Acura NSX (2017 year). Manual

Gauges and Displays

Driver Information Interface

100

strum

nt Pa

nel

Shows the total number of miles (U.S.) or kilometers (Canada) that your vehicle has
accumulated.

Shows the total number of miles (U.S.) or kilometers (Canada) driven since the last
reset. Meters A and B can be used to measure two separate trips.

■

Resetting a trip meter

To reset a trip meter, display it, then press and hold the TRIP button. The trip meter
is reset to 0.0.
When a trip meter is reset, the average fuel economy, the elapsed time, and the
average speed are also reset.

Shows the outside temperature in Fahrenheit (U.S.) or Celsius (Canada).

■

Adjusting the outside temperature display

Adjust the temperature reading up to ± 5°F or ± 3°C if the temperature reading
seems incorrect.

■

Odometer

■

Trip Meter

■

Outside Temperature

Trip Meter

Switch between trip meter A and trip meter B by
pressing the TRIP button.

Outside Temperature

The temperature sensor is in the front bumper.
Road heat and exhaust from another vehicle can
affect the temperature reading when your vehicle
speed is less than 19 mph (30 km/h).

It may take several minutes for the display to be
updated after the temperature reading has stabilized.

Use the audio system’s customized features to
correct the temperature.

2 Customized Features P. 232

17 NSX-31T6N6000.book 100 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

101

Gauges and Displays

Driver Information Interface

strum

nt Pa

nel

Shows the estimated average fuel economy of each trip meter in mpg (U.S.) or
l/100 km (Canada). The display is updated at set intervals. When a trip meter is reset,
the average fuel economy is also reset.

Shows the instant fuel economy as a bar graph in mpg (U.S.) or l/100 km (Canada).

Shows the estimated distance you can travel on the remaining power and fuel. This
distance is estimated from the fuel economy of your previous trips.

Shows the time elapsed since Trip A or Trip B was reset.

Shows the average speed in mph (U.S.) or km/h (Canada) since Trip A or Trip B was
reset.

■

Average Fuel Economy

■

Instant Fuel Economy

■

Range

■

Elapsed Time

■

Average Speed

Average Fuel Economy

You can change when to reset the average fuel
economy.

2 Customized Features P. 232

Range

The displayed range may change even when the
vehicle is stationary.

Elapsed Time

You can change when to reset the elapsed time.

2 Customized Features P. 232

Average Speed

You can change when to reset the average speed.

2 Customized Features P. 232

17 NSX-31T6N6000.book 101 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Gauges and Displays

Driver Information Interface

102

strum

nt Pa

nel

Shows you turn-by-turn driving directions to your destination linked with the
navigation system

2 Refer to the Navigation System Manual

Shows the remaining oil life and Maintenance Minder

2 Maintenance Minder

P. 365

Shows the engine oil level check assist display.

2 Oil Check P. 377

Shows each tire’s pressure.

2 Tire Pressure Monitoring System (TPMS) P. 339

■

Turn-by-Turn Directions

■

Engine Oil Life

■

Oil Level Check Assist

■

Tire Pressure Monitor

Turn-by-Turn Directions

The driver information interface shows a compass
when the route guidance is not in use.

You can select whether the turn-by-turn display
comes on or not during the route guidance.

2 Customized Features P. 232

* Not available on all models

17 NSX-31T6N6000.book 102 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

104

Co
ntrols

Clock

Adjusting the Clock

You can adjust the time in the clock display with the power mode in ON.

■

Using the Settings menu on the audio/
information screen

1. Select Settings.
2. Select Clock/Info.
3. Select Clock Adjustment.
4. Select

to change hour.

5. Select

to change minute, then

select OK.

■

Adjusting the Time

Adjusting the Clock

The clock is automatically updated through the audio
system, so the time does not need to be adjusted.

You cannot adjust the time while the vehicle is
moving.

Models with navigation system

Models with Display Audio

Models without navigation system

Using the Settings menu on the audio/information screen

You can customize the clock display to show the 12
hour clock or 24 hour clock.

2 Customized Features P. 232

The clock display is set to on by factory default.
You can turn the clock display on and off.

2 Customized Features P. 232

The clock is automatically updated when your
smartphone is connected to the audio system.
You can also adjust the clock by touching the clock
displayed on the upper right corner of the display.
1. Touch the clock on the display for a few seconds.
2. Select Clock Adjustment.
3. Select

to change hour.

4. Select

to change minute, then select OK.

Models with Display Audio

17 NSX-31T6N6000.book 104 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

105

Continued

Co
ntrols

Locking and Unlocking the Doors

Key Types and Functions

This vehicle comes with the following keys:

Use the keyless access remote to turn on and
off the power system, to lock and unlock the
doors and to open the hatch. You can also use
the keyless access system to lock and unlock
the doors and hatch.

The built-in key can be used to lock or unlock
the doors when the keyless access remote
battery becomes weak and the power door
lock/unlock operation is disabled.

To remove the built-in key, slide the release
knob and then pull out the key. To reinstall
the built-in key, push the built-in key into the
keyless access remote until it clicks.

Key Types and Functions

All the keys have an immobilizer system. The
immobilizer system helps to protect against vehicle
theft.

2 Immobilizer System P. 122

The keys contain precision electronics.
Adhere to the following advice to prevent damage to
the electronics:

•

Do not leave the keys in direct sunlight, or in
locations with high temperature or high humidity.

•

Do not drop the keys or set heavy objects on them.

•

Keep the keys away from liquids.

•

Do not take the keys apart except for replacing the
battery.

If the circuits in the keys are damaged, the power
system may not activate, and the keyless access
system may not work.
If the keys do not work properly, have them
inspected by an authorized Acura NSX dealer.

■

Keyless Access Remote

Built-in Key

Release Knob

17 NSX-31T6N6000.book 105 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Locking and Unlocking the Doors

Low Keyless Access Remote Signal Strength

106

Co
ntrols

Contains a number that you will need if you
purchase a replacement key.

Low Keyless Access Remote Signal Strength

The vehicle transmits radio waves to locate the keyless access remote when locking/
unlocking the doors, opening the hatch, or to activate the power system.

In the following cases, locking/unlocking the doors, opening the hatch, or activating
the power system may be inhibited or operation may be unstable:
• Strong radio waves are being transmitted by nearby equipment.
• You are carrying the keyless access remote together with telecommunications

equipment, laptop computers, cell phones, or wireless devices.

• A metallic object is touching or covering the keyless access remote.

■

Key Number Tag

Key Number Tag

Keep the key number tag separate from the key in a
safe place outside of your vehicle.
If you wish to purchase an additional key, contact an
authorized Acura NSX dealer.

If you lose your key and you cannot activate the
power system, contact an authorized Acura NSX
dealer.

Low Keyless Access Remote Signal Strength

Communication between the keyless access remote
and the vehicle consumes the keyless access remote’s
battery.
Battery life is about two years, but this varies
depending on regularity of use.
The battery is consumed whenever the keyless access
remote is receiving strong radio waves. Avoid placing
it near electrical appliances such as televisions and
personal computers.

17 NSX-31T6N6000.book 106 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

107

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Continued

Co
ntrols

Locking/Unlocking the Doors from the Outside

When you carry the keyless access remote, the
outer door handles automatically pop in/out
and you can lock/unlock the doors and open
the hatch.
Outer door handles automatically pop in/out
within about 6 feet (2 m) radius of the outside
door handle.
You can lock/unlock the doors within a radius
of about 32 inches (80 cm) of the outside door
handle. You can open the hatch within about
32 inches (80 cm) radius from the hatch
release button.

■

Locking the vehicle

Press the door lock button on either door.

Some exterior lights flash; the beeper
sounds; both doors lock; both outer door
handles pop in if they are popped out;
and the security system sets.

■

Using the Keyless Access System

Using the Keyless Access System

If you do not open a door within 30 seconds of
unlocking the vehicle, the doors will automatically
relock and the outer handles of the doors will
automatically pop back in.

You can lock or unlock doors using the remote
transmitter or keyless access system only when the
power mode is in VEHICLE OFF.

•

Do not leave the keyless access remote in the
vehicle when you get out. Carry it with you.

•

Even if you are not carrying the keyless access
remote, you can lock/unlock the doors while
someone else with the remote is within range.

•

The door may be unlocked if the door handle is
covered with water in heavy rain or in a car wash if
the keyless access remote is within range.

•

If you grip either door handle wearing gloves, the
door sensor may be slow to respond or may not
respond by unlocking the doors.

•

The door may not open if you pull it immediately
after gripping the door handle. Grip the handle
again and confirm that the door is unlocked before
pulling the handle.

•

Even within the 32 inches (80 cm) radius, you may
not be able to lock/unlock the doors with the
keyless access remote if it is above or below the
outside handle.

•

The keyless access remote may not operate if it is
too close to the door and door glass.

17 NSX-31T6N6000.book 107 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

108

Co
ntrols

■

Unlocking the vehicle

When you walk to the vehicle while carrying
the keyless access remote, the outer door
handles will automatically pop out.
The auto pop-out function activates when
both doors are closed, and the keyless access
remote is within a 6-foot (2 m) radius of the
outside door handle.

Pushing out the door handle
To push out the outer door handle manually,
push the front side inwards.

Using the Keyless Access System

If you lock the doors and then keep the keyless
remote within the detection range for more than 2
minutes, the auto pop-out function will be disabled.
If the function is disabled, pop out the handle
manually or use the unlock button on the keyless
access remote.

If you walk away from the vehicle when the power
system is on, the auto pop-out function will not
work.

If you close the doors and take the keyless access
remote out of the 6-foot (2m) detection range and
then bring it back into the range within 10 seconds,
the pop-out function will not work. In this case, pop
out the door handle manually or use the remote
transmitter.
If, however, you bring the remote back into range
after 10 seconds, the handles will automatically pop
out.

17 NSX-31T6N6000.book 108 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

109

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

Grab the driver’s door handle:

The driver’s door unlocks.

Some exterior lights flash twice and the
beeper sounds twice.

Grab the front passenger’s door handle:

Both doors unlock.

Some exterior lights flash twice and the
beeper sounds twice.

Using the Keyless Access System

If the passenger’s door is not opened, the outer
handle of the passenger’s door will pop back in 30
seconds after the driver’s door is closed or when the
gear position is moved out of

(

If the vehicle is left for more than 8 days, the auto
pop-out function will not work. In this case, unlock
the vehicle using the remote transmitter.

2 Auto Pop-Out Main Switch P. 111

If the outer handle of a door is popped out and the
keyless access remote is taken out of the 6-feet (2m)
detection range, the handle will pop back in after 18
to 30 seconds.

The light flash, beep and unlock settings can be
customized using the audio/information screen.

2 Customized Features P. 232

17 NSX-31T6N6000.book 109 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

110

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

Press the hatch release button:

The hatch unlocks and opens.

The beeper sounds.

2 Using the Hatch Release Button P. 119

17 NSX-31T6N6000.book 110 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

111

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

By switching the auto pop-out main switch to OFF, you can disable the auto pop-out
function. For the purpose of safety and to prevent damaging the vehicle, disable this
function and manually operate the handle, especially when the vehicle is:
• being shipped by train, truck, or boat.
• going through a car wash.
• having maintenance performed on it.

■

To temporarily deactivate the auto pop-out function:

Turn off the auto pop-out main switch in the
glove box.

■

Auto Pop-Out Main Switch

Auto Pop-Out Main Switch

The auto pop-out function is deactivated in the
following situations:

•

The auto pop-out main switch is turned off.

•

The keyless access remote is not within a 6-foot
(2m) radius of the outside door handle.

•

The keyless access remote is in the vehicle.

•

The power mode is in ACCESSORY or ON.

Main Switch

OFF

17 NSX-31T6N6000.book 111 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

112

Co
ntrols

■

Locking the doors

Press the lock button.
Once:

Some exterior lights flash, both doors
lock, both outer door handles pop in,
and the security system sets.

Twice (within five seconds after the first
push):

The beeper sounds and verifies the
security system is set.

■

Using the Remote Transmitter

Using the Remote Transmitter

If you do not open a door within 30 seconds of
unlocking the vehicle with the remote transmitter,
the doors will automatically relock and the outer
handles of the doors will automatically pop back in.
You can change the relock timer setting.

2 Customized Features P. 232

If the interior light switch is in the door activated
position, the interior lights come on when you press
the unlock button.
No doors opened: The lights fade out after 30
seconds.
Doors relocked with the remote: The lights go off
immediately.

2 Interior Lights P. 149

The remote transmitter uses low-power signals, so
the operating range may vary depending on the
surroundings.

The remote will not lock the vehicle when a door is
open.

LED

Unlock
Button

Lock
Button

17 NSX-31T6N6000.book 112 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

113

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

■

Unlocking the doors

Press the unlock button.
Once:

Some exterior lights flash twice, the driver’s door unlocks and the driver’s outer
door handle pops out.

Twice:

The passenger’s door unlocks and the passenger’s outer door handle pops out.

Using the Remote Transmitter

If the distance at which the remote transmitter works
varies, the battery is probably low.
If the LED does not come on when you press a
button, the battery is dead.

2 Replacing the Button Battery P. 404

You can customize the door unlock mode setting.

2 Customized Features P. 232

If the passenger’s door is not opened, the outer
handle of the passenger’s door will pop back in 30
seconds after the driver’s door is closed or when the
gear position is moved out of

(

To pop out the outer handle of the passenger’s door
when the gear position is in

(

P, press the unlock

button on the remote transmitter or press the master
door unlock switch.

17 NSX-31T6N6000.book 113 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

114

Co
ntrols

If the keyless remote battery or the vehicle battery is dead, use the key instead of the
keyless remote.

Fully insert the key and turn it.

■

Locking the doors

Push the lock tab forward

or push the

master door lock switch in the lock direction

, and close the door.

■

Lockout prevention system

The doors cannot be locked when the keyless access remote is inside the vehicle, and
either door is open.

■

Locking/Unlocking the Doors Using a Key

Locking/Unlocking the Doors Using a Key

When you lock the driver’s door with a key, the
passenger’s door locks at the same time. When
unlocking, the driver’s door unlocks first. Turn the
key a second time within a few seconds to unlock the
passenger’s door.

If you unlock the doors with the key, the alarm goes
off when you open the hood or select other than

(

before the power mode is set to ON.

You can customize the door unlock mode setting.

2 Customized Features P. 232

Lock

Unlock

■

Locking a Door Without Using a Key

Locking a Door Without Using a Key

When you lock the driver’s door, the passenger’s
door locks at the same time.
Make sure you have the key in your hand when you
lock the driver’s door, any of the other door,
otherwise you may end up locking the key inside the
vehicle.

17 NSX-31T6N6000.book 114 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

115

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Inside

Continued

Co
ntrols

Locking/Unlocking the Doors from the Inside

■

Locking a door

Push the lock tab forward.

■

Unlocking a door

Pull the lock tab rearward.

■

Using the Lock Tab

Using the Lock Tab

When you lock the door using the lock tab on the
driver's door, both doors lock at the same time.
When you unlock the door using the lock tab on the
driver’s door, only the driver’s door will unlock.

To Unlock

Lock Tab

To Lock

17 NSX-31T6N6000.book 115 ページ２０１６年４月２２日　金曜日　午後３時４４分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Acura NSX (2017 year). Manual - part 7
