Fig. 451: Removing Intermediary Shaft Bearing From Transmission Housing
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2. Install the new bearing until it bottoms in the transmission housing using the driver and the attachment

(37 x 40 mm).

Fig. 452: Pressing Bearing Into Transmission Housing
Courtesy of AMERICAN HONDA MOTOR CO., INC.

PARK LEVER SHAFT BEARING REPLACEMENT

Special Tools Required



Bearing remover shaft, 10 mm 07936-GE00100



Bearing remover head, 10 mm 07936-GE00200



Sliding hammer weight 07741-0010201



Driver 07749-0010000



Attachment, 22 x 24 mm 07746-0010800

1. Remove the park lever shaft bearing from the transmission housing using the bearing remover head (10

mm), the bearing remover shaft (10 mm), and the sliding hammer weight.



2007 Acura RL

2005-08 TRANSMISSION Automatic Transmission - RL



me



Friday, June 05, 2009 1:18:16 PM

Page 431

© 2005 Mitchell Repair Information Company, LLC.

Fig. 453: Removing Park Lever Shaft Bearing From Transmission Housing
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2. Install the new bearing until it bottoms in the transmission housing using the driver and the attachment

(22 x 24 mm).

Fig. 454: Pressing Bearing Until Into Transmission Housing
Courtesy of AMERICAN HONDA MOTOR CO., INC.

CONTROL SHAFT BEARING REPLACEMENT

Special Tools Required



Bearing remover shaft, 10 mm 07936-GE00100



Bearing remover head, 10 mm 07936-GE00200



Sliding hammer weight 07741-0010201



Driver 07749-0010000



Attachment, 22 x 24 mm 07746-0010800

1. Remove the control shaft bearing from the transmission housing using the bearing remover head (10



2007 Acura RL

2005-08 TRANSMISSION Automatic Transmission - RL



me



Friday, June 05, 2009 1:18:16 PM

Page 432

© 2005 Mitchell Repair Information Company, LLC.

mm), the bearing remover shaft (10 mm), and the sliding hammer weight.

Fig. 455: Removing Control Shaft Bearing From Transmission Housing
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2. Install the new bearing in the transmission housing using the driver and the attachment (22 x 24 mm).

Fig. 456: Pressing Bearing Into Transmission Housing
Courtesy of AMERICAN HONDA MOTOR CO., INC.

CONTROL SHAFT OIL SEAL REPLACEMENT

Special Tools Required



Driver 07749-0010000



Attachment, 22 x 24 mm 07746-0010800

1. Remove the oil seal from the transmission housing.



2007 Acura RL

2005-08 TRANSMISSION Automatic Transmission - RL



me



Friday, June 05, 2009 1:18:16 PM

Page 433

© 2005 Mitchell Repair Information Company, LLC.

Fig. 457: Identifying Oil Seal
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2. Install the new oil seal in the transmission housing using the driver and the attachment (22 x 24 mm).

Fig. 458: Tapping Oil Seal Into Transmission Housing
Courtesy of AMERICAN HONDA MOTOR CO., INC.

VALVE BODY

VALVE BODY REPAIR

1. Soak a sheet of # 600 abrasive paper in ATF for about 30 minutes.

2. Carefully tap the valve body so the sticking valve drops out of its bore. It may be necessary to use a small

screwdriver to pry the valve free. Be careful not to scratch the bore with the screwdriver.

3. Inspect the valve for any scuff marks. Use the ATF-soaked # 600 paper to polish off any burrs that are on

the valve, then wash the valve in solvent and dry it with compressed air.

4. Roll up half of the ATF-soaked #600 paper and insert it in the valve bore of the sticking valve. Twist the

NOTE:

Valve body repair is only necessary if one or more of the valves in a valve body
do not slide smoothly in their bores. Use this procedure to free the valves.
