Kia Sedona (2008 year). Manual - part 388

Fig. 3: Identifying Engine Hood Insulator And Clip
Courtesy of KIA MOTORS AMERICA, INC.

2. Installation is the reverse of removal.

HOOD WEATHERSTRIP REPLACEMENT

1. Detach the clips, then remove the hood weatherstrip (A) Take care not to scratch the hood.

NOTE:



Take care not to scratch the hood panel.

NOTE:



Replace any damaged clips.

2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Exterior - Sedona

Microsoft

Monday, May 24, 2010 4:07:08 PM

Page 4

Fig. 4: Identifying Hood Seal Weatherstrip And Clip
Courtesy of KIA MOTORS AMERICA, INC.

2. Installation is the reverse of removal.

HOOD SEAL WEATHERSTRIP REPLACEMENT

1. Detach the clips, then remove the hood weather strip (A) Take care not to scratch the hood.

NOTE:



Replace any damaged clips.

2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Exterior - Sedona

Microsoft

Monday, May 24, 2010 4:07:08 PM

Page 5

Fig. 5: Identifying Hood Weather Strip And Clip
Courtesy of KIA MOTORS AMERICA, INC.

2. Installation is the reverse of removal.

HOOD LIFT REPLACEMENT

1. Using a screwdriver (A), lift up slightly the socket clips (B) of both ends on the lifter (D), and then

remove the lifter from the bracket (C).

NOTE:



Replace any damaged clips.

2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Exterior - Sedona

Microsoft

Monday, May 24, 2010 4:07:08 PM

Page 6

Fig. 6: Identifying Screwdriver, Socket Clips, Lifter And Bracket
Courtesy of KIA MOTORS AMERICA, INC.

2. Push the socket of the lifter into the bracket for installation.

HOOD RELEASE HANDLE REPLACEMENT

1. Remove the mounting bolt, then remove the hood release handle (A).

2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Exterior - Sedona

Microsoft

Monday, May 24, 2010 4:07:08 PM

Page 7
