Acura NSX (2017 year). Manual

148

Adjusting the Seats

Maintain a Sitting Proper Position

Co
ntrols

Maintain a Sitting Proper Position

After all occupants have adjusted their seats and put on their seat belts, it is very
important that they continue to sit upright, well back in their seats, with their feet
on the floor, until the vehicle is safely parked and the power system is off.

Sitting improperly can increase the chance of injury during a crash. For example, if
an occupant slouches, lies down, turns sideways, sits forward, leans forward or
sideways, or puts one or both feet up, the chance of injury during a crash is greatly
increased.

In addition, an occupant who is out of position in the seat can be seriously or fatally
injured in a crash by striking interior parts of the vehicle or being struck by an
inflating front airbag.

Maintain a Sitting Proper Position

WARNING

Sitting improperly or out of position can
result in serious injury or death in a crash.

Always sit upright, well back in the seat,
with your feet on the floor.

17 NSX-31T6N6000.book 148 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

149

Continued

Co
ntrols

Interior Lights/Interior Convenience Items

Interior Lights

■

The interior lights come on regardless whether
the doors are open or closed.

■

Door activated

The interior lights come on in the following
situations:
• When either of the doors are opened.
• You unlock the driver’s door.
• When the power mode is set to VEHICLE

OFF (LOCK).

■

OFF

The interior lights remain off regardless
whether the doors are open or closed.

■

Interior Light Switches

Interior Light Switches

In the door activated position, the interior lights fade
out and go off about 30 seconds after the doors are
closed.
The lights go off after 30 seconds in the following
situations:

•

When you unlock the driver’s door but do not open
it.

•

When you set the power mode to VEHICLE OFF
(LOCK) but do not open a door.

You can change the interior lights dimming time.

2 Customized Features P. 232

The interior lights go off immediately in the following
situations:

•

When you lock the driver’s door.

•

When you close the driver’s door in ACCESSORY
mode.

•

When you set the power mode to ON.

If you leave either door open in VEHICLE OFF (LOCK)
mode, the interior lights go off after about 15
minutes.

Door Activated Position

Off

17 NSX-31T6N6000.book 149 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Interior Lights/Interior Convenience Items

Interior Lights

150

Co
ntrols

The map lights can be turned on and off by
pressing the

(map light) button.

■

Map Lights

Map Lights

When the ceiling light switch is in the door activated
position and either door is open, the map light will
not go off when you press the

(map light) button.

17 NSX-31T6N6000.book 150 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

151

Interior Lights/Interior Convenience Items

Interior Convenience Items

Continued

Co
ntrols

Interior Convenience Items

Pull the handle to open the glove box.
You can lock the glove box with the built-in
key.

■

Glove Box

Glove Box

WARNING

An open glove box can cause serious injury
to your passenger in a crash, even if the
passenger is wearing the seat belt.

Always keep the glove box closed while
driving.

Glove Box

Handle

17 NSX-31T6N6000.book 151 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

152

Interior Lights/Interior Convenience Items

Interior Convenience Items

Co
ntrols

Pull the lid to open the console compartment.

■

Console Compartment

17 NSX-31T6N6000.book 152 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

153

Interior Lights/Interior Convenience Items

Interior Convenience Items

Co
ntrols

Insert the beverage holders into the passenger
side of the center console.

■

Beverage Holders

Beverage Holders

NOTICE

Spilled liquids damage the upholstery, carpeting, and
electrical components in the interior.

17 NSX-31T6N6000.book 153 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Interior Lights/Interior Convenience Items

Interior Convenience Items

154

Co
ntrols

The accessory power socket can be used when the power mode is in ACCESSORY or
ON.

■

Accessory power socket

Open the cover to use it.

■

Accessory Power Socket

Accessory Power Socket

NOTICE

Do not insert an automotive type cigarette lighter
element.
The power socket can overheat.

The accessory power socket is designed to supply
power for 12-volt DC accessories that are rated 180
watts (15 amps) or less.

To prevent draining the 12-volt battery, use the
power socket only when the power system on.

17 NSX-31T6N6000.book 154 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

155

Interior Lights/Interior Convenience Items

Interior Convenience Items

Co
ntrols

The power mode must be in ON to use the
seat heaters. The HI setting heats the seats
faster than the LO setting.

Press the seat heater button:
Once - The HI setting (three indicators on)
Twice - The MID setting (two indicators on)
Three times - The LO setting (one indicator on)
Four times - The OFF setting (no indicators on)

Once a comfortable temperature has been
reached using HI setting, select MID or LO to
keep the seat warm.

■

Seat Heaters

Seat Heaters

Do not use the seat heaters even in LO when the
power system is off. Under such conditions, the 12-
volt battery may be weakened, making the power
system difficult to start.

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models

17 NSX-31T6N6000.book 155 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

156

Co
ntrols

Climate Control System

Using Automatic Climate Control

The automatic climate control system maintains the interior temperature you select.
The system also selects the proper mix of heated or cooled air to raise or lower the
interior temperature to your preference as quickly as possible.

Use the system when the

power system is ON.

1. Press the AUTO button.
2. Adjust the interior temperature using the driver’s side or passenger’s side control

buttons.

3. Press the

button to cancel.

Using Automatic Climate Control

Press the CLIMATE button to display A/C, MODE, fan
control information on the audio/information screen
for several seconds. Select icon to turn on or off A/C,
change the vent mode, or change the fan speed.

If any buttons are pressed while using the climate
control system in auto, the function of the button
that was pressed will take priority.

The AUTO indicator will go off, but functions
unrelated to the button that was pressed will be
controlled automatically.

To prevent cold air from blowing in from outside, the
fan may not start immediately when the AUTO
button is pressed.

If the interior is very warm, you can cool it down
more rapidly by partially opening the windows,
turning the system to AUTO, and setting the
temperature to low. Change the fresh mode to
recirculation mode until the temperature cools down.

When you set the temperature to the lower or upper
limit, Lo or Hi is displayed.

Pressing the

button switches the climate control

system on or off. When turned on, the system returns
to your last selection.

*1: MID vents provide supplemental air to the lower
body of the occupant(s). MID vents can be used
together with any other vent mode.

Dashboard
vents

Dashboard
and floor
vents

Floor vents

Floor and
defroster
vents

MID vents

17 NSX-31T6N6000.book 156 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

157

Climate Control System

Using Automatic Climate Control

Continued

Co
ntrols

■

Switching between the recirculation and fresh air modes

Press the

(recirculation) button and switch the mode depending on

environmental conditions.
Recirculation mode (indicator on): Recirculates air from the vehicle’s interior through
the system.
Fresh air mode (indicator off): Maintains outside ventilation. Keep the system in
fresh air mode in normal situations.

17 NSX-31T6N6000.book 157 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Climate Control System

Using Automatic Climate Control

158

Co
ntrols

Pressing the

(windshield defroster) button

turns the air conditioning system on and
automatically switches the system to fresh air
mode.

Press the

button again to turn off, the

system returns to the previous settings.

■

To rapidly defrost the windows

1. Press the

button.

2. Press the

button.

■

Defrosting the Windshield and Windows

Defrosting the Windshield and Windows

For your safety, make sure you have a clear view
through all the windows before driving.

Do not set the temperature near the upper or lower
limit.
When cold air hits the windshield, the outside of the
windshield may fog up.

If the side windows fog up, adjust the vents so that
the air hits the side windows.

To rapidly defrost the windows

After defrosting the windows, switch over to fresh air
mode. If you keep the system in recirculation mode,
the windows may fog up from humidity. This
impedes visibility.

17 NSX-31T6N6000.book 158 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

159

Climate Control System

Synchronized Mode

Co
ntrols

Synchronized Mode

You can set the temperature synchronously for the driver’s side and the passenger’s
side in synchronized mode.
1. Press the SYNC button.

The system switches to synchronized mode.

2. Adjust the temperature using the driver’s side temperature control buttons.

Press the SYNC button to return to dual mode.

Synchronized Mode

When the system is in dual mode, the driver’s side
temperature and the passenger’s side temperature
can be set separately.

SYNC Button

Driver Side
Temperature
Control
Button

Passenger Side
Temperature
Control
Button

17 NSX-31T6N6000.book 159 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

160

Climate Control System

Automatic Climate Control Sensors

Co
ntrols

Automatic Climate Control Sensors

The automatic climate control system is
equipped with sensors. Do not cover or spill
any liquid on them.

Sensor

17 NSX-31T6N6000.book 160 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

162

Features

Audio System

About Your Audio System

The audio system features FM radio and SiriusXM® Radio service

. It can also play

USB flash drives, and iPod, iPhone and Bluetooth® devices.

You can operate the audio system from the icons on the touchscreen interface or
the remote controls on the steering wheel.

About Your Audio System

SiriusXM® Radio

is available on a subscription basis

only. For more information on SiriusXM® Radio,
contact an authorized Acura NSX dealer.

2 General Information on the Audio System

P. 226

SiriusXM® Radio

is available in the United States and

Canada, except Hawaii, Alaska, and Puerto Rico.

SiriusXM®

is a registered trademark of SiriusXM

Radio, Inc.

iPod, iPhone and iTunes are trademarks of Apple Inc.

State or local laws may prohibit the operation of
handheld electronic devices while operating a
vehicle.

Remote Controls

iPod

USB Flash Drive

* Not available on all models

17 NSX-31T6N6000.book 162 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

163

Audio System

USB Ports

Features

USB Ports

Install the iPod USB connector or the USB flash drive to the USB port.

■

In the glove box

The USB port (1.0A) is for playing audio files
on a USB flash drive and connecting a cellular
phone and charging device.

■

In the console compartment

The USB port (1.5A) is for charging devices,
playing audio files and connecting compatible
phones with Apple CarPlay or Android Auto.

USB Ports

•

Do not leave the iPod or USB flash drive in the
vehicle. Direct sunlight and high temperatures may
damage it.

•

We recommend using an extension cable with the
USB port.

•

Do not connect the iPod or USB flash drive using a
hub.

•

Do not use a device such as a card reader or hard
disk drive, as the device or your files may be
damaged.

•

We recommend keeping your data backed up
before using the device in your vehicle.

•

Displayed messages may vary depending on the
device model and software version.

If the audio system does not recognize the iPod, try
reconnecting it a few times or reboot the device. To
reboot, follow the manufacturer’s instructions
provided with the iPod or visit www.apple.com/ipod.

The USB port can supply up to 1.0A/1.5A of power. It
does not output 1.0A/1.5A unless requested by the
device.
For amperage details, read the operating manual of
the device that needs to be charged.
Set the power mode to ACCESSORY or ON first.

Under certain conditions, a device connected to the
port may generate noise in the radio you are listening
to.

USB charge

In the glove box

In the console compartment

17 NSX-31T6N6000.book 163 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Acura NSX (2017 year). Manual - part 10
