Acura NSX (2017 year). Manual - part 9

uu

Operating the Switches Around the Steering Wheel

u

Light Switches

132

Co
ntrols

Automatic lighting control can be used when
the power mode is in ON.

When the light switch is in AUTO, the
headlights and other exterior lights will switch
on and off automatically depending on the
ambient brightness.

You can change the auto light sensitivity
setting.

2 Customized Features P. 232

■

Automatic Operation (automatic lighting control)

1

Automatic Operation (automatic lighting control)

We recommend that you turn on the lights manually
when driving at night, in a dense fog, or in dark areas
such as long tunnels or parking facilities.

The light sensor is in the location shown below.
Do not cover this light sensor with anything;
otherwise, the automatic lighting system may not
work properly.

Adjust the auto light sensitivity as follows:

2 Customized Features P. 232

Setting

The exterior lights come on

when the ambient light is at

MAX

HIGH

MID

LOW

MIN

Light Sensor

Bright

Dark

17 NSX-31T6N6000.book  132 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

133

uu

Operating the Switches Around the Steering Wheel

u

Light Switches

Co
ntrols

The headlights automatically come on when the wipers are used several times within
a certain interval with the headlight switch in AUTO.
The headlights automatically go off a few minutes later if the wipers are stopped.

The headlights, all other exterior lights, and the instrument panel lights turn off 15
seconds after you set the power mode to VEHICLE OFF (LOCK), take the remote with
you, and close the driver’s door.

If you set the power mode to VEHICLE OFF (LOCK) with the headlight switch on, but
do not open the door, the lights turn off after 10 minutes (3 minutes, if the switch
is in the AUTO position).

The lights turn on again when you unlock or open the driver’s door. If you unlock
the door, but do not open it within 15 seconds, the lights go off. If you open the
driver’s door, you will hear a lights on reminder chime.

■

Headlight Integration with Wipers

■

Automatic Lighting Off Feature

1

Headlight Integration with Wipers

This feature activates when the headlights are off in
AUTO.
The instrument panel brightness does not change
when the headlights come on.

At dark ambient light levels, the automatic lighting
control feature turns on the headlights, regardless of
the number of wiper sweeps.

1

Automatic Lighting Off Feature

 You can change the headlight auto off timer setting.

2 Customized Features P. 232

17 NSX-31T6N6000.book  133 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

134

uu

Operating the Switches Around the Steering Wheel

u

Daytime Running Lights

Co
ntrols

Daytime Running Lights

The daytime running lights come on when the following conditions have been met:
• The power mode is in ON.
• The headlight switch is in AUTO or

.

• The parking brake is released.

The daytime running lights are off the headlight switch is turned on, or when the
headlight switch is in AUTO and it is getting darker outside.

1

Daytime Running Lights

The brightness of the daytime running lights is lower
when the headlight switch is in

 than when it is

in AUTO. When it is in AUTO, the low-beam
headlights come on once the level of ambient light is
very low.

U.S. models

17 NSX-31T6N6000.book  134 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

135

uu

Operating the Switches Around the Steering Wheel

u

Wipers and Washers

Co
ntrols

Wipers and Washers

The windshield wipers and washers can be
used when the power mode is in ON.

■

MIST

The wipers run at high speed until you release
the lever.

■

Wiper switch (OFF, INT, LO, HI)

Change the wiper switch setting according to
the amount of rain.

■

Adjusting wiper operation

Turn the adjustment ring to adjust wiper
operation.

■

Washer

Sprays while you pull the lever toward you.
When you release the lever for more than one
second, the spray stops, the wipers sweep two
or three more times to clear the windshield,
then stop.

■

Windshield Wiper/Washer

1

Wipers and Washers

NOTICE

Do not use the wipers when the windshield is dry.
The windshield will get scratched, or the rubber
blades will get damaged.

NOTICE

In cold weather, the blades may freeze to the
windshield.
Operating the wipers in this condition may damage
wipers. Use the defroster to warm the windshield,
then turn the wipers on.

If the vehicle speeds up while the wipers are
operating intermittently, the length of the wipe
interval shortens.
When the vehicle speeds up, the wiper operation’s
shortest delay setting ( ) and the LO setting become
the same.

Turn the washers off if no washer fluid comes out.
The pump may get damaged.

The wiper motor may stop motor operation
temporarily to prevent an overload. Wiper operation
will return to normal within a few minutes, once the
circuit has returned to normal.

If the wipers stop operating due to any obstacle such
as the build-up of snow, park the vehicle in a safe
place.
Rotate the wiper switch to OFF, and set the power
mode to ACCESSORY or VEHICLE OFF (LOCK), then
remove the obstacle.

MIST

OFF

LO: Low speed wipe

HI: High speed wipe

Pull to
use
washer.

INT: Low speed with
intermittent

Lower speed, fewer sweeps

Higher speed, more sweeps

17 NSX-31T6N6000.book  135 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

136

uu

Operating the Switches Around the Steering Wheel

u

Brightness Control

Co
ntrols

Brightness Control

When the power mode is in ON, you can use
the

(

+ or

(

- button to adjust instrument

panel brightness.
To brighten: Press the

(

+ button.

To dim: Press the

(

- button.

You will hear a beep when the brightness
reaches minimum or maximum. Several
seconds after you have adjusted the
brightness, you will be returned to the
previous screen.

■

Brightness level indicator

The brightness level is shown on the driver
information interface while you are adjusting
it.

1

Brightness Control

Instrument panel brightness varies, depending on
whether the exterior lights are on or off. The
instrument panel dims to reduce glare when they are
on.

When it is bright outside and the headlight
integration with the wiper is activated, the
instrument panel brightness does not change.

If you press the

(

+ button until the brightness display

is up to max

, the beeper sounds. This cancels the

reduced instrument panel brightness when the
exterior lights are on.

The brightness can be set differently for when the
exterior lights are on, and when they are off.

(

+ Button

(

- Button

17 NSX-31T6N6000.book  136 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

137

uu

Operating the Switches Around the Steering Wheel

u

Rear Defogger/Heated Door Mirror Button

Co
ntrols

Rear Defogger/Heated Door Mirror Button

Press the rear defogger and heated door
mirror button to defog the rear window and
mirrors when the power mode is in ON.

The rear defogger and heated door mirrors
automatically switch off after 10-30 minutes
depending on the outside temperature.

However, if the outside temperature is 32°F
(0°C) or below, they do not automatically
switch off.

1

Rear Defogger/Heated Door Mirror Button

NOTICE

When cleaning the inside of the rear window, be
careful not to damage the heating wires.
It is critical to wipe the window from side to side
along the defogger heating wires.

This system consumes a lot of power, so turn it off
when the window has been defogged.
Also, do not use the system for a long time while the
power system is stopped. This may weaken the 12-
volt battery, making it difficult to turn the power
system on.

When the outside temperature is below 41°F (5°C),
the heated door mirror may activate automatically for
10 minutes when you set the power mode to ON.

17 NSX-31T6N6000.book  137 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

138

uu

Operating the Switches Around the Steering Wheel

u

Driving Position Memory System

*

Co
ntrols

Driving Position Memory System

*

You can store two driver’s seat (except for power lumbar) and outside door mirrors
position with the driving position memory system.
When you unlock and open the driver’s door with a remote transmitter, or keyless
access system, the seat and outside door mirrors adjust automatically to one of the
two preset positions.

When you enter the vehicle, the driver information interface briefly shows you which
remote transmitter you used to unlock the vehicle.
• DRIVER 1 transmitter is linked to memory button 1.
• DRIVER 2 transmitter is linked to memory button 2.

The driver’s seat moves rearward depending
on the set seating position once you
• Stop the vehicle.
• Put the transmission in

(

P.

• Set the power mode to VEHICLE OFF

(LOCK).

• Then open the driver’s door.
Once the power mode is in the ACCESSORY
position, the driver’s seat moves to the
DRIVER 1 or 2 preset position.

1

Driving Position Memory System

*

Using the audio/information screen, you can disable
the automatic seat and door mirrors adjustment
function.

2 Customized Features P. 232

The driver’s seat easy exit feature:

•

Will tilt slightly forward and then move rearward to
allow you to more easily exit the vehicle.

•

Can be turned ON/OFF.

2 Customized Features P. 232

System Operation
The system will not operate if:

•

The vehicle speed is above 3 mph (5 km/h).

•

Either memory position button is pressed while the
seat is in motion.

•

The seat position is adjusted while in operation.

•

The memory 1 or 2 position is set fully to the rear.

DRIVER 1

DRIVER 2

* Not available on all models

17 NSX-31T6N6000.book  138 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

139

uu

Operating the Switches Around the Steering Wheel

u

Driving Position Memory System

*

Co
ntrols

1. Set the power mode to ON. Adjust the

driver’s seat and the door mirrors to the
desired position.

2. Press the SET button.

u

You will hear the beep, and the memory
button indicator light will blink.

3. Press memory button

(

1 or

(

2 within five

seconds of pressing the SET button.

u

Once the seat and the outside mirrors
position have been memorized, the
indicator light on the button you pressed
stays on.

1. Change to

(

P.

2. Apply the parking brake.
3. Press a memory button (

(

1 or

(

2).

u

You will hear the beep, and the indicator
light will blink.

The seat and the door mirrors will
automatically move to the memorized
positions. When it has finished moving, you
will hear the beep, and the indicator light
stays on.

■

Storing a Position in Memory

1

Storing a Position in Memory

After you press the SET button, the storing operation
will be canceled when:

•

You do not press the memory button within five
seconds.

•

You readjust the seat or the outside mirror position
before the double-beep.

•

You set the power mode to any position except
ON.

SET Button

Memory
Button 1

Memory
Button 2

■

Recalling the Stored Position

1

Recalling the Stored Position

The seat and door mirrors will stop moving if you:

•

Press the SET button, or a memory button (

(

1 or

(

2).

•

Adjust the seat position or door mirrors.

•

Shift into a position other than

(

P.

Memory Buttons

17 NSX-31T6N6000.book  139 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

140

uu

Operating the Switches Around the Steering Wheel

u

Adjusting the Steering Wheel

Co
ntrols

Adjusting the Steering Wheel

The steering wheel height and distance from your body can be adjusted so that you
can comfortably grip the steering wheel in an appropriate driving posture.

1. Push the steering wheel adjustment lever

down.

u

The steering wheel adjustment lever is
under the steering column.

2. Move the steering wheel up or down, and

in or out.

u

Make sure you can see the instrument
panel gauges and indicators.

3. Pull the steering wheel adjustment lever up

to lock the steering wheel in position.

u

After adjusting the position, make sure
you have securely locked the steering
wheel in place by trying to move it up,
down, in, and out.

1

Adjusting the Steering Wheel

Make any steering wheel adjustments before you
start driving.

3

WARNING

Adjusting the steering wheel position while
driving may cause you to lose control of the
vehicle and be seriously injured in a crash.

Adjust the steering wheel only when the
vehicle is stopped.

To adjust

To lock

Lever

17 NSX-31T6N6000.book  140 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

141

Co
ntrols

Adjusting the Mirrors

Interior Rearview Mirror

Adjust the angle of the rearview mirror when you are sitting in the correct driving
position.

When you are driving after dark, the
automatic dimming rearview mirror reduces
the glare from headlights behind you, based
in inputs from the mirror sensor. This feature
is always active.

■

Automatic Dimming Rearview Mirror

1

Adjusting the Mirrors

Keep the inside and outside mirrors clean and
adjusted for best visibility.

Adjust the mirrors before you start driving.

2 Adjusting the Seat Positions P. 144

1

Automatic Dimming Rearview Mirror

The auto dimming function cancels when the
transmission is in

(

R.

17 NSX-31T6N6000.book  141 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

142

uu

Adjusting the Mirrors

u

Power Door Mirrors

Co
ntrols

Power Door Mirrors

You can adjust the door mirrors when the
power mode is in ON.

■

Mirror position adjustment

L/R selector switch: Select the left or right
mirror. After adjusting the mirror, return the
switch to the center position.
Mirror position adjustment switch: Press
the switch left, right, up, or down to move the
mirror.

Selector
Switch

Adjustment
Switch

17 NSX-31T6N6000.book  142 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

143

uu

Adjusting the Mirrors

u

Power Door Mirrors

Co
ntrols

If activated, either side door mirror
automatically tilts downward when you press
back the

(

R button; this improves close-in

visibility on the selected side of the vehicle
when backing up. The mirror automatically
returns to its original position when you shift
out of

(

R.

To activate this feature, set the power mode
to ON and slide the selector switch to the left
or right side.

If activated, passenger side door mirror
automatically tilts downward when you press
back the

(

R button; this improves close-in

visibility on the passenger side of the vehicle
when backing up. The mirror automatically
returns to its original position when you shift
out of

(

R.

To activate this feature, set the power mode
to ON and slide the selector switch to the
passenger side.

■

Reverse Tilt Door Mirror

Slide the selector switch to left
or right to tilt down either side
door mirror.

Models with driving position memory system

Selector Switch

Models without driving position memory system

17 NSX-31T6N6000.book  143 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

144

Co
ntrols

Adjusting the Seats

Adjust the driver’s seat as far back as possible
while allowing you to maintain full control of
the vehicle. You should be able to sit upright,
well back in the seat and be able to
adequately depress the pedals without
leaning forward, and grip the steering wheel
comfortably. The passenger’s seat should be
adjusted in a similar manner, so that it is as far
back from the front airbag in the dashboard
as possible.

■

Adjusting the power seats

*

1

Adjusting the Seats

The National Highway Traffic Safety Administration
and Transport Canada recommend that drivers allow
at least 10 inches (25 cm) between the center of the
steering wheel and the chest.

Always make seat adjustments before driving.

3

WARNING

Sitting too close to a front airbag can result
in serious injury or death if the front
airbags inflate.

Always sit as far back from the front
airbags as possible while maintaining
control of the vehicle.

Move back.

Allow sufficient
space.

■

Adjusting the Seat Positions

Horizontal
Position
Adjustment

Seat-back Angle
Adjustment

Driver’s seat is shown.

* Not available on all models

17 NSX-31T6N6000.book  144 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

145

uu

Adjusting the Seats

u

Continued

Co
ntrols

■

Lumbar Support Adjustment Switch

*

Press the top: To increase the higher part of
the lumbar support.
Press the bottom: To increase the lower part
of the lumbar support. (The higher part
support is decreased.)
Press the front: To increase the entire
lumbar support.
Press the rear: To decrease the entire lumbar
support.

Higher part of
the Lumbar
support

Lumbar
Support
Adjustment
Switch

Lower part of
the Lumbar
support

* Not available on all models

17 NSX-31T6N6000.book  145 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

uu

Adjusting the Seats

u

146

Co
ntrols

■

Adjusting the manual seats

*

1

Adjusting the manual seats

*

Once a seat is adjusted correctly, rock it back and
forth to make sure it is locked in position.

Horizontal Position
Adjustment
Pull up on the bar to move the
seat, then release the bar.

Seat-back Angle
Adjustment
Pull up the lever to
change the angle.

Driver’s seat is shown.

* Not available on all models

17 NSX-31T6N6000.book  146 ページ  ２０１６年４月２２日　金曜日　午後３時４４分

147

uu

Adjusting the Seats

u

Co
ntrols

Adjust the driver’s seat-back to a comfortable,
upright position, leaving ample space
between your chest and the airbag cover in
the center of the steering wheel.

The passenger should also adjust their seat-
back to a comfortable, upright position.

Reclining a seat-back so that the shoulder part of the belt no longer rests against the
occupant’s chest reduces the protective capability of the belt. It also increases the
chance of sliding under the belt in a crash and being seriously injured. The farther a
seat-back is reclined, the greater the risk of injury.

■

Adjusting the Seat-Backs

1

Adjusting the Seat-Backs

Do not put a cushion, or other object, between the
seat-back and your back. Doing so may interfere with
proper seat belt or airbag operation.

If you cannot get far enough away from the steering
wheel and still reach the controls, we recommend
that you investigate whether some type of adaptive
equipment may help.

3

WARNING

Reclining the seat-back too far can result in
serious injury or death in a crash.

Adjust the seat-back to an upright position,
and sit well back in the seat.

17 NSX-31T6N6000.book  147 ページ  ２０１６年４月２２日　金曜日　午後３時４４分
