373

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

■

To make a call using the call history

Call history is stored by All, Dialed, Missed,
and Received.
1. Go to the phone screen.

2 Phone screen P. 362

2. Select Recents.

u

You can sort by All, Dialed, Missed, or
Received. Select the icon on the upper
right of the screen.

3. Select a number.

u

Dialing starts automatically.

■

To make a call using a Favorite Contact
entry

1. Go to the phone screen.

2 Phone screen P. 362

2. Select desired favorite contact.

u

Dialing starts automatically.

19 ACURA RDX-31TJB6000.book  373 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

374

Features

When there is an incoming call, an audible
notification sounds (if activated) and the
Incoming Call... screen appears.

Move the left selector wheel to the right to
answer the call. Move it to the left to decline
or end the call.

u

You can also select Answer or Ignore
on the audio/information screen to use
hands-free calling.

■

Receiving a Call

1

Receiving a Call

Call Waiting
To put a call on hold so that you can answer an
incoming call, move the left selector wheel to the
right.
Move the left selector wheel to the right to resume
the call.

Select Ignore to ignore the incoming call if you do
not want to answer it.
Move the left selector wheel to the left to end a call.

Instead of using the selector wheel, you can use the
icons on the audio/information screen to perform the
above mentioned functions.

When a screen other than the phone screen is
displayed in the primary information area, the
incoming call screen is displayed in the secondary
information area.

19 ACURA RDX-31TJB6000.book  374 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

375

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

The following options are available during a call.
MUTE: Mute your voice.
TRANSFER TO MOBILE: Transfer a call from the system to your phone.
ENTER NUMBER: Send numbers during a call. This is useful when you call a menu-
driven phone system.

The available options are shown on the lower
half of the screen.

Select the option.

u

UNMUTE is displayed when the mute
function is on. Select UNMUTE to turn it
off.

u

TRANSFER TO VEHICLE is displayed
when the hands-free mode is off. Select
TRANSFER TO VEHICLE to turn the
hands-free mode is on.

■

Options During a Call

1

Options During a Call

You can select the icons on the audio/information
screen.

19 ACURA RDX-31TJB6000.book  375 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

376

uu

Bluetooth® HandsFreeLink®

u

Text Message

Features

Text Message

You can operate the various options of the text message function from the message
box.

1. Press the

 (home) button.

2. Select Messages.

The following options are available:
Inbox: Shows received messages.
Send Message to Contact: Sends a message
to your contact on the list.

2 Send Message to Contact P. 386

Add Favorite: Adds the favorite contact to
the message box.

u

You can add a shortcut to the home
screen that will take you directly to your
favorite contact. Select and hold the
contact, then select Add to Home
Page.

MENU: Sets the message option for changing
the connected device, turning on or off
message notifications, or editing replies.

1

Text Message

The text message features may not be available
depending on a cellular phone.

19 ACURA RDX-31TJB6000.book  376 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

377

uu

Bluetooth® HandsFreeLink®

u

Text Message

Continued

Features

■

To edit a Favorite Contact

1. Press the

 (home) button.

2. Select Messages.
3. Select and hold a desired favorite contact.
4. Select following options.

• Remove Favorite: Delete a favorite

contact.

• Add to Home Page: Add the shortcut

icon of a favorite contact to the home
screen.

5. Press the

 (back) button on the true

touchpad A.

u

The screen will return to the previous
screen.

19 ACURA RDX-31TJB6000.book  377 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Bluetooth® HandsFreeLink®

u

Text Message

378

Features

■

To turn on or off the text message
notice

1. Press the

 (home) button.

2. Select Messages.
3. Select MENU.
4. Select Notifications.
5. Select On or Off.

■

To Set Up Text Message Options

1

To Set Up Text Message Options

To use the text message function, it may be necessary
to set up on your phone.

1

To turn on or off the text message notice

On: A pop-up notification comes on every time you
receive a new message.
Off: The message you receive is stored in the system
without notification.

When a screen other than the Messages function
screen is displayed in the primary information area, a
text message notification is displayed in the
secondary information area.

19 ACURA RDX-31TJB6000.book  378 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

Continued

379

uu

Bluetooth® HandsFreeLink®

u

Text Message

Features

HFL can display newly received text messages as well as the last 20 messages
received on a linked cell phone. Each received message can be read aloud and
replied to using a fixed common phrase.

1. A pop-up appears and notifies you of a new

text message.

2. Select Open.
3. Select

 to listen to the message. To stop

listening to the message, select

.

u

Select

 to hear the message from the

beginning.

■

Receiving a Text Message

1

Receiving a Text Message

Some cell phones might not be able to read the
transmission log of data sent and data received.

The system does not display any received messages
while you are driving. You can only hear them read
aloud.

The system can only receive messages that are sent a
text (SMS) messages. The message sent using the
data services will not be displayed in the list.

With some phones, you may be able to display up to
20 of the last text messages received.

State or local laws may limit your use of the HFL text
message feature. Only use the text message feature
when conditions allow you to do so safely.

Depending on the status of primary information area,
the received message screen may be displayed on the
secondary information area.

19 ACURA RDX-31TJB6000.book  379 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Bluetooth® HandsFreeLink®

u

Text Message

380

Features

You can select one from the Bluetooth® device list to be active and receive
notifications.

1. Press the

 (home) button.

2. Select Messages.
3. Select MENU.
4. Select Change Connected Phone.
5. Change a desired phone.

2 To change the currently paired phone

P. 366

■

Selecting a Phone

1

Selecting a Phone

You can only receive notifications from one phone at
a time.

You can only connect one device to use both text
message function and Bluetooth® hands-free phone
function.

19 ACURA RDX-31TJB6000.book  380 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

Continued

381

uu

Bluetooth® HandsFreeLink®

u

Text Message

Features

1. Press the

 (home) button.

2. Select Messages.
3. Select Inbox.
4. Select a message.

u

The message information is displayed.

5. Select View Message.

u

The text message is displayed.

■

Displaying Messages

1

Displaying Messages

The

 icon appears next to an unread message.

If you delete a message on the phone, the message
will also be deleted from the system. If you send a
message from the system, the message goes to your
phone’s outbox.

To see the previous or next message, select Prev or
Next on the message screen.

Message List

Message
Information

19 ACURA RDX-31TJB6000.book  381 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Bluetooth® HandsFreeLink®

u

Text Message

382

Features

■

Read or Stop reading a message

1. Display the message information.
2. Select .

u

The system starts reading the message
aloud.

3. Select

 to stop reading.

Select

 again to start reading the

message.

u

While listen to the message, select

 to

start reading the message from the
beginning.

■

Reply to a message

1. Display the message information.
2. Select Reply.
3. Select the reply message.

u

The pop-up menu appears on the screen.

4. Select Send to send the message.

u

Message sent appears on the screen
when the reply message was successfully
sent.

1

Reply to a message

The available reply messages are as follows:

•

I’m on my way.

•

I’m running late.

•

No

•

OK

•

Talk to you later, I'm driving.

•

Yes

The display language of the default reply message
depends on the connected phone.

2 To edit a reply message P. 383

You can add a reply message by selecting Create
New Message.

2 To edit a reply message P. 383

Only certain phones receive and send messages when
paired and connected. For a list of compatible
phones:

•

U.S.: Visit www.handsfreelink.com/Acura, or call 1-
888-528-7876.

•

Canada: For more information on smartphone
compatibility, call 1-888-528-7876.

19 ACURA RDX-31TJB6000.book  382 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

Continued

383

uu

Bluetooth® HandsFreeLink®

u

Text Message

Features

■

To edit a reply message

1. Press the

 (home) button.

2. Select Messages.
3. Select MENU.
4. Select Saved Replies.
5. Select Create New Message.
6. Use true touchpad A to write a reply. When

you finish writing you message, press the
true touchpad.

u

You can enter the number using the on-
screen keyboard. Select KEYBOARD
located to the upper right of the screen.

■

To delete a reply message

1. Press the

 (home) button.

2. Select Messages.
3. Select MENU.
4. Select Saved Replies.
5. Select a reply message you want to delete.

u

A confirmation screen appears on the
screen. Select Delete.

u

To cancel the delete, press the



(back) button.

1

To delete a reply message

Reset to Default
Select to reset all reply messages to their factory
default.

19 ACURA RDX-31TJB6000.book  383 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

384

uu

Bluetooth® HandsFreeLink®

u

Text Message

Features

■

Making a call to a sender

1. Display the message information.
2. Select Call.

19 ACURA RDX-31TJB6000.book  384 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

385

uu

Bluetooth® HandsFreeLink®

u

Text Message

Continued

Features

■

Displaying message on the head-up display

You can read a text message on the head-up display only when text message is
received.
1. Move right the left selector wheel to select Open.
2. Roll up or down the left selector wheel to select Reply, and then press the left

selector wheel.

u

Select Call to dialing a call.

u

Select Play to start reading the message from the beginning. Select Stop to
stop reading.

3. Roll up or down the left selector wheel to select a message, and then press the

left selector wheel.

4. Roll up or down the left selector wheel to select Send, and then press the left

selector wheel.

u

Message sent appears on the head-up display when the reply message was
successfully sent.

Models with head-up display

19 ACURA RDX-31TJB6000.book  385 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Bluetooth® HandsFreeLink®

u

Text Message

386

Features

1. Press the

 (home) button.

2. Select Messages.
3. Select Send Message to Contact.
4. Select a contact name.

u

You can sort by First Name or Last
Name. Select the icon on the upper right
of the screen.

5. Select a number.
6. Select the reply message.

u

The pop-up menu appears on the screen.

7. Select Send to send the message.

u

Message sent appears on the screen
when the reply message was successfully
sent.

■

Send Message to Contact

1

Send Message to Contact

You can make a call or set a navigation route

*

 to

contact address other than sending a message on this
feature.

2 Making a Call P. 371
2 Refer to Navigation System Manual

* Not available on all models

19 ACURA RDX-31TJB6000.book  386 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

387

Continued

Features

AcuraLink®

Is a subscription-based service that provides convenient features such as voice
communication in case of emergency, online security, one-on-one operator
assistance, and the transmission of important messages regarding your vehicle’s
status.

Use the following procedure to connect to AcuraLink.

■

To enable the AcuraLink

You need to allow the consent of the location service to enable the AcuraLink.

1. Press the

 (home) button.

2. Select AcuraLink.

u

The confirmation message appears on
the screen for the first time, then select
Allow.

■

To Connect to AcuraLink

1

AcuraLink®

AcuraLink also provides services you can operate
from the Internet or your smartphone.

To subscribe to AcuraLink, or to get more
information about all of its features, contact an Acura
dealer, or visit owners.acura.com (U.S.) or
www.acura.ca/owners/acuralink (Canada).

1

To enable the AcuraLink

You can also set up a Vehicle Data Collection by
the following procedure.
1. Press the

 (home) button.

2. Select AcuraLink.
3. Select MENU.
4. Select Vehicle Data Collection.
5. Select Allow or Block.

•

Allow: Sends the vehicle location data, diagnostic
information, driving behavior data and phone data
when you have previously allowed it when you
connect a phone with Bluetooth®.

•

Block: Does not send the vehicle location data,
diagnostic information, driving behavior data.

For detail information of all data shared visit https://
acuralink.acura.com/#/acuralinkLegalTerms

19 ACURA RDX-31TJB6000.book  387 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

AcuraLink®

u

388

Features

■

To link with AcuraLink

You may see the connection guide screen
after launching AcuraLink when there is no
phone connection available.

Continue Without Connecting: Displays
the AcuraLink menu screen without phone
connection.
Connect Phone: Displays the Bluetooth®
setup screen.

2 To change the currently paired phone

P. 366

1. Press the

 (home) button.

2. Select AcuraLink.

1

To link with AcuraLink

We recommend that you install AcuraLink app in
your smartphone to make AcuraLink more
functional, contact an Acura dealer, or visit
owners.acura.com (U.S.) or www.acura.ca/owners/
acuralink (Canada).

If you do not connect a phone to AcuraLink, Last Mile
function of AcuraLink app is disabled.

■

AcuraLink

1

AcuraLink

You can also select AcuraLink from the All Apps
screen.

2 Audio/Information Screen P. 249

AcuraLink

19 ACURA RDX-31TJB6000.book  388 ページ  ２０１８年４月２６日　木曜日　午後４時５１分
