Acura RDX (2019 year). Manual - part 23

357

uu

HomeLink® Universal Transceiver

u

Training HomeLink

Features

■

Programming a Button

1

Training HomeLink

Reprogramming a Button
If you want to retrain a programmed button for a
new device, you do not have to erase all button
memory. You can replace the existing memory code
using this procedure:

Erasing Button Memory
To erase programming from the buttons, press and hold
the two outside HomeLink buttons until the HomeLink
indicator changes from orange to rapidly flashing green.
This should take about 10 seconds. You should erase all
programming before selling the vehicle.

Operating
To operate, simple press and release the
programmed HomeLink button. Activation will now
occur for the trained device.

Questions
For questions or comments, visit
www.HomeLink.com, www.youtube.com/
HomeLinkGentex, or by calling the HomeLink Hotline
(North America only) at (800) 355-3515.

HomeLink® is a registered trademark of Gentex
Corporation.

2.

1. Press and hold the desired HomeLink button until

the HomeLink indicator begins to slowly flash
orange. This should take about 20 seconds.

Release the HomeLink button and position the
remote transmitter you wish to link 1 - 3 inches
(3 - 8 cm) from the HomeLink button you want to
program, then follow steps 3 - 6 under
“programming a button.”

Training
Complete

HomeLink LED is
continuously on green.

YES

YES

1. Position the remote transmitter you wish to link 1 to 3 inches (3 - 8 cm) from the

HomeLink® button you want to program.

3b. Canadian Garage Door Opener

A. Press and release the HomeLink
button. Press, hold and release the
button on the remote every 2 secs.
Does the HomeLink indicator (LED)
change from slowly flashing orange to
rapidly flashing or continuously on
green? The process should take less
than 60 seconds.

NO

2. Press and release the desired HomeLink button. Is the HomeLink indicator (LED) slowly

flashing orange?

NO

3a. Hold the button on the remote

transmitter. Does HomeLink indicator
(LED) change from slowly flashing
orange to rapidly flashing green or
continuously on green? The process
should take less than 60 seconds.

5. Press and hold the HomeLink button again.

HomeLink indicator rapidly flashes
green.

5a. The remote has a rolling code. Press the

“learn” button on the remote-controlled
device (e.g. garage door opener).

6. Press and hold the HomeLink button

again.
The remote-controlled device should
operate.

Training Complete

5b. Within 30 secs, press and hold the

programmed HomeLink button for 2
secs.

4. Press and hold the programmed HomeLink

button for about a second. Does the device
(garage door opener) work?

19 ACURA RDX-31TJB6000.book  357 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

358

Features

Bluetooth® HandsFreeLink®

Bluetooth® HandsFreeLink® (HFL) allows you to place and receive phone calls using
your vehicle’s audio system, without handling your cell phone.

Using HFL

■

HFL Buttons

1

Bluetooth® HandsFreeLink®

Place your phone where you can get good reception.

To use HFL, you need a Bluetooth-compatible cell
phone. For a list of compatible phones, pairing
procedures, and special feature capabilities:

•

U.S.: Visit www.handsfreelink.com/Acura, or call 1-
888-528-7876.

•

Canada: For more information on smartphone
compatibility, call 1-888-528-7876.

To use the system, the Bluetooth® setting must be
On.

2 Phone Setup P. 364

Voice control tips

•

Aim the vents away from the ceiling and close the
windows, as noise coming from them may interfere
with the microphones.

•

Press the

 button when you want to call a

number using a phonebook name or a number.
Speak clearly and naturally after a beep.

•

If the microphone picks up voices other than yours,
the command may be misinterpreted.

•

To change the volume level, select the audio
system’s VOL (Volume) or use the remote audio
controls on the steering wheel.

 (Talk) Button

Microphone

 (Back) Button

VOL

(

+/VOL

(

- (Volume) Switch

Left Selector Wheel

APPS Button

19 ACURA RDX-31TJB6000.book  358 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

Continued

359

uu

Bluetooth® HandsFreeLink®

u

Using HFL

Features

Left Selector Wheel:
• Incomming call: Move the selector wheel to the right to answer the call. Move it

to the left to decline the call.

• During a call: Move the selector wheel to the right to display the call options

menu. Move it to the left to end the call.

•

 (back) button: Press the button to go back to the previous screen or to

cancel a command.

•

 (talk) button: Press the button to start voice recognition.

To go to the phone screen of the multi-information display or the head-up display

*

:

1. Press the APPS button on the steering wheel.
2. Using the selector wheel, scroll to Phone on the multi-information display or the

head-up display

*

, and then press the left selector wheel.

u

You can select Favorites or Recents by moving the selector wheel to the left
or the right.

1

Bluetooth® HandsFreeLink®

Bluetooth® Wireless Technology
The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc., and any
use of such marks by Honda Motor Co., Ltd., is under
license. Other trademarks and trade names are those
of their respective owners.

HFL Limitations
An incoming call on HFL will interrupt the audio
system when it is playing. It will resume when the call
is ended.

* Not available on all models

19 ACURA RDX-31TJB6000.book  359 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Bluetooth® HandsFreeLink®

u

Using HFL

360

Features

The audio/information screen notifies you when there is an incoming call.

Bluetooth® connection status is displayed in the secondary information area.

■

HFL Status Display

1

HFL Status Display

The information that appears on the audio/
information screen varies between phone models.

HFL Mode

Caller’s Name (If registered)/
Caller’s Number (If not registered)

Bluetooth Indicator
Appears when your phone is connected to HFL.

Signal Strength

Battery Level Status

19 ACURA RDX-31TJB6000.book  360 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

361

uu

Bluetooth® HandsFreeLink®

u

Using HFL

Features

Certain manual functions are disabled or inoperable while the vehicle is in motion.
You cannot select a grayed-out option until the vehicle is stopped.

■

Limitations for Manual Operation

*

* Not available on all models

19 ACURA RDX-31TJB6000.book  361 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

362

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

HFL Menus

The power mode must be in ACCESSORY or ON to use the system.

■

Phone screen

1. Press the

 (home) button.

2. Select Phone.

1

HFL Menus

To use HFL, you must first pair your Bluetooth-
compatible cell phone to the system while the vehicle
is parked.

Some functions are limited while driving.

Display the last outgoing, incoming and missed calls.

Recents

All

Dialed

Received

Display the last outgoing calls.

Display the last incoming calls.

Missed

Display the last missed calls.

Enter Number

Enter a phone number to dial.

Contacts

Display the phonebook of the paired phone.

Add Favorite

(Favorite Contact List)

MENU

From Recents

From Contacts

Using Enter Number

Dial the selected number in the favorite contact list.

Display the Phone Menu screen.

Select a phone number from the call history to store as a
favorite contact number.
Select a phone number from the phonebook to store as a
favorite contact number.
Enter a phone number to store as a favorite contact number.

19 ACURA RDX-31TJB6000.book  362 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

363

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

■

Phone Menu screen

1. Press the

 (home) button.

2. Select Phone.
3. Select MENU.

Change Connected Phone

(Existing entry list)

+ Connect New Device

Pair a new phone to the system.

Connect or disconnect a paired device.

Ringtone

Select the ring tone.

Auto Sync Phone

Set phonebook and call history data to be automatically imported when a phone is paired to HFL.

Auto Phone Call Transfer

Set calls to automatically transfer from your phone to HFL when you enter the vehicle.

AcuraLink Assist

Turn AcuraLink Assist on and off.

Options

Delete Device

Automatically

Download Updates

Delete a paired device.

Turn automatic download
function of the software
on and off.

19 ACURA RDX-31TJB6000.book  363 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

364

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

■

Bluetooth® setup

You can turn Bluetooth® function on and off.
1. Press the

 (home) button.

2. Select Settings.
3. Select Connections.
4. Select Bluetooth.
5. Select Options.
6. Select On.

■

Phone Setup

19 ACURA RDX-31TJB6000.book  364 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

Continued

365

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

■

To pair a cell phone (when there is no
phone paired to the system)

1. Press the

 (home) button.

2. Select Phone.
3. Select Connect Phone.
4. Make sure your phone is in search or

discoverable mode, then select + Connect
New Device.

u

HFL automatically searches for a
Bluetooth® device.

5. Select your phone when it appears on the

list.

u

If your phone still does not appear,
search for Bluetooth® devices using your
phone.
From your phone, search for
HandsFreeLink.

6. The system gives you a pairing code on the

audio/information screen.

u

Confirm if the pairing code on the screen
and your phone match.
This may vary by phone.

7. Select desired functions and then select

Connect.

u

The pop-up menu appears on the screen,
if the internet wireless hotspot function
is selected.

1

Phone Setup

Your Bluetooth-compatible phone must be paired to
the system before you can make and receive hands-
free calls.

Phone Pairing Tips:

•

You cannot pair your phone while the vehicle is
moving.

•

Up to six phones can be paired.

•

Your phone’s battery may drain faster when it is
paired to the system.

Once you have paired a phone, you can see it
displayed on the screen with one or more icons on
the right side.
These icons indicate the following:

: The phone is compatible with Bluetooth® Audio.
: The phone can be used with HFL.

: The phone can be used with internet wireless

hotspot.

If there is an active connection to Apple CarPlay
pairing of additional Bluetooth® compatible devices is
unavailable.

Enable Smart Sharing pop-up
Smart Sharing to share phone data with Acura, you
can change the setting later by deleting the device in
Phone Menu.
For detail information of all data shared visit https://
acuralink.acura.com/#/acuralinkLegalTerms

19 ACURA RDX-31TJB6000.book  365 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

366

Features

■

To change the currently paired phone

1. Go to the Phone Menu screen.

2 Phone Menu screen P. 363

2. Select Change Connected Phone.

When connecting to other phone:
3. Select a phone to connect.
4. Select ,

or  .

5. Select Connect.

When changing the currently paired phone
setting:
3. Select a currently paired phone.
4. Select ,

or  .

5. Select Apply Changes.

1

To change the currently paired phone

If no other phones are found or paired when trying to
switch to another phone, HFL will continue to
connect a original phone.

To pair other phones, select + Connect New Device
from the Bluetooth screen.

19 ACURA RDX-31TJB6000.book  366 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

Continued

367

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

■

To delete a paired phone

1. Go to the Phone Menu screen.

2 Phone Menu screen P. 363

2. Select Change Connected Phone.
3. Select a phone you want to delete.

4. Select Options.
5. Select Delete Device.
6. A confirmation message appears on the

screen. Select Delete.

1

To delete a paired phone

You can also delete a paired phone by the following
procedure.
1. Press the

 (home) button.

2. Select Settings.
3. Select Connections.
4. Select Bluetooth.
5. Select a phone you want to delete.
6. Select Options.
7. Select Delete Device.
8. A confirmation message appears on the screen.

Select Delete.

19 ACURA RDX-31TJB6000.book  367 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

368

Features

You can change the ring tone setting.

1. Go to the Phone Menu screen.

2 Phone Menu screen P. 363

2. Select Ringtone.
3. Select Vehicle or Phone.

If you get into the vehicle while you are on the phone, the call can be automatically
transferred to HFL.

1. Go to the Phone Menu screen.

2 Phone Menu screen P. 363

2. Select Auto Phone Call Transfer.
3. Select On or Off.

■

Ring Tone

1

Ring Tone

Vehicle: The fixed ring tone sounds from the
speakers.
Phone: Depending on the make and model of the
cell phone, the ring tone stored in the phone will
sound if the phone is connected.

■

Automatic Transferring

19 ACURA RDX-31TJB6000.book  368 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

Continued

369

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

■

When Auto Sync Phone is set to On:

When your phone is paired, the contents of its
phonebook and call history are automatically
imported to the system.

■

Changing the Auto Sync Phone setting

1. Go to the Phone Menu screen.

2 Phone Menu screen P. 363

2. Select Auto Sync Phone.
3. Select On or Off.

■

Automatic Import of Cellular Phonebook and Call History

1

Automatic Import of Cellular Phonebook and Call History

On some phones, it is necessary to set up it enabled
to be imported the cellular phonebook.

When you select a name from the list in the cellular
phonebook, you can see a category icon. The icons
indicate what types of numbers are stored for that
name.

On some phones, it may not be possible to import the
category icons to the system.

The phonebook is updated after every connection.
Call history is updated after every connection or call.

Home

Mobile

Work

Other

Pager

Car

Preference

Fax

Voice

19 ACURA RDX-31TJB6000.book  369 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

370

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

To store a favorite contact number:
1. Go to the phone screen.

2 Phone screen P. 362

2. Select Add Favorite.

3. Select a place from where to choose a

number.
From Recents:

u

Select a number from the call history.

From Contacts:

u

Select a number from the phonebook of
a cellular phone connected to the
system.

Using Enter Number:

u

Trace the number on true touchpad A,
then press it.
If the KEYPAD icon located to the upper
right of the screen is selected, the
keyboard will appear.

4. Select a number.

■

Favorite Contacts

19 ACURA RDX-31TJB6000.book  370 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

Continued

371

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

■

To edit a Favorite Contact

1. Go to the phone screen.

2 Phone screen P. 362

2. Select and hold a desired favorite contact.
3. Select the following options:

• Remove Favorite: Delete the favorite

contact.

• Add to Home Page: Add a favorite

contact shortcut icon to the home
screen.

• Add to Heads-Up Display

*

: Add a

favorite contact shortcut icon to the
head-up display menu.

4. Press the

 (back) button on the true

touchpad A.

u

The screen will return to the previous
screen.

You can make calls by inputting any phone
number, or by using the imported
phonebook, call history, or Favorite Contact
entries.

■

Making a Call

1

Making a Call

Once a call is connected, you can hear the voice of
the person you are calling through the audio
speakers.

While there is an active connection with Apple
CarPlay, phone calls cannot be made with
HandsFreeLink® and are only made from Apple
CarPlay.

* Not available on all models

19 ACURA RDX-31TJB6000.book  371 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

372

Features

■

To make a call using the imported
phonebook

1. Go to the phone screen.

2 Phone screen P. 362

2. Select Contacts.
3. Select a name.

u

You can sort by First Name or Last
Name. Select the icon on the upper right
of the screen.

4. Select a number.

u

Dialing starts automatically.

■

To make a call using a phone number

1. Go to the phone screen.

2 Phone screen P. 362

2. Select Enter Number.
3. Trace the number on true touchpad A, then

press it.

u

You can enter the number using the on-
screen keyboard. Select KEYPAD located
to the upper right of the screen.

4. Press the true touchpad A.

u

Dialing starts automatically.

u

If the on screen keyboard is displayed,
select Call.

1

To make a call using the imported phonebook

You can send a message or set a navigation

*

 route to

contact address other than making a call on this
feature.

2 Text Message P. 376
2 Refer to Navigation System Manual

* Not available on all models

19 ACURA RDX-31TJB6000.book  372 ページ  ２０１８年４月２６日　木曜日　午後４時５１分
