IN CASE OF EMERGENCY

5. While holding the locking tab in the

disengaged position, pull the tether strap to

rotate the lever rearward, until it locks in place

pointing towards the driver's seat. Release the

locking tab and verify that the Manual Park

Release lever is locked in the released

position.

6. The vehicle is now out of PARK and can be

towed. Release the parking brake only when

the vehicle is securely connected to a tow

vehicle.

To Reset The Manual Park Release:
1. Push the locking tab to the right, to unlock the

lever.

2. Rotate the Manual Park Release lever forward

to its original position, until the locking tab

snaps into place to secure the lever.

3. Pull gently on the tether strap to confirm that

the lever is locked in its stowed position.

4. Re-install the access cover.

FREEING A STUCK VEHICLE

If your vehicle becomes stuck in mud, sand, or

snow, it can often be moved using a rocking

motion. Turn the steering wheel right and left to

clear the area around the front wheels. Then shift

back and forth between DRIVE (D) and REVERSE

(R), while gently pressing the accelerator. Use the

least amount of accelerator pedal pressure that

will maintain the rocking motion, without spinning

the wheels or racing the engine.
NOTE:



For trucks equipped with an 8–speed transmis

sion, shifts between DRIVE and REVERSE can

only be achieved at wheel speeds of 5 mph

(8 km/h) or less. Whenever the transmission

remains in NEUTRAL (N) for more than two

seconds, you must press the brake pedal to

engage DRIVE or REVERSE.



Push the ESC OFF button, to place the Electronic

Stability Control (ESC) system in “Partial Off”

mode, before rocking the vehicle

page 236.

Once the vehicle has been freed, push the ESC

OFF button again to restore ESC On mode.

WARNING!

Fast spinning tires can be dangerous. Forces

generated by excessive wheel speeds may cause

damage, or even failure, of the axle and tires. A

tire could explode and injure someone. Do not

spin your vehicle's wheels faster than 30 mph

(48 km/h) or for longer than 30 seconds

continuously without stopping when you are

stuck and do not let anyone near a spinning

wheel, no matter what the speed.

CAUTION!



Racing the engine or spinning the wheels may

lead to transmission overheating and failure.

Allow the engine to idle with the transmission

in NEUTRAL for at least one minute after every

five rocking-motion cycles. This will minimize

overheating and reduce the risk of transmis

sion failure during prolonged efforts to free a

stuck vehicle.



When “rocking” a stuck vehicle by shifting

between DRIVE and REVERSE, do not spin the

wheels faster than 15 mph (24 km/h), or

drivetrain damage may result.



Revving the engine or spinning the wheels too

fast may lead to transmission overheating and

failure. It can also damage the tires. Do not

spin the wheels above 30 mph (48 km/h)

while in gear (no transmission shifting occur

ring).

-------------------------------------------------------------------------------------------------------------------------------------------------------------

IN CASE OF EMERGENCY

299

TOWING A DISABLED VEHICLE

This section describes procedures for towing a disabled vehicle using a commercial towing service. If the transmission and drivetrain are operable, disabled

vehicles may also be towed as described

page 182.

Proper towing or lifting equipment is required to prevent damage to your vehicle. Use only tow bars and other equipment designed for this purpose, following

equipment manufacturer’s instructions. Use of safety chains is mandatory. Attach a tow bar or other towing device to main structural members of the vehicle,

not to fascia/bumpers or associated brackets. State and local laws regarding vehicles under tow must be observed.
If you must use the accessories (wipers, defrosters, etc.) while being towed, the ignition must be in the ON/RUN mode, not the ACC mode.
If the key fob is unavailable or the vehicle's battery is discharged,

page 297.

Towing Condition

Wheels OFF The

Ground

2WD Models

4WD Models

Flat Tow

NONE

If transmission is operable:



Transmission in NEUTRAL



30 mph (48 km/h) max speed



15 miles (24 km) max distance (six speed transmis

sion)



30 miles (48 km) max distance (eight speed transmis

sion)

Detailed instructions

page 182



Auto Transmission in PARK



Transfer Case in NEUTRAL



Tow in forward direction

Wheel Lift Or Dolly

Tow

Front

NOT ALLOWED

Rear

NOT ALLOWED

Flatbed

ALL

BEST METHOD

CAUTION!



Do not use sling type equipment when towing. Vehicle damage may occur.



When securing the vehicle to a flat bed truck, do not attach to front or rear suspension components. Damage to your vehicle may result from improper

towing.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

300

IN CASE OF EMERGENCY

(Continued)

-W

HEEL

RIVE

ODELS

FCA US LLC recommends towing your vehicle with

all four wheels OFF the ground using a flatbed.
If flatbed equipment is not available, and the

transmission is operable, the vehicle may be towed

(with the rear wheels on the ground) under the

following conditions:



The transmission must be in NEUTRAL

page 297.



The towing speed must not exceed 30 mph

(48 km/h).



The towing distance must not exceed 15 miles

(24 km) for six speed transmission, or 30 miles

(48 km) for eight speed transmission.

If the transmission is not operable, or the vehicle

must be towed faster than 30 mph (48 km/h) or

farther than 15 miles (24 km) for six speed

transmission, or 30 miles (48 km) for eight speed

transmission, tow with the rear wheels OFF the

ground. Acceptable methods are to tow the vehicle

on a flatbed, or with the front wheels raised and

the rear wheels on a towing dolly, or (when using a

suitable steering wheel stabilizer to hold the front

wheels in the straight position) with rear wheels

raised and the front wheels ON the ground.

OUR

-W

HEEL

RIVE

ODELS

FCA US LLC recommends towing with all wheels

OFF the ground. Acceptable methods are to tow

the vehicle on a flatbed or with one end of vehicle

raised and the opposite end on a towing dolly.
If flatbed equipment is not available, and the

transfer case is operable, the vehicle may be

towed (in the forward direction, with ALL wheels on

the ground), IF the transfer case is in NEUTRAL and

the transmission is in PARK

page 182.

MERGENCY

OOKS

—

QUIPPED

Your vehicle may be equipped with emergency tow

hooks. The tow hooks are located in the front lower

fascia/bumper.

Emergency Tow Hooks

NOTE:

For off-road recovery, it is recommended to use

both of the front tow hooks to minimize the risk of

damage to the vehicle.

CAUTION!

Towing this vehicle in violation of the above

requirements can cause severe engine and/or

transmission damage. Damage from improper

towing is not covered under the New Vehicle

Limited Warranty.

CAUTION!



Front or rear wheel lifts must not be used (if

the remaining wheels are on the ground).

Internal damage to the transmission or

transfer case will occur if a front or rear wheel

lift is used when towing.



Towing this vehicle in violation of the above

requirements can cause severe transmission

and/or transfer case damage. Damage from

improper towing is not covered under the New

Vehicle Limited Warranty.

CAUTION!

-------------------------------------------------------------------------------------------------------------------------------------------------------------

IN CASE OF EMERGENCY

301

ENHANCED ACCIDENT RESPONSE SYSTEM

(EARS)

This vehicle is equipped with an Enhanced

Accident Response System.
This feature is a communication network that

takes effect in the event of an impact

page 265.

EVENT DATA RECORDER (EDR)

This vehicle is equipped with an event data

recorder (EDR). The main purpose of an EDR is to

record data that will assist in understanding how a

vehicle’s systems performed under certain crash

or near crash-like situations, such as an air bag

deployment or hitting a road obstacle

page 267.

WARNING!



Do not use a chain for freeing a stuck vehicle.

Chains may break, causing serious injury or

death.



Stand clear of vehicles when pulling with tow

hooks. Tow straps may become disengaged,

causing serious injury.

CAUTION!

Tow hooks are for emergency use only, to rescue

a vehicle stranded off-road. Do not use tow

hooks for tow truck hookup or highway towing.

You could damage your vehicle.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

302

SERVICING AND MAINTENANCE

SCHEDULED SERVICING —

GASOLINE ENGINE

Your vehicle is equipped with an automatic oil

change indicator system. The oil change indicator

system will remind you that it is time to take your

vehicle in for scheduled maintenance.
Based on engine operation conditions, the oil

change indicator message will illuminate. This

means that service is required for your vehicle.

Operating conditions such as frequent short-trips,

trailer tow, extremely hot or cold ambient

temperatures, and E85 fuel usage will influence

when the “Oil Change Required” message is

displayed. Have your vehicle serviced as soon as

possible, within the next 500 miles (805 km).

An authorized dealer will reset the oil change

indicator message after completing the scheduled

oil change.
Under no circumstances should oil change

intervals exceed 8,000 miles (13,000 km),

12 months or 350 hours of engine run time,

whichever comes first. The 350 hours of engine

run or idle time is generally only a concern for fleet

customers.

Once A Month Or Before A Long Trip:



Check engine oil level.



Check windshield washer fluid level.



Check the tire inflation pressures and look for

unusual wear or damage. Rotate at the first sign

of irregular wear.



Check the fluid levels of the coolant reservoir,

brake master cylinder, power steering and auto

matic transmission (6-Speed only), and fill as

needed.



Check function of all interior and exterior lights.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SERVICING AND MAINTENANCE

303

AINTENANCE

LAN

Refer to the maintenance plan on the following pages for required maintenance. More frequent maintenance may be needed in severe conditions, such as dusty

areas and very short trip driving. In some extreme conditions, additional maintenance not specified in the maintenance schedule may be required.

NOTE:

Using white lithium grease, lubricate the door hinge pivot joints twice a year to prevent premature wear.

At Every Oil Change Interval As Indicated By Oil Change Indicator System:



Change oil and filter.



Rotate the tires at the first sign of irregular wear, even if it occurs before the oil indicator system turns on.



Inspect engine cooling system protection and hoses.



Inspect exhaust system.



Inspect engine air cleaner filter if using in dusty or off-road conditions. Replace the engine air cleaner filter, if necessary.



Inspect battery and clean and tighten terminals as required.



Inspect the CV/Universal joints.



Inspect automatic transmission fluid if equipped with dipstick.



Inspect brake pads, shoes, rotors, drums, hoses and parking brake.



Inspect front end, and lubricate — If equipped with serviceable fittings.



Inspect and replace the Evaporative System Fresh Air Filter as necessary, replacement may be more frequent if vehicle is operated in extreme dusty condi

tions.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

304

SERVICING AND MAINTENANCE

Mileage or time passed

(whichever comes first)

20,000

30,000

40,000

50,000

60,000

70,000

80,000

90,000

100,000

110,000

120,000

130,000

140,000

150,000

Or Years:

Or Kilometers:

32,000

48,000

64,000

80,000

96,000

112,000

128,000

144,000

160,000

176,000

192,000

208,000

224,000

240,000

Additional Inspections
Inspect the CV/Universal joints.

Inspect front suspension, tie rod ends, and

replace if necessary.

Inspect the front and rear axle surfaces. If gear

oil leakage is suspected, check the fluid level. If

using your vehicle for police, taxi, fleet, off-road

or frequent trailer towing, change axle fluid.

Inspect the brake linings, parking brake function.

Additional Maintenance
Replace the cabin air filter.

Replace the engine air cleaner filter.

Replace spark plugs.

Flush and replace the engine coolant at

10 years or 150,000 miles (240,000 km)

whichever comes first.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SERVICING AND MAINTENANCE

305

Change the automatic transmission fluid

(AS66RC Transmission Only).

Change the automatic transmission fluid and

sump filter (AS66RC Transmission Only).

Inspect the transfer case fluid, change for any of

the following: police, taxi, fleet, or frequent trailer

towing.

Change the transfer case fluid.

Inspect and replace PCV valve if necessary.

1. The spark plug change interval is mileage based only, yearly intervals do not apply.

Mileage or time passed

(whichever comes first)

20,000

30,000

40,000

50,000

60,000

70,000

80,000

90,000

100,000

110,000

120,000

130,000

140,000

150,000

Or Years:

Or Kilometers:

32,000

48,000

64,000

80,000

96,000

112,000

128,000

144,000

160,000

176,000

192,000

208,000

224,000

240,000

WARNING!



You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have

any doubt about your ability to perform a service job, take your vehicle to a competent mechanic.



Failure to properly inspect and maintain your vehicle could result in a component malfunction and effect vehicle handling and performance. This could cause

an accident.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

306

SERVICING AND MAINTENANCE

SCHEDULED SERVICING — DIESEL ENGINE

Required Maintenance Intervals
Refer to the maintenance plan on the following

pages for the required maintenance intervals.

More frequent maintenance may be needed in

severe conditions, such as dusty areas and very

short trip driving. In some extreme conditions,

additional maintenance not specified in the

maintenance schedule may be required.
At Each Stop For Fuel
Check the engine oil level at least 30 minutes after

a fully warmed engine is shut off. Checking the oil

level while the vehicle is on level ground will

improve the accuracy of the oil level reading. Add

oil only when the level is at or below the ADD or

MIN mark.

Once A Month



Inspect the batteries, and clean and tighten the

terminals as required.



Check the fluid levels of the coolant reservoir,

brake master cylinder, and automatic transmis

sion, and add as needed.

At Each Oil Change



Change the engine oil filter.



Inspect the exhaust system.



Inspect engine air cleaner filter. Replace the

engine air cleaner filter, if necessary.



Inspect the CV/Universal joints.



Check the coolant level, hoses, and clamps.



Inspect front end, and lubricate — If equipped

with serviceable fittings.



Inspect and replace the Evaporative System

Fresh Air Filter as necessary, replacement may

be more frequent if vehicle is operated in

extreme dusty conditions.

Inspection and service should also be performed

anytime a malfunction is observed or suspected.

Retain all receipts.
NOTE:

Using white lithium grease, lubricate the door

hinge pivot joints twice a year to prevent

premature wear.

HANGE

NDICATOR

YSTEM

—

UMMINS

® D

IESEL

Your vehicle is equipped with an engine oil change

indicator system. This system will alert you when it

is time to change your engine oil by displaying the

words “Oil Change Due” in your instrument cluster

display. The oil change reminder will remind the

owner to change the engine oil every 15,000 miles

(24,000 km) or 500 hours, whichever comes first,

except for the Chassis Cab models configured with

optional B20 capability that are using greater than

5% levels of biodiesel, which are 12,500 miles

(20,000 km) or 400 hours, whichever comes first.

Failure to change the engine oil per the

maintenance schedule can result in internal

engine damage.

CAUTION!

Failure to perform the required maintenance

items may result in damage to the vehicle.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SERVICING AND MAINTENANCE

307

An authorized dealer will reset the oil change

indicator message after completing the scheduled

oil change. If a scheduled oil change is performed

by someone other than an authorized dealer

page 78.

Replace the engine oil and oil filter every

15,000 miles (24,000 km) or 12 months, or

sooner if prompted by the oil change indicator

system. Under no circumstances should oil change

intervals exceed 15,000 miles (24,000 km) or

12 months, whichever comes first.

NOTE:



Under no circumstances should oil change inter

vals exceed 15,000 miles (24,000 km) or

12 months or 500 Hours, whichever comes

first.



Replace the engine oil and oil filter every

12,500 miles (20,000 km) or 400 hours, which

ever comes first when running greater than 5%

levels of biodiesel (Chassis Cab models config

ured with optional B20 capability).

If Chassis Cab models configured with optional

B20 capability are operated with greater than 5%

levels of biodiesel, the oil change interval must not

exceed 12,500 miles (20,000 km) or 400 hours,

whichever comes first under any circumstances.

See the Fuel Requirements section for more

information regarding operation with biodiesel

blend (B6-B20) fuel meeting ASTM specification

D-7467.

ERFORM

ERVICE

NDICATOR

—

UMMINS

® D

IESEL

Your vehicle will require emissions maintenance at

a set interval. To help remind you when this

maintenance is due, the instrument cluster will

display “Perform Service”. When the “Perform

Service” message is displayed on the instrument

cluster it is necessary to have the emissions

maintenance performed. Emissions maintenance

may include replacing the Closed Crankcase

Ventilation (CCV) filter element. The procedure for

clearing and resetting the “Perform Service”

indicator message is located in the appropriate

Service Information.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

308

SERVICING AND MAINTENANCE

AINTENANCE

LAN

— C

UMMINS

® D

IESEL

NGINE

Mileage or time passed

(whichever comes first):

500

15,000

22,500

30,000

37,500

45,000

52,500

60,000

67,500

75,000

82,500

90,000

97,500

105,000

112,500

120,000

127,500

135,000

142,500

150,000

Or Months:

12 18 24 30 36 42 48 54 60 66 72 78 84 90 96 102 108 114 120

Or Kilometers:

12,000

24,000

36,000

48,000

60,000

72,000

84,000

96,000

108,000

120,000

132,000

144,000

156,000

168,000

180,000

192,000

204,000

216,000

228,000

240,000

Change engine oil every 15,000 miles

(24,000 km) or 12 months or 500

hours or sooner if prompted by the oil

change indicator system, whichever
comes first.

Additional Inspections
Check the Diesel Exhaust Fluid (DEF)

tank, refill if necessary.

Rotate the tires.

Inspect the CV/Universal joints.

Inspect front end, and lubricate — If

equipped with serviceable fittings.

Inspect engine air cleaner filter,
replace if necessary.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SERVICING AND MAINTENANCE

309

Inspect the front suspension, tie rod

ends and boot seals for cracks or

leaks and all parts for damage, wear,

improper looseness or end play;

replace if necessary.

Inspect the brake linings.

Inspect and adjust parking brake.

Inspect drive belt; replace as

necessary.

Inspect wheel bearings.

Additional Maintenance
Replace the cabin air filter.

Replace the engine fuel filter.

Replace the chassis mounted fuel

filter.

Inspect the front and rear axle surfaces. If gear oil leakage is suspected, check the fluid level. If using your vehicle for police, taxi, fleet, off-road or frequent
trailer towing change the axle fluid.

Mileage or time passed

(whichever comes first):

500

15,000

22,500

30,000

37,500

45,000

52,500

60,000

67,500

75,000

82,500

90,000

97,500

105,000

112,500

120,000

127,500

135,000

142,500

150,000

Or Months:

12 18 24 30 36 42 48 54 60 66 72 78 84 90 96 102 108 114 120

Or Kilometers:

12,000

24,000

36,000

48,000

60,000

72,000

84,000

96,000

108,000

120,000

132,000

144,000

156,000

168,000

180,000

192,000

204,000

216,000

228,000

240,000

-------------------------------------------------------------------------------------------------------------------------------------------------------------

310

SERVICING AND MAINTENANCE

Inspect the transfer case fluid (4x4),

change for any of the following:

police, taxi, fleet, or frequent trailer

towing.

Change the transfer case fluid (4x4).

Change automatic transmission fluid

(AS69RC transmission only).

Change the automatic transmission

fluid and sump filter (AS69RC

transmission only).

Change automatic transmission fluid

and filter(s) (AS69RC transmission

only).

Replace Crankcase Ventilation Filter

(CCV).

Mileage or time passed

(whichever comes first):

500

15,000

22,500

30,000

37,500

45,000

52,500

60,000

67,500

75,000

82,500

90,000

97,500

105,000

112,500

120,000

127,500

135,000

142,500

150,000

Or Months:

12 18 24 30 36 42 48 54 60 66 72 78 84 90 96 102 108 114 120

Or Kilometers:

12,000

24,000

36,000

48,000

60,000

72,000

84,000

96,000

108,000

120,000

132,000

144,000

156,000

168,000

180,000

192,000

204,000

216,000

228,000

240,000

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SERVICING AND MAINTENANCE

311

Inspection and service should also be performed anytime a malfunction is observed or suspected. Retain all receipts.

Flush and replace power steering fluid.

Flush and replace engine coolant. ***

1. Under no circumstances should oil change intervals exceed 15,000 miles (24,000 km) or 12 months or 500 Hours, whichever comes first.

2. Under no circumstances should the engine air cleaner filter exceed 30,000 miles (48,000 km) or 24 months, whichever comes first.

3. Inspect the front and rear axle surfaces every 20,000 miles (32,000 km). If gear oil leakage is suspected, check the fluid level. If using your vehicle for police, taxi, fleet, off-road or

frequent trailer towing change the axle fluid every 20,000 miles (32,000 km).

Mileage or time passed

(whichever comes first):

500

15,000

22,500

30,000

37,500

45,000

52,500

60,000

67,500

75,000

82,500

90,000

97,500

105,000

112,500

120,000

127,500

135,000

142,500

150,000

Or Months:

12 18 24 30 36 42 48 54 60 66 72 78 84 90 96 102 108 114 120

Or Kilometers:

12,000

24,000

36,000

48,000

60,000

72,000

84,000

96,000

108,000

120,000

132,000

144,000

156,000

168,000

180,000

192,000

204,000

216,000

228,000

240,000

WARNING!



You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have

any doubt about your ability to perform a service job, take your vehicle to a competent mechanic.



Failure to properly inspect and maintain your vehicle could result in a component malfunction and effect vehicle handling and performance. This could cause

an accident.

CAUTION!

***The manufacturer highly recommends that all cooling system service, maintenance, and repairs be performed by an authorized dealer.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

RAM Chassis Cab (2021 year). Manual in english - page 19
