Acura RDX (2019 year). Manual - part 12

181

uu

Panoramic Roof

u

Co
ntrols

■

Automatic operation

To open: Pull the switch back firmly.
To close: Push the switch forward firmly.

The panoramic roof will automatically open or
close all the way. To stop the panoramic roof
midway, push the switch briefly.

■

Manual operation

To open: Pull the switch back lightly, and
hold it until the desired position is reached.
To close: Push the switch forward lightly, and
hold it until the desired position is reached.

■

Tilting the panoramic roof up

To tilt: Push on the center of the panoramic
roof switch.

u

The sunshade will open automatically
and the panoramic roof will start to tilt
up.

To close: Push the switch forward firmly, then
release.

■

Using the Panoramic Roof Switch

1

Using the Panoramic Roof Switch

The panoramic roof cannot be fully opened in a
single operation. The panoramic roof has a
“comfort” position or wind noise reduction position
at which the roof first stops. To open fully, pull the
switch back again after the roof has stopped at this
position.

Whenever the panoramic roof is opening, the
sunshade moves along with it. However, when the
panoramic roof is closing, the sunshade does not
move.

When you tilt open the panoramic roof, the sunshade
opens slightly to let in fresh air. When you close the
panoramic roof from this position, the sunshade
returns to its closed position.

Comfort Position

Full Open Position

Open

Close

Tilt

19 ACURA RDX-31TJB6000.book  181 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

182

Co
ntrols

Operating the Switches Around the Steering Wheel

ENGINE START/STOP Button

*1:Canadian models

■

Changing the Power Mode

1

ENGINE START/STOP Button

ENGINE START/STOP Button Operating Range

You can start the engine when the keyless access
remote is inside the vehicle.
The engine may also run if the keyless access remote
is close to the door or window, even if it is outside the
vehicle.

ON mode:
The ENGINE START/STOP button is on (in red), if the
engine is running.

If the battery of the keyless access remote is getting
low, the engine may not start when you press the
ENGINE START/STOP button. If the engine does not
start, refer to the following link.

2 If the Keyless Access Remote Battery is

Weak P. 602

Do not leave the power mode in ACCESSORY or ON
when you get out.

Operating Range

VEHICLE OFF (LOCK)
The button is off.
The steering wheel is locked

*1

.

The power to all electrical components is turned off.

ACCESSORY
The button blinks (in red).
Operate the audio system and other accessories in this
position.

ON
The button blinks (in red).
All electrical components can be used.

Without pressing the brake pedal

Press the button.

Put the transmission into

(

P.

U.S. models

Press the button without the
transmission in

(

P.

Press the button with the
transmission in

(

P.

19 ACURA RDX-31TJB6000.book  182 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

183

uu

Operating the Switches Around the Steering Wheel

u

ENGINE START/STOP Button

Continued

Co
ntrols

If you leave the vehicle for 30 to 60 minutes with the transmission in

(

P and the

power mode in ACCESSORY, the vehicle automatically goes into the mode similar to
VEHICLE OFF (LOCK) to avoid draining the battery.

When in this mode:
The steering wheel does not lock.
You cannot lock or unlock doors with the remote transmitter or the keyless access
system.

Press the ENGINE START/STOP button twice to switch the mode to VEHICLE OFF
(LOCK).

If you open the driver’s door when the power mode is set to ACCESSORY, a warning
beep sounds.

■

Automatic Power Off

■

Power Mode Reminder

Canadian models

19 ACURA RDX-31TJB6000.book  183 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Operating the Switches Around the Steering Wheel

u

ENGINE START/STOP Button

184

Co
ntrols

Warning buzzers may sound from inside
and/or outside the vehicle to remind you that
the keyless access remote is out of the vehicle.
If the buzzer continues even after the remote
is put back inside, place it to be within its
operational range.

■

When the power mode is in ON

If the keyless access remote is taken out of the
vehicle, and all doors are closed, a warning
buzzer sounds from both inside and outside
the vehicle. A warning message on the multi-
information display notifies the driver inside
that the remote is outside of the vehicle.

■

When the power mode is in
ACCESSORY

If the keyless access remote is taken out of the
vehicle, and all doors are closed, a warning
buzzer sounds from outside the vehicle.

■

Keyless Access Remote Reminder

1

Keyless Access Remote Reminder

When the keyless access remote is within the
system’s operational range, and the driver’s door is
closed, the warning function cancels.

If the keyless access remote is taken out of the vehicle
after the engine has been started, you can no longer
change the ENGINE START/STOP button mode or
restart the engine. Always make sure if the remote is
in your vehicle when you operate the ENGINE
START/STOP button.

Removing the keyless access remote from the vehicle
through a window does not activate the warning
buzzer.

Do not put the keyless access remote on the
dashboard or in the glove box. It may cause the
warning buzzer to go off. Under some other
conditions that can prevent the vehicle from locating
the remote, the warning buzzer may also go off even
if the remote is within the system’s operational
range.

19 ACURA RDX-31TJB6000.book  184 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

185

uu

Operating the Switches Around the Steering Wheel

u

Turn Signals

Co
ntrols

Turn Signals

The turn signals can be used when the power
mode is in ON.

■

One-touch turn signal

When you lightly push up or down and release
the turn signal lever, the exterior turn signals
and turn signal indicator blink three times.

This feature can be used when signaling for a
lane change.

Right Turn

Left Turn

19 ACURA RDX-31TJB6000.book  185 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

186

uu

Operating the Switches Around the Steering Wheel

u

Light Switches

Co
ntrols

Light Switches

Rotating the light switch turns the lights on
and off, regardless of the power mode
setting.

■

High beams

Push the lever forward until you hear a click.

■

Low beams

When in high beams, pull the lever back to
return to low beams.

■

Flashing the high beams

Pull the lever back, and release it.

■

Lights off

Turn the lever to OFF either when:
• The transmission is in

(

P.

• The parking brake is applied.

To turn the lights on again, turn the lever to
OFF to cancel the lights off mode. Even if you
do not cancel the lights off mode, the lights
come on automatically when:
• The transmission is taken out of

(

P and the

parking brake is released.

• The vehicle starts to move.

■

Manual Operation

1

Light Switches

If you leave the power mode in VEHICLE OFF (LOCK)
while the lights are on, a chime sounds when the
driver’s door is opened.

When the lights are on, the lights on indicator in the
instrument panel will be on.

2 Lights On Indicator P. 87

Do not leave the lights on when the engine is off
because it will cause the battery to discharge.

If you sense that the level of the headlights is
abnormal, have the vehicle inspected by a dealer.

High Beams

Flashing the high beams

Low Beams

Turns on parking, side marker,
tail, and rear license plate lights

Turns on headlights, parking,
side marker, tail, and rear
license plate lights

19 ACURA RDX-31TJB6000.book  186 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

Continued

187

uu

Operating the Switches Around the Steering Wheel

u

Light Switches

Co
ntrols

Automatic lighting control can be used when
the power mode is in ON.

When the light switch is in AUTO, the
headlights and other exterior lights will switch
on and off automatically depending on the
ambient brightness.

u

You can change the auto light sensitivity
setting.

2 Customized Features P. 332

The headlights comes on when you unlock a
door in dark areas with the headlight switch in
AUTO.

u

Once you lock the door, the headlights
will go off.

■

Automatic Operation (automatic lighting control)

1

Automatic Operation (automatic lighting control)

We recommend that you turn on the lights manually
when driving at night, in a dense fog, or in dark areas
such as long tunnels or parking facilities.

The light sensor is in the location shown below.
Do not cover this light sensor with anything;
otherwise, the automatic lighting system may not
work properly.

Light Sensor

Models with automatic
intermittent wipers

Models without automatic
intermittent wipers

Light Sensor

U.S. models

19 ACURA RDX-31TJB6000.book  187 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Operating the Switches Around the Steering Wheel

u

Light Switches

188

Co
ntrols

The headlights automatically come on when the wipers are used several times within
a certain number of intervals with the headlight switch in AUTO.
The headlights automatically go off a few minutes later if the wipers are stopped.

The headlights, all other exterior lights, and the instrument panel lights turn off 15
seconds after you set the power mode to VEHICLE OFF (LOCK), take the remote with
you, and close the driver’s door.

If you set the power mode to VEHICLE OFF (LOCK) with the headlight switch on, but
do not open the door, the lights turn off after 10 minutes (3 minutes, if the switch
is in the AUTO position).

The lights turn on again when you unlock or open the driver’s door. If you unlock
the door, but do not open it within 15 seconds, the lights go off. If you open the
driver’s door, you will hear a lights on reminder chime.

■

Headlight Integration with Wiper

■

Automatic Lighting Off Feature

1

Automatic Operation (automatic lighting control)

Adjust the auto light sensitivity as follows:

Setting

The exterior lights come on

when the ambient light is at

Max

High

Mid

Low

Min

U.S. models

Bright

Dark

1

Headlight Integration with Wiper

This feature activates while the headlights are off in
AUTO.
The instrument panel brightness does not change
when the headlights come on.

At dark ambient light levels, the automatic lighting
control feature turns on the headlights, regardless of
the number of wiper sweeps.

1

Automatic Lighting Off Feature

You can change the headlight auto off timer setting.

2 Customized Features P. 332

19 ACURA RDX-31TJB6000.book  188 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

189

uu

Operating the Switches Around the Steering Wheel

u

Adaptive Front Lighting System (AFS)

*

Co
ntrols

Adaptive Front Lighting System (AFS)

*

The adaptive front lighting system (AFS) helps to improve visibility during nighttime
driving. The AFS optimizes the distribution of light from the low beam headlights
according to the degree to which the steering wheel is turned when the vehicle is
rounding a curve.

The system activates when the following conditions have been met:
• The power mode is in ON.
• The low beam headlights are on.
• The vehicle speed is above 25 mph (40 km/h).

1

Adaptive Front Lighting System (AFS)

*

The system does not operate when the transmission
is in

(

R.

■

Operating the System

Curve

Right Curve

Left Curve

Straight

Straight

AFS Light

AFS Light

AFS Light

* Not available on all models

19 ACURA RDX-31TJB6000.book  189 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

190

uu

Operating the Switches Around the Steering Wheel

u

Fog Lights

*

Co
ntrols

Fog Lights

*

When the low beam headlights are on, turn
the fog light switch on to use the fog lights.

Daytime Running Lights

The parking/daytime running lights come on when the following conditions have
been met:
• The power mode is in ON.
• The headlight switch is in AUTO.
• The parking brake is released.

The lights remain on even if you set the parking brake. Setting the power mode to
VEHICLE OFF (LOCK) will turn off the daytime running lights.

The daytime running lights are off once the headlight switch is turned on, or when
the headlight switch is in AUTO and it is getting darker outside.

Fog Light Switch

* Not available on all models

19 ACURA RDX-31TJB6000.book  190 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

191

uu

Operating the Switches Around the Steering Wheel

u

Auto High-Beam

Continued

Co
ntrols

Auto High-Beam

Using a camera mounted to the inside of the windshield, this system detects light
sources ahead of the vehicle. Depending on the light source, the system
automatically switches the headlights to high beam for optimal visibility at night.

1

Auto High-Beam

The auto high-beam determines when to change the
headlight beams by responding to the brightness of
the lights ahead of your vehicle. In the following
cases, the system may not respond to the lights
properly:

•

The brightness of the lights from the preceding or
oncoming vehicle is intense or poor.

•

Visibility is poor due to the weather (rain, snow,
fog, windshield frost, etc.).

•

Other light sources, such as street lights and
electric billboards are illuminating the road ahead.

•

The brightness level of the road ahead constantly
changes.

•

The road is bumpy or has many curves.

•

A vehicle cuts in front of you, or a vehicle in front
of you is not in the preceding or oncoming
direction.

•

Your vehicle is tilted with a heavy load in the rear.

If you find the timing of beam changes inconvenient
for driving, change the headlight beams manually.

If you do not want the system to be activated at any
time when the headlight switch is in AUTO, consult a
dealer or disable the system.

2 Disabling or Re-enabling the System P. 193

■

The headlight switch is in AUTO.

■

The lever is in the low beam
position.

■

The low beams are on and the
system recognizes that you are
driving at night.

■

The vehicle speed is above 25 mph
(40 km/h).

The system operates when:

When the camera detects lights coming from a preceding or oncoming vehicle, the
headlights remain in low beam.

When the camera detects no lights coming from a preceding or oncoming vehicle,
the headlights change to high beam.

The view angle or distance that the camera can detect lights ahead differs
depending on conditions, such as the brightness of the lights and the weather.

How it works

19 ACURA RDX-31TJB6000.book  191 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

uu

Operating the Switches Around the Steering Wheel

u

Auto High-Beam

192

Co
ntrols

To activate the system, turn the headlight
switch to AUTO and then set the headlights
to low beam. The auto high-beam indicator
will come on.

2 Light Switches P. 186

The high beams remain on unless:
• You have been driving below 15 mph (24 km/h) for an extended amount of time.
• The speed of the vehicle drops below 6 mph (10 km/h).
• The windshield wipers have been running at a high speed for more than a few

seconds.

• You enter a well lit location.

The high beams come back on once the condition that caused them to turn off no
longer exists.

If needed, you can temporarily turn the system off manually. Turn on the high
beams by pushing the lever forward until you hear a click, or flash the high beams
once by pulling the lever toward you. To turn the system back on, repeat one of the
procedures.

■

Operating the System

1

Operating the System

For the auto high-beam to work properly:

•

Do not place an object that reflects light on the
dashboard.

•

Keep the windshield around the camera clean.

•

Do not attach an object, sticker or film to the area
around the camera.

If the camera receives a strong impact, or repairing of
the area near the camera is required, consult a dealer.

If the Some Driver Assist Systems Cannot
Operate: Camera Temperature Too High message
appears:

•

Use the climate control system to cool down the
interior and, if necessary, also use defroster mode
with the airflow directed toward the camera.

•

Start driving the vehicle to lower the windshield
temperature, which cools down the area around
the camera.

If the Some Driver Assist Systems Cannot
Operate: Clean Front Windshield message
appears:

•

Park your vehicle in a safe place, and clean the
windshield. If the message does not disappear after
you have cleaned the windshield and driven for a
while, have your vehicle checked by a dealer.

Headlight Switch

19 ACURA RDX-31TJB6000.book  192 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

193

uu

Operating the Switches Around the Steering Wheel

u

Auto High-Beam

Co
ntrols

Disable or re-enable the system when the
vehicle is parked with the power mode in ON
and the light switch is in the AUTO position.
Disabling the system: Pull the light switch
lever toward you and hold it for at least 40
seconds. The auto high-beam indicator in the
meter will blink twice.
Re-enabling the system: Pull the light
switch lever toward you and hold it for at least
30 seconds. The auto high-beam indicator in
the meter will blink once.

■

Disabling or Re-enabling the System

1

Disabling or Re-enabling the System

The auto high-beam is in the previously selected
disabled or re-enabled setting each time you start the
engine.

AUTO Position

19 ACURA RDX-31TJB6000.book  193 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

194

uu

Operating the Switches Around the Steering Wheel

u

Wipers and Washers

Co
ntrols

Wipers and Washers

The windshield wipers and washers can be
used when the power mode is in ON.

■

MIST

The wipers run at high speed until you release
the lever.

■

Wiper switch (OFF, INT

*1

/AUTO

*2

, LO, HI)

Move the lever up or down to change the
wiper settings.

■

Adjusting wiper operation

*

Turn the adjustment ring to adjust the wiper
operation.

■

Washer

Sprays while you pull the lever toward you.
When you release the lever for more than one
second, the spray stops, the wipers sweep two
or three more times to clear the windshield,
then stop.

*1 : Models with manual intermittent operation
*2 : Models with automatic intermittent operation

■

Windshield Wipers/Washers

1

Wipers and Washers

NOTICE

Do not use the wipers when the windshield is dry.
The windshield will get scratched, or the rubber
blades will get damaged.

NOTICE

Turn the washers off if no washer fluid comes out.
The pump may get damaged.

The wiper motor may stop motor operation
temporarily to prevent an overload. Wiper operation
will return to normal within a few minutes, once the
circuit has returned to normal.

If the vehicle speeds up while the wipers are
operating intermittently, the length of the wipe
interval shortens.
When the vehicle speeds up, the wiper operation’s
shortest delay setting ( ) and the LO setting become
the same.

NOTICE

In cold weather, the blades may freeze to the
windshield.
Operating the wipers in this condition may damage
the wipers. Use the defroster or heated windshield

*



to warm the windshield, then turn the wipers on.

Models without automatic intermittent wipers

Intermittent Time
Adjustment Ring

*

MIST

INT

*1

/AUTO

*2

OFF

LO: Low speed wipe

HI: High speed wipe

Pull to
use
washer.

Lower speed, fewer sweeps

Higher speed, more sweeps

* Not available on all models

19 ACURA RDX-31TJB6000.book  194 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

Continued

195

uu

Operating the Switches Around the Steering Wheel

u

Wipers and Washers

Co
ntrols

When you push the lever down to AUTO, the
windshield wipers sweep once, and go into
the automatic mode.

The wipers operate intermittently, at low
speed, or at high speed and stops in
accordance with the amount of rainfall the
rainfall sensor detects.

■

Auto sensitivity adjustment

When the wiper function is set to AUTO, you
can adjust the sensitivity of the rainfall sensor
(using the adjustment ring) so that wipers will
operate in accordance with your preference.

Sensor sensitivity

■

Automatic Intermittent Wipers

*

1

Wipers and Washers

If the wipers stop operating due to an obstacle such
as the build-up of snow, park the vehicle in a safe
place.
Rotate the wiper switch to OFF, and set the power
mode to ACCESSORY or VEHICLE OFF (LOCK), then
remove the obstacle.

1

Automatic Intermittent Wipers

*

The rainfall sensor is in the location shown below.

NOTICE

AUTO should always be turned OFF before the
following situations in order to prevent severe
damage to the wiper system:

•

Cleaning the windshield

•

Driving through a car wash

•

No rain present

Rainfall Sensor

Low sensitivity

High sensitivity

* Not available on all models

19 ACURA RDX-31TJB6000.book  195 ページ  ２０１８年４月２６日　木曜日　午後４時５１分

196

uu

Operating the Switches Around the Steering Wheel

u

Wipers and Washers

Co
ntrols

The rear wiper and washer can be used when
the power mode is in ON.

■

Wiper switch (OFF, INT, ON)

Change the wiper switch setting according to
the amount of rain.

■

Washer (



*

)

Sprays on the rear window and rearview
camera

*

 while you rotate the switch to this

position.
Hold it to activate the rear wiper and to spray
the washer. Once released, the washer spray
will stop and the rear wiper will return to its
selected switch setting after a few sweeps.

■

Operating in reverse

When you select the transmission to

(

R with the windshield wipers activated, the

rear wiper operates automatically as follows even if its switch is off.

■

Rear Wiper/Washer

INT: Intermittent

OFF

ON: Continuous wipe

Washer

Windshield Wiper Operation

Rear Wiper Operation

Intermittent

Intermittent

Low speed wipe

High speed wipe

Continuous

* Not available on all models

19 ACURA RDX-31TJB6000.book  196 ページ  ２０１８年４月２６日　木曜日　午後４時５１分
