14. Install door speaker with three mounting screws.

15. Install pull handle bracket with one mounting screws.

16. Install door trim.

17. Install inner door handle cover with one mounting screw.

18. Fasten door trim. Refer to "Trim" in this section.

19. Connect negative battery cable.

Body (Interior and Exterior)

Exterior - Rear Door

Body (Interior and Exterior)

  2001 > 1.8L DOHC >



Component

  2001 > 1.8L DOHC >



Removal

1. Remove door trim. Refer to "Trim" in this section.

2. Remove one screw on pull handle bracket.

3. Remove inside door handle assembly.

A. Remove one screw from inside door handle.
B. Disconnect two control rods.

C. Remove inside door handle assembly.

4. Peel off plastic door screen carefully by pulling it away gradually from door frame.

5. Remove glass guide.

6. Remove rear door garnish.

7. Remove window glass :

A. Reconnect window operating switch.
B. Connect negative battery cable.

C. Turn on ignition and position window glass on access hole.

D. Turn off ignition.

E. Remove two glass retaining bolts on regulator assembly.

F. Remove door glass carefully. Hold glass from both its inner and outer surfaces. While tilting it toward

hinge side of door, pull it out from outside door frame.
