Acura RDX (2019 year). Manual - part 11

165

uu

Opening and Closing the Tailgate

u

Opening/Closing the Power Tailgate

Continued

Co
ntrols

Opening/Closing the Power Tailgate

Use a forward and back kicking motion under
the center of the rear bumper to open or close
the power tailgate while carrying the keyless
access remote.

u

Some exterior lights flash twice and a
beeper sounds once, then the tailgate
begins to move.

■

Using the Hands Free Access

*

1

Opening/Closing the Power Tailgate

During rain or in other instances when the vehicle
becomes wet, the sensor may not properly detect
your foot motion.

When performing work on or around the rear section
of the vehicle, you may inadvertently open or close
the tailgate.
To prevent this from happening, select Customized
Features on the audio/information screen and then
select OFF for the feature.

2 Customized Features P. 332

If you hold your foot under the bumper for too long,
the power tailgate does not open or close.

This function will not operate if you don’t have the
keyless access remote on you. Please make sure you
have the keyless access remote on you.

The duration of the kicking motion should be
approximately one second.

Models with Hands Free Access

1 sec.

* Not available on all models

19 ACURA RDX-31TJB6000.book  165 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Opening and Closing the Tailgate

u

Opening/Closing the Power Tailgate

166

Co
ntrols

Press the power tailgate button for more than
one second to operate when the power mode
is in VEHICLE OFF (LOCK).

u

Some exterior lights flash and the beeper
sounds.

If you press the button again while the power
tailgate is moving, it will stop.
Press the button for more than one second,
and the power tailgate will reverse direction.

■

Customizing when to open the tailgate

Anytime: The power tailgate unlocks and opens at the same time. This is the
default setting.
When Unlocked: The tailgate opens when all doors are unlocked.

2 Customized Features P. 332

■

Using the Remote Transmitter

1

Opening/Closing the Power Tailgate

If you close the power tailgate when all the doors are
locked, the power tailgate locks automatically.

If you replace the battery or the power tailgate fuse
while the tailgate is open, the power tailgate may be
disabled. The power tailgate resumes once you
manually close the tailgate.

Installing aftermarket components other than Acura
genuine accessories on the power tailgate may
prevent it from fully opening or closing.

Make sure the power tailgate is fully open before you
get your luggage in and out.

Make sure the power tailgate is fully closed before
you start the vehicle.

The beeper sounds when you start driving while the
power tailgate is still open, or closing.

HOLD

Power
Tailgate
Button

HOLD

19 ACURA RDX-31TJB6000.book  166 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

Continued

167

uu

Opening and Closing the Tailgate

u

Opening/Closing the Power Tailgate

Co
ntrols

To open or close the power tailgate, press the
power tailgate button for about one second.

u

Some exterior lights flash and the beeper
sounds.

If you press the button again while the power
tailgate is moving, it will stop.
Press the button for about one second, and
the power tailgate will reverse direction.

■

Using the Power Tailgate Button

1

Opening/Closing the Power Tailgate

If the power tailgate meets resistance while opening
or closing, the auto reverse feature reverses the
direction. The beeper sounds three times.

The auto reverse function stops sensing when the
tailgate is almost closed to make sure that it fully
closes.

Do not touch the sensors located on both sides of the
tailgate. The power tailgate does not close if you
touch either sensor when you are trying to close the
tailgate.

Be careful not to scratch the sensors with a sharp
object. If scratched, they can be damaged, and the
power tailgate closing feature malfunctions.

Power Tailgate Button

19 ACURA RDX-31TJB6000.book  167 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Opening and Closing the Tailgate

u

Opening/Closing the Power Tailgate

168

Co
ntrols

If you press the outer handle of the tailgate for
no longer than one second, the tailgate opens
automatically.

u

The beeper sounds.

u

If you want to open the tailgate
manually, press the button for more than
one second.

2 Opening/Closing the Tailgate P. 172

If you are carrying the keyless access remote,
you do not have to unlock the tailgate before
opening it.

If you press the outer handle again while the
power tailgate is moving, it will stop.
Press the outer handle again, and the power
tailgate will reverse direction.

■

Using the Tailgate Outer Handle

1

Opening/Closing the Power Tailgate

Do not leave the keyless access remote in the cargo
area before closing the tailgate.

Even if you are not carrying the keyless access
remote, you can lock/unlock the tailgate while
someone else with the remote is within range.

You can change the power tailgate operation setting
on and off.

2 Customized Features P. 332

Outer Handle

19 ACURA RDX-31TJB6000.book  168 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

169

uu

Opening and Closing the Tailgate

u

Opening/Closing the Power Tailgate

Continued

Co
ntrols

Press the button on the tailgate to close the
power tailgate.

u

The beeper sounds.

If you press the button again while the power
tailgate is moving, it will stop. Press and
release the button again, and the power
tailgate will reverse direction.

■

Using the Tailgate Inner Button

19 ACURA RDX-31TJB6000.book  169 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Opening and Closing the Tailgate

u

Opening/Closing the Power Tailgate

170

Co
ntrols

The extent to which the power tailgate
automatically opens can be programed.

To program:
1. Open the tailgate to the desired position.

u

If you want to reprogram the power
tailgate to open all the way, manually
raise the tailgate to its upper most
position and follow the next step.

2. Press and hold the tailgate inner button

until you hear short two beeps following
one long buzzer.

■

Programming Tailgate Position

1

Programming Tailgate Position

If the tailgate is only slightly opened, the position
cannot be programmed, even if you push the inner
button.

19 ACURA RDX-31TJB6000.book  170 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

171

uu

Opening and Closing the Tailgate

u

Opening/Closing the Power Tailgate

Co
ntrols

If you manually close the power tailgate, it latches automatically.

Automatically lowers the power tailgate when there is a possibility that the fully
opened power tailgate can fall down by its own weight (for example, by snow on
the tailgate). The beeper sounds while the power tailgate lowers.

■

Auto-Closer

■

Power Tailgate Fall Detection

1

Auto-Closer

The auto-closer feature does not activate if you press
and hold the tailgate outer handle while the power
tailgate is closing.

Do not put any force on the tailgate while the power
tailgate is latching.

Keep your hands away from the tailgate when you
manually close the tailgate and let it latch
automatically. It is dangerous to put your hands
around the tailgate as it starts to latch itself.

1

Power Tailgate Fall Detection

If you try to manually close the power tailgate
immediately after it fully opens, the power tailgate
fall detection may activate.

Once the power tailgate fall detection activates, wait
until the power tailgate fully closes. Keep away from
the power tailgate when it is in motion.

If the power tailgate fall detection constantly
activates, consult at a dealer.

19 ACURA RDX-31TJB6000.book  171 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

172

uu

Opening and Closing the Tailgate

u

Opening/Closing the Tailgate

Co
ntrols

Opening/Closing the Tailgate

When all the doors are unlocked, the tailgate
is unlocked.

Press the outer handle of the tailgate and lift
open the tailgate.

If you are carrying the keyless access remote,
you do not have to unlock the tailgate before
opening it.
To close the tailgate, grab the inner handle,
pull the tailgate down, and push it closed
from outside.

If you close the tailgate when the driver's door
is locked, the tailgate locks automatically.

u

Some exterior lights flash.

■

Using the Tailgate Outer Handle

1

Opening/Closing the Tailgate

Do not leave the keyless access remote in the cargo
area before closing the tailgate.

Even if you are not carrying the keyless access
remote, you can lock/unlock the tailgate while
someone else with the remote is within range.

Outer Handle

Inner Handle

19 ACURA RDX-31TJB6000.book  172 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

173

Continued

Co
ntrols

Security System

Immobilizer System

The immobilizer system prevents a key that has not been pre-registered from
starting the engine. Each key contains electronic transmitters that use electronic
signals to verify the key.

Pay attention to the following when pressing the ENGINE START/STOP button:
• Do not allow objects that emit strong radio waves near the ENGINE START/

STOP button.

• Make sure the key is not covered by or touching a metal object.
• Do not bring a key from another vehicle’s immobilizer system near the ENGINE

START/STOP button.

• Do not put the key near magnetic items. Electronic devices, such as televisions

and audio systems emit strong magnetic fields. Note that even a key chain can
become magnetic.

Security System Alarm

The security system alarm activates when the tailgate, hood or doors are forcibly
opened. The alarm does not activate if the tailgate or doors are opened with the key,
remote transmitter or keyless access system.

However, the alarm activates if a door is opened with the key and then the hood is
opened before the power mode is set to ON.

■

When the security system alarm activates

The horn sounds intermittently and some exterior lights flash.

■

To deactivate the security system alarm

Unlock the vehicle using the key, remote transmitter or keyless access system. The
system, along with the horn and flashing lights, is deactivated.

1

Immobilizer System

NOTICE

Leaving the key in the vehicle can result in theft or
accidental movement of the vehicle.
Always take the key with you whenever you leave the
vehicle unattended.

Do not alter the system or add other devices to it.
Doing so may damage the system and make your
vehicle inoperable.

Canadian models only: Apply and hold the brake
pedal before turning the vehicle on the first time after
the battery has been disconnected.

1

Security System Alarm

Do not alter the system or add other devices to it.
Doing so may damage the system and make your
vehicle inoperable.

The security alarm continues for a maximum of two
minutes until the security system alarm deactivates.

19 ACURA RDX-31TJB6000.book  173 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Security System

u

Security System Alarm

174

Co
ntrols

■

Setting the security system alarm

The security system alarm automatically sets when the following conditions have
been met:
• The power mode is set to VEHICLE OFF (LOCK).
• The hood is closed.
• All doors and the tailgate are locked from outside with the key, remote

transmitter, or keyless access system.

■

When the security system alarm sets

The security system alarm indicator in the instrument panel blinks. When the
blinking interval changes after about 15 seconds, the security system alarm is set.

■

To cancel the security system alarm

The security system alarm is canceled when the vehicle is unlocked using the remote
transmitter, keyless access system, or the power mode is set to ON. The security
system alarm indicator goes off at the same time.

1

Security System Alarm

Do not set the security system alarm when someone
is in the vehicle or a window is open. The system can
accidentally activate when:

•

Unlocking the door with the lock tab.

•

Opening the hood with the hood release.

If the battery goes dead after you have set the
security system alarm, the security alarm may go off
once the battery is recharged or replaced.
If this occurs, deactivate the security system alarm by
unlocking a door using the key, remote transmitter or
keyless access system.

19 ACURA RDX-31TJB6000.book  174 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

175

uu

Security System

u

Security System Alarm

Co
ntrols

■

The panic button on the remote
transmitter

If you press the panic button for
approximately one second, the following will
occur for about 30 seconds:
• The horn sounds.
• Some exterior lights flash.

■

Canceling panic mode

• Press any button on the remote transmitter.
• Set the power mode to ON.

■

Panic Mode

Panic
Button

Panic
Button

19 ACURA RDX-31TJB6000.book  175 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

176

Co
ntrols

Opening and Closing the Windows

Opening/Closing the Power Windows

The power windows can be opened and closed when the power mode is in ON,
using the switches on the doors.

The driver’s side switches can be used to open and close all the windows. The power
window lock button on the driver’s side must be switched off (indicator off) to open
and close the windows from anywhere other than the driver’s seat.

When the power window lock button is pressed, the indicator comes on and you
can only operate the driver’s window. Turn the power window lock button on if a
child is in the vehicle.

■

Manual operation

To open: Push the switch down lightly, and
hold it until the desired position is reached.
To close: Pull the switch up lightly, and hold it
until the desired position is reached.

■

Automatic operation

To open: Push the switch down firmly.
To close: Pull the switch up firmly.

The window opens or closes completely. To
stop the window at any time, push or pull the
switch briefly.

■

Opening/Closing Windows with Auto-Open/Close Function

1

Opening/Closing the Power Windows

The power windows can be operated for up to 10
minutes after you set the power mode to VEHICLE
OFF (LOCK).
Opening either front door cancels this function.

Auto Reverse
If a power window senses resistance when closing
automatically, it will stop closing and reverse
direction.

The driver’s window auto reverse function is disabled
when you continuously pull up the switch.

The auto reverse function stops sensing when the
window is almost closed to ensure that it fully closes.

3

WARNING

Closing a power window on someone’s
hands or fingers can cause serious injury.

Make sure your passengers are away from
the windows before closing them.

Power
Window
Lock Button

Indicator

Driver’s Window
Switch

Front Passenger’s
Window Switch

Rear Passenger’s
Window Switches

19 ACURA RDX-31TJB6000.book  176 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

177

uu

Opening and Closing the Windows

u

Opening/Closing the Power Windows

Continued

Co
ntrols

To open: Press the unlock button, and then
within 10 seconds, press it again and hold it.

If the windows and panoramic roof stop
midway, repeat the procedure.

■

Opening the Windows and Panoramic Roof with the
Remote

Unlock
Button

19 ACURA RDX-31TJB6000.book  177 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

178

uu

Opening and Closing the Windows

u

Opening/Closing the Power Windows

Co
ntrols

To open: Unlock the driver’s door with the
key. Within 10 seconds of returning the key to
the central position, turn the key in the unlock
direction and hold it there.

To close: Lock the driver’s door with the key.
Within 10 seconds of returning the key to the
central position, turn the key in the lock
direction and hold it there.

Release the key to stop the windows and
panoramic roof at the desired position. If you
want further adjustment, repeat the same
operation.

■

Opening/Closing the Windows and Panoramic Roof with
the Key

Close

Open

19 ACURA RDX-31TJB6000.book  178 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

179

Continued

Co
ntrols

Panoramic Roof

You can only operate the panoramic roof and sunshade when the power mode is in
ON. Use the switch in the front of the ceiling to open and close the panoramic roof
and sunshade.

1

Panoramic Roof

NOTICE

Opening the panoramic roof in below freezing
temperature or when it is covered with snow or ice
can damage the panoramic roof panel or motor.

The panoramic roof and sunshade can be operated
for up to 10 minutes after you set the power mode to
VEHICLE OFF (LOCK).
Opening either front door cancels this function.

When resistance is detected, the auto reverse
function causes the panoramic roof and sunshade to
change directions, then stop. Auto reverse stops
sensing when the panoramic roof and sunshade are
almost closed to ensure that it fully closes. Make sure
that all objects, including fingers, are clear of the
panoramic roof and sunshade.

3

WARNING

Opening or closing the panoramic roof and
sunshade on someone’s hands or fingers
can cause serious injury.

Make sure all hands and fingers are clear of
the panoramic roof and sunshade before
opening or closing it.

19 ACURA RDX-31TJB6000.book  179 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Panoramic Roof

u

180

Co
ntrols

■

Automatic operation

To open: Pull the switch back firmly.
To open half: Push on the center of the
sunshade switch.
To close: Push the switch forward firmly.

The sunshade will automatically open or close
all the way. To stop the sunshade midway,
push the switch briefly.

■

Manual operation

To open: Pull the switch back lightly, and
hold it until the desired position is reached.
To close: Push the switch forward lightly, and
hold it until the desired position is reached.

■

Using the Sunshade Switch

1

Panoramic Roof

You can use the remote transmitter or the key to
operate the panoramic roof.

2 Opening the Windows and Panoramic

Roof with the Remote P. 177

2 Opening/Closing the Windows and

Panoramic Roof with the Key P. 178

1

Using the Sunshade Switch

The sunshade can be opened or closed to adjust the
amount of light that enters the cabin.

When you use the sunshade switch to open the
sunshade, the panoramic roof does not move.

The sunshade cannot be fully closed if the panoramic
roof is open. When you close the sunshade with the
panoramic roof open, the sunshade stops slightly
before the panoramic roof. When you push the
switch forward again, the sunshade and the
panoramic roof close together.

Open

Half Open

Close

19 ACURA RDX-31TJB6000.book  180 ページ  ２０１８年４月２６日　木曜日　午後４時５１分
