Audio System Basic Operation

u

Audio/Information Screen

180

Features

You can close specific apps running in the background on the system.

1. Select and hold

.

2. Select an app you want to close.
3. Select Stop.

u

The display will return to the app list.

■

Closing Apps

1

Closing Apps

If you have a number of apps running in the
background and something goes wrong with the
audio system, some of those apps may not work
properly. If this happens, close all the apps and re-
launch the app/apps that you want to use.

To close all apps on the system, select Stop All, then
Yes.

You cannot close the Garmin

*

 apps.

* Not available on all models

17 NSX-31T6N6000.book  180 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

181

uu

Audio System Basic Operation

u

Adjusting the Sound

Features

Adjusting the Sound

1. Select .
2. Select Audio.
3. Select .
4. Select Sound.

Select a tab from the following choices:
• BAS-TRE: Bass, Treble
• FAD-BAL: Fader, Balance
• CTR

*

-SUBW: Center

*

, Subwoofer

• SVC-Neural

*

: Speed Volume

Compensation, DTS Neural Surround

TM*

1

Adjusting the Sound

The SVC has four modes: Off, Low, Mid, and High.
SVC adjusts the volume level based on the vehicle
speed. As you go faster, audio volume increases. As
you slow down, audio volume decreases.

You can also adjust the sound the following
procedure.
1. Select .
2. Select Settings.
3. Select Audio.
4. Select Sound.

* Not available on all models

17 NSX-31T6N6000.book  181 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

182

uu

Audio System Basic Operation

u

Display Setup

Features

Display Setup

You can change the brightness or color theme of the audio/information screen.

1. Select .
2. Select Settings.
3. Select System.
4. Select the Display tab.
5. Select Display Settings.
6. Select the setting you want.
7. Select OK.

1. Select .
2. Select Settings.
3. Select System.
4. Select the Display tab.
5. Select Background Color.
6. Select the setting you want.
7. Select OK.

■

Changing the Screen Brightness

1

Changing the Screen Brightness

You can change the Contrast and Black Level
settings in the same manner.

■

Changing the Screen’s Color Theme

1

Changing the Screen’s Color Theme

When the vehicle is in SPORT+ or TRACK mode, the
background color of the screen automatically
changes to red.

17 NSX-31T6N6000.book  182 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

183

uu

Audio System Basic Operation

u

Display Setup

Features

Select the current source icon, then select an icon on the source list to switch the
audio source.

Certain manual functions are disabled or inoperable while the vehicle is in motion.
You cannot select a grayed-out option until the vehicle is stopped.

■

Selecting an Audio Source

1

Selecting an Audio Source

If you startup pre-installed audio apps,

 is

displayed on the lower right of the screen.
These pre-installed apps cannot be displayed on the
source select screen.
You can startup those audio apps from

.

Pandora® is available only in the U.S..

■

Limitations for Manual Operation

Select the source icon.

Source Select Screen

Source List Icons

1

Limitations for Manual Operation

When the vehicle is in TRACK mode, the following
screen is displayed and the audio system becomes
inoperable. To return to the normal screen, touch any
part of the audio/information screen.
You can turn the limitation on and off.

2 Customized Features P. 232

17 NSX-31T6N6000.book  183 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

184

uu

Audio System Basic Operation

u

Voice Control Operation

Features

Voice Control Operation

Your vehicle has a voice control system that allows hands-free operation.
The voice control system uses the

 (Talk) and

 (hang-up/back) buttons on

the steering wheel and a microphone near the map lights on the ceiling.

To achieve optimum voice recognition when using the voice control system:
• Make sure the correct screen is displayed for the voice command that you are

using.

• Close the windows.
• Adjust the dashboard and side vents so air does not blow onto the microphone

on the ceiling.

• Speak clearly in a natural speaking voice without pausing between words.
• Reduce any background noise if possible. The system may misinterpret your

command if more than one person is speaking at the same time.

■

Voice Recognition

1

Voice Control Operation

When you press the

 button, a helpful prompt asks

what you would like to do. Press and release the



button again to bypass this prompt and give a
command.

1

Voice Recognition

The voice control system can only be used from the
driver’s seat because the microphone unit removes
noises from the front passenger’s side.

17 NSX-31T6N6000.book  184 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

185

uu

Audio System Basic Operation

u

Voice Control Operation

Continued

Features

When the

 (Talk) button is pressed,

available voice commands appear on the
screen.
For a complete list of commands, say “Voice
Help” after the beep or select Voice Help.

You can see the list of commands in Voice
Info on the Info menu screen. Select Info,
then select

.

*1: Models with navigation system

■

Voice Portal Screen

■

Phone Call

This can be only used when the phone is
connected. When the system recognizes the
Phone call command, the screen will
change to the voice recognition screen for
phone commands.
• Dial by number
• Call history
• Redial
• Call <Your Contact Name>
• Call <Phone Number>
• Call Police
• Call 911
Phone Call commands are not available if
using Apple CarPlay.

■

Music Search

*1

This can be only used when the iPod or USB
device is connected.

■

Climate Control

*1

When the system recognizes the Climate
Control command, the screen will change
the dedicated screen to the climate control
voice recognition screen.

2 Climate Control Commands

*1

 P. 187

■

Audio

*1

When the system recognizes the Audio
command, the screen will change to the
audio voice recognition screen.
• Audio On
• Audio Off
• Radio FM
• Radio SXM

*

• Pandora

*

• iPod
• USB
• Other Sources
When there is an active connection to
Android Auto, Pandora

*

 can only be played

from within Android Auto.

■

Navigation

*1

The screen changes to the navigation
screen.

2 Refer to the Navigation System Manual

■

Voice Setting

The screen changes to the Voice Recog tab
on the System settings screen.

* Not available on all models

17 NSX-31T6N6000.book  185 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

186

uu

Audio System Basic Operation

u

Voice Control Operation

Features

■

Voice Help

You can see a list of the available
commands on the screen.
• Useful Commands
• Phone Commands
• Audio Commands

*1

• On Screen Commands
• Music Search Commands

*1

• General Commands
• Climate Control Commands

*1

The system accepts these commands on the
voice portal top screen.
• Call <Phone Number>
• Call <Your Contact Name>
• What time is it?
• What is today’s date?

*1: Models with navigation system

■

Useful Commands

The system accepts these commands on the
dedicated screen for the voice recognition
of the phone.
• Call by Number
• Call by Name
• Call <Phone Number>
• Call <Your Contact Name>

The system accepts these commands on the
dedicated screen for the voice recognition
of the audio.

■

Radio FM Commands

• Radio tune to <87.7-107.9> FM
• Radio tune to <87.7 -107.9> HD <1-8>

FM

• Radio FM preset <1-12>

■

Radio SXM Commands

*

• SXM channel <1-999>
• SXM channel <channel name, category

name, traffic and weather city name,
sports team name>

• Radio SXM preset <1-12>

■

Phone Commands

■

Audio Commands

*1

■

Pandora Commands

*

• Pandora play

■

iPod Commands

• iPod play
• iPod play track <1-30>
• Music Search
• What album is this?
• What am I listening to?

■

USB Commands

• USB play
• USB play track <1-30>
• Music Search
• What album is this?
• What am I listening to?

■

Bluetooth® Audio Commands

• Bluetooth® Audio play
NOTE:
Bluetooth® Audio commands may not work
on some phones or Bluetooth® Audio
devices.

* Not available on all models

17 NSX-31T6N6000.book  186 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

187

uu

Audio System Basic Operation

u

Voice Control Operation

Features

When On Screen Commands is selected,
the explanation screen is displayed.

The system accepts these commands on the
Music Search screen.

■

Using Song By Voice

Song By Voice

TM

 is a feature that allows you

to select music from your iPod or USB device
using Voice Commands. To activate this
mode, you must push the talk switch and
say: “Music search”.

■

Song By Voice Commands

• What am I listening to?
• Who am I listening to?
• Who is this?
• What’s playing?
• Who’s playing?
• What album is this?

*1: Models with navigation system

■

On Screen Commands

■

Music Search Commands

*1

■

Play Commands

• Play artist <Name>
• Play track/song <Name>
• Play album <Name>
• Play genre/category <Name>
• Play playlist <Name>
• Play composer <Name>

■

List Commands

• List artist <Name>
• List album <Name>
• List genre/category <Name>
• List playlist <Name>
• List composer <Name>

• What time is it?
• What is today’s date?

■

General Commands

• Climate Control on
• Climate Control off
• Fan Speed <1-7>
• Temperature max heat
• Temperature max cool
• Temperature <57-87> degrees
• Defrost on
• Defrost off
• Air conditioner on
• Air conditioner off
• More
• Climate control automatic
• Vent
• Dash and floor
• Fan speed up
• Fan speed down
• Floor vents
• Floor and defrost
• Temperature up
• Temperature down

■

Climate Control Commands

*1

17 NSX-31T6N6000.book  187 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

188

uu

Audio System Basic Operation

u

Playing FM Radio

Features

Playing FM Radio

*1:Some or all of the lists may not be displayed.

VOL (Volume) Icons
Select to adjust the volume.

 (Back) Icon

Select to go back to the previous
display.

Seek Icons
Select

 or

 to search the

selected band up or down for a
station with a strong signal.

 (Power/Audio) Icon

Select to turn the audio system on
and off.

Open/Close Icon

*1

Displays/hides the detailed
information.

 (Menu) Icon

Select to display the menu items.

Tune Icons
Select

 or

 to tune the radio frequency.

Audio/Information Screen

Scan Icon
Select to scan each station with a strong signal.

Preset Icons
Tune the preset radio frequency. Select and hold the
preset icon to store that station. Select   to display
preset 7 onwards.

17 NSX-31T6N6000.book  188 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

Continued

189

uu

Audio System Basic Operation

u

Playing FM Radio

Features

To store a station:
1. Tune to the selected station.
2. Select and hold the preset number for the station you want to store.

You can also store a preset station by the following procedure.
1. Tune to the selected station.
2. Select the open/close icon to display a list.
3. Select the Preset tab.
4. Select and hold the preset number for the station you want to store.

Lists the strongest stations on the selected band.
1. Select the open/close icon to display a list.
2. Select the Station List tab.
3. Select the station.

■

Manual update

Updates your available station list at any time.
1. Select the open/close icon to display a list.
2. Select the Station List tab.
3. Select Refresh.

■

Preset Memory

■

Station List

1

Preset Memory

The ST indicator appears on the display indicating
stereo FM broadcasts.

Switching the Audio Mode
Press the SOURCE button on the steering wheel or
select SOURCE on the screen.

2 Audio Remote Controls P. 165

You can store 12 FM stations into preset memory.

HD Radio Technology manufactured under license
from iBiquity Digital Corporation. U.S. and Foreign
Patents. HD Radio

TM

 and the HD, HD Radio, and

“Arc” logos are proprietary trademarks of iBiquity
Digital Corp.

17 NSX-31T6N6000.book  189 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

190

uu

Audio System Basic Operation

u

Playing FM Radio

Features

Samples each of the strongest stations on the selected band for 10 seconds. To turn
off scan, select Cancel or

.

Displays the subchannel list when an HD Radio

TM

 station is selected while listening to

an FM station.
1. Select .
2. Select HD Radio Subchannel.
3. Select the channel number.

■

Scan

■

HD Subchannel

17 NSX-31T6N6000.book  190 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

191

uu

Audio System Basic Operation

u

Playing FM Radio

Features

Provides text data information related to your selected RDS-capable FM station.

■

To find an RDS station from Station List

1. Select the open/close icon to display a list while listening to an FM station.
2. Select the Station List tab.
3. Select the station.

■

Manual update

Updates your available station list at any time.
1. Select the open/close icon to display a list while listening to an FM station.
2. Select the Station List tab.
3. Select Refresh.

■

Radio text

Displays the radio text information of the selected RDS station.
1. Select .
2. Select View Radio Text.

■

Scan

Samples each of the strongest stations on the selected band for 10 seconds.

To turn off scan, select Cancel or

.

■

Radio Data System (RDS)

1

Radio Data System (RDS)

When you select an RDS-capable FM station, the RDS
automatically turns on, and the frequency display
changes to the station name. However, when the
signals of that station become weak, the display
changes from the station name to the frequency.

17 NSX-31T6N6000.book  191 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

192

uu

Audio System Basic Operation

u

Playing SiriusXM® Radio

*

Features

Playing SiriusXM® Radio

*

*1:Some or all of the lists may not be displayed.

VOL (Volume) Icons
Select to adjust the volume.

 (Back) Icon

Select to go back to the previous
display.

Channel Icons
Select

 or

 to the previous

or next channel.
Select and hold to rapidly skip 10
channels at a time.

 (Power/Audio) Icon

Press to turn the audio system on
and off.

Open/Close Icon

*1

Displays/hides the detailed
information.

 (Menu) Icon

Select to display the menu items.

Category Icons
Select

 or

 to display and select a

SiriusXM® Radio category.

Audio/Information Screen

Scan Icon
Select to scan each channel.

Preset Icons
Tune the preset radio station. Select
and hold the preset icon to store that
station. Select   to display preset 7
onwards.

Skip Icons
Select

 or

 to change

section in the channel.Select and
hold to move rapidly within the
section.

Station Art

* Not available on all models

17 NSX-31T6N6000.book  192 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

Continued

193

uu

Audio System Basic Operation

u

Playing SiriusXM® Radio

*

Features

1. Select .
2. Select Tune Mode.
3. Select Channel Mode or Category Mode.

■

To Change the Tune Mode

1

Playing SiriusXM® Radio

*

In the channel mode, all available channels are
selectable. In the category mode, you can select a
channel within a category (Jazz, Rock, Classical, etc.).

There may be instances when SiriusXM® Radio does
not broadcast all the data fields (artist name, title).
This does not indicate a problem with your audio
system.

SiriusXM® Radio stations load in ascending order,
which can take about a minute. Once they have
loaded you will be able to scroll up or down to make
your selections.

Switching the Audio Mode
Press the SOURCE button on the steering wheel or
select SOURCE on the screen.

2 Audio Remote Controls P. 165

Tune Start:
When you change to a preset channel, a song being
played on that channel restarts from the beginning
with this function. This can be turned on or off from
the Audio settings screen.

2 Customized Features P. 232

* Not available on all models

17 NSX-31T6N6000.book  193 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

uu

Audio System Basic Operation

u

Playing SiriusXM® Radio

*

194

Features

To store a channel:
1. Tune to the selected channel.
2. Press and hold the preset number for the station you want to store.
3. Select Replace.

You can also store a channel by the following procedure.
1. Tune to the selected channel.
2. Select the open/close icon to display a list.
3. Select the Preset tab.
4. Select and hold the preset number for the station you want to store.

■

Multi-channel preset (for music channels only)

You can store up to five of your preferred music channels per preset.

1. Tune a station.
2. Select the open/close icon to display a list.
3. Select the Preset tab.
4. Select and hold the preset number you

want to add a music channel.

u

A message appears if there are no
available presets.

5. Select Combine.

■

Preset Memory

1

Playing SiriusXM® Radio

*

You can store 12 SiriusXM® channels into the preset
memory.

* Not available on all models

17 NSX-31T6N6000.book  194 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

Continued

195

uu

Audio System Basic Operation

u

Playing SiriusXM® Radio

*

Features

Suggested channel listing received from SiriusXM® can be displayed and selected.
1. Select the open/close icon to display a channel list.
2. Select the Channel List tab.
3. Select the featured channel list title you want to listen to.

u

The selected channel list of the title is displayed.

4. Select the channel.

■

Listening to Featured Channels

1

Listening to Featured Channels

Up to three featured channels by SiriusXM® can be
displayed.

Featured channel lists are at the top of the channel
list.

17 NSX-31T6N6000.book  195 ページ  ２０１６年４月２２日　金曜日　午後３時４４分
