Outside

Fig. 40: Identifying Hook Strips And Seat Cushion
Courtesy of AMERICAN HONDA MOTOR CO., INC.

Inside

Fig. 41: Identifying Hook Strips And Seat Cushion (Inside)
Courtesy of AMERICAN HONDA MOTOR CO., INC.

5. Release the clips (A) and hooks (B), and disconnect the seat cushion heater connectors (C), then

detach the connectors and harness clip (D), and pull back the seat cushion trim cover (E).



2007 Acura RL

2005-08 ACCESSORIES AND EQUIPMENT Seats - RL



me



Friday, June 05, 2009 3:27:16 PM

Page 26

© 2005 Mitchell Repair Information Company, LLC.

Fig. 42: Identifying Clips, Hooks, Seat Cushion Heater Connectors And Connectors And
Harness Clip
Courtesy of AMERICAN HONDA MOTOR CO., INC.

6. Remove the silencer (A) and seat cushion pad (B) from the seat cushion frame (C).

Fig. 43: Identifying Silencer, Seat Cushion Pad And Seat Cushion Frame
Courtesy of AMERICAN HONDA MOTOR CO., INC.

7. Pull back the seat cushion cover (A), and release the clips (B) from under the seat cushion.



2007 Acura RL

2005-08 ACCESSORIES AND EQUIPMENT Seats - RL



me



Friday, June 05, 2009 3:27:16 PM

Page 27

© 2005 Mitchell Repair Information Company, LLC.

Fig. 44: Identifying Seat Cushion Cover, Clips And Seat Cushion
Courtesy of AMERICAN HONDA MOTOR CO., INC.

8. Pull back the edge of the seat cushion cover all the way around, and release the clips (A), then remove

the seat cushion cover.

Fig. 45: Identifying Front Seats Clips
Courtesy of AMERICAN HONDA MOTOR CO., INC.

9. Install the cover in the reverse order of removal, and note these items:



To prevent wrinkles when installing a seat cushion cover, make sure the material is stretched
evenly over the pad before securing the clips and hook strips.



Replace any clips you removed with new ones (A). Install them with commercially available
upholstery ring pliers (B).



2007 Acura RL

2005-08 ACCESSORIES AND EQUIPMENT Seats - RL



me



Friday, June 05, 2009 3:27:17 PM

Page 28

© 2005 Mitchell Repair Information Company, LLC.

Fig. 46: Installing Upholstery Clips
Courtesy of AMERICAN HONDA MOTOR CO., INC.

FRONT SEAT HEAD RESTRAINT COVER REPLACEMENT

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

1. Remove the head restraint.

2. Detach the clips, and remove the head restraint cover B (A).

Fig. 47: Identifying Head Restraint Cover
Courtesy of AMERICAN HONDA MOTOR CO., INC.

NOTE:



Use the appropriate tool from the KTC trim tool set to avoid damage
when prying components.



Take care not to tear the seams or damage the seat covers.



Put on gloves to protect your hands.



2007 Acura RL

2005-08 ACCESSORIES AND EQUIPMENT Seats - RL



me



Friday, June 05, 2009 3:27:17 PM

Page 29
