.

•

DRIVER 2

 transmitter is linked to memory button 2.

The driver’s seat moves rearward and steering
wheel fully up depending on the set seating
position once you

•

Stop the vehicle.

•

Put the transmission in

(

P

.

•

Set the power mode to VEHICLE OFF.

•

Then open the driver’s door.

Once the power mode is in the ACCESSORY
position, the driver’s seat and steering wheel
moves to the

DRIVER 1

 or

2

 preset position.

1

Driving Position Memory System

Using the audio/information screen, you can disable
the automatic seat, steering wheel and door mirrors
adjustment function.

2

Customized Features

 P. 295

You can change the driver’s seat easy exit feature
setting.

2

Customized Features

 P. 295

System Operation

The system will not operate if:

•

The vehicle speed is above 2 mph (3 km/h).

•

Either memory position button is pressed while the
seat, steering wheel or the outside mirror is in
motion.

•

The seat, steering wheel or the outside mirror
position is adjusted while in operation.

•

The memory 1 or 2 position is set fully to the rear.

DRIVER 1

DRIVER 2

uu

Operating the Switches Around the Steering Wheel

u

Driving Position Memory System

170

Co
ntrols

1.

Set the power mode to ON. Adjust the
driver’s seat, the steering wheel and the
door mirrors to the desired position.

2.

Press the

SET

 button.

u

You will hear the beep, and the memory
button indicator light will blink.

3.

Press memory button

(

1

 or

(

2

 within five

seconds of pressing the

SET

 button.

u

You will hear two beeps, and the
indicator light on the button you pressed
stays on once the seat, the steering
wheel, and the outside mirror positions
have been memorized.

1.

Change to

(

P

.

2.

Apply the parking brake.

3.

Press a memory button (

(

1

 or

(

2

).

u

You will hear the beep, and the indicator
light will blink.

The seat, the steering wheel and the door
mirrors will automatically move to the
memorized positions. When it has finished
moving, you will hear two beeps, and the
indicator light stays on.

■

Storing a Position in Memory

1

Storing a Position in Memory

After you press the

SET

 button, the storing operation

will be canceled when:

•

You do not press the memory button within five
seconds.

•

You readjust the seat, the steering wheel or the
outside mirror position before the double-beep.

•

You set the power mode to any position except
ON.

SET

 Button

Memory Button 1

Memory Button 2

■

Recalling the Stored Position

1

Recalling the Stored Position

The seat, the steering wheel and the door mirrors will
stop moving if you:

•

Press the

SET

 button, or a memory button (

(

1

 or

(

2

).

•

Adjust the seat, the steering wheel or the door
mirror position.

•

Put the transmission into a position other than

(

P

.

Memory Buttons

SET

 Button

171

uu

Operating the Switches Around the Steering Wheel

u

Adjusting the Steering Wheel

Co
ntrols

Adjusting the Steering Wheel

The steering wheel height and distance from your body can be adjusted so that you
can comfortably grip the steering wheel in an appropriate driving posture.

Push and hold the adjustment switch to move
the steering wheel in, out, up or down.

Make sure you can see the instrument panel
gauges and indicators.

1

Adjusting the Steering Wheel

3

WARNING

Adjusting the steering wheel position while
driving may cause you to lose control of the
vehicle and be seriously injured in a crash.

Adjust the steering wheel only when the
vehicle is stopped.

Adjustment Switch

172

Co
ntrols

Adjusting the Mirrors

Interior Rearview Mirror

Adjust the angle of the rearview mirror when you are sitting in the correct driving
position.

When driving after dark, the automatic
dimming rearview mirror and power door
mirrors

*

 reduce the glare from headlights

behind you, based in inputs from the mirror
sensor. This feature is always active.

■

Automatic Dimming Rearview Mirror and Power Door
Mirrors

*

1

Adjusting the Mirrors

Keep the inside and outside mirrors clean and
adjusted for best visibility.

Adjust the mirrors before you start driving.

2

Front Seats

 P. 175

1

Automatic Dimming Rearview Mirror and Power Door Mirrors

*

The auto dimming function cancels when the
transmission is in

(

R

.

Sensor

* Not available on all models

173

uu

Adjusting the Mirrors

u

Power Door Mirrors

Continued

Co
ntrols

Power Door Mirrors

You can adjust the door mirrors when the
power mode is in ON.

■

Mirror position adjustment

L/R selector switch:

 Select the left or right

mirror. After adjusting the mirror, return the
switch to the center position.

Mirror position adjustment switch:

 Press

the switch left, right, up, or down to move the
mirror.

■

Folding door mirrors

Press the folding button to fold in and out the
door mirrors.

If activated, either side door mirror
automatically tilts downward when you put
the transmission into

(

R

; this improves close-

in visibility on the selected side of the vehicle
when backing up. The mirror automatically
returns to its original position when you take
the transmission out of

(

R

.

To activate this feature, set the power mode
to ON and slide the selector switch to the left
or right side.

Selector
Switch

Folding Button

Adjustment
Switch

■

Reverse Tilt Door Mirror

Slide the selector switch to left
or right to tilt down either side
door mirror.

uu

Adjusting the Mirrors

u

Power Door Mirrors

174

Co
ntrols

■

Folding in the door mirrors

Press the lock button on the keyless access remote, or press the door lock button on
any door.

u

The mirrors start folding in automatically.

■

Folding out the door mirrors

Press the unlock button on the keyless access remote, or grab the door handle on
any door.

u

The mirrors start folding out automatically.

■

Automatic Folding Door Mirror Function

1

Automatic Folding Door Mirror Function

You can turn the automatic folding door mirror
function on and off.

2

Customized Features

 P. 295

1

Folding out the door mirrors

You cannot turn the automatic folding out
automatically if they have been folded in using the
folding button.

175

Continued

Co
ntrols

Adjusting the Seats

Front Seats

Adjust the driver’s seat as far back as possible
while allowing you to maintain full control of
the vehicle. You should be able to sit upright,
well back in the seat and be able to
adequately depress the pedals without
leaning forward, and grip the steering wheel
comfortably. The passenger’s seat should be
adjusted in a similar manner, so that it is as far
back from the front airbag in the dashboard
as possible.

■

Adjusting the front power seats

1

Adjusting the Seats

The National Highway Traffic Safety Administration
and Transport Canada recommend that drivers allow
at least 10 inches (25 cm) between the center of the
steering wheel and the chest.

Always make seat adjustments before driving.

3

WARNING

Sitting too close to a front airbag can result
in serious injury or death if the front
airbags inflate.

Always sit as far back from the front
airbags as possible while maintaining
control of the vehicle.

Move back.

Allow sufficient
space.

Horizontal
Position
Adjustment

Height
Adjustment

Seat-back Angle
Adjustment
