Acura TSX (2014 year). Manual - part 17

265

uu

Checking and Maintaining Tires

u

Tire and Wheel Replacement





Tire and Wheel Replacement

Replace your tires with radials of the same size, load range, speed rating, and
maximum cold tire pressure rating (as shown on the tire’s sidewall). Using tires of a
different size or construction can cause the ABS and Vehicle Stability Assist (VSA®)
system to work incorrectly.

It is best to replace all four tires at the same time. If that isn’t possible, replace the
front or rear tires in pairs.

Make sure that the wheel’s specifications match those of the original wheels.
If you replace a wheel, only use TPMS specified wheels approved for your vehicle.

1

Tire and Wheel Replacement

3

WARNING

Installing improper tires on your vehicle can
affect handling and stability. This can cause
a crash in which you can be seriously hurt or
killed.

Always use the size and type of tires
recommended in this owner’s manual.

14 ACURA TSX 5D-31TL76300.book  265 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Maint

e

nance

TOC

2014 TSX Sport Wagon

266

uu

Checking and Maintaining Tires

u

Tire Rotation







Tire Rotation

Rotating tires according to the maintenance messages on the multi-information
display helps to distribute wear more evenly and increase tire life.

■

Tires without rotation marks

Rotate the tires as shown here.

■

Tires with rotation marks

Rotate the tires as shown here.

1

Tire Rotation

Tires with directional tread patterns should only be
rotated front to back (not from one side to the other).
Directional tires should be mounted with the rotation
indication mark facing forward, as shown below.

Front

Direction Mark

Front

Front

14 ACURA TSX 5D-31TL76300.book  266 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Maint

e

nance

TOC

2014 TSX Sport Wagon

267

uu

Checking and Maintaining Tires

u

Winter Tires





Winter Tires

If driving on snowy or frozen roads, mount all season marked “M+S” tires, snow
tires, or tire chains; reduce speed; and maintain sufficient distance between vehicles
when driving.

Be particularly careful when operating the steering wheel or brakes to prevent
skidding.

Use tire chains, snow tires, or all season tires when necessary or according to the law.

When mounting, refer to the following points.

For winter tires:
• Select the size and load ranges that are the same as the original tires.

• Mount the tires to all four wheels.

For tire chains:
• Install them on the front tires only.

• Because your vehicle has limited tire clearance, we strongly recommend using the

chains listed below:

• Follow the chain manufacturer’s instruction when installing. Mount them as

tightly as you can.

• Check that the chains do not touch the brake lines or suspension.

• Drive slowly.

Cable-type: SCC Radial Chain SC1034

1

Winter Tires

NOTICE

Traction devices that are the wrong size or improperly
installed can damage your vehicle’s brake lines,
suspension, body, and wheels. Stop driving if they are
hitting any part of the vehicle.

When tire chains are mounted, follow the chain
manufacturer’s instructions regarding vehicle
operational limits.

3

WARNING

Using the wrong chains, or not properly
installing chains, can damage the brake
lines and cause a crash in which you can be
seriously injured or killed.

Follow all instructions in this owner’s
manual regarding the selection and use of
tire chains.

14 ACURA TSX 5D-31TL76300.book  267 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Maint

e

nance

TOC

2014 TSX Sport Wagon

268







Battery

Checking the Battery

Check the battery condition monthly. Look at
the test indicator window and check the
terminals for corrosion.

If your vehicle’s battery is disconnected or goes dead:

• The audio system is disabled.

2 Entering the audio security code P. 148

• The clock resets.

2 Adjusting the Time P. 86

• The navigation system is disabled. A PIN code will be required.

2 Refer to the navigation system manual

1

Battery

WARNING: Battery post, terminals,
and related accessories contain lead
and lead compounds.
Wash your hands after handling.

The test indicator’s color information is on the
battery.

3

WARNING

The battery gives off explosive hydrogen
gas during normal operation.

A spark or flame can cause the battery to
explode with enough force to kill or
seriously hurt you.

When conducting any battery
maintenance, wear protective clothing and
a face shield, or have a skilled technician do
it.

Test Indicator Window

14 ACURA TSX 5D-31TL76300.book  268 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Maint

e

nance

TOC

2014 TSX Sport Wagon

269

uu

Battery

u

Charging the Battery





Charging the Battery

Disconnect both battery cables to prevent damaging your vehicle’s electrical system.
Always disconnect the negative (–) cable first, and reconnect it last.

1

Battery

When you find corrosion, clean the battery terminals
by applying a baking powder and water solution.
Clean the terminals with a damp towel. Cloth/towel
dry the battery. Coat the terminals with grease to
help prevent future corrosion.

When replacing the battery, the replacement must be
of the same specifications.

Please consult a dealer for more information.

14 ACURA TSX 5D-31TL76300.book  269 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Maint

e

nance

TOC

2014 TSX Sport Wagon

270







Remote Transmitter Care

Replacing the Battery

If the indicator does not come on when the button is pushed, replace the battery.

1. Unscrew the cover with a small Phillips-

head screwdriver. Push a button to pry
open the transmitter.

2. Open the keypad.

u

Wrap the small flat-tip screwdriver

with a cloth to prevent scratching
the transmitter.

3. Make sure to replace the battery with the

correct polarity.

1

Replacing the Battery

NOTICE

An improperly disposed of battery can damage the
environment. Always confirm local regulations for
battery disposal.

Replacement batteries are commercially available or
at a dealer.

Keypad

Screw

Battery type: CR1616

Battery

14 ACURA TSX 5D-31TL76300.book  270 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Maint

e

nance

TOC

2014 TSX Sport Wagon

271





Climate Control System Maintenance

Dust and Pollen Filter

The climate control system is equipped with a dust and pollen filter that collects
pollen, dust, and other debris in the air. The Maintenance Minder

TM

 messages will let

you know when to replace the filter.

We recommend that you replace the dust and pollen filter sooner when using your
vehicle in areas with high concentrations of dust.

1

Dust and Pollen Filter

Using an air freshener may reduce the deodorizing
effect of the dust and pollen filter, and may reduce its
life.

If the air flow from the climate control system
deteriorates noticeably, and the windows fog up
easily, the filter may need to be replaced. Please
contact a dealer for replacement.

14 ACURA TSX 5D-31TL76300.book  271 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Maint

e

nance

TOC

2014 TSX Sport Wagon

272







Cleaning

Interior Care

Use a damp cloth with a mixture of mild detergent and warm water to remove dirt.
Use a clean cloth to remove detergent residue.

Use a soft brush with a mixture of mild soap and warm water to clean the seat belts.
Let the belts air dry. Wipe the openings of the seat belt anchors using a clean cloth.

■

Cleaning Seat Belts

1

Interior Care

Do not spill liquids inside the vehicle.

Electrical devices and systems may malfunction if
liquids are splashed on them.

Do not use silicone based sprays on electrical devices
such as audio devices and switches.

Doing so may cause the items to malfunction or a fire
inside the vehicle.

If a silicone based spray is inadvertently used on
electrical devices, consult a dealer.

Depending on their composition, chemicals and
liquid aromatics may cause discoloration, wrinkles,
and cracking to resin-based parts and textiles.

Do not use alkali solvents or organic solvents such as
benzene or gasoline.

After using chemicals, make sure to gently wipe them
off using a dry cloth.

Do not place used cloths on top of resin based parts
or textiles for long periods of time without washing.

Opening

14 ACURA TSX 5D-31TL76300.book  272 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Maint

e

nance

TOC

2014 TSX Sport Wagon

273

uu

Cleaning

u

Interior Care





The front floor mats hook over the floor
anchors, which keep the mats from sliding
forward. To remove a mat for cleaning, turn
the anchor knobs to the unlock position.
When reinstalling the mat after cleaning, turn
the knobs to the lock position.

Do not put additional floor mats on top of
the anchored mats.

Vacuum dirt and dust from the leather frequently. Pay close attention to the pleats
and seams. Clean the leather with a soft cloth dampened with a 90% water and
10% neutral soap solution. Then buff it with a clean, dry cloth. Remove any dust or
dirt on leather surfaces immediately.

■

Floor Mats

1

Floor Mats

If you use any floor mats that were not originally
provided with your vehicle, make sure they are
designed for your specific vehicle, fit correctly, and
are securely anchored by the floor anchors.
Position the rear seat floor mats properly. If they are
not properly positioned, the floor mats can interfere
with the front seat functions.

To unlock

Driver’s floor mat is shown.

■

Maintaining Genuine Leather

14 ACURA TSX 5D-31TL76300.book  273 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Maint

e

nance

TOC

2014 TSX Sport Wagon

274

uu

Cleaning

u

Exterior Care







Exterior Care

Dust off the vehicle body after you drive.

Regularly inspect your vehicle for scratches on painted surfaces. A scratch on a
painted surface can result in body rust. If you find a scratch, promptly repair it.

Wash the vehicle regularly. Wash more frequently when driving in the
folllowing conditions:

• If driving on roads with road salt.

• If driving in coastal areas.

• If tar, soot, bird droppings, insects, or tree sap are stuck to painted surfaces.

• Remove the audio antenna.

• Fold in the door mirrors.

Make sure to follow the instructions indicated on the automated car wash.

• Keep sufficient distance between the cleaning nozzle and the vehicle body.

• Take particular care around the windows. Standing too close may cause water to

enter the vehicle interior. Do not spray water into the engine compartment.

■

Washing the Vehicle

■

Using an Automated Car Wash

■

Using High Pressure Cleaners

1

Washing the Vehicle

Do not spray water into the air intake vents or engine
compartment. It can cause a malfunction.

Air Intake Vents

14 ACURA TSX 5D-31TL76300.book  274 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Maint

e

nance

TOC

2014 TSX Sport Wagon

275

uu

Cleaning

u

Exterior Care





A good coat of automotive body wax helps protect your vehicle’s paint from the
elements. Wax will wear off over time and expose your vehicle’s paint to the
elements, so reapply as necessary.

If you get gasoline, oil, engine coolant, or battery fluid on resin coated parts, they
may be stained or the coating may peel. Promptly wipe it away using a soft cloth and
clean water.

Wipe using a glass cleaner.

Aluminum is susceptible to deterioration caused by salt and other road
contaminants. Use a sponge and mild detergent to wipe away promptly.

Be careful not to use harsh chemicals (including some commercial wheel cleaners) or
a stiff brush. They can damage the clear coat of the aluminum alloy wheels that
helps keep the aluminum from corroding and tarnishing.

■

Applying Wax

■

Maintaining the Bumpers and Other Resin Coated Parts

■

Cleaning the Window

■

Maintaining Aluminum Wheels

1

Applying Wax

NOTICE

Chemical solvents and strong cleaners can damage
the paint, metal, and plastic on your vehicle. Wipe up
spills immediately.

1

Maintaining the Bumpers and Other Resin Coated Parts

Ask a dealer about the correct coating material when
you want to repair the painted surface of the parts
made of resin.

1

Cleaning the Window

Wires are mounted to the inside of the rear window.
Wipe along the same direction as the wires with a
soft cloth so as not to damage them.

14 ACURA TSX 5D-31TL76300.book  275 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Maint

e

nance

TOC

2014 TSX Sport Wagon

278









H

a

n

d

li

ng
 th
e Un

ex
pe
ct

e

d

Temporarily Repairing a Flat Tire

This vehicle is not equipped with a spare tire. If the tire has a large cut or is otherwise
severely damaged, you will need to have the vehicle towed. If the tire only has a
small puncture, from a nail for instance, you can use the tire repair kit so that you
can drive to the nearest service station for a more permanent repair.

If a tire goes flat while driving, grasp the steering wheel firmly, and brake gradually
to reduce speed. Then stop in a safe place.

1. Park the vehicle on firm, level, and non-slippery ground.

2. Put the shift lever in

 (

P .

3. Set the parking brake.

4. Turn on the hazard warning lights and turn the ignition switch to LOCK

 (

0 .

■

Getting Ready to Temporarily Repair the Flat Tire

1

Temporarily Repairing a Flat Tire

The kit should not be used in the following situations.
Instead, contact a dealer or a roadside assistant to
have the vehicle towed.

•

The tire sealant has expired.

•

More than two tires are punctured.

•

The puncture or cut is larger than 3/16 inch (4mm).

•

The tire side wall is damaged or the puncture is
outside the tire tread.

•

Damage has been caused by driving with the tire
extremely under inflated.

•

The tire bead is no longer seated.

•

The rim is damaged.

Do not remove a nail or screw that punctured the
tire. If you remove it from the tire, you may not be
able to repair the puncture using the kit.

NOTICE

Do not use a puncture-repairing agent other than the
one provided in the kit that came with your vehicle. If
used, you may permanently damage the tire pressure
sensor.

When the puncture is:

Kit Use

Smaller than 3/16 inch
(4mm)

Yes

Larger than 3/16 inch
(4mm)

No

Contact
Area

Instruction
Manual

Air Only Hose (Black)

Speed Restriction Label

Repair Notification Label

Pressure Relief
Button

Inflator Switch

Selector Switch
SEALANT/AIR side

Sealant/Air Hose (Clear)

AIR ONLY side

Power Plug

Pressure Gauge

Tire Sealant
Expiration Date

14 ACURA TSX 5D-31TL76300.book  278 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

TOC

2014 TSX Sport Wagon

Continued

279

uu

Temporarily Repairing a Flat Tire

u







1. Pull the handle on the cargo area floor lid

and open the lid.

2. Pull the strap and take the kit out of

the case.

u

Place the kit face up, on flat ground near
the flat tire, and away from traffic. Do
not place the kit on its side.

1

Getting Ready to Temporarily Repair the Flat Tire

When making a temporary repair, carefully read the
instruction manual provided with the kit.

In cold temperatures, the sealant may not flow easily.
In this situation, warm it up for five minutes before
using.

Handle

Lid

Tire Repair Kit

Strap

14 ACURA TSX 5D-31TL76300.book  279 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

H

a

n

d

li

ng
 th
e Un

ex
pe
ct

e

d

TOC

2014 TSX Sport Wagon

uu

Temporarily Repairing a Flat Tire

u

280









1. Remove the valve cap from the tire

valve stem.

2. Remove the sealant/air hose from

the packaging.

3. Attach the sealant/air hose onto the tire

valve stem. Screw it until it is tight.

■

Injecting Sealant and Air

1

Injecting Sealant and Air

The sealant is latex based and can permanently stain
clothing and other materials. Be careful during
handling and wipe up any spills immediately.

NOTICE

Do not operate the tire repair kit compressor for
more than 15 minutes. The accessory power socket
and compressor can overheat and become
permanently damaged.

There are three accessory power sockets:

•

In the console compartment

•

In the front of the center console

•

In the left side panel in the cargo area

2 Accessory Power Sockets P. 135

Valve Stem

Valve Cap

Sealant/Air Hose

Valve Stem

Sealant/Air Hose

14 ACURA TSX 5D-31TL76300.book  280 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

H

a

n

d

li

ng
 th
e Un

ex
pe
ct

e

d

TOC

2014 TSX Sport Wagon

Continued

281

uu

Temporarily Repairing a Flat Tire

u







4. Plug in the compressor to the accessory

power socket. Be careful not to pinch the
cord in a door or window.

u

Do not plug any other electric devices
into other accessory power sockets.

5. Start the engine.

u

Keep the engine running while injecting
sealant and air.

2 Carbon Monoxide Gas P. 61

6. Turn the selector switch to

SEALANT/AIR .

7. Press the inflator switch to turn on the kit.

u

The compressor starts injecting sealant
and air into the tire.

8. When the sealant injection is complete

continue to add air.

9. After the air pressure reaches 33 psi (230

kPa), turn off the kit.

u

To check the pressure, occasionally turn
off the compressor and read the gauge.

1

Injecting Sealant and Air

Until the sealant injection is complete, the pressure
shown on the pressure gauge will appear higher than
actual. After the sealant injection is complete the
pressure will drop and then begin to rise again as the
tire is inflated with air. This is normal. To accurately
measure the air pressure using the gauge, turn the air
compressor off only after the sealant injection is
complete.

If the required air pressure is not reached within 10
minutes, the tire may be too severely damaged for
the kit to provide the necessary seal and your vehicle
will need to be towed.

See an Acura dealer for a replacement sealant bottle
and proper disposal of an empty bottle.

3

WARNING

Running the engine with the vehicle in an
enclosed or even partly enclosed area can
cause a rapid build-up of toxic carbon
monoxide.

Breathing this colorless, odorless gas can
cause unconsciousness and even death.
Only run the engine to power the air
compressor with the vehicle outdoors.

SEALANT/AIR side

Pressure Gauge

ON

OFF

14 ACURA TSX 5D-31TL76300.book  281 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

H

a

n

d

li

ng
 th
e Un

ex
pe
ct

e

d

TOC

2014 TSX Sport Wagon

uu

Temporarily Repairing a Flat Tire

u

282









10. Unplug the power plug from the accessory

power socket.

11. Unscrew the sealant/air hose from the tire

valve stem. Reinstall the valve cap.

12. Apply the repair notification label to the

flat surface of the wheel.

u

The wheel surface must be clean to
ensure the label adheres properly.

1. Apply the speed restriction label to the

location as shown.

2. Drive the vehicle for about 10 minutes.

u

Do not exceed 50 mph (80 km/h).

3. Stop the vehicle in a safe location.

Sealant/Air Hose

Valve Stem

Repair Notification Label

■

Distributing the Sealant in the Tire

1

Distributing the Sealant in the Tire

Stop and recheck the air pressure after every 10
minutes of driving as necessary until you reach the
nearest service station where you should have the tire
permanently repaired or replaced.

Speed Restriction Label

14 ACURA TSX 5D-31TL76300.book  282 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

H

a

n

d

li

ng
 th
e Un

ex
pe
ct

e

d

TOC

2014 TSX Sport Wagon
