240

uu

Audio System

u

Auxiliary Input Jack

Features

Auxiliary Input Jack

Use the jack to connect a standard audio
device.

1.

Open the

AUX

 cover.

2.

Connect a standard audio device to the
input jack using a 1/8 inch (3.5 mm) stereo
miniplug.

u

The audio system automatically switches
to the AUX mode.

Audio System Theft Protection

The audio system is disabled when it is disconnected from the power source, such as
when the 12-volt battery is disconnected or goes dead. In certain conditions, the
system may display a code entry screen. If this occurs, reactivate the audio system.

■

Reactivating the audio system

1.

Set the power mode to ON.

2.

Turn on the audio system.

3.

Press and hold the audio system power button for more than two seconds.

u

The audio system is reactivated when the audio control unit establishes a
connection with the vehicle control unit. If the control unit fails to recognize
the audio unit, you must go to a dealer and have the audio unit checked.

1

Auxiliary Input Jack

To switch to another mode or return to the AUX
mode, press the

SOURCE

 button on the steering

wheel or select

Source

 on the On Demand Multi-Use

Display

TM

.

241

uu

Audio System

u

Audio Remote Controls

Continued

Features

Audio Remote Controls

Allows you to operate the audio system while driving. The information is shown on
the multi-information display (MID).

SOURCE Button

Cycles through the audio modes as follows:
FM   AM   SiriusXM

®

   CD

 Rear DVD

*



HDD   USB/iPod/Apple CarPlay/Android Auto



Bluetooth

®

 Audio   Pandora

®

*



AUX

Left Selector Wheel
Roll Up:

 To increase the volume.

Roll Down:

 To decrease the volume.

Push:

 To mute. Push again to unmute.

•

When listening to the radio

Move to the right:

 To select the next preset radio station.

Move to the left:

 To select the previous preset radio station.

Move to the right and hold:

 To select the next strong station.

To select the next channel. (SiriusXM

®

 only)

Move to the left and hold:

 To select the previous strong station.

To select the previous channel. (SiriusXM

®

 only)

•

When listening to a CD, HDD, iPod, USB flash drive, or

Bluetooth

®

 Audio

Move to the right:

 To skip to the next song.

Move to the left:

 To go back to the beginning of the current or previous song.

Move to the right and hold:

 To go to the next folder. (

Bluetooth

®

 Audio only)

Move to the left and hold:

 To go to the previous folder. (

Bluetooth

®

 Audio only)

1

Audio Remote Controls

Some mode appears only when an appropriate
device or medium is used.

Depending on the

Bluetooth

®

 device you connect,

some functions may not be available.

If you operate some remote control switch while rear
source mode is selected, the rear source mode
changes to the front source mode.

2

Selecting an Audio Source

 P. 244

Models with rear entertainment system

Left Selector Wheel

SOURCE

 Button

* Not available on all models

242

uu

Audio System

u

Audio Remote Controls

Features

•

When listening to a CD, HDD or USB flash drive

Move to the right and hold:

 To skip to the next folder.

Move to the left and hold:

 To go back to the previous folder.

•

When listening to Pandora

®

*

Move to the right:

 To skip to the next track.

Move to the right and hold:

 To select the next station.

Move to the left and hold:

 To select the previous station.

* Not available on all models

243

Features

Audio System Basic Operation

To use the audio system, the power mode must be in ACCESSORY or ON.

Use the interface dial or

ENTER/MENU



button to access phone, information or
smartphone functions.

Interface dial (ENTER/MENU button):

Rotate left or right to scroll through the
available choices. Press to set your selection.
Move right, left, up or down to select a
secondary menu.
Press to switch the display to the

Information

Menu

 screen while the trip computer screen

or clock/wallpaper screen is displayed.

BACK button:

Press to go back to the

previous display.

 (Day/Night) button:

Press to change

the information screen brightness.
Press

 once and make an adjustment

using the interface dial.

u

Each time you press

, the mode

switches between the daytime mode,
nighttime mode and off mode.

1

Audio System Basic Operation

Voice Control System
The navigation/audio system is voice operable.

2

Voice Control Operation

 P. 258

These indications are used to show how to operate
the interface dial.

Rotate

 to select.

Press

to

enter.

Move

,  ,

 or   to select a secondary menu.

Audio function items

2

Preset Memory

 P. 262, 266

2

Radio Text

 P. 263

2

Music Search

 P. 276, 280, 292, 301

2

Scan

 P. 263, 274, 277, 281, 302

2

Random/Repeat

 P. 277, 282, 293, 302

When you unlock the doors with your remote, the
driver’s ID (

Driver 1

 or

Driver 2

) is detected, and the

audio system settings and preset memory are turned
to the respective mode automatically when you set
the power mode to ON.

 (Day/Night)

Button

BACK

 Button

Interface Dial (

ENTER/

MENU

 Button)

244

uu

Audio System Basic Operation

u

On Demand Multi-Use Display

TM

Features

On Demand Multi-Use Display

TM

Use the On Demand Multi-Use Display

TM

 to operate the audio system.

Select

Source

, then select an item on the source list to switch the audio source.

Select

Front

/

Rear

 to changes between the front side audio source selection and

rear side audio source selection.

2

Selecting the Audio Source using Front Control Panel

 P. 356

■

Selecting an Audio Source

1

On Demand Multi-Use Display

TM

Icons that appear on the screen vary by the source
selected.

Select

 or

 to go back to the previous screen.

Use the

/

 icons to turn the page.

X

1

Selecting an Audio Source

You can change the order of source list displayed.

1. Select

Audio Menu

, then

Edit Source Order

.

2. Select

or .

You can also change the source order by pressing
and holding the source on the source list for two
seconds.

Select

Source

.

Source List

Front

/

Rear

*

Models with rear entertainment system

* Not available on all models

245

uu

Audio System Basic Operation

u

On Demand Multi-Use Display

TM

Continued

Features

Select

Audio Menu

 to display the menu items.

The following items are available:

•

Edit Source Order

: Displays the

Edit Source Order

 screen.

2

Selecting an Audio Source

 P. 244

•

Sound Settings

: Displays the

Sound Settings

 screen.

2

Adjusting the Sound

 P. 256

•

Edit/Delete HDD Music

 (HDD mode): Displays the

Edit/Delete HDD Music



screen.

2

Editing an Album or Playlist

 P. 284

•

Radio Text

 (FM mode): Displays the text information broadcast by the current

RDS station.

2

Radio text

 P. 263

■

Displaying the Menu Items

Select

Audio Menu

.

Menu Items

246

uu

Audio System Basic Operation

u

On Demand Multi-Use Display

TM

Features

•

SportsFlash

 (SiriusXM

®

 mode): Displays the SportsFlash

TM

 list. If the favorite sport

team is not registered, the setup screen of SportsFlash

TM

 is displayed.

2

Live Sports Alert

 P. 270

2

Customized Features

 P. 362

•

Traffic & Weather Now

 (SiriusXM

®

 mode): Displays to the Traffic & Weather

Now screen.

2

Traffic and Weather Information

 P. 272

•

View Channel Schedule

 (SiriusXM

®

 mode): Displays the SiriusXM

®

 channel

schedule.

•

Audio Settings

: Displays the

Audio Settings

 screen.

2

Customized Features

 P. 362

•

Screen Settings

: Displays the

Screen Settings

 screen.

2

Changing the Screen Settings

 P. 247

•

RES Settings

*

: Displays the

RES Settings

 screen.

2

Rear System Setup

 P. 360

2

Customized Features

 P. 362

* Not available on all models

247

uu

Audio System Basic Operation

u

On Demand Multi-Use Display

TM

Features

1.

Select

Audio Menu

, then select

Screen

Settings

.

2.

Use

(

+

,

(

-

 or other icons to adjust the

setting.

■

Changing the Screen Settings

1

Changing the Screen Settings

The following are adjustable screen settings:

•

Sync Display Brightness

Selects whether the screen brightness synchronizes
with the instruments panel brightness.

•

Brightness

•

Contrast

•

Black Level

•

Beep

Mutes a beep that sounds every time you touch the
screen.

•

Keyboard

Changes the on-screen keyboard from the
alphabetical order to the qwerty type.

Instead of using

(

+

,

(

-

 or icons, you can also touch

the point where your desired setting is.

248

uu

Audio System Basic Operation

u

Information Screen

Features

Information Screen

Displays the navigation, HFL information, clock/wallpaper, trip computer, Apple
CarPlay and Android Auto. From this screen, you can go to various setup options.

Press the

NAV

,

PHONE

,

INFO

 and

SMARTPHONE

 buttons to go to the

corresponding display.

■

Switching the Display

Phone

Info

Smartphone

SMARTPHONE

 Button

PHONE

 Button

NAV

 Button

INFO

 Button

Navigation

249

uu

Audio System Basic Operation

u

Information Screen

Continued

Features

■

Navigation

Shows the navigation screen.

2

 Refer to the Navigation System Manual

■

Phone

Shows the HFL information.

2



Bluetooth

®

 HandsFreeLink

®

 P. 397

■

Info

Shows the

AcuraLink/Messages

,

Trip Computer

,

Clock

,

Traffic Incidents

,

Power Distribution Monitor

 or

Voice Recognition Guide

. Press

 or

INFO



button to display the

Information Menu

 screen.

AcuraLink/Messages

:

Shows a AcuraLink

®

 message menu list.

2

 AcuraLink Message

 P. 442

Trip Computer

:

Current Drive

Shows the range, instant and average fuel economy, and EV/total drive of the
current trip, as well as the average fuel economy from your last trip.

History of Trip A

Shows the range, average fuel economy and distances traveled for the current trip,
as well as the average fuel economy and distances traveled during the last three
driving cycles.
Each time you reset the trip meter A, the information on the display updates. The
history of the previous three driving cycles is kept.

250

uu

Audio System Basic Operation

u

Information Screen

Features

Deleting the history manually
1.

Press

on

the

History of Trip A

 screen to select

Delete History

.

2.

A confirmation message appears on the screen. Rotate

 to select

Yes

, then

press .

Clock

:

Shows a clock screen and an image you import.

Traffic Incidents

:

Shows a traffic incidents list.

2

Refer to the Navigation System Manual

Power Distribution Monitor

:

Displays the power flow monitor.

2

Power Distribution Monitor

 P. 251

Voice Recognition Guide

:

Shows a voice recognition guide screen.

■

Smartphone

Displays the Apple CarPlay or Android Auto.

2

Apple CarPlay

 P. 306

2

Android Auto

 P. 310

Continued

251

uu

Audio System Basic Operation

u

Information Screen

Features

■

Power flow monitor

Consists of the information screen showing the vehicle’s power flow and torque
distribution indicators.

Shows motor and engine power flow, indicating what supplies power to the vehicle,
or if the High Voltage battery is being charged.

■

Power Distribution Monitor

1

Power Distribution Monitor

While the vehicle is stationary with the engine
running, the following may appear on the screen.

The High Voltage battery charge level gauge shows
the current High Voltage battery charge level.

High Voltage

Battery Charge

Level Gauge

Power flow pattern

Color of indicators

Vehicle’s Condition

Blue

Power is supplied by the
motors and the engine.

Torque Indicator

Engine Icon

Torque Indicator

Power Flow

Indicator

252

uu

Audio System Basic Operation

u

Information Screen

Features

Power flow pattern

Color of indicators

Vehicle’s Condition

Blue

Power is only supplied by
the motors.

Blue

Power is only supplied by
the engine.

Green

The motors charge the
High Voltage battery.

253

uu

Audio System Basic Operation

u

Information Screen

Continued

Features

■

SPORT HYBRID SH-AWD

®

 torque distribution monitor

The indicators on the screen show the amount of torque being transferred to each
wheel or regenerative energy being supplied to the High Voltage battery.

2

SPORT HYBRID Super Handling-All Wheel Drive

TM

 (SPORT HYBRID SH-AWD

®

)



P. 509

How much regenerative braking is

being supplied to the High Voltage

battery is shown in four scales. The

indicators appear in green.

How much torque is being

transferred is shown in four scales.

The indicators appear in blue.

Torque Indicator

Torque Indicator

uu

Audio System Basic Operation

u

Information Screen

254

Features

You can change, store, and delete the wallpaper on the information screen.

■

Import wallpaper

1.

Connect the USB flash drive to the USB port

 (2.5A).

2

USB Ports

 P. 237

2.

Press the

SETTINGS

 button.

3.

Rotate

 to select

Clock Settings

, then

press .

u

Repeat the procedure to select

Clock/

Wallpaper Type

.

4.

Move

 to select

Wallpaper

 tab.

u

The screen will change to the wallpaper
list.

5.

Rotate

 to select

Options…

, then press

.

u

Repeat the procedure to select,

Add

New Wallpaper

.

6.

Rotate

 to select a desired picture.

u

The preview is displayed on the left side
on the screen.

7.

Rotate

 to select

Start Import

, then

press

 to save the data.

u

The display will return to the wallpaper
list.

■

Wallpaper Setup

1

Wallpaper Setup

•

When importing wallpaper files, the image must be
in the USB flash drive’s root directory. Images in a
folder cannot be imported.

•

The file name must be fewer than 210 characters.

•

The file format of the image that can be imported
is BMP (bmp) or JPEG (jpg).

•

The individual file size limit is 10 MB.

•

The maximum image size is 5,800 x 5,800 pixels.

•

Up to 10 files can be saved for each driver (Driver 1
and Driver 2).

•

If the USB flash drive does not have any pictures,
the

No files detected

 message appears.

255

uu

Audio System Basic Operation

u

Information Screen

Features

■

Select wallpaper

1.

Press the

SETTINGS

 button.

2.

Rotate

 to select

Clock Settings

, then press

.

u

Repeat the procedure to select

Clock/Wallpaper Type

.

3.

Move

to

select

Wallpaper

.

u

The screen changes to the wallpaper list.

4.

Rotate

 to select a desired wallpaper, then press

.

u

The preview is displayed on the left side on the screen.

u

The pop-up menu appears on the screen.

5.

Rotate

 to select

Set

, then press

.

u

The display will return to the

Clock Settings

 screen.

■

Delete wallpaper

1.

Press the

SETTINGS

 button.

2.

Rotate

 to select

Clock Settings

, then press

.

u

Repeat the procedure to select

Clock/Wallpaper Type

.

3.

Move

to

select

Wallpaper

.

u

The screen changes to the wallpaper list.

4.

Rotate

 to select a wallpaper that you want to delete, then press

.

u

The preview is displayed on the left side on the screen.

u

The pop-up menu appears on the screen.

5.

Rotate

 to select

Delete

, then press

.

u

The confirmation message will appear.

6.

Rotate

 to select

Yes

, then press

 to delete completely.

u

The display will return to the wallpaper list.
