Fig. 25: Identifying Hood Switch 2P Connector
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Check for continuity between the terminals. There should be continuity between the No. 1 and No. 2

terminals when the hood is opened (latch released). There should be no continuity between the No. 1
and No. 2 terminals when the hood is closed (latch pushed down).

4. If the continuity is not as specified, replace the hood switch.

REMOTE TEST

WITH HDS

Do a remote test using the HDS by selecting the KEYLESS INSPECTION MENU.

NOTE:



If the doors unlock or lock with the remote, but the LED on the remote
does not come on, the LED is faulty; replace the remote.



If any door is open, you cannot lock the doors with the remote.



If the UNLOCK button is pressed on the remote and a door is not
opened within 30 seconds, the doors relock automatically.



The doors do not lock or unlock with the remote if the key is in the
ignition switch.



Panic function will not operate if the ignition switch is ON (II).



If the lock and unlock function works normally, but the driving position
memory system (DPMS) is not linked, confirm the link is turned ON with
the HDS, then check for problems in the DPMS (see SYSTEM INPUT
TEST AND FUNCTION TEST ) or B-CAN System Diagnosis Test Mode A
(see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE
A ). Refer to SYSTEM DESCRIPTION for more information.

2007 Acura RL

2005-08 ACCESSORIES AND EQUIPMENT Keyless/Power Door Locks/Security System - RL

Friday, June 05, 2009 3:51:13 PM

Page 33

WITHOUT HDS

1. Open the remote and check for water damage.



If you find any water damage, replace the remote.



If there is no water damage, go to step 2.

2. Replace the remote batteries (A) with new ones, and try to lock and unlock the doors with the remote

by pressing the lock or unlock button five or six times.



If the doors lock and unlock, the remote is OK.



If the doors don't lock and unlock, go to step 3.

Fig. 26: Identifying Remote Batteries
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Reprogram the remote with the HDS, then try to lock and unlock the doors.



If the doors lock and unlock, the remote is OK.



If the doors don't lock and unlock, try and program to another vehicle.



If the remote programs to another vehicle, go to B-CAN System Diagnosis Test Mode A
(see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).



If the remote will not program to another vehicle, replace it.

2007 Acura RL

2005-08 ACCESSORIES AND EQUIPMENT Keyless/Power Door Locks/Security System - RL

Friday, June 05, 2009 3:51:13 PM

Page 34

GENERAL INFORMATION

Service Reminder Indicators - Acura

SCHEDULED SERVICE DUE LIGHT

1988-90 LEGEND

1. Every 7500 miles, a SCHEDULED SERVICE DUE warning light will come on as a reminder to

change oil and oil filter. After servicing is completed, reset warning light.

2. To reset warning light, locate SERVICE RESET button. See Fig. 1. With ignition switch in the ON

position, press SERVICE RESET button for 3 seconds. To verify reset, turn ignition switch off and
on. Light should not come on.

Fig. 1: Identifying Scheduled Service Light Reset Button (1988-90 Acura Legend)
Courtesy of AMERICAN HONDA MOTOR CO., INC.

MAINTENANCE REQUIRED LIGHT

NOTE:

This article is only to be used for resetting maintenance reminder lights
(when applicable). Some models (not all) may be equipped with one or more
resettable maintenance reminder lights indicating maintenance is required.
Once required maintenance services are performed, resetting of lights may
be required. Information is provided to reset these lights where applicable.

NOTE:

Most vehicles are equipped with a Malfunction Indicator Light (MIL) or
CHECK ENGINE light. If light comes on and remains on while driving, the
vehicle requires some type of repair. See appropriate service and repair
information. After repairing fault(s) and clearing fault code(s), the
Malfunction Indicator Light (MIL) or check engine light should go out. Some
models may use a dual-function indicator light, which is also used to
indicate emission component service is due. After performing required
service, reset indicator light.

2007 Acura RL

GENERAL INFORMATION Service Reminder Indicators - Acura

2007 Acura RL

GENERAL INFORMATION Service Reminder Indicators - Acura

Friday, June 05, 2009 2:24:29 PM

Page 1

Friday, June 05, 2009 2:24:33 PM

Page 1

1987-95 LEGEND COUPE

1. At each 7500 mile service interval, the MAINTENANCE REQUIRED light will change from Green

to Yellow. If service is not performed (and light is not reset), the MAINTENANCE REQUIRED light
will change from Yellow to Red.

2. On Integra, when service has been completed, reset MAINTENANCE REQUIRED reminder light. To

reset light, turn ignition ON. Push button located under dash to the right of steering column (above
gas pedal) and hold for 3 seconds. Turn ignition OFF. Start engine and verify light has been reset.

3. On all others, when service has been completed, reset MAINTENANCE REQUIRED reminder light.

To reset reminder light, turn ignition off. Insert ignition key in slot provided below tachometer. See
Fig. 2.

Fig. 2: Resetting Maintenance Required Light
Courtesy of AMERICAN HONDA MOTOR CO., INC.

1991-95 LEGEND

1. At each 7500 mile service interval, the MAINTENANCE REQUIRED light will change from Green

to Yellow. If service is not performed (and light is not reset), the MAINTENANCE REQUIRED light
will change from Yellow to Red.

2. On Integra, when service has been completed, reset MAINTENANCE REQUIRED reminder light. To

3. On all others, when service has been completed, reset MAINTENANCE REQUIRED reminder light.

To reset reminder light, turn ignition off. Insert ignition key in slot provided below tachometer. See
Fig. 2.

1992-94 VIGOR

1. At each 7500 mile service interval, the MAINTENANCE REQUIRED light will change from Green

2007 Acura RL

GENERAL INFORMATION Service Reminder Indicators - Acura

Friday, June 05, 2009 2:24:29 PM

Page 2
