Acura NSX (2017 year). Manual

292

Features

AcuraLink®

Is a subscription-based service that provides convenient features such as voice
communication in case of an airbag deployment, online security, and one-on-one
operator assistance.
For information on traffic rerouting and traffic information updates, provided by the
AcuraLink server, see the Navigation System Manual.

■

Automatic collision notification

If your vehicle’s airbags deploy or if the unit detects that the vehicle is severely
impacted, your vehicle will automatically attempt to connect to the AcuraLink
operator. Once connected, information about your vehicle, its positioning, and its
condition will be sent to the operator; you also can speak to the operator when
connected.

■

In Case of a Crash

AcuraLink®

AcuraLink also provides services you can operate
from the Internet or your smartphone.

To subscribe to AcuraLink, or to get more
information about all of its features, contact an
authorized Acura NSX dealer, or visit
owners.acura.com (in U.S.) or www.acura.ca (in
Canada).

In Case of a Crash

Your vehicle may not be able to connect to the
operator if the battery level is low, the line is
disconnected or you do not have adequate cellular
coverage.

You cannot use the Assist services when:

•

You travel outside the AcuraLink service coverage
areas.

•

There is a problem with the connecting devices,
such as the ASSIST button, microphone, speakers,
or the unit itself.

•

You are not subscribed to the service or your
subscription is no longer valid.

You cannot operate other navigation- or phone-
related functions using the screens while talking to
the operator.
Only the operator can terminate the connection to
your vehicle.

Automatic collision notification

If the unit fails to connect to the operator, it
repeatedly tries until it succeeds.

* Not available on all models

17 NSX-31T6N6000.book 292 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

293

AcuraLink®

Features

■

Manual operator connection

If you need to talk to the AcuraLink operator
in a situation where no airbag has deployed,
you can manually connect to them by pressing
the ASSIST button with the power mode in
ACCESSORY or ON.
1. Open the cover attached to the ceiling

console.

2. Press the ASSIST button.

You are connected to the AcuraLink
operator.

Manual operator connection

Do not press the button while driving. When you
need to contact the operator, park the vehicle in a
safe place.

If the unit fails to connect to the operator, it
automatically cancels the action after three minutes.

If necessary, the cover can be broken to access the
ASSIST button.

ASSIST
Button

17 NSX-31T6N6000.book 293 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

AcuraLink®

294

Features

Your subscribed telematics service provider can track your vehicle’s location,
remotely lock or unlock doors, and help you find your vehicle.
To use these features, you need your user ID and personal identification number
(PIN).

■

Stolen vehicle tracking

This feature searches and tracks down your vehicle position even if it is on the move.
If you believe that your vehicle has been stolen, contact the police as well as the
provider. Tracking requests must be initiated by the police.

■

Remote door lock/unlock

The provider can remotely lock or unlock doors upon your request.

■

Vehicle finder

This feature is convenient to use when trying to locate your vehicle in large areas,
such as a crowded parking lot. If you cannot locate your vehicle after using the
remote transmitter’s answerback function, you can contact the provider which can
then flash your vehicle’s exterior lights and sound the horn.

■

Security alarm notification

If the security system in your vehicle detects an abnormal condition, such as
someone tampering with the lock on your vehicle, the provider notifies you by email
or SMS.

■

Security Features

Security Features

The contact information of your provider, your user
ID and PIN will be given when you subscribe to
AcuraLink. If you forget any of the above, contact an
authorized Acura NSX dealer, or go to
owners.acura.com (in U.S.) or www.acura.ca (in
Canada).

You can also activate the remote door lock/unlock
and vehicle finder features from the Internet or using
your smartphone app. Ask an authorized Acura NSX
dealer, or visit owners.acura.com (in U.S.) or
www.acura.ca (in Canada) for details.

Vehicle finder

The lights will stop flashing and horn will stop
sounding under the following conditions:

•

When 30 seconds have elapsed.

•

You unlock the doors using the remote transmitter.

•

You unlock the doors using the keyless access
system.

•

You unlock the doors using the built-in key.

•

The power mode is set to ACCESSORY or ON.

17 NSX-31T6N6000.book 294 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

295

AcuraLink®

Features

Connect to the AcuraLink operator when trying to find a destination or for roadside
assistance.

1. Press the LINK button.

Connection to the operator begins.

2. Talk to the operator.

To disconnect, select End Call on the
audio/information screen or press the

button on the steering wheel.

■

Operator Assistance

Operator Assistance

Remain attentive to road conditions and driving
during operator assistance.

LINK Button

Audio/information screen
when connected to the
AcuraLink operator.

17 NSX-31T6N6000.book 295 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

298

Driving

Before Driving

Driving Preparation

Check the following items before you start driving.

• Make sure there are no obstructions on the windows, door mirrors, exterior

lights, or other parts of the vehicle.

Remove any frost, snow, or ice.

Remove any snow on the roof, as this can slip down and obstruct your field of
vision while driving. If frozen solid, remove ice once it has softened.

When removing ice from around the wheels, be sure not to damage the wheel
or wheel components.

• Make sure the hood is securely closed.

If the hood opens while driving, your front view will be blocked.

• Make sure the tires are in good condition.

Check air pressures, and check for damage and excessive wear.

2 Checking and Maintaining Tires P. 393

• Make sure there are no people or objects behind or around the vehicle.

There are blind spots from the inside.

• Check the front bumper ducts and side intercooler ducts for mud, leaves, and

road debris that could build up and prevent proper cooling performance.

■

Exterior Checks

Exterior Checks

NOTICE

When doors are frozen shut, use warm water around
the door edges to melt any ice. Do not try to force
them open, as this can damage the rubber trim
around the doors. When done, wipe dry to avoid
further freezing.

Do not pour warm water into the key cylinder.
You will be unable to insert the key if the water
freezes in the hole.

Heat from the engine and exhaust can ignite
flammable materials left under the hatch, causing a
fire. If you’ve parked your vehicle for an extended
period, inspect and remove any debris that may have
collected, such as dried grass and leaves that have
fallen or have been carried in for use as a nest by a
small animal.
Also check under the hatch for leftover flammable
materials after you or someone else has performed
maintenance on your vehicle.

17 NSX-31T6N6000.book 298 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

299

Before Driving

Driving Preparation

Driving

• Store or secure all items on board properly.

Carrying too much cargo, or improperly storing it, can affect your vehicle’s
handling, stability, stopping distance, and tires, and make it unsafe.

2 Maximum Load Limit P. 301

• Do not pile items higher than the seat height.

They can block your view and may be thrown forward in the event of sudden
braking.

• Do not place anything in the seat footwells. Make sure to secure the floor mat.

An object or unsecured floor mat can interfere with your brake and accelerator
pedal operation while driving.

• If you have any animals on board, do not let them move around in the vehicle.

They may interfere with driving and a crash could occur.

• Securely close and lock both doors and the hatch.

2 Locking/Unlocking the Doors from the Inside P. 115

• Adjust your seating position properly.

2 Adjusting the Seats P. 144

• Adjust the mirrors and steering wheel properly.

Adjust them while sitting in the proper driving position.

2 Adjusting the Mirrors P. 141
2 Adjusting the Steering Wheel P. 140

■

Interior Checks

Interior Checks

The headlight aim is set by the factory, and does not
need to be adjusted. However, if you regularly carry
heavy items in the trunk have the aiming readjusted
at an authorized Acura NSX dealer or by a qualified
technician.

17 NSX-31T6N6000.book 299 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

300

Before Driving

Driving Preparation

Driving

• Be sure items placed on the floor behind the driver’s and passenger’s seats cannot

roll under the seats.

They can interfere with the driver’s ability to operate the pedals, the operation
of the seats, or the operation of the sensors under the seats.

• Everyone in the vehicle must fasten their seat belt.

2 Fastening a Seat Belt P. 39

• Make sure that the indicators in the instrument panel come on when you start the

vehicle, and go off soon after.

Always have an authorized Acura NSX dealer check the vehicle if a problem is
indicated.

2 Indicators P. 70

17 NSX-31T6N6000.book 300 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

301

Before Driving

Maximum Load Limit

Continued

Driving

Maximum Load Limit

The maximum load for your vehicle is 507 lbs (230 kg).
The maximum load for the cargo area is 100 lbs (45 kg).
See the Tire and Loading Information label attached to the driver’s
doorjamb.

This figure includes the total weight of all occupants, cargo, and
accessories, and the tongue load if you are towing a trailer.

Steps for Determining Correct Load Limit -
(1) Locate the statement “The combined weight of occupants and cargo

should never exceed XXX kg or XXX lbs.” on your vehicle’s placard.

(2) Determine the combined weight of the driver and passengers

that will be riding in your vehicle.

(3) Subtract the combined weight of the driver and passengers

from XXX kg or XXX lbs.

(4) The resulting figure equals the available amount of cargo and

luggage load capacity. For example, if the “XXX” amount equals
1,400 lbs. and there will be five 150 lb. passengers in your vehicle, the
amount of available cargo and luggage load capacity is 650 lbs.
(1,400 - 750 (5 x 150) = 650 lbs.)

Maximum Load Limit

Gross Vehicle Weight Rating (GVWR):
The maximum allowable weight of the vehicle, all
occupants, all accessories and all cargo.

2 Specifications P. 454

Gross Axle Weight Rating (GAWR):
The maximum allowable weight of the vehicle axle.

2 Specifications P. 454

WARNING

Overloading or improper loading
can affect handling and stability
and cause a crash in which you
can be hurt or killed.

Follow all load limits and other
loading guidelines in this manual.

Label Example

17 NSX-31T6N6000.book 301 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

302

Before Driving

Maximum Load Limit

Driving

(5) Determine the combined weight of luggage and cargo being

loaded on the vehicle. That weight may not safely exceed the
available cargo and luggage load capacity calculated in step 4.

(6) If your vehicle will be towing a trailer, load from your trailer will

be transferred to your vehicle. Consult this manual to
determine how this reduces the available cargo and luggage
load capacity of your vehicle.

In addition, the total weight of the vehicle, all occupants,
accessories, cargo, and trailer tongue load must not exceed the
Gross Vehicle Weight Rating (GVWR) or the Gross Axle Weight
Rating (GAWR). Both are on a label on the driver’s doorjamb.

Load Limits Example

Example1

Max Load

507 lbs

(230 kg)

Passenger Weight

150 lbs x 1 + 257 lbs = 407 lbs

(68 kg x 1 + 117 kg = 185 kg)

Maximum Cargo

Weight

100 lbs
(45 kg)

Example2

Max Load

507 lbs

(230 kg)

Passenger Weight

150 lbs x 2 + 107 lbs = 407 lbs

(68 kg x 2 + 49 kg = 185 kg)

Maximum Cargo

Weight

100 lbs
(45 kg)

17 NSX-31T6N6000.book 302 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

303

Before Driving

High-Performance Driving

Continued

Driving

High-Performance Driving

Your Acura NSX is designed, built and equipped with systems and features to
provide you with exceptional driving performance, including the ability to engage in
high-performance driving. However, due to the risks to both you and other road
users, including the risk of injury or death from a high-speed loss of control or crash,
if you engage in high-performance driving, Acura recommends you only do so
where conditions are controlled, such as at a track or other closed-course venue.
When driving on public roads you should always obey the posted speed limits and
other traffic laws, reduce speed as needed for traffic and environmental conditions,
and not engage in driving behaviors (including, for instance, use of Launch Control)
that may create heightened risks for yourself and any other road users who may be
present (even if you are unaware of them).

NSX TRACK mode, Launch Control and other systems are designed for increased
performance, both in terms of acceleration and handling, up to near-performance-
limit conditions. They are most appropriately used on closed courses and they should
not be used on public roads. Use of these systems may delay the intervention of
vehicle safety systems designed to minimize the risk of a loss of traction or steering
control, and can cause the NSX to handle differently than you might expect or
would experience under normal driving conditions. Use of these systems will not
make up for a lack of appropriate driver experience and skill, and will not allow the
driver to overcome risks created by:
• A lack of proper vehicle maintenance
• Less than ideal road conditions and/or unfamiliarity with the driving environment
• Other traffic or road users

High-Performance Driving

NOTICE

The NSX warranty does not cover any damage or
failure resulting from high-performance driving,
racing, competitive driving of any sort whatsoever, or
use on a track or similar-type venue. See warranty
book for details.

2 TRACK Mode P. 327
2 Launch Control P. 328

17 NSX-31T6N6000.book 303 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

304

Before Driving

High-Performance Driving

Driving

High-performance driving requires special skills, knowledge and experience, as the
safety risks are greatly increased when the NSX is operated at its upper performance
abilities. As a responsible NSX driver, you should not drive above your skill limits or
training, even if the NSX’s performance levels would otherwise allow you to do so.
If you intend to engage in high-performance driving, Acura strongly recommends
that:
• You first obtain appropriate, professional training
• Turn off any devices or systems that may distract you from the driving task

High-performance driving in general, and the use of TRACK mode and Launch
Control in particular, puts very high loads on the NSX and its components, and
results in greater wear and tear on the vehicle. Because of these high loads, if your
NSX is not in top condition or if certain components, such as the brakes or tires, have
undue wear, those components could experience a loss of performance, or fail,
when engaging in high-performance driving. Therefore, Acura highly recommends
that you undertake more proactive and frequent maintenance than that required
under normal use and have your vehicle inspected at an authorized Acura NSX
dealer (and all necessary repairs or adjustments made) before you engage in any
high-performance driving. In addition to any required maintenance, there are
certain NSX specific items and protocols that you should pay special attention to
before, during and after engaging in any high-performance driving. Ultimately, the
decision whether to engage in high-performance driving is yours, and depending on
your NSX’s condition and prior usage, the items and protocols listed below may or
may not be sufficient to ensure a safe driving experience.

BEFORE DRIVING
• With the vehicle parked on level ground, properly bleed brake system after

replacing with Acura Heavy Duty Brake Fluid DOT 4 or equivalent

• Inspect brake pad thickness and replace if 6.0 mm or less

17 NSX-31T6N6000.book 304 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

305

Before Driving

High-Performance Driving

Driving

• Burnish the brake pads shortly before high-performance driving so that they have

the performance characteristics necessary to repeatedly and quickly slow the NSX
when it is being operated at significantly high speeds. (While the NSX’s brake
pads are properly burnished for the demands expected in ordinary day-to-day
driving, high-performance driving puts unique demands on the brake system
which require further burnishing.)

• Inspect ALL cooling openings to confirm they are open and free of debris such as

leaves, etc. Cooling openings include engine undercover ducts, heat resistance
ducts, brake ducts, radiators, and intercoolers

• Remove Tire Repair Kit from the trunk, along with any other cargo area contents
• Check tire wear and tire pressure, and make certain wheel lug bolts are properly

torqued, as driving at high speed puts additional strain on tires and wheels. Never
use slick tires, and do not use Summer Only tires and Ultra High Performance tires
if temperatures will be lower than 45°F (7°C)

• If you anticipate sustained driving at speeds greater than 168 mph/270 km/h,

adjust the cold tire pressure as shown on the driver door jamb warning label. This
will help avoid heat build-up and sudden tire failure

High-Performance Driving

WARNING

Use of slick tires/racing slicks may subject
the chassis and body components to higher
dynamic loads than they were designed for.
Higher than intended dynamic loads could
result in component failure, loss of control,
and serious injury or death to you or others.
Do not install slick tires on the NSX.

Canadian models

U.S. models

17 NSX-31T6N6000.book 305 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

306

Before Driving

High-Performance Driving

Driving

• Inspect all exhaust mounts for cracks or signs of wear
• Inspect tailpipe active exhaust valves to ensure they are functioning correctly. You

can do this by cycling the IDS switch between SPORT and TRACK modes, while
the engine is idling

WHILE DRIVING
• You may see a brake warning message in the Driver Information Interface (and

warning message chime) and/or experience increased brake pedal stroke.
If either occurs, immediately slow down and allow for increased stopping
distances. The message will disappear once the brakes have cooled and the
system has returned to normal operating condition

• After high-performance driving, it is critical to allow your vehicle to properly cool

down. Do not immediately stop your vehicle. Instead, continue driving at reduced
speeds, allowing for increased braking distances until your vehicle returns to
normal operating temperatures. Once you stop and safely park the NSX, open the
hatch to aid cooling. If the engine oil temperature reaches the

mark during

high-performance driving, have your NSX inspected by an authorized Acura NSX
dealer

17 NSX-31T6N6000.book 306 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

307

Before Driving

High-Performance Driving

Driving

AFTER DRIVING
• Check your NSX, and each of its relevant components, to make sure that it still is

in a safe operating condition (example: wheel lug bolt torque, tire pressure, etc.).
We recommend repeating the BEFORE DRIVING protocol, and if any item shows
excessive wear or appears to be in an unusual condition, have it replaced, or
exercise appropriate caution when driving and see your authorized Acura NSX
dealer

For more information, please contact your authorized Acura NSX dealer, and/or
Acura Client Relations.

2 Client Service Information P. 464

17 NSX-31T6N6000.book 307 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

308

Driving

Towing a Trailer

Your vehicle is not designed to tow a trailer. Attempting to do so can void your
warranties.

Towing Your Vehicle

Your vehicle is not designed to be towed behind a motor home. If your vehicle needs
to be towed in an emergency, refer to the emergency towing information.

2 Emergency Towing P. 448

17 NSX-31T6N6000.book 308 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Acura NSX (2017 year). Manual - part 19
