Continued

127

Gauges and Multi-Information Display (MID)

MID

strum

ent Pa

nel

Shows the total number of miles (U.S.) or kilometers (Canada) driven since the last
reset. Meters A and B can be used to measure two separate trips.

■

Resetting a trip meter

To reset a trip meter, display it, then press and hold the

TRIP

button until the trip

meter is reset to

0.0

Shows the outside temperature in Fahrenheit (U.S.) or Celsius (Canada).

■

Adjusting the outside temperature display

Adjust the temperature reading up to ±5°F or ±3°C if the temperature reading
seems incorrect.

Shows the estimated average fuel economy of each trip meter in mpg (U.S.) or l/100
km (Canada). The display is updated at set intervals. When a trip meter is reset, the
average fuel economy is also reset.

■

Trip Meter

■

Outside Temperature

■

Average Fuel Economy

Trip Meter

Switch between trip meter A and trip meter B by
pressing the

TRIP

button.

Outside Temperature

The temperature sensor is located in the front
bumper.
Road heat and exhaust from another vehicle can
affect the temperature reading when your vehicle
speed is less than 19 mph (30 km/h).

It may take several minutes for the display to be
updated after the temperature reading has stabilized.

Use the MID’s customized features to correct the
temperature.

Customized Features

P. 131

Average Fuel Economy

You can change when to reset the average fuel
economy.

Customized Features

P. 131

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Gauges and Multi-Information Display (MID)

MID

128

strum

ent Pa

nel

Shows the instant fuel economy as a bar graph in mpg (U.S.) or l/100 km (Canada).

Shows the estimated distance you can travel on the remaining power and fuel. This
estimated distance is based on the vehicle’s current fuel economy.

Shows the time elapsed since Trip A or Trip B was reset.

Shows the average speed in mph (U.S.) or km/h (Canada) since Trip A or Trip B was
reset.

■

Instant Fuel Economy

■

Range

■

Elapsed Time

■

Average Speed

Elapsed Time

You can change when to reset the elapsed time.

Customized Features

P. 131

Average Speed

You can change when to reset the average speed.

Customized Features

P. 131

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

129

Gauges and Multi-Information Display (MID)

MID

strum

ent Pa

nel

The indicators on the display show the
amount of torque being transferred to the
right front, left front, right rear, and left rear
wheels.

SPORT HYBRID Super Handling-All Wheel
Drive

(SPORT HYBRID SH-AWD

)

P. 509

Shows the current mode for Dynamic Mode.

Integrated Dynamics System

P. 474

■

Compass

Shows the compass screen.

■

Turn-by-Turn Directions

When driving guidance is provided by the navigation system or Android Auto, turn-
by-turn directions to your destination appear.

Refer to the Navigation System Manual

Android Auto

P. 310

■

SH-AWD

Torque Distribution Monitor

■

Current Mode for Dynamic Mode

■

Navigation

Navigation

You can select whether the turn-by-turn display
comes on or not during the route guidance.

Customized Features

P. 131, 362

-------------------------------------------------------------------------------------------------------------------------------------------------------------

130

Gauges and Multi-Information Display (MID)

MID

strum

ent Pa

nel

Shows the remaining oil life and Maintenance Minder

Maintenance Minder

P. 565

Shows each tire’s pressure.

Tire Pressure Monitoring System (TPMS) with Tire Fill Assist

P. 513

■

Engine Oil Life and Maintenance Items

■

Tire Pressure Monitor

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

131

Gauges and Multi-Information Display (MID)

MID

strum

ent Pa

nel

Use the MID to customize certain features.

■

How to customize

Select the

Vehicle Settings

screen by rolling the multi-function steering-wheel

controls while the power mode is in ON, and the vehicle is at a complete stop. Push
the multi-function steering-wheel controls.

■

Customized Features

Customized Features

To customize other features, roll the multi-function
steering-wheel controls.

List of customizable options

P. 134

Example of customization settings

P. 139

Customization is possible when you see the driver’s
ID (

Driver 1

Driver 2

) on the screen.

The driver’s ID indicates which remote transmitter
you have used to unlock the driver’s door. The
customized settings are recalled every time you
unlock the driver’s door with that remote.

Put the transmission into

(

before you attempt to

change any customized setting.

Customizing is also available from the information
screen.
You cannot have

Vehicle Settings

displayed on the

multi-information display while the information
screen shows the same menu.

Customized Features

P. 362

Multi-function Steering-
wheel Controls
Roll:

Changes the

customize menus and

items.

Push:

Enter the selected

item.

MID: Goes to

Vehicle Settings

-------------------------------------------------------------------------------------------------------------------------------------------------------------

132

Gauges and Multi-Information Display (MID)

MID

strum

ent Pa

nel

■

Customization flow

Roll the multi-function steering-wheel controls to select

Vehicle Settings

and push the multi-function steering-wheel controls.

Vehicle Settings

“Trip A” Reset Timing

Language Selection

Adjust Outside Temp. Display

Memory Position Link

Door Unlock Mode

Keyless Access Beep

Driver Assist System Setup

Meter Setup

Driving Position Setup

Keyless Access Setup

“Trip B” Reset Timing

Forward Collision Warning Distance

ACC Forward Vehicle Detect Beep

ACC Display Speed Unit

Push

Lane Keeping Assist Suspend Beep

Blind Spot Info

Easy Entry/Exit

Roll

Walk Away Auto Lock

Push

Keyless Access Light Flash

Roll

Turn by Turn Display

Road Departure Mitigation Setting

Reverse Alert Tone

Remote Start System On/Off

Roll

Push

Roll

-------------------------------------------------------------------------------------------------------------------------------------------------------------

133

Gauges and Multi-Information Display (MID)

MID

Continued

strum

ent Pa

nel

Exit

Door Setup

Dynamic Mode Setup

Default All

Lighting Setup

Key And Remote Unlock Mode

Auto Door Lock

Auto Door Unlock

Keyless Lock Answer Back

Auto Folding Door Mirror

Interior Light Dimming Time

Headlight Auto Off Timer

Auto Light Sensitivity

Roll

Push

Roll

Power Tailgate Setup

Push

Power Open By Outer Handle

Keyless Open Mode

Push

Maintenance Info.

Roll

Push

Preferred Dynamic Mode

Roll

Push

Maintenance Reset

Security Relock Timer

* Not available on all models

-------------------------------------------------------------------------------------------------------------------------------------------------------------

134

Gauges and Multi-Information Display (MID)

MID

strum

ent Pa

nel

■

List of customizable options

*1:Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Driver Assist
System Setup

Forward Collision
Warning Distance

Changes at which distance forward collision
warning alerts.

Long

Normal

Short

ACC Forward Vehicle
Detect Beep

Causes the system to beep when the system detects
a vehicle, or when the vehicle goes out of the ACC
with Low Speed Follow range.

Off

ACC Display Speed Unit

Changes the speed unit for ACC with Low Speed
Follow on the MID.

mph

km/h

(U.S.)

mph

km/h

(Canada)

Road Departure
Mitigation Setting

Changes the setting for the road departure
mitigation system.

Normal

Wide

Warning

Only

Lane Keeping Assist
Suspend Beep

Causes the system to beep when the LKAS is
suspended.

Off

Blind Spot Info

Changes the setting for the blind spot information.

Audible And Visual Alert

Visual Alert

Off

-------------------------------------------------------------------------------------------------------------------------------------------------------------

135

Gauges and Multi-Information Display (MID)

MID

Continued

strum

ent Pa

nel

*1:Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Meter Setup

Language Selection

Changes the displayed language.

English

Français

Español

Adjust Outside Temp.
Display

Adjusts the temperature reading by a few degrees.

-5°F

±0°F

+5°F

(U.S.)

-3°C

±0°C

+3°C

(Canada)

“Trip A” Reset Timing

Changes the setting of how to reset trip meter A,
average fuel economy A, average speed A, and
elapsed time A.

When Refueled

IGN Off

Manually Reset

“Trip B” Reset Timing

Changes the setting of how to reset trip meter B,
average fuel economy B, average speed B, and
elapsed time B.

When Refueled

IGN Off

Manually Reset

Reverse Alert Tone

Causes the beeper to sound once when the change
the gear position to

(

Off

Turn by Turn Display

Select whether the turn-by-turn display comes on
during the route guidance.

Off

-------------------------------------------------------------------------------------------------------------------------------------------------------------

136

Gauges and Multi-Information Display (MID)

MID

strum

ent Pa

nel

*1: Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Driving
Position
Setup

Memory Position Link

Turns the driving position memory system on and
off.

Off

Easy Entry/Exit

Moves the seat rearward and steering wheel fully up
when you get in/get out of the vehicle. Changes the
setting for this feature.

Seat & Steering Wheel

Seat Only

Steering Wheel

Only

Off

Keyless
Access Setup

Door Unlock Mode

Changes which doors unlock when you grab the
driver’s door handle.

Driver’s Door or Tailgate
Only

All Doors

Keyless Access Light
Flash

Causes some exterior lights to flash when you
unlock/lock the doors.

Off

Keyless Access Beep

Causes the beeper to sound when you unlock/lock
the doors.

Off

Remote Start System
On/Off

Turns the remote engine start feature on and off.

Off

Walk Away Auto Lock

Changes the settings for the automatic locking the
doors when you walk away from the vehicle while
carrying the keyless access remote.

Off

-------------------------------------------------------------------------------------------------------------------------------------------------------------

137

Gauges and Multi-Information Display (MID)

MID

Continued

strum

ent Pa

nel

*1: Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Lighting
Setup

Interior Light Dimming
Time

Changes the length of time the interior lights stay
on after you close the doors.

60sec

30sec

15sec

Headlight Auto Off
Timer

Changes the length of time the exterior lights stay
on after you close the driver’s door.

60sec

30sec

15sec

0sec

Auto Light Sensitivity

Changes the timing for the headlights to come on.

Max

High

Mid

Low

Min

Door Setup

Auto Door Lock

Changes the setting for when the doors
automatically lock.

With Vehicle Speed

Shift

From P

Off

Auto Door Unlock

Changes the setting for when the doors
automatically unlock.

All Doors When Driver’s
Door Opens

All Doors

When Shifted To Park

All

Doors When Ignition
Switched Off

Off

Key And Remote Unlock
Mode

Sets up either the driver’s door or all doors to unlock
on the first operation of the remote or built-in key.

Driver Door

All Doors

Keyless Lock Answer
Back

LOCK/UNLOCK- The exterior lights flash.
LOCK (2nd push)- The beeper sounds.

Off

Security Relock Timer

Changes the time it takes for the doors to relock and
the security system to set after you unlock the
vehicle without opening any door.

90sec

60sec

30sec

Auto Folding Door
Mirror

Changes how you can fold the door mirrors.

Auto Fold With Keyless

Manual Only

* Not available on all models

-------------------------------------------------------------------------------------------------------------------------------------------------------------

138

Gauges and Multi-Information Display (MID)

MID

strum

ent Pa

nel

*1: Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Power
Tailgate Setup

Keyless Open Mode

Changes the keyless setting for when the power
tailgate opens.

Anytime

When Unlocked

Power Open By Outer
Handle

Changes the setting to open power tailgate by
tailgate outer handle.

Off (Manual Only)

(Power/Manual)

Dynamic
Mode Setup

Preferred Dynamic
Mode

Changes the Dynamic Mode setting for when you
set the power mode to ON.

Last Used

Comfort

Normal

Sport

Maintenance
Info.

Maintenance Reset

Resets/Cancels the engine oil life display when you
have performed the maintenance service.

Cancel

Reset

Default All

—

Cancels/Resets all the customized settings as
default.

Cancel

Set

-------------------------------------------------------------------------------------------------------------------------------------------------------------

139

Gauges and Multi-Information Display (MID)

MID

Continued

strum

ent Pa

nel

■

Example of customization settings

The steps for changing the

“Trip A” Reset Timing

setting to

When Refueled

are

shown below. The default setting for

“Trip A” Reset Timing

Manually Reset

Roll the multi-function steering-wheel
controls to select

Vehicle Settings

, then

push the multi-function steering-wheel
controls.

Roll the multi-function steering-wheel
controls until

Meter Setup

appears on the

display.

Push the multi-function steering-wheel
controls.

Language Selection

appears first on

the display.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

140

Gauges and Multi-Information Display (MID)

MID

strum

ent Pa

nel

Roll the multi-function steering-wheel
controls until

“Trip A” Reset Timing

appears on the display, then push the multi-
function steering-wheel controls.

The display switches to the
customization setup screen, where you
can select

When Refueled

IGN Off

Manually Reset

, or

Exit

Roll the multi-function steering-wheel
controls and select

When Refueled

, then

push the multi-function steering-wheel
controls.

The

When Refueled Setup

screen

appears, then the display returns to the
customization menu screen.

Roll the multi-function steering-wheel
controls until

Exit

appears on the display,

then push the multi-function steering-
wheel controls.

Repeat Step 6 until you return to the
normal screen.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

142

Co
ntrols

Clock

Adjusting the Clock

The clock is automatically updated through the navigation system, so the time does
not need to be adjusted.
You can adjust the time manually in the information screen with the power mode in
ON.

■

Using the Settings menu on the information screen

Press the

SETTINGS

button.

Rotate

to select

Clock Settings

, then

press .

Repeat the procedure to select

Clock

Adjustment

Rotate

to change hour, then move

Rotate

to change minute, then press

■

Adjusting the Time

Clock

These indications are used to show how to operate
the interface dial.
Rotate

to select.

Press

enter.

Move

to select a secondary menu.

You can customize the clock display to show the 12
hour clock or 24 hour clock.

Customized Features

P. 362

You can turn the clock display in the information
screen on and off.

Customized Features

P. 362

You cannot adjust the time while the vehicle is
moving.

Except Canadian models

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Acura MDX HYBRID (2020 year). Manual in english - page 8
