Acura NSX (2017 year). Manual - part 14

uu

Audio System Basic Operation

u

Playing Bluetooth® Audio

212

Features

1. Make sure that your phone is paired and

connected to the system.

2 Phone Setup P. 266

2. Select the Bluetooth® Audio mode.

If the phone is not recognized, another HFL-
compatible phone, which is not compatible
for Bluetooth® Audio, may already be
connected.

■

To pause or resume a file

Select the play icon or pause icon.

1. Select .
2. Select Music Search.
3. Select a search category (e.g., Albums).
4. Select an item.

u

The selection begins playing.

■

To Play Bluetooth® Audio Files

1

To Play Bluetooth® Audio Files

To play the audio files, you may need to operate your
phone. If so, follow the phone maker’s operating
instructions.

Switching to another mode pauses the music playing
from your phone.

You can change the connected phone in the
Bluetooth® settings on the Audio menu screen by
the following procedure.
1. Select .
2. Select Setting.

■

Searching for Music

1

Searching for Music

Depending on the Bluetooth® device you connect,
some or all of the lists may not be displayed.

17 NSX-31T6N6000.book  212 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

213

uu

Audio System Basic Operation

u

Wi-Fi Connection

Continued

Features

Wi-Fi Connection

You can connect the audio system to the Internet using Wi-Fi and browse websites
or use online services on the audio/information screen. If your phone has wireless
hotspot capabilities, the system can be tethered to the phone. Use the following
steps to setup.

1. Select .
2. Select Settings.
3. Select Bluetooth/Wi-Fi.
4. Select the Wi-Fi tab.
5. Select Wi-Fi On/Off Status, then On.
6. Select Wi-Fi Network List.

u

Make sure your phone’s Wi-Fi setting is
in access point (tethering) mode.

u

Select the phone you want to connect to
the system.

u

If you do not find the phone you want to
connect in the list, select Scan.

7. Select Connect.

u

If needed, enter a password for your
phone and select OK.

u

When the connection is successful, the

 icon is displayed on the top of the

screen.

8. Select

 to go back to the home screen.

■

Wi-Fi mode (setting for the first time)

1

Wi-Fi mode (setting for the first time)

You cannot go through the setting procedure while a
vehicle is moving. Park in a safe place to setup the
Wi-Fi connection.

Some cell phone carriers charge for tethering and
smartphone data use. Check your phone’s data
subscription package.

Check your phone manual to find out if the phone
has Wi-Fi connectivity.

You can confirm whether Wi-Fi connection is on or
off with the

 icon on Wi-Fi Network List.

Network speed will not be displayed on this screen.

17 NSX-31T6N6000.book  213 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

uu

Audio System Basic Operation

u

Wi-Fi Connection

214

Features

Make sure your phone's Wi-Fi setting is in access point (tethering) mode.

■

Wi-Fi mode (after the initial setting has been made)

1

Wi-Fi mode (after the initial setting has been made)

You may need to go through an initial setup for Wi-
Fi connection again after you boot your phone.

iPhone users

17 NSX-31T6N6000.book  214 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

215

uu

Audio System Basic Operation

u

Siri Eyes Free

Features

Siri Eyes Free

You can talk to Siri using the

 (Talk) button on the steering wheel when your

iPhone is paired to the Bluetooth® HandsFreeLink® (HFL) system.

2 Phone Setup P. 266

■

Using Siri Eyes Free

1

Siri Eyes Free

Siri is a trademark of Apple Inc.

Check Apple Inc. website for features available for
Siri.

We recommend against using Siri other than in Siri
Eyes Free mode while operating a vehicle.

1

Using Siri Eyes Free

Some commands work only on specific phone
features or apps.

 (Talk) Button

Press and hold until the display changes as shown.

 (Hang-up/back) Button

Press to deactivate Siri Eyes Free.

While in Siri Eyes Free:
The display remains the same.
No feedback or commands
appear.

Appears
when Siri is
activated in
Siri Eyes Free

17 NSX-31T6N6000.book  215 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

216

uu

Audio System Basic Operation

u

Apple CarPlay

Features

Apple CarPlay

If you connect an Apple CarPlay-compatible iPhone to the system via USB, you can
use the audio/information screen, instead of the iPhone display, to make a phone
call, listen to music, view maps (navigation), and access messages.

2 USB Ports P. 163

■

Phone

Access the contact list, make phone calls, or listen to voice mail.

■

Messages

Check and reply to text messages, or have messages read to you.

■

Music

Play music stored on your iPhone.

■

Apple CarPlay Menu

1

Apple CarPlay

Only iPhone 5 or newer versions with iOS 8.4 or later
are compatible with Apple CarPlay.

Park in a safe place before connecting your iPhone to
Apple CarPlay and when launching any compatible
apps.

To use Apple CarPlay, connect the USB cable to the
USB port located in the console compartment. The
USB port located in the glove box will not enable
Apple CarPlay operation.

2 USB Ports P. 163

To directly access the Apple CarPlay phone function,
select Phone on the home screen. While connected
to Apple CarPlay, calls are only made through Apple
CarPlay. If you want to make a call with
HandsFreeLink, turn Apple CarPlay OFF or detach the
USB cable from your iPhone.

2 Setting Up Apple CarPlay P. 217

When your iPhone is connected to Apple CarPlay, it is
not possible to use the Bluetooth® Audio or
Bluetooth® HandsFreeLink®. However, other
previously paired phones can stream audio via
Bluetooth® while Apple CarPlay is connected.

2 Phone Setup P. 266

For details on countries and regions where Apple
CarPlay is available, as well as information pertaining
to function, refer to the Apple homepage.

Home screen

Apple CarPlay
icon

Apple CarPlay menu screen

Go back to the Apple
CarPlay menu screen

Go back to the
home screen

17 NSX-31T6N6000.book  216 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

Continued

217

uu

Audio System Basic Operation

u

Apple CarPlay

Features

■

Maps

Display Apple CarPlay map and use the navigation function just as you would on
your iPhone.

Only one navigation system (pre-installed navigation or Apple CarPlay) can give
directions at a time. When you are using one system, directions to any prior
destination set on the other system will be canceled, and the system you are
currently using will direct you to your destination.

After you have connected your iPhone to the system via USB, use the following
procedure to set up Apple CarPlay. Use of Apple CarPlay will result in the
transmission of certain user and vehicle information (such as vehicle location, speed,
and status) to your iPhone to enhance the Apple CarPlay experience. You will need
to consent to the sharing of this information on the audio/information screen.

■

Enabling Apple CarPlay

Enable once: Allows only once. (Prompt
shows again next time.)
Always enable: Allows anytime. (Prompt
does not show again.)
Cancel: Does not allow this consent.

You may change the consent settings under
the Smartphone settings menu.

■

Setting Up Apple CarPlay

1

Apple CarPlay

Apple CarPlay Operating Requirements &
Limitations
Apple CarPlay requires a compatible iPhone with an
active cellular connection and data plan. Your
carrier’s rate plans will apply.

Changes in operating systems, hardware, software,
and other technology integral to providing Apple
CarPlay functionality, as well as new or revised
governmental regulations, may result in a decrease or
cessation of Apple CarPlay functionality and services.
Acura cannot and does not provide any warranty or
guarantee of future Apple CarPlay performance or
functionality.

It is possible to use 3rd party apps if they are
compatible with Apple CarPlay. Refer to the Apple
homepage for information on compatible apps.

Models with navigation system

1

Setting Up Apple CarPlay

You can also use the method below to set up Apple
CarPlay:
Select Settings

Smartphone

Apple

CarPlay

Use of user and vehicle information
The use and handling of user and vehicle information
transmitted to/from your iPhone by Apple CarPlay is
governed by the Apple iOS terms and conditions and
Apple’s Privacy Policy.

17 NSX-31T6N6000.book  217 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

uu

Audio System Basic Operation

u

Apple CarPlay

218

Features

Press and hold the talk button to activate Siri Eyes Free.

■

Operating Apple CarPlay with Siri Eyes Free

1

Operating Apple CarPlay with Siri Eyes Free

Below are examples of questions and commands for
Siri Eyes Free.

•

What movies are playing today?

•

Call dad at work.

•

What song is this?

•

How’s the weather tomorrow?

•

Read my latest email.

•

Find a table for four tonight in Chicago.

For more information, please visit
www.apple.com/ios/siri.

 (Talk) button:

Press and hold to activate Siri Eyes Free.
Press again to deactivate Siri Eyes Free.
Press and release to activate standard voice recognition system.

17 NSX-31T6N6000.book  218 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

219

uu

Audio System Basic Operation

u

Android Auto

Continued

Features

Android Auto

When you connect an Android phone to the audio system via USB, Android Auto is
automatically initiated. When connected via Android Auto, you can use the audio/
information screen to access the Phone, Google Maps (Navigation), Google Play
Music, and Google Now functions. When you first use Android Auto, a tutorial will
appear on the screen.
We recommend that you complete this tutorial while safely parked before using
Android Auto.

2 USB Ports P. 163
2 Auto Pairing Connection P. 221

1

Android Auto

To use Android Auto, you need to download the
Android Auto app from Google Play to your
smartphone.

Only Android 5.0 (Lollipop) or later versions are
compatible with Android Auto.
Bluetooth A2DP cannot be used on your phone while
connected to Android Auto.

Park in a safe place before connecting your Android
phone to Android Auto and when launching any
compatible apps.

To use Android Auto, connect the USB cable to the
USB port located in the console compartment. The
USB port in the glove box will not enable Android
Auto operation.

2 USB Ports P. 163

To directly access the Android Auto phone function,
select Phone on the home screen.

2 Auto Pairing Connection P. 221

When your Android phone is connected to Android
Auto, it is not possible to use the Bluetooth® Audio.
However, other previously paired phones can stream
audio via Bluetooth® while Android Auto is
connected.

2 Phone Setup P. 266

17 NSX-31T6N6000.book  219 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

uu

Audio System Basic Operation

u

Android Auto

220

Features

a

 Maps (Navigation)

Display Google Maps and use the navigation function just as you would with your
Android phone. When the vehicle is in motion, it is not possible to make keyboard
entries. Stop the vehicle in a safe location to undertake a search or provide other
inputs.

Only one navigation system (pre-installed navigation or Android Auto) can give
directions at a time. When you are using one system, directions to any prior
destination set on the other system will be canceled, and the system you are
currently using will direct you to your destination.
The audio/information screen shows you turn-by-turn driving directions to your
destination.

b

 Phone (Communication)

Make and receive phone calls as well as listen to voicemail.

c

 Google Now (Home screen)

Display useful information organized by Android Auto into simple cards that appear
just when they’re needed.

■

Android Auto Menu

1

Android Auto

For details on countries and regions where Android
Auto is available, as well as information pertaining to
function, refer to the Android Auto homepage.

Android Auto Operating Requirements &
Limitations
Android Auto requires a compatible Android phone
with an active cellular connection and data plan.
Your carrier’s rate plans will apply.

Changes in operating systems, hardware, software,
and other technology integral to providing Android
Auto functionality, as well as new or revised
governmental regulations, may result in a decrease or
cessation of Android Auto functionality and services.
Acura cannot and does not provide any warranty or
guarantee of future Android Auto performance or
functionality.

It is possible to use 3rd party apps if they are
compatible with Android Auto. Refer to the Android
Auto homepage for information on compatible apps.

: Go back to

the home screen

Android Auto icon

6

Models with navigation system

17 NSX-31T6N6000.book  220 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

Continued

221

uu

Audio System Basic Operation

u

Android Auto

Features

d

 Music and audio

Play Google Play Music and music apps that are compatible with Android Auto.
To switch between music apps, press this icon.

e

 Go back to the Home Screen.

f

 Voice

Operate Android Auto with your voice.

When you connect an Android phone to the unit via USB, Android Auto is
automatically initiated.

■

Enabling Android Auto

Enable once: Allows only once. (Prompt
shows again next time.)
Always enable: Allows anytime. (Prompt
does not show again.)
Cancel: Does not allow this consent.

You may change the consent settings under
the Smartphone settings menu.

■

Auto Pairing Connection

1

Enabling Android Auto

Only initialize Android Auto when you are safely
parked. When Android Auto first detects your phone,
you will need to set up your phone so that auto
pairing is possible. Refer to the instruction manual
that came with your phone.

You can use the method below to change Android
Auto settings after you have completed the initial
setup:
Select Settings

Smartphone

Android

Auto

Use of user and vehicle information
The use and handling of user and vehicle information
transmitted to/from your phone by Android Auto is
governed by Google’s Privacy Policy.

17 NSX-31T6N6000.book  221 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

uu

Audio System Basic Operation

u

Android Auto

222

Features

Press and hold the talk button to operate Android Auto with your voice.

■

Operating Android Auto with Voice Recognition

1

Operating Android Auto with Voice Recognition

Below are examples of commands you can give with
voice recognition:

•

Reply to text.

•

Call my wife.

•

Navigate to Acura.

•

Play my music.

•

Send a text message to my wife.

•

Call flower shop.

For more information, please refer to the Android
Auto homepage.

You can also activate the voice recognition function
by pressing the

 icon in the upper-right corner of

the screen.

 (Talk) button:

Press and hold to operate Android Auto with your voice.
Press again to deactivate voice recognition.
Press and release to activate standard voice recognition system.

17 NSX-31T6N6000.book  222 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

223

Features

Audio Error Messages

iPod/USB Flash Drive

If an error occurs while playing an iPod or USB flash drive, you may see the following
error messages. If you cannot clear the error message, contact an authorized Acura
NSX dealer.

Error Message

Solution

USB Error

Appears when there is a problem with the audio system. Check if the device is
compatible with the audio system.

The connected USB device has a problem.
See Owner’s Manual

Appears when an incompatible device is connected. Disconnect the device. Then turn
the audio system off, and turn it on again. Do not reconnect the device that caused the
error.

Unsupported Version

Appears when an unsupported iPod is connected. If it appears when a supported iPod
is connected, update the iPod software to the newer version.

Connect Retry

Appears when the system does not acknowledge the iPod. Reconnect the iPod.

Unplayable File

Appears when the files in the USB flash drive are copyright protected or an unsupported
format. This error message appears for about three seconds, then plays the next song.

No Data

Appears when the iPod is empty.

Appears when the USB flash drive is empty or there are no MP3, WMA, or AAC files in
the USB flash drive.

Check that compatible files are stored on the device.

Unsupported

Appears when an unsupported device is connected. If it appears when a supported
device is connected, reconnect the device.

iPod

USB flash drive

iPod and USB flash drive

17 NSX-31T6N6000.book  223 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

224

uu

Audio Error Messages

u

Pandora®

Features

Pandora®

If an error occurs while playing Pandora®, you may see the following error messages.
If you cannot clear the error message, contact an authorized Acura NSX dealer.

Error Message

Solution

To begin listening, select a station from the Stations list.

Appears when there is no station list on the device. Use the device
to create a station.

Unable to rate track. Please try again.
Skip limit reached.

Appears when you try to skip a song or select Like/Dislike over
the predetermined number of times in an hour.

Unable to play Pandora. Please try again later.
Unable to retrieve a track explanation. Please try again later.
Unable to create bookmark. Please try again later.

Appears when the commanded operation fails. Try again later.

No Data

Appears when no data is available with Pandora® activated.
Reboot the app and reconnect the device.

Pandora App version is not supported

Appears when Pandora® version is not supported. Update
Pandora® to the latest version.

Unable to complete the operation. Please try again later.

Appears when the Pandora® server is in maintenance. Try again
later.

Unable to connect Pandora. When stopped, check your
mobile phone

Appears when Pandora® is unable to play music. Check your
device.

Unable to connect Pandora. When stopped, check your
mobile phone

Appears when Pandora® app is not installed on your device. Install
Pandora® app to your device.

U.S. models

17 NSX-31T6N6000.book  224 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

225

uu

Audio Error Messages

u

Android/Apps

Features

Android/Apps

If an error occurs while using the audio system or apps, you may see the following
error messages. If you cannot clear the error message, contact an authorized Acura
NSX dealer.

*1:****part is variable characters, and will change depending upon where an error

occurs.

Error Message

*1

Solution

Unfortunately, **** has
stopped.

Error has occurred within app, select OK on the screen to close the app.

**** is not responding.
Would you like to close it?

App is not responding.
Select Wait if you can wait for a response from app a little longer. If it does not respond even if you keep
waiting, select OK to close the app and start it up. If the error message continues, perform Factory Data
Reset.

2 Defaulting All the Settings P. 254

17 NSX-31T6N6000.book  225 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

226

Features

General Information on the Audio System

SiriusXM® Radio Service

*

1. You need your radio ID ready before registering for subscription. To see the ID on

the screen, select Channel 0.

2. Have your radio ID ready, and either call SiriusXM® or visit the SiriusXM® website

to subscribe.

Switch to the SiriusXM® mode by using the SOURCE button on the steering wheel,
or through the audio/information screen, and stay in this mode for about 30
minutes until the service is activated. Make sure your vehicle is in an open area with
good reception.

Channel Not Subscribed:
You are not subscribed to the channel selected.
Subscription Update:
SiriusXM® radio is receiving information update from the network.
Channel Not Available:
No such channel exists, or the artist or title information is unavailable.
No Signal:
The signal is too weak in the current location.
Antenna Disconnected:
The SiriusXM® antenna is disconnected. Contact an authorized Acura NSX dealer.

■

Subscribing to SiriusXM® Radio

■

Receiving SiriusXM® Radio

■

SiriusXM® Radio Display Messages

1

Subscribing to SiriusXM® Radio

Contact Information for SiriusXM® Radio:

•

U.S.: SiriusXM® Radio at www.siriusxm.com or 1-
800-852-9696

•

Canada: SiriusXM® Canada at www.siriusxm.ca, or
1-877-209-0079

1

Receiving SiriusXM® Radio

The SiriusXM® satellites are in orbit over the equator;
therefore, objects south of the vehicle may cause
satellite reception interruptions. Satellite signals are
more likely to be blocked by tall buildings and
mountains the farther north you travel from the
equator.

You may experience reception problems under the
following circumstances:

•

In a location with an obstruction to the south of
your vehicle.

•

In tunnels

•

On the lower level of a multi-tiered road

•

Large items carried on the roof rack

* Not available on all models

17 NSX-31T6N6000.book  226 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

227

uu

General Information on the Audio System

u

Compatible iPod, iPhone, and USB Flash Drives

Features

Compatible iPod, iPhone, and USB Flash Drives

• A USB flash drive of 256 MB or higher is recommended.
• Some digital audio players may not be compatible.
• Some USB flash drives (e.g., a device with security lockout) may not work.
• Some software files may not allow for audio play or text data display.
• Some versions of MP3, WMA, or AAC formats may be unsupported.

■

iPod and iPhone Model Compatibility

Model

iPod (5th generation)

iPod classic 80GB/160GB (launch in 2007)

iPod classic 120GB (launch in 2008)
iPod classic 160GB (launch in 2009)

iPod nano (1st to 7th generation) released between 2005 and 2012

iPod touch (1st to 5th generation) released between 2007 and 2012

iPhone 3G/iPhone 3GS/iPhone 4/iPhone 4S/iPhone 5/iPhone 5c/iPhone 5s/iPhone

6/iPhone 6s/iPhone 6 Plus/iPhone 6s Plus

■

USB Flash Drives

1

iPod and iPhone Model Compatibility

This system may not work with all software versions
of these devices.

1

USB Flash Drives

Files on the USB flash drive are played in their stored
order. This order may be different from the order
displayed on your PC or device.

17 NSX-31T6N6000.book  227 ページ  ２０１６年４月２２日　金曜日　午後３時４４分
