Intel 64 and IA-32 Architectures. Software Developer’s Manual (Collection, 2023)

OPCODE MAP

Table A-3. Two-byte Opcode Map: 00H — 77H (First Byte is 0FH) *

pfx

Grp 6^1A

Grp 7^1A

LAR

LSL

SYSCALL^o64

CLTS

SYSRET^o64

Gv, Ew

vmovups

vmovlps

vunpcklps

vunpckhps

vmovhps^v1

Vps, Wps

Wps, Vps

Vq, Hq, Mq

Mq, Vq

Vx, Hx, Wx

Vdq, Hq, Mq

Mq, Vq

vmovhlps

vmovlhps

Vq, Hq, Uq

Vdq, Hq, Uq

vmovupd

vmovlpd

vunpcklpd

vunpckhpd

vmovhpd^v1

Vpd, Wpd

Wpd,Vpd

Vq, Hq, Mq

Mq, Vq

Vx,Hx,Wx

Vdq, Hq, Mq

Mq, Vq

vmovss

vmovsldup

vmovshdup

Vx, Hx, Wss

Wss, Hx, Vss

Vx, Wx

vmovsd

vmovddup

Vx, Hx, Wsd

Wsd, Hx, Vsd

Vx, Wx

MOV

Rd, Cd

Rd, Dd

Cd, Rd

Dd, Rd

WRMSR

RDTSC

RDMSR

RDPMC

SYSENTER

SYSEXIT

GETSEC

CMOVcc, (Gv, Ev) - Conditional Move

B/C/NAE

AE/NB/NC

E/Z

NE/NZ

BE/NA

A/NBE

vmovmskps

vsqrtps

vrsqrtps

vrcpps

vandps

vandnps

vorps

vxorps

Gy, Ups

Vps, Wps

Vps, Hps, Wps

vmovmskpd

vsqrtpd

vandpd

vandnpd

vorpd

vxorpd

Gy,Upd

Vpd, Wpd

Vpd, Hpd, Wpd

vsqrtss

vrsqrtss

vrcpss

Vss, Hss, Wss

vsqrtsd

Vsd, Hsd, Wsd

punpcklbw

punpcklwd

punpckldq

packsswb

pcmpgtb

pcmpgtw

pcmpgtd

packuswb

Pq, Qd

Pq, Qq

vpunpcklbw

vpunpcklwd

vpunpckldq

vpacksswb

vpcmpgtb

vpcmpgtw

vpcmpgtd

vpackuswb

Vx, Hx, Wx

pshufw

(Grp 12^1A)

(Grp 13^1A)

(Grp 14^1A)

pcmpeqb

pcmpeqw

pcmpeqd

emms

Pq, Qq, Ib

Pq, Qq

vzeroupper^v

vzeroall^v

vpshufd

vpcmpeqb

vpcmpeqw

vpcmpeqd

Vx, Wx, Ib

Vx, Hx, Wx

vpshufhw

Vx, Wx, Ib

vpshuflw

Vx, Wx, Ib

Vol. 2D A-9

OPCODE MAP

Table A-3. Two-byte Opcode Map: 08H — 7FH (First Byte is 0FH) *

pfx

INVD

WBINVD

2-byte Illegal

prefetchw(/1)

Opcodes

UD2^1B

Prefetch^1C

Reserved-NOP

bndldx

bndstx

Reserved-NOP

NOP /0 Ev

(Grp 16^1A)

bndmov

bndcl

bndmk

bndcu

bndcn

vmovaps

cvtpi2ps

vmovntps

cvttps2pi

cvtps2pi

vucomiss

vcomiss

Vps, Wps

Wps, Vps

Vps, Qpi

Mps, Vps

Ppi, Wps

Vss, Wss

vmovapd

cvtpi2pd

vmovntpd

cvttpd2pi

cvtpd2pi

vucomisd

vcomisd

Vpd, Wpd

Wpd,Vpd

Vpd, Qpi

Mpd, Vpd

Ppi, Wpd

Qpi, Wpd

Vsd, Wsd

vcvtsi2ss

vcvttss2si

vcvtss2si

Vss, Hss, Ey

Gy, Wss

vcvtsi2sd

vcvttsd2si

vcvtsd2si

Vsd, Hsd, Ey

Gy, Wsd

3-byte escape

(Table A-4)

(Table A-5)

CMOVcc(Gv, Ev) - Conditional Move

P/PE

NP/PO

L/NGE

NL/GE

LE/NG

NLE/G

vaddps

vmulps

vcvtps2pd

vcvtdq2ps

vsubps

vminps

vdivps

vmaxps

Vps, Hps, Wps

Vpd, Wps

Vps, Wdq

Vps, Hps, Wps

vaddpd

vmulpd

vcvtpd2ps

vcvtps2dq

vsubpd

vminpd

vdivpd

vmaxpd

Vpd, Hpd, Wpd

Vps, Wpd

Vdq, Wps

Vpd, Hpd, Wpd

vaddss

vmulss

vcvtss2sd

vcvttps2dq

vsubss

vminss

vdivss

vmaxss

Vss, Hss, Wss

Vsd, Hx, Wss

Vdq, Wps

Vss, Hss, Wss

vaddsd

vmulsd

vcvtsd2ss

vsubsd

vminsd

vdivsd

vmaxsd

Vsd, Hsd, Wsd

Vss, Hx, Wsd

Vsd, Hsd, Wsd

punpckhbw

punpckhwd

punpckhdq

packssdw

movd/q

movq

Pq, Qd

Pd, Ey

Pq, Qq

vpunpckhbw

vpunpckhwd

vpunpckhdq

vpackssdw

vpunpcklqdq

vpunpckhqdq

vmovd/q

vmovdqa

Vx, Hx, Wx

Vy, Ey

Vx, Wx

vmovdqu

Vx, Wx

VMREAD

VMWRITE

movd/q

movq

Ey, Gy

Gy, Ey

Ey, Pd

Qq, Pq

vhaddpd

vhsubpd

vmovd/q

vmovdqa

Vpd, Hpd, Wpd

Ey, Vy

Wx,Vx

vmovq

vmovdqu

Vq, Wq

Wx,Vx

vhaddps

vhsubps

Vps, Hps, Wps

A-10

Vol. 2D

OPCODE MAP

Table A-3. Two-byte Opcode Map: 80H — F7H (First Byte is 0FH) *

pfx

Jcc^f64, Jz - Long-displacement jump on condition

B/CNAE

AE/NB/NC

E/Z

NE/NZ

BE/NA

A/NBE

SETcc, Eb - Byte Set on condition

B/C/NAE

AE/NB/NC

E/Z

NE/NZ

BE/NA

A/NBE

PUSH^d64

POP^d64

CPUID

SHLD

Ev, Gv

Ev, Gv, Ib

Ev, Gv, CL

CMPXCHG

LSS

BTR

LFS

LGS

MOVZX

Gv, Mp

Ev, Gv

Gv, Mp

Eb, Gb

Ev, Gv

Gv, Eb

Gv, Ew

XADD

vcmpps

movnti

pinsrw

pextrw

vshufps

Grp 9^1A

Eb, Gb

Ev, Gv

Vps,Hps,Wps,Ib

My, Gy

Pq,Ry/Mw,Ib

Gd, Nq, Ib

Vps,Hps,Wps,Ib

vcmppd

vpinsrw

vpextrw

vshufpd

Vpd,Hpd,Wpd,Ib

Vdq,Hdq,Ry/Mw,Ib

Gd, Udq, Ib

Vpd,Hpd,Wpd,Ib

vcmpss

Vss,Hss,Wss,Ib

vcmpsd

Vsd,Hsd,Wsd,Ib

psrlw

psrld

psrlq

paddq

pmullw

pmovmskb

Pq, Qq

Gd, Nq

vaddsubpd

vpsrlw

vpsrld

vpsrlq

vpaddq

vpmullw

vmovq

vpmovmskb

Vpd, Hpd, Wpd

Vx, Hx, Wx

Wq, Vq

Gd, Ux

movq2dq

Vdq, Nq

vaddsubps

movdq2q

Vps, Hps, Wps

Pq, Uq

pavgb

psraw

psrad

pavgw

pmulhuw

pmulhw

movntq

Pq, Qq

Mq, Pq

vpavgb

vpsraw

vpsrad

vpavgw

vpmulhuw

vpmulhw

vcvttpd2dq

vmovntdq

Vx, Hx, Wx

Vx, Wpd

Mx, Vx

vcvtdq2pd

Vx, Wpd

vcvtpd2dq

Vx, Wpd

psllw

pslld

psllq

pmuludq

pmaddwd

psadbw

maskmovq

Pq, Qq

Pq, Nq

vpsllw

vpslld

vpsllq

vpmuludq

vpmaddwd

vpsadbw

vmaskmovdqu

Vx, Hx, Wx

Vdq, Udq

vlddqu

Vx, Mx

Vol. 2D A-11

OPCODE MAP

Table A-3. Two-byte Opcode Map: 88H — FFH (First Byte is 0FH) *

pfx

Jcc^f64, Jz - Long-displacement jump on condition

P/PE

NP/PO

L/NGE

NL/GE

LE/NG

NLE/G

SETcc, Eb - Byte Set on condition

P/PE

NP/PO

L/NGE

NL/GE

LE/NG

NLE/G

d64

PUSH

POP^d64

RSM

BTS

SHRD

(Grp 15^1A)^1C

IMUL

Ev, Gv

Ev, Gv, Ib

Ev, Gv, CL

Gv, Ev

JMPE

Grp 10^1A

Grp 8^1A

BTC

BSF

BSR

MOVSX

(reserved for

Invalid Opcode^1B

Ev, Ib

Ev, Gv

Gv, Ev

Gv, Eb

Gv, Ew

emulator on IPF)

POPCNT

TZCNT

LZCNT

Gv, Ev

BSWAP

RAX/EAX/

RCX/ECX/

RDX/EDX/

RBX/EBX/

RSP/ESP/

RBP/EBP/

RSI/ESI/

RDI/EDI/

R8/R8D

R9/R9D

R10/R10D

R11/R11D

R12/R12D

R13/R13D

R14/R14D

R15/R15D

psubusb

psubusw

pminub

pand

paddusb

paddusw

pmaxub

pandn

Pq, Qq

vpsubusb

vpsubusw

vpminub

vpand

vpaddusb

vpaddusw

vpmaxub

vpandn

Vx, Hx, Wx

psubsb

psubsw

pminsw

por

paddsb

paddsw

pmaxsw

pxor

Pq, Qq

vpsubsb

vpsubsw

vpminsw

vpor

vpaddsb

vpaddsw

vpmaxsw

vpxor

Vx, Hx, Wx

psubb

psubw

psubd

psubq

paddb

paddw

paddd

Pq, Qq

UD0

vpsubb

vpsubw

vpsubd

vpsubq

vpaddb

vpaddw

vpaddd

Vx, Hx, Wx

NOTES:

* All blanks in all opcode maps are reserved and must not be used. Do not depend on the operation of undefined or reserved locations.

A-12

Vol. 2D

OPCODE MAP

Table A-4. Three-byte Opcode Map: 00H — F7H (First Two Bytes are 0F 38H) *

pfx

pshufb

phaddw

phaddd

phaddsw

pmaddubsw

phsubw

phsubd

phsubsw

Pq, Qq

vpshufb

vphaddw

vphaddd

vphaddsw

vpmaddubsw

vphsubw

vphsubd

vphsubsw

Vx, Hx, Wx

pblendvb

vcvtph2ps^v

blendvps

blendvpd

vpermps^v

vptest

Vdq, Wdq

Vx, Wx, Ib

Vdq, Wdq

Vqq, Hqq, Wqq

Vx, Wx

vpmovsxbw

vpmovsxbd

vpmovsxbq

vpmovsxwd

vpmovsxwq

vpmovsxdq

Vx, Ux/Mq

Vx, Ux/Md

Vx, Ux/Mw

Vx, Ux/Mq

Vx, Ux/Md

Vx, Ux/Mq

vpmovzxbw

vpmovzxbd

vpmovzxbq

vpmovzxwd

vpmovzxwq

vpmovzxdq

vpermd

vpcmpgtq

Vx, Ux/Mq

Vx, Ux/Md

Vx, Ux/Mw

Vx, Ux/Mq

Vx, Ux/Md

Vx, Ux/Mq

Vqq, Hqq, Wqq

Vx, Hx, Wx

vpmulld

vphminposuw

vpsrlvd/q

vpsravd^v

vpsllvd/q^v

Vx, Hx, Wx

Vdq, Wdq

Vx, Hx, Wx

INVEPT

INVVPID

INVPCID

Gy, Mdq

vgatherdd/q^v

vgatherqd/q^v

vgatherdps/d^v

vgatherqps/d^v

vfmaddsub132ps/d^v

vfmsubadd132ps/d^v

Vx,Hx,Wx

vfmaddsub213ps/d^v

vfmsubadd213ps/d^v

Vx,Hx,Wx

vfmaddsub231ps/d^v

vfmsubadd231ps/d^v

Vx,Hx,Wx

MOVBE

ANDN^v

BZHI^v

BEXTR^v

Gy, My

My, Gy

Gy, By, Ey

Gy, Ey, By

MOVBE

ADCX

SHLX

Gw, Mw

Mw, Gw

Gy, Ey

Gy, Ey, By

PEXT

ADOX

SARX^v

Grp 17^1A

Gy, By, Ey

Gy, Ey

Gy, Ey, By

CRC32

PDEP

MULX^v

SHRX^v

Gd, Eb

Gd, Ey

Gy, By, Ey

By,Gy,rDX,Ey

Gy, Ey, By

66 &

CRC32

Gd, Eb

Gd, Ew

Vol. 2D A-13

OPCODE MAP

Table A-4. Three-byte Opcode Map: 08H — FFH (First Two Bytes are 0F 38H) *

pfx

psignb

psignw

psignd

pmulhrsw

Pq, Qq

vpsignb

vpsignw

vpsignd

vpmulhrsw

vpermilps^v

vpermilpd^v

vtestps^v

vtestpd^v

Vx, Hx, Wx

Vx,Hx,Wx

Vx, Wx

pabsb

pabsw

pabsd

Pq, Qq

vbroadcastss^v

vbroadcastsd^v Vqq,

vbroadcastf128^v Vqq,

vpabsb

vpabsw

vpabsd

Vx, Wd

Mdq

Vx, Wx

vpmuldq

vpcmpeqq

vmovntdqa

vpackusdw

vmaskmovps^v

vmaskmovpd^v

vmaskmovps^v

vmaskmovpd^v

Vx, Hx, Wx

Vx, Mx

Vx, Hx, Wx

Vx,Hx,Mx

Mx,Hx,Vx

vpminsb

vpminsd

vpminuw

vpminud

vpmaxsb

vpmaxsd

vpmaxuw

vpmaxud

Vx, Hx, Wx

vpbroadcastd^v

vpbroadcastq^v

vbroadcasti128^v

Vx, Wx

Vqq, Mdq

vpbroadcastb^v

vpbroadcastw^v

Vx, Wx

vpmaskmovd/q^v

Vx,Hx,Mx

Mx,Vx,Hx

vfmadd132ps/d^v

vfmadd132ss/d^v

vfmsub132ps/d^v

vfmsub132ss/d^v

vfnmadd132ps/d^v

vfnmadd132ss/d^v

vfnmsub132ps/d^v

vfnmsub132ss/d^v

Vx, Hx, Wx

vfmadd213ps/d^v

vfmadd213ss/d^v

vfmsub213ps/d^v

vfmsub213ss/d^v

vfnmadd213ps/d^v

vfnmadd213ss/d^v

vfnmsub213ps/d^v

vfnmsub213ss/d^v

Vx, Hx, Wx

vfmadd231ps/d^v

vfmadd231ss/d^v

vfmsub231ps/d^v

vfmsub231ss/d^v

vfnmadd231ps/d^v

vfnmadd231ss/d^v

vfnmsub231ps/d^v

vfnmsub231ss/d^v

Vx, Hx, Wx

sha1nexte

sha1msg1

sha1msg2

sha256rnds2

sha256msg1

sha256msg2

Vdq,Wdq

VAESIMC

VAESENC

VAESENCLAST

VAESDEC

VAESDECLAST

Vdq, Wdq

Vdq,Hdq,Wdq

66 & F2

NOTES:

* All blanks in all opcode maps are reserved and must not be used. Do not depend on the operation of undefined or reserved locations.

A-14

Vol. 2D

OPCODE MAP

Table A-5. Three-byte Opcode Map: 00H — F7H (First two bytes are 0F 3AH) *

pfx

vpermq^v

vpermpd^v

vpblendd^v

vpermilps^v

vpermilpd^v

vperm2f128^v

Vqq, Wqq, Ib

Vx,Hx,Wx,Ib

Vx, Wx, Ib

Vqq,Hqq,Wqq,Ib

vpextrb

vpextrw

vpextrd/q

vextractps

Rd/Mb, Vdq, Ib

Rd/Mw, Vdq, Ib

Ey, Vdq, Ib

Ed, Vdq, Ib

vpinsrb

vinsertps

vpinsrd/q

Vdq,Hdq,Ry/Mb,Ib

Vdq,Hdq,Udq/Md,Ib

Vdq,Hdq,Ey,Ib

vdpps

vdppd

vmpsadbw

vpclmulqdq

vperm2i128

Vx,Hx,Wx,Ib

Vdq,Hdq,Wdq,Ib

Vx,Hx,Wx,Ib

Vdq,Hdq,Wdq,Ib

Vqq,Hqq,Wqq,Ib

vpcmpestrm

vpcmpestri

vpcmpistrm

vpcmpistri

Vdq, Wdq, Ib

RORX^v

Gy, Ey, Ib

Vol. 2D A-15

OPCODE MAP

Table A-5. Three-byte Opcode Map: 08H — FFH (First Two Bytes are 0F 3AH) *

pfx

palignr

Pq, Qq, Ib

vroundps

vroundpd

vroundss

vroundsd

vblendps

vblendpd

vpblendw

vpalignr

Vx,Wx,Ib

Vss,Wss,Ib

Vsd,Wsd,Ib

Vx,Hx,Wx,Ib

vinsertf128^v

vextractf128^v

vcvtps2ph^v

Vqq,Hqq,Wqq,Ib

Wdq,Vqq,Ib

Wx, Vx, Ib

vinserti128^v

vextracti128^v

Vqq,Hqq,Wqq,Ib

Wdq,Vqq,Ib

vblendvps

vblendvpd^v

vpblendvb^v

Vx,Hx,Wx,Lx

sha1rnds4

Vdq,Wdq,Ib

VAESKEYGEN

Vdq, Wdq, Ib

NOTES:

* All blanks in all opcode maps are reserved and must not be used. Do not depend on the operation of undefined or reserved locations.

A-16

Vol. 2D

OPCODE MAP

A.4

OPCODE EXTENSIONS FOR ONE-BYTE AND TWO-BYTE OPCODES

Some 1-byte and 2-byte opcodes use bits 3-5 of the ModR/M byte (the nnn field in Figure A-1) as an extension of

the opcode.

mod

nnn

R/M

Figure A-1. ModR/M Byte nnn Field (Bits 5, 4, and 3)

Opcodes that have opcode extensions are indicated in Table A-6 and organized by group number. Group numbers

(from 1 to 16, second column) provide a table entry point. The encoding for the r/m field for each instruction can

be established using the third column of the table.

A.4.1

Opcode Look-up Examples Using Opcode Extensions

An Example is provided below.

Example A-4. Interpreting an ADD Instruction

An ADD instruction with a 1-byte opcode of 80H is a Group 1 instruction:

• Table A-6 indicates that the opcode extension field encoded in the ModR/M byte for this instruction is 000B.

• The r/m field can be encoded to access a register (11B) or a memory address using a specified addressing

mode (for example: mem = 00B, 01B, 10B).

Example A-5. Looking Up 0F01C3H

Look up opcode 0F01C3 for a VMRESUME instruction by using Table A-2, Table A-3, and Table A-6:

•

0F indicates that this instruction is in the 2-byte opcode map.

•

01 (row 0, column 1 in Table A-3) reveals that this opcode is in Group 7 of Table A-6.

• C3 is the ModR/M byte. The first two bits of C3 are 11B. This tells us to look at the second of the Group 7 rows

in Table A-6.

• The Op/Reg bits [5,4,3] are 000B. This tells us to look in the 000 column for Group 7.

• Finally, the R/M bits [2,1,0] are 011B. This identifies the opcode as the VMRESUME instruction.

A.4.2

Opcode Extension Tables

See Table A-6 below.

Vol. 2D A-17

OPCODE MAP

Table A-6. Opcode Extensions for One- and Two-byte Opcodes by Group Number *

Encoding of Bits 5,4,3 of the ModR/M Byte (bits 2,1,0 in parenthesis)

Opcode

Group

Mod 7,6

pfx

000

001

010

011

100

101

110

111

80-83

mem, 11B

ADD

ADC

SBB

AND

SUB

XOR

CMP

mem, 11B

POP

C0,C1 reg, imm

mem, 11B

ROL

ROR

RCL

RCR

SHL/SAL

SHR

SAR

D0, D1 reg, 1

D2, D3 reg, CL

mem, 11B

TEST

NOT

NEG

MUL

IMUL

DIV

IDIV

F6, F7

Ib/Iz

AL/rAX

mem, 11B

INC

DEC

mem, 11B

INC

DEC

near CALL

f64

far CALL

near JMP^f64

far JMP

PUSH^d64

mem, 11B

SLDT

STR

LLDT

LTR

VERR

VERW

0F 00

Rv/Mw

mem

SGDT

SIDT

LGDT

LIDT

SMSW

LMSW

INVLPG

Mw/Rv

11B

VMCALL (001)

MONITOR

XGETBV (000)

SWAPGS

VMLAUNCH

(000)

XSETBV (001)

^o64(000)

0F 01

(010)

MWAIT (001)

RDTSCP (001)

VMFUNC

VMRESUME

CLAC (010)

(100)

(011) VMXOFF

STAC (011)

XEND (101)

(100)

ENCLS (111)

XTEST (110)

ENCLU(111)

0F BA

mem, 11B

BTS

BTR

BTC

CMPXCH8B Mq

VMPTRLD

VMPTRST

CMPXCHG16B

Mdq

mem

VMCLEAR

0F C7

VMXON

RDRAND

RDSEED

11B

RDPID

Rd/q

mem

UD1

0F B9

11B

mem

MOV

Eb, Ib

11B

XABORT (000) Ib

mem

MOV

Ev, Iz

11B

XBEGIN (000) Jz

mem

psrlw

psraw

psllw

0F 71

Nq, Ib

11B

vpsrlw

vpsraw

vpsllw

Hx,Ux,Ib

mem

psrld

psrad

pslld

0F 72

Nq, Ib

11B

vpsrld

vpsrad

vpslld

Hx,Ux,Ib

mem

psrlq

psllq

0F 73

Nq, Ib

11B

vpsrlq

vpsrldq

vpsllq

vpslldq

Hx,Ux,Ib

A-18

Vol. 2D

OPCODE MAP

Table A-6. Opcode Extensions for One- and Two-byte Opcodes by Group Number * (Contd.)

Encoding of Bits 5,4,3 of the ModR/M Byte (bits 2,1,0 in parenthesis)

Opcode

Group

Mod 7,6

pfx

000

001

010

011

100

101

110

111

mem

fxsave

fxrstor

ldmxcsr

stmxcsr

XSAVE

XRSTOR

XSAVEOPT

clflush

lfence

mfence

sfence

0F AE

RDFSBASE

RDGSBASE

WRFSBASE

WRGSBASE

11B

prefetch

Reserved NOP

mem

NTA

0F 18

11B

Reserved NOP

mem

BLSR^v

BLSMSK^v

BLSI^v

VEX.0F38 F3

By, Ey

11B

NOTES:

* All blanks in all opcode maps are reserved and must not be used. Do not depend on the operation of undefined or reserved locations.

Vol. 2D A-19

OPCODE MAP

A.5

ESCAPE OPCODE INSTRUCTIONS

Opcode maps for coprocessor escape instruction opcodes (x87 floating-point instruction opcodes) are in Table A-7

through Table A-22. These maps are grouped by the first byte of the opcode, from D8-DF. Each of these opcodes

has a ModR/M byte. If the ModR/M byte is within the range of 00H-BFH, bits 3-5 of the ModR/M byte are used as

an opcode extension, similar to the technique used for 1-and 2-byte opcodes (see A.4). If the ModR/M byte is

outside the range of 00H through BFH, the entire ModR/M byte is used as an opcode extension.

A.5.1

Opcode Look-up Examples for Escape Instruction Opcodes

Examples are provided below.

Example A-6. Opcode with ModR/M Byte in the 00H through BFH Range

DD0504000000H can be interpreted as follows:

• The instruction encoded with this opcode can be located in Section . Since the ModR/M byte (05H) is within the

00H through BFH range, bits 3 through 5 (000) of this byte indicate the opcode for an FLD double-real

instruction (see Table A-9).

• The double-real value to be loaded is at 00000004H (the 32-bit displacement that follows and belongs to this

opcode).

Example A-7. Opcode with ModR/M Byte outside the 00H through BFH Range

D8C1H can be interpreted as follows:

• This example illustrates an opcode with a ModR/M byte outside the range of 00H through BFH. The instruction

can be located in Section A.4.

• In Table A-8, the ModR/M byte C1H indicates row C, column 1 (the FADD instruction using ST(0), ST(1) as

operands).

A.5.2

Escape Opcode Instruction Tables

Tables are listed below.

A.5.2.1

Escape Opcodes with D8 as First Byte

Table A-7 and A-8 contain maps for the escape instruction opcodes that begin with D8H. Table A-7 shows the map if the ModR/M

byte is in the range of 00H-BFH. Here, the value of bits 3-5 (the nnn field in Figure A-1) selects the instruction.

Table A-7. D8 Opcode Map When ModR/M Byte is Within 00H to BFH *

nnn Field of ModR/M Byte (refer to Figure A.4)

000B

001B

010B

011B

100B

101B

110B

111B

FADD

FMUL

FCOM

FCOMP

FSUB

FSUBR

FDIV

FDIVR

single-real

NOTES:

* All blanks in all opcode maps are reserved and must not be used. Do not depend on the operation of undefined or reserved locations.

A-20

Vol. 2D

OPCODE MAP

Table A-8 shows the map if the ModR/M byte is outside the range of 00H-BFH. Here, the first digit of the ModR/M byte selects the

table row and the second digit selects the column.

Table A-8. D8 Opcode Map When ModR/M Byte is Outside 00H to BFH *

FADD

ST(0),ST(0)

ST(0),ST(1)

ST(0),ST(2)

ST(0),ST(3)

ST(0),ST(4)

ST(0),ST(5)

ST(0),ST(6)

ST(0),ST(7)

FCOM

ST(0),ST(0)

ST(0),ST(1)

ST(0),T(2)

ST(0),ST(3)

ST(0),ST(4)

ST(0),ST(5)

ST(0),ST(6)

ST(0),ST(7)

FSUB

ST(0),ST(0)

ST(0),ST(1)

ST(0),ST(2)

ST(0),ST(3)

ST(0),ST(4)

ST(0),ST(5)

ST(0),ST(6)

ST(0),ST(7)

FDIV

ST(0),ST(0)

ST(0),ST(1)

ST(0),ST(2)

ST(0),ST(3)

ST(0),ST(4)

ST(0),ST(5)

ST(0),ST(6)

ST(0),ST(7)

FMUL

ST(0),ST(0)

ST(0),ST(1)

ST(0),ST(2)

ST(0),ST(3)

ST(0),ST(4)

ST(0),ST(5)

ST(0),ST(6)

ST(0),ST(7)

FCOMP

ST(0),ST(0)

ST(0),ST(1)

ST(0),T(2)

ST(0),ST(3)

ST(0),ST(4)

ST(0),ST(5)

ST(0),ST(6)

ST(0),ST(7)

FSUBR

ST(0),ST(0)

ST(0),ST(1)

ST(0),ST(2)

ST(0),ST(3)

ST(0),ST(4)

ST(0),ST(5)

ST(0),ST(6)

ST(0),ST(7)

FDIVR

ST(0),ST(0)

ST(0),ST(1)

ST(0),ST(2)

ST(0),ST(3)

ST(0),ST(4)

ST(0),ST(5)

ST(0),ST(6)

ST(0),ST(7)

NOTES:

* All blanks in all opcode maps are reserved and must not be used. Do not depend on the operation of undefined or reserved locations.

A.5.2.2

Escape Opcodes with D9 as First Byte

Table A-9 and A-10 contain maps for escape instruction opcodes that begin with D9H. Table A-9 shows the map if the ModR/M

byte is in the range of 00H-BFH. Here, the value of bits 3-5 (the nnn field in Figure A-1) selects the instruction.

Table A-9. D9 Opcode Map When ModR/M Byte is Within 00H to BFH *

nnn Field of ModR/M Byte

000B

001B

010B

011B

100B

101B

110B

111B

FLD

FST

FSTP

FLDENV

FLDCW

FSTENV

FSTCW

single-real

14/28 bytes

2 bytes

14/28 bytes

2 bytes

NOTES:

* All blanks in all opcode maps are reserved and must not be used. Do not depend on the operation of undefined or reserved locations.

Vol. 2D A-21

OPCODE MAP

Table A-10 shows the map if the ModR/M byte is outside the range of 00H-BFH. Here, the first digit of the ModR/M byte selects

the table row and the second digit selects the column.

Table A-10. D9 Opcode Map When ModR/M Byte is Outside 00H to BFH *

FLD

ST(0),ST(0)

ST(0),ST(1)

ST(0),ST(2)

ST(0),ST(3)

ST(0),ST(4)

ST(0),ST(5)

ST(0),ST(6)

ST(0),ST(7)

FNOP

FCHS

FABS

FTST

FXAM

F2XM1

FYL2X

FPTAN

FPATAN

FXTRACT

FPREM1

FDECSTP

FINCSTP

FXCH

ST(0),ST(0)

ST(0),ST(1)

ST(0),ST(2)

ST(0),ST(3)

ST(0),ST(4)

ST(0),ST(5)

ST(0),ST(6)

ST(0),ST(7)

FLD1

FLDL2T

FLDL2E

FLDPI

FLDLG2

FLDLN2

FLDZ

FPREM

FYL2XP1

FSQRT

FSINCOS

FRNDINT

FSCALE

FSIN

FCOS

NOTES:

* All blanks in all opcode maps are reserved and must not be used. Do not depend on the operation of undefined or reserved locations.

A.5.2.3

Escape Opcodes with DA as First Byte

Table A-11 and A-12 contain maps for escape instruction opcodes that begin with DAH. Table A-11 shows the map if the ModR/M

byte is in the range of 00H-BFH. Here, the value of bits 3-5 (the nnn field in Figure A-1) selects the instruction.

Table A-11. DA Opcode Map When ModR/M Byte is Within 00H to BFH *

nnn Field of ModR/M Byte

000B

001B

010B

011B

100B

101B

110B

111B

FIADD

FIMUL

FICOM

FICOMP

FISUB

FISUBR

FIDIV

FIDIVR

dword-integer

NOTES:

* All blanks in all opcode maps are reserved and must not be used. Do not depend on the operation of undefined or reserved locations.

A-22

Vol. 2D

OPCODE MAP

Table A-12 shows the map if the ModR/M byte is outside the range of 00H-BFH. Here, the first digit of the ModR/M byte selects

the table row and the second digit selects the column.

Table A-12. DA Opcode Map When ModR/M Byte is Outside 00H to BFH *

FCMOVB

ST(0),ST(0)

ST(0),ST(1)

ST(0),ST(2)

ST(0),ST(3)

ST(0),ST(4)

ST(0),ST(5)

ST(0),ST(6)

ST(0),ST(7)

FCMOVBE

ST(0),ST(0)

ST(0),ST(1)

ST(0),ST(2)

ST(0),ST(3)

ST(0),ST(4)

ST(0),ST(5)

ST(0),ST(6)

ST(0),ST(7)

FCMOVE

ST(0),ST(0)

ST(0),ST(1)

ST(0),ST(2)

ST(0),ST(3)

ST(0),ST(4)

ST(0),ST(5)

ST(0),ST(6)

ST(0),ST(7)

FCMOVU

ST(0),ST(0)

ST(0),ST(1)

ST(0),ST(2)

ST(0),ST(3)

ST(0),ST(4)

ST(0),ST(5)

ST(0),ST(6)

ST(0),ST(7)

FUCOMPP

NOTES:

* All blanks in all opcode maps are reserved and must not be used. Do not depend on the operation of undefined or reserved locations.

A.5.2.4

Escape Opcodes with DB as First Byte

Table A-13 and A-14 contain maps for escape instruction opcodes that begin with DBH. Table A-13 shows the map if the ModR/M

byte is in the range of 00H-BFH. Here, the value of bits 3-5 (the nnn field in Figure A-1) selects the instruction.

Table A-13. DB Opcode Map When ModR/M Byte is Within 00H to BFH *

nnn Field of ModR/M Byte

000B

001B

010B

011B

100B

101B

110B

111B

FILD

FISTTP

FIST

FISTP

FLD

FSTP

dword-integer

extended-real

NOTES:

* All blanks in all opcode maps are reserved and must not be used. Do not depend on the operation of undefined or reserved locations.

Vol. 2D A-23

OPCODE MAP

Table A-14 shows the map if the ModR/M byte is outside the range of 00H-BFH. Here, the first digit of the ModR/M byte selects

the table row and the second digit selects the column.

Table A-14. DB Opcode Map When ModR/M Byte is Outside 00H to BFH *

FCMOVNB

ST(0),ST(0)

ST(0),ST(1)

ST(0),ST(2)

ST(0),ST(3)

ST(0),ST(4)

ST(0),ST(5)

ST(0),ST(6)

ST(0),ST(7)

FCMOVNBE

ST(0),ST(0)

ST(0),ST(1)

ST(0),ST(2)

ST(0),ST(3)

ST(0),ST(4)

ST(0),ST(5)

ST(0),ST(6)

ST(0),ST(7)

FCLEX

FINIT

FCOMI

ST(0),ST(0)

ST(0),ST(1)

ST(0),ST(2)

ST(0),ST(3)

ST(0),ST(4)

ST(0),ST(5)

ST(0),ST(6)

ST(0),ST(7)

FCMOVNE

ST(0),ST(0)

ST(0),ST(1)

ST(0),ST(2)

ST(0),ST(3)

ST(0),ST(4)

ST(0),ST(5)

ST(0),ST(6)

ST(0),ST(7)

FCMOVNU

ST(0),ST(0)

ST(0),ST(1)

ST(0),ST(2)

ST(0),ST(3)

ST(0),ST(4)

ST(0),ST(5)

ST(0),ST(6)

ST(0),ST(7)

FUCOMI

ST(0),ST(0)

ST(0),ST(1)

ST(0),ST(2)

ST(0),ST(3)

ST(0),ST(4)

ST(0),ST(5)

ST(0),ST(6)

ST(0),ST(7)

NOTES:

* All blanks in all opcode maps are reserved and must not be used. Do not depend on the operation of undefined or reserved locations.

A.5.2.5

Escape Opcodes with DC as First Byte

Table A-15 and A-16 contain maps for escape instruction opcodes that begin with DCH. Table A-15 shows the map if the ModR/M

byte is in the range of 00H-BFH. Here, the value of bits 3-5 (the nnn field in Figure A-1) selects the instruction.

Table A-15. DC Opcode Map When ModR/M Byte is Within 00H to BFH *

nnn Field of ModR/M Byte (refer to Figure A-1)

000B

001B

010B

011B

100B

101B

110B

111B

FADD

FMUL

FCOM

FCOMP

FSUB

FSUBR

FDIV

FDIVR

double-real

NOTES:

* All blanks in all opcode maps are reserved and must not be used. Do not depend on the operation of undefined or reserved locations.

A-24

Vol. 2D

OPCODE MAP

Table A-16 shows the map if the ModR/M byte is outside the range of 00H-BFH. In this case the first digit of the ModR/M byte

selects the table row and the second digit selects the column.

Table A-16. DC Opcode Map When ModR/M Byte is Outside 00H to BFH *

FADD

ST(0),ST(0)

ST(1),ST(0)

ST(2),ST(0)

ST(3),ST(0)

ST(4),ST(0)

ST(5),ST(0)

ST(6),ST(0)

ST(7),ST(0)

FSUBR

ST(0),ST(0)

ST(1),ST(0)

ST(2),ST(0)

ST(3),ST(0)

ST(4),ST(0)

ST(5),ST(0)

ST(6),ST(0)

ST(7),ST(0)

FDIVR

ST(0),ST(0)

ST(1),ST(0)

ST(2),ST(0)

ST(3),ST(0)

ST(4),ST(0)

ST(5),ST(0)

ST(6),ST(0)

ST(7),ST(0)

FMUL

ST(0),ST(0)

ST(1),ST(0)

ST(2),ST(0)

ST(3),ST(0)

ST(4),ST(0)

ST(5),ST(0)

ST(6),ST(0)

ST(7),ST(0)

FSUB

ST(0),ST(0)

ST(1),ST(0)

ST(2),ST(0)

ST(3),ST(0)

ST(4),ST(0)

ST(5),ST(0)

ST(6),ST(0)

ST(7),ST(0)

FDIV

ST(0),ST(0)

ST(1),ST(0)

ST(2),ST(0)

ST(3),ST(0)

ST(4),ST(0)

ST(5),ST(0)

ST(6),ST(0)

ST(7),ST(0)

NOTES:

* All blanks in all opcode maps are reserved and must not be used. Do not depend on the operation of undefined or reserved locations.

A.5.2.6

Escape Opcodes with DD as First Byte

Table A-17 and A-18 contain maps for escape instruction opcodes that begin with DDH. Table A-17 shows the map if the ModR/M

byte is in the range of 00H-BFH. Here, the value of bits 3-5 (the nnn field in Figure A-1) selects the instruction.

Table A-17. DD Opcode Map When ModR/M Byte is Within 00H to BFH ^*

nnn Field of ModR/M Byte

000B

001B

010B

011B

100B

101B

110B

111B

FLD

FISTTP

FST

FSTP

FRSTOR

FSAVE

FSTSW

double-real

integer64

double-real

98/108bytes

2 bytes

NOTES:

* All blanks in all opcode maps are reserved and must not be used. Do not depend on the operation of undefined or reserved locations.

Vol. 2D A-25

OPCODE MAP

Table A-18 shows the map if the ModR/M byte is outside the range of 00H-BFH. The first digit of the ModR/M byte selects the table

row and the second digit selects the column.

Table A-18. DD Opcode Map When ModR/M Byte is Outside 00H to BFH *

FFREE

ST(0)

ST(1)

ST(2)

ST(3)

ST(4)

ST(5)

ST(6)

ST(7)

FST

ST(0)

ST(1)

ST(2)

ST(3)

ST(4)

ST(5)

ST(6)

ST(7)

FUCOM

ST(0),ST(0)

ST(1),ST(0)

ST(2),ST(0)

ST(3),ST(0)

ST(4),ST(0)

ST(5),ST(0)

ST(6),ST(0)

ST(7),ST(0)

FSTP

ST(0)

ST(1)

ST(2)

ST(3)

ST(4)

ST(5)

ST(6)

ST(7)

FUCOMP

ST(0)

ST(1)

ST(2)

ST(3)

ST(4)

ST(5)

ST(6)

ST(7)

NOTES:

* All blanks in all opcode maps are reserved and must not be used. Do not depend on the operation of undefined or reserved locations.

A.5.2.7

Escape Opcodes with DE as First Byte

Table A-19 and A-20 contain opcode maps for escape instruction opcodes that begin with DEH. Table A-19 shows the opcode map

if the ModR/M byte is in the range of 00H-BFH. In this case, the value of bits 3-5 (the nnn field in Figure A-1) selects the instruc-

tion.

Table A-19. DE Opcode Map When ModR/M Byte is Within 00H to BFH *

nnn Field of ModR/M Byte

000B

001B

010B

011B

100B

101B

110B

111B

FIADD

FIMUL

FICOM

FICOMP

FISUB

FISUBR

FIDIV

FIDIVR

word-integer

NOTES:

* All blanks in all opcode maps are reserved and must not be used. Do not depend on the operation of undefined or reserved locations.

A-26

Vol. 2D

OPCODE MAP

Table A-20 shows the opcode map if the ModR/M byte is outside the range of 00H-BFH. The first digit of the ModR/M byte selects

the table row and the second digit selects the column.

Table A-20. DE Opcode Map When ModR/M Byte is Outside 00H to BFH *

FADDP

ST(0),ST(0)

ST(1),ST(0)

ST(2),ST(0)

ST(3),ST(0)

ST(4),ST(0)

ST(5),ST(0)

ST(6),ST(0)

ST(7),ST(0)

FSUBRP

ST(0),ST(0)

ST(1),ST(0)

ST(2),ST(0)

ST(3),ST(0)

ST(4),ST(0)

ST(5),ST(0)

ST(6),ST(0)

ST(7),ST(0)

FDIVRP

ST(0),ST(0)

ST(1),ST(0)

ST(2),ST(0)

ST(3),ST(0)

ST(4),ST(0)

ST(5),ST(0)

ST(6),ST(0)

ST(7),ST(0)

FMULP

ST(0),ST(0)

ST(1),ST(0)

ST(2),ST(0)

ST(3),ST(0)

ST(4),ST(0)

ST(5),ST(0)

ST(6),ST(0)

ST(7),ST(0)

FCOMPP

FSUBP

ST(0),ST(0)

ST(1),ST(0)

ST(2),ST(0)

ST(3),ST(0)

ST(4),ST(0)

ST(5),ST(0)

ST(6),ST(0)

ST(7),ST(0)

FDIVP

ST(0),ST(0)

ST(1),ST(0)

ST(2),ST(0).

ST(3),ST(0)

ST(4),ST(0)

ST(5),ST(0)

ST(6),ST(0)

ST(7),ST(0)

NOTES:

* All blanks in all opcode maps are reserved and must not be used. Do not depend on the operation of undefined or reserved locations.

A.5.2.8

Escape Opcodes with DF As First Byte

Table A-21 and A-22 contain the opcode maps for escape instruction opcodes that begin with DFH. Table A-21 shows the opcode

map if the ModR/M byte is in the range of 00H-BFH. Here, the value of bits 3-5 (the nnn field in Figure A-1) selects the instruction.

Table A-21. DF Opcode Map When ModR/M Byte is Within 00H to BFH *

nnn Field of ModR/M Byte

000B

001B

010B

011B

100B

101B

110B

111B

FILD

FISTTP

FIST

FISTP

FBLD

FILD

FBSTP

FISTP

word-integer

packed-BCD

qword-integer

packed-BCD

qword-integer

NOTES:

* All blanks in all opcode maps are reserved and must not be used. Do not depend on the operation of undefined or reserved locations.

Vol. 2D A-27

OPCODE MAP

Table A-22 shows the opcode map if the ModR/M byte is outside the range of 00H-BFH. The first digit of the ModR/M byte selects

the table row and the second digit selects the column.

Table A-22. DF Opcode Map When ModR/M Byte is Outside 00H to BFH ^*

FSTSW

FCOMIP

ST(0),ST(0)

ST(0),ST(1)

ST(0),ST(2)

ST(0),ST(3)

ST(0),ST(4)

ST(0),ST(5)

ST(0),ST(6)

ST(0),ST(7)

FUCOMIP

ST(0),ST(0)

ST(0),ST(1)

ST(0),ST(2)

ST(0),ST(3)

ST(0),ST(4)

ST(0),ST(5)

ST(0),ST(6)

ST(0),ST(7)

NOTES:

* All blanks in all opcode maps are reserved and must not be used. Do not depend on the operation of undefined or reserved locations.

A-28

Vol. 2D

APPENDIX B

INSTRUCTION FORMATS AND ENCODINGS

This appendix provides machine instruction formats and encodings of IA-32 instructions. The first section describes

the IA-32 architecture’s machine instruction format. The remaining sections show the formats and encoding of

general-purpose, MMX, P6 family, SSE/SSE2/SSE3, x87 FPU instructions, and VMX instructions. Those instruction

formats also apply to Intel 64 architecture. Instruction formats used in 64-bit mode are provided as supersets of

the above.

B.1

MACHINE INSTRUCTION FORMAT

All Intel Architecture instructions are encoded using subsets of the general machine instruction format shown in

Figure B-1. Each instruction consists of:

•

an opcode

•

a register and/or address mode specifier consisting of the ModR/M byte and sometimes the scale-index-base

(SIB) byte (if required)

•

a displacement and an immediate data field (if required)

7 6 5 4 3 2 1 0

Legacy Prefixes

REX Prefixes

T T T T T T T T

Grp

1, Grp 2,

(optional)

Grp 3, Grp 4

1, 2, or 3 Byte Opcodes (T = Opcode

7-6

5-3

2-0

7-6

5-3

2-0

Mod Reg* R/M

Scale Index Base

d32 | 16 | 8 | None

ModR/M Byte

SIB Byte

Address Displacement

Immediate Data

(4, 2, 1 Bytes or None)

(4,2,1 Bytes or None)

NOTE:

Mode Specifier

* The Reg Field may be used as an

opcode extension field (TTT) and as a

way to encode diagnostic registers

(eee).

Figure B-1. General Machine Instruction Format

The following sections discuss this format.

B.1.1

Legacy Prefixes

The legacy prefixes noted in Figure B-1 include 66H, 67H, F2H, and F3H. They are optional, except when F2H, F3H,

and 66H are used in instruction extensions. Legacy prefixes must be placed before REX prefixes.

Refer to Chapter 2, “Instruction Format,” in the Intel® 64 and IA-32 Architectures Software Developer’s Manual,

Volume 2A, for more information on legacy prefixes.

Vol. 2D B-1

INSTRUCTION FORMATS AND ENCODINGS

B.1.2

REX Prefixes

REX prefixes are a set of 16 opcodes that span one row of the opcode map and occupy entries 40H to 4FH. These

opcodes represent valid instructions (INC or DEC) in IA-32 operating modes and in compatibility mode. In 64-bit

mode, the same opcodes represent the instruction prefix REX and are not treated as individual instructions.

Refer to Chapter 2, “Instruction Format,” in the Intel® 64 and IA-32 Architectures Software Developer’s Manual,

Volume 2A, for more information on REX prefixes.

B.1.3

Opcode Fields

The primary opcode for an instruction is encoded in one to three bytes of the instruction. Within the primary

opcode, smaller encoding fields may be defined. These fields vary according to the class of operation being

performed.

Almost all instructions that refer to a register and/or memory operand have a register and/or address mode byte

following the opcode. This byte, the ModR/M byte, consists of the mod field (2 bits), the reg field (3 bits; this field

is sometimes an opcode extension), and the R/M field (3 bits). Certain encodings of the ModR/M byte indicate that

a second address mode byte, the SIB byte, must be used.

If the addressing mode specifies a displacement, the displacement value is placed immediately following the

ModR/M byte or SIB byte. Possible sizes are 8, 16, or 32 bits. If the instruction specifies an immediate value, the

immediate value follows any displacement bytes. The immediate, if specified, is always the last field of the instruc-

tion.

Refer to Chapter 2, “Instruction Format,” in the Intel® 64 and IA-32 Architectures Software Developer’s Manual,

Volume 2A, for more information on opcodes.

B.1.4

Special Fields

Table B-1 lists bit fields that appear in certain instructions, sometimes within the opcode bytes. All of these fields

(except the d bit) occur in the general-purpose instruction formats in Table B-13.

Table B-1. Special Fields Within Instruction Encodings

Number of

Field Name

Description

Bits

reg

General-register specifier (see Table B-4 or B-5).

Specifies if data is byte or full-sized, where full-sized is 16 or 32 bits (see Table B-6).

Specifies sign extension of an immediate field (see Table B-7).

sreg2

Segment register specifier for CS, SS, DS, ES (see Table B-8).

sreg3

Segment register specifier for CS, SS, DS, ES, FS, GS (see Table B-8).

eee

Specifies a special-purpose (control or debug) register (see Table B-9).

tttn

For conditional instructions, specifies a condition asserted or negated (see Table B-12).

Specifies direction of data operation (see Table B-11).

B-2

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

B.1.4.1

Reg Field (reg) for Non-64-Bit Modes

The reg field in the ModR/M byte specifies a general-purpose register operand. The group of registers specified is

modified by the presence and state of the w bit in an encoding (refer to Section B.1.4.3). Table B-2 shows the

encoding of the reg field when the w bit is not present in an encoding; Table B-3 shows the encoding of the reg field

when the w bit is present.

Table B-2. Encoding of reg Field When w Field is Not Present in Instruction

reg Field

16-Bit Data Operations

32-Bit Data Operations

000

EAX

001

ECX

010

EDX

011

EBX

100

ESP

101

EBP

110

ESI

111

EDI

Table B-3. Encoding of reg Field When w Field is Present in Instruction

During 16-Bit Data Operations

During 32-Bit Data Operations

Function of w Field

reg

When w = 0

When w = 1

When w = 0

When w = 1

000

EAX

001

ECX

010

EDX

011

EBX

100

ESP

101

EBP

110

ESI

111

EDI

Vol. 2D B-3

INSTRUCTION FORMATS AND ENCODINGS

B.1.4.2

Reg Field (reg) for 64-Bit Mode

Just like in non-64-bit modes, the reg field in the ModR/M byte specifies a general-purpose register operand. The

group of registers specified is modified by the presence of and state of the w bit in an encoding (refer to Section

B.1.4.3). Table B-4 shows the encoding of the reg field when the w bit is not present in an encoding; Table B-5

shows the encoding of the reg field when the w bit is present.

Table B-4. Encoding of reg Field When w Field is Not Present in Instruction

reg Field

16-Bit Data Operations

32-Bit Data Operations

64-Bit Data Operations

000

EAX

RAX

001

ECX

RCX

010

EDX

RDX

011

EBX

RBX

100

ESP

RSP

101

EBP

RBP

110

ESI

RSI

111

EDI

RDI

Table B-5. Encoding of reg Field When w Field is Present in Instruction

During 16-Bit Data Operations

During 32-Bit Data Operations

Function of w Field

reg

When w = 0

When w = 1

When w = 0

When w = 1

000

EAX

001

ECX

010

EDX

011

EBX

100

AH¹

100

AH*

ESP

101

CH¹

101

CH*

EBP

110

DH¹

110

DH*

ESI

111

BH¹

111

BH*

EDI

NOTES:

1. AH, CH, DH, BH can not be encoded when REX prefix is used. Such an expression defaults to the low byte.

B.1.4.3

Encoding of Operand Size (w) Bit

The current operand-size attribute determines whether the processor is performing 16-bit, 32-bit or 64-bit opera-

tions. Within the constraints of the current operand-size attribute, the operand-size bit (w) can be used to indicate

operations on 8-bit operands or the full operand size specified with the operand-size attribute. Table B-6 shows the

encoding of the w bit depending on the current operand-size attribute.

Table B-6. Encoding of Operand Size (w) Bit

Operand Size When

w Bit

Operand-Size Attribute is 16 Bits

Operand-Size Attribute is 32 Bits

8 Bits

16 Bits

32 Bits

B-4

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

B.1.4.4

Sign-Extend (s) Bit

The sign-extend (s) bit occurs in instructions with immediate data fields that are being extended from 8 bits to 16

or 32 bits. See Table B-7.

Table B-7. Encoding of Sign-Extend (s) Bit

Effect on 8-Bit

Effect on 16- or 32-Bit

Immediate Data

None

Sign-extend to fill 16-bit or 32-bit destination

None

B.1.4.5

Segment Register (sreg) Field

When an instruction operates on a segment register, the reg field in the ModR/M byte is called the sreg field and is

used to specify the segment register. Table B-8 shows the encoding of the sreg field. This field is sometimes a 2-bit

field (sreg2) and other times a 3-bit field (sreg3).

Table B-8. Encoding of the Segment Register (sreg) Field

2-Bit sreg2 Field

Segment Register Selected

3-Bit sreg3 Field

Segment Register Selected

000

001

010

011

100

101

110

Reserved¹

111

Reserved

NOTES:

1. Do not use reserved encodings.

B.1.4.6

Special-Purpose Register (eee) Field

When control or debug registers are referenced in an instruction they are encoded in the eee field, located in bits 5

though 3 of the ModR/M byte (an alternate encoding of the sreg field). See Table B-9.

Table B-9. Encoding of Special-Purpose Register (eee) Field

eee

Control Register

Debug Register

000

CR0

DR0

001

Reserved¹

DR1

010

CR2

DR2

011

CR3

DR3

100

CR4

Reserved

101

Reserved

110

Reserved

DR6

111

Reserved

DR7

NOTES:

1. Do not use reserved encodings.

Vol. 2D B-5

INSTRUCTION FORMATS AND ENCODINGS

B.1.4.7

Condition Test (tttn) Field

For conditional instructions (such as conditional jumps and set on condition), the condition test field (tttn) is

encoded for the condition being tested. The ttt part of the field gives the condition to test and the n part indicates

whether to use the condition (n = 0) or its negation (n = 1).

• For 1-byte primary opcodes, the tttn field is located in bits 3, 2, 1, and 0 of the opcode byte.

• For 2-byte primary opcodes, the tttn field is located in bits 3, 2, 1, and 0 of the second opcode byte.

Table B-10 shows the encoding of the tttn field.

Table B-10. Encoding of Conditional Test (tttn) Field

t t t n

Mnemonic

Condition

0000

Overflow

0001

No overflow

0010

B, NAE

Below, Not above or equal

0011

NB, AE

Not below, Above or equal

0100

E, Z

Equal, Zero

0101

NE, NZ

Not equal, Not zero

0110

BE, NA

Below or equal, Not above

0111

NBE, A

Not below or equal, Above

1000

Sign

1001

Not sign

1010

P, PE

Parity, Parity Even

1011

NP, PO

Not parity, Parity Odd

1100

L, NGE

Less than, Not greater than or equal to

1101

NL, GE

Not less than, Greater than or equal to

1110

LE, NG

Less than or equal to, Not greater than

1111

NLE, G

Not less than or equal to, Greater than

B.1.4.8

Direction (d) Bit

In many two-operand instructions, a direction bit (d) indicates which operand is considered the source and which

is the destination. See Table B-11.

• When used for integer instructions, the d bit is located at bit 1 of a 1-byte primary opcode. Note that this bit

does not appear as the symbol “d” in Table B-13; the actual encoding of the bit as 1 or 0 is given.

• When used for floating-point instructions (in Table B-16), the d bit is shown as bit 2 of the first byte of the

primary opcode.

Table B-11. Encoding of Operation Direction (d) Bit

Source

Destination

reg Field

ModR/M or SIB Byte

reg Field

B.1.5

Other Notes

Table B-12 contains notes on particular encodings. These notes are indicated in the tables shown in the following

sections by superscripts.

B-6

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Table B-12. Notes on Instruction Encoding

Symbol

Note

A value of 11B in bits 7 and 6 of the ModR/M byte is reserved.

A value of 01B (or 10B) in bits 7 and 6 of the ModR/M byte is reserved.

B.2

GENERAL-PURPOSE INSTRUCTION FORMATS AND ENCODINGS FOR NON-

64-BIT MODES

Table B-13 shows machine instruction formats and encodings for general purpose instructions in non-64-bit

modes.

Table B-13. General Purpose Instruction Formats and Encodings for Non-64-Bit Modes

Instruction and Format

Encoding

AAA - ASCII Adjust after Addition

0011 0111

AAD - ASCII Adjust AX before Division

1101 0101 : 0000 1010

AAM - ASCII Adjust AX after Multiply

1101 0100 : 0000 1010

AAS - ASCII Adjust AL after Subtraction

0011 1111

ADC - ADD with Carry

register1 to register2

0001 000w : 11 reg1 reg2

register2 to register1

0001 001w : 11 reg1 reg2

memory to register

0001 001w : mod reg r/m

0001 000w : mod reg r/m

immediate to register

1000 00sw : 11 010 reg : immediate data

immediate to AL, AX, or EAX

0001 010w : immediate data

immediate to memory

1000 00sw : mod 010 r/m : immediate data

ADD - Add

register1 to register2

0000 000w : 11 reg1 reg2

register2 to register1

0000 001w : 11 reg1 reg2

memory to register

0000 001w : mod reg r/m

0000 000w : mod reg r/m

immediate to register

1000 00sw : 11 000 reg : immediate data

immediate to AL, AX, or EAX

0000 010w : immediate data

immediate to memory

1000 00sw : mod 000 r/m : immediate data

AND - Logical AND

register1 to register2

0010 000w : 11 reg1 reg2

register2 to register1

0010 001w : 11 reg1 reg2

memory to register

0010 001w : mod reg r/m

0010 000w : mod reg r/m

immediate to register

1000 00sw : 11 100 reg : immediate data

immediate to AL, AX, or EAX

0010 010w : immediate data

immediate to memory

1000 00sw : mod 100 r/m : immediate data

Vol. 2D B-7

INSTRUCTION FORMATS AND ENCODINGS

Table B-13. General Purpose Instruction Formats and Encodings for Non-64-Bit Modes (Contd.)

Instruction and Format

Encoding

ARPL - Adjust RPL Field of Selector

from register

0110 0011 : 11 reg1 reg2

from memory

0110 0011 : mod reg r/m

BOUND - Check Array Against Bounds

0110 0010 : mod^A reg r/m

BSF - Bit Scan Forward

register1, register2

0000 1111 : 1011 1100 : 11 reg1 reg2

memory, register

0000 1111 : 1011 1100 : mod reg r/m

BSR - Bit Scan Reverse

register1, register2

0000 1111 : 1011 1101 : 11 reg1 reg2

memory, register

0000 1111 : 1011 1101 : mod reg r/m

BSWAP - Byte Swap

0000 1111 : 1100 1 reg

BT - Bit Test

0000 1111 : 1011 1010 : 11 100 reg: imm8 data

memory, immediate

0000 1111 : 1011 1010 : mod 100 r/m : imm8 data

register1, register2

0000 1111 : 1010 0011 : 11 reg2 reg1

memory, reg

0000 1111 : 1010 0011 : mod reg r/m

BTC - Bit Test and Complement

0000 1111 : 1011 1010 : 11 111 reg: imm8 data

memory, immediate

0000 1111 : 1011 1010 : mod 111 r/m : imm8 data

register1, register2

0000 1111 : 1011 1011 : 11 reg2 reg1

memory, reg

0000 1111 : 1011 1011 : mod reg r/m

BTR - Bit Test and Reset

0000 1111 : 1011 1010 : 11 110 reg: imm8 data

memory, immediate

0000 1111 : 1011 1010 : mod 110 r/m : imm8 data

register1, register2

0000 1111 : 1011 0011 : 11 reg2 reg1

memory, reg

0000 1111 : 1011 0011 : mod reg r/m

BTS - Bit Test and Set

0000 1111 : 1011 1010 : 11 101 reg: imm8 data

memory, immediate

0000 1111 : 1011 1010 : mod 101 r/m : imm8 data

register1, register2

0000 1111 : 1010 1011 : 11 reg2 reg1

memory, reg

0000 1111 : 1010 1011 : mod reg r/m

CALL - Call Procedure (in same segment)

direct

1110 1000 : full displacement

1111 1111 : 11 010 reg

memory indirect

1111 1111 : mod 010 r/m

CALL - Call Procedure (in other segment)

direct

1001 1010 : unsigned full offset, selector

indirect

1111 1111 : mod 011 r/m

B-8

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Table B-13. General Purpose Instruction Formats and Encodings for Non-64-Bit Modes (Contd.)

Instruction and Format

Encoding

CBW - Convert Byte to Word

1001 1000

CDQ - Convert Doubleword to Qword

1001 1001

CLC - Clear Carry Flag

1111 1000

CLD - Clear Direction Flag

1111 1100

CLI - Clear Interrupt Flag

1111 1010

CLTS - Clear Task-Switched Flag in CR0

0000 1111 : 0000 0110

CMC - Complement Carry Flag

1111 0101

CMP - Compare Two Operands

register1 with register2

0011 100w : 11 reg1 reg2

register2 with register1

0011 101w : 11 reg1 reg2

memory with register

0011 100w : mod reg r/m

0011 101w : mod reg r/m

immediate with register

1000 00sw : 11 111 reg : immediate data

immediate with AL, AX, or EAX

0011 110w : immediate data

immediate with memory

1000 00sw : mod 111 r/m : immediate data

CMPS/CMPSB/CMPSW/CMPSD - Compare String Operands

1010 011w

CMPXCHG - Compare and Exchange

register1, register2

0000 1111 : 1011 000w : 11 reg2 reg1

memory, register

0000 1111 : 1011 000w : mod reg r/m

CPUID - CPU Identification

0000 1111 : 1010 0010

CWD - Convert Word to Doubleword

1001 1001

CWDE - Convert Word to Doubleword

1001 1000

DAA - Decimal Adjust AL after Addition

0010 0111

DAS - Decimal Adjust AL after Subtraction

0010 1111

DEC - Decrement by 1

1111 111w : 11 001 reg

0100 1 reg

memory

1111 111w : mod 001 r/m

DIV - Unsigned Divide

AL, AX, or EAX by register

1111 011w : 11 110 reg

AL, AX, or EAX by memory

1111 011w : mod 110 r/m

HLT - Halt

1111 0100

IDIV - Signed Divide

AL, AX, or EAX by register

1111 011w : 11 111 reg

AL, AX, or EAX by memory

1111 011w : mod 111 r/m

Vol. 2D B-9

INSTRUCTION FORMATS AND ENCODINGS

Table B-13. General Purpose Instruction Formats and Encodings for Non-64-Bit Modes (Contd.)

Instruction and Format

Encoding

IMUL - Signed Multiply

AL, AX, or EAX with register

1111 011w : 11 101 reg

AL, AX, or EAX with memory

1111 011w : mod 101 reg

register1 with register2

0000 1111 : 1010 1111 : 11 : reg1 reg2

0000 1111 : 1010 1111 : mod reg r/m

register1 with immediate to register2

0110 10s1 : 11 reg1 reg2 : immediate data

memory with immediate to register

0110 10s1 : mod reg r/m : immediate data

IN - Input From Port

fixed port

1110 010w : port number

variable port

1110 110w

INC - Increment by 1

reg

1111 111w : 11 000 reg

reg (alternate encoding)

0100 0 reg

memory

1111 111w : mod 000 r/m

INS - Input from DX Port

0110 110w

INT n - Interrupt Type n

1100 1101 : type

INT - Single-Step Interrupt 3

1100 1100

INTO - Interrupt 4 on Overflow

1100 1110

INVD - Invalidate Cache

0000 1111 : 0000 1000

INVLPG - Invalidate TLB Entry

0000 1111 : 0000 0001 : mod 111 r/m

INVPCID - Invalidate Process-Context Identifier

0110 0110:0000 1111:0011 1000:1000 0010: mod reg r/m

IRET/IRETD - Interrupt Return

1100 1111

Jcc - Jump if Condition is Met

8-bit displacement

0111 tttn : 8-bit displacement

full displacement

0000 1111 : 1000 tttn : full displacement

JCXZ/JECXZ - Jump on CX/ECX Zero

Address-size prefix differentiates JCXZ

1110 0011 : 8-bit displacement

and JECXZ

JMP - Unconditional Jump (to same segment)

short

1110 1011 : 8-bit displacement

direct

1110 1001 : full displacement

1111 1111 : 11 100 reg

memory indirect

1111 1111 : mod 100 r/m

JMP - Unconditional Jump (to other segment)

direct intersegment

1110 1010 : unsigned full offset, selector

indirect intersegment

1111 1111 : mod 101 r/m

LAHF - Load Flags into AHRegister

1001 1111

B-10

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Table B-13. General Purpose Instruction Formats and Encodings for Non-64-Bit Modes (Contd.)

Instruction and Format

Encoding

LAR - Load Access Rights Byte

from register

0000 1111 : 0000 0010 : 11 reg1 reg2

from memory

0000 1111 : 0000 0010 : mod reg r/m

LDS - Load Pointer to DS

1100 0101 : mod^A,B reg r/m

LEA - Load Effective Address

1000 1101 : mod^A reg r/m

LEAVE - High Level Procedure Exit

1100 1001

LES - Load Pointer to ES

1100 0100 : mod^A,B reg r/m

LFS - Load Pointer to FS

0000 1111 : 1011 0100 : mod^A reg r/m

LGDT - Load Global Descriptor Table Register

0000 1111 : 0000 0001 : mod^A 010 r/m

LGS - Load Pointer to GS

0000 1111 : 1011 0101 : mod^A reg r/m

LIDT - Load Interrupt Descriptor Table Register

0000 1111 : 0000 0001 : mod^A 011 r/m

LLDT - Load Local Descriptor Table Register

LDTR from register

0000 1111 : 0000 0000 : 11 010 reg

LDTR from memory

0000 1111 : 0000 0000 : mod 010 r/m

LMSW - Load Machine Status Word

from register

0000 1111 : 0000 0001 : 11 110 reg

from memory

0000 1111 : 0000 0001 : mod 110 r/m

LOCK - Assert LOCK# Signal Prefix

1111 0000

LODS/LODSB/LODSW/LODSD - Load String Operand

1010 110w

LOOP - Loop Count

1110 0010 : 8-bit displacement

LOOPZ/LOOPE - Loop Count while Zero/Equal

1110 0001 : 8-bit displacement

LOOPNZ/LOOPNE - Loop Count while not Zero/Equal

1110 0000 : 8-bit displacement

LSL - Load Segment Limit

from register

0000 1111 : 0000 0011 : 11 reg1 reg2

from memory

0000 1111 : 0000 0011 : mod reg r/m

LSS - Load Pointer to SS

0000 1111 : 1011 0010 : mod^A reg r/m

LTR - Load Task Register

from register

0000 1111 : 0000 0000 : 11 011 reg

from memory

0000 1111 : 0000 0000 : mod 011 r/m

MOV - Move Data

register1 to register2

1000 100w : 11 reg1 reg2

register2 to register1

1000 101w : 11 reg1 reg2

memory to reg

1000 101w : mod reg r/m

reg to memory

1000 100w : mod reg r/m

immediate to register

1100 011w : 11 000 reg : immediate data

immediate to register (alternate encoding)

1011 w reg : immediate data

immediate to memory

1100 011w : mod 000 r/m : immediate data

memory to AL, AX, or EAX

1010 000w : full displacement

Vol. 2D B-11

INSTRUCTION FORMATS AND ENCODINGS

Table B-13. General Purpose Instruction Formats and Encodings for Non-64-Bit Modes (Contd.)

Instruction and Format

Encoding

AL, AX, or EAX to memory

1010 001w : full displacement

MOV - Move to/from Control Registers

CR0 from register

0000 1111 : 0010 0010 : -- 000 reg

CR2 from register

0000 1111 : 0010 0010 : -- 010reg

CR3 from register

0000 1111 : 0010 0010 : -- 011 reg

CR4 from register

0000 1111 : 0010 0010 : -- 100 reg

0000 1111 : 0010 0000 : -- eee reg

MOV - Move to/from Debug Registers

DR0-DR3 from register

0000 1111 : 0010 0011 : -- eee reg

DR4-DR5 from register

0000 1111 : 0010 0011 : -- eee reg

DR6-DR7 from register

0000 1111 : 0010 0011 : -- eee reg

0000 1111 : 0010 0001 : -- eee reg

MOV - Move to/from Segment Registers

1000 1110 : 11 sreg3 reg

memory to segment reg

1000 1110 : mod sreg3 r/m

memory to SS

1000 1110 : mod sreg3 r/m

segment register to register

1000 1100 : 11 sreg3 reg

segment register to memory

1000 1100 : mod sreg3 r/m

MOVBE - Move data after swapping bytes

memory to register

0000 1111 : 0011 1000:1111 0000 : mod reg r/m

0000 1111 : 0011 1000:1111 0001 : mod reg r/m

MOVS/MOVSB/MOVSW/MOVSD - Move Data from String to

1010 010w

String

MOVSX - Move with Sign-Extend

memory to reg

0000 1111 : 1011 111w : mod reg r/m

MOVZX - Move with Zero-Extend

register2 to register1

0000 1111 : 1011 011w : 11 reg1 reg2

memory to register

0000 1111 : 1011 011w : mod reg r/m

MUL - Unsigned Multiply

AL, AX, or EAX with register

1111 011w : 11 100 reg

AL, AX, or EAX with memory

1111 011w : mod 100 r/m

NEG - Two's Complement Negation

1111 011w : 11 011 reg

memory

1111 011w : mod 011 r/m

NOP - No Operation

1001 0000

B-12

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Table B-13. General Purpose Instruction Formats and Encodings for Non-64-Bit Modes (Contd.)

Instruction and Format

Encoding

NOP - Multi-byte No Operation¹

0000 1111 0001 1111 : 11 000 reg

memory

0000 1111 0001 1111 : mod 000 r/m

NOT - One's Complement Negation

1111 011w : 11 010 reg

memory

1111 011w : mod 010 r/m

OR - Logical Inclusive OR

register1 to register2

0000 100w : 11 reg1 reg2

register2 to register1

0000 101w : 11 reg1 reg2

memory to register

0000 101w : mod reg r/m

0000 100w : mod reg r/m

immediate to register

1000 00sw : 11 001 reg : immediate data

immediate to AL, AX, or EAX

0000 110w : immediate data

immediate to memory

1000 00sw : mod 001 r/m : immediate data

OUT - Output to Port

fixed port

1110 011w : port number

variable port

1110 111w

OUTS - Output to DX Port

0110 111w

POP - Pop a Word from the Stack

1000 1111 : 11 000 reg

0101 1 reg

memory

1000 1111 : mod 000 r/m

POP - Pop a Segment Register from the Stack (Note: CS cannot be sreg2 in this usage.)

segment register DS, ES

000 sreg2 111

segment register SS

000 sreg2 111

segment register FS, GS

0000 1111: 10 sreg3 001

POPA/POPAD - Pop All General Registers

0110 0001

POPF/POPFD - Pop Stack into FLAGS or EFLAGS Register

1001 1101

PUSH - Push Operand onto the Stack

1111 1111 : 11 110 reg

0101 0 reg

memory

1111 1111 : mod 110 r/m

immediate

0110 10s0 : immediate data

PUSH - Push Segment Register onto the Stack

segment register CS,DS,ES,SS

000 sreg2 110

segment register FS,GS

0000 1111: 10 sreg3 000

PUSHA/PUSHAD - Push All General Registers

0110 0000

Vol. 2D

B-13

INSTRUCTION FORMATS AND ENCODINGS

Table B-13. General Purpose Instruction Formats and Encodings for Non-64-Bit Modes (Contd.)

Instruction and Format

Encoding

PUSHF/PUSHFD - Push Flags Register onto the Stack

1001 1100

RCL - Rotate thru Carry Left

1101 000w : 11 010 reg

memory by 1

1101 000w : mod 010 r/m

1101 001w : 11 010 reg

memory by CL

1101 001w : mod 010 r/m

1100 000w : 11 010 reg : imm8 data

memory by immediate count

1100 000w : mod 010 r/m : imm8 data

RCR - Rotate thru Carry Right

1101 000w : 11 011 reg

memory by 1

1101 000w : mod 011 r/m

1101 001w : 11 011 reg

memory by CL

1101 001w : mod 011 r/m

1100 000w : 11 011 reg : imm8 data

memory by immediate count

1100 000w : mod 011 r/m : imm8 data

RDMSR - Read from Model-Specific Register

0000 1111 : 0011 0010

RDPMC - Read Performance Monitoring Counters

0000 1111 : 0011 0011

RDTSC - Read Time-Stamp Counter

0000 1111 : 0011 0001

RDTSCP - Read Time-Stamp Counter and Processor ID

0000 1111 : 0000 0001: 1111 1001

REP INS - Input String

1111 0011 : 0110 110w

REP LODS - Load String

1111 0011 : 1010 110w

REP MOVS - Move String

1111 0011 : 1010 010w

REP OUTS - Output String

1111 0011 : 0110 111w

REP STOS - Store String

1111 0011 : 1010 101w

REPE CMPS - Compare String

1111 0011 : 1010 011w

REPE SCAS - Scan String

1111 0011 : 1010 111w

REPNE CMPS - Compare String

1111 0010 : 1010 011w

REPNE SCAS - Scan String

1111 0010 : 1010 111w

RET - Return from Procedure (to same segment)

no argument

1100 0011

adding immediate to SP

1100 0010 : 16-bit displacement

RET - Return from Procedure (to other segment)

intersegment

1100 1011

adding immediate to SP

1100 1010 : 16-bit displacement

B-14

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Table B-13. General Purpose Instruction Formats and Encodings for Non-64-Bit Modes (Contd.)

Instruction and Format

Encoding

ROL - Rotate Left

1101 000w : 11 000 reg

memory by 1

1101 000w : mod 000 r/m

1101 001w : 11 000 reg

memory by CL

1101 001w : mod 000 r/m

1100 000w : 11 000 reg : imm8 data

memory by immediate count

1100 000w : mod 000 r/m : imm8 data

ROR - Rotate Right

1101 000w : 11 001 reg

memory by 1

1101 000w : mod 001 r/m

1101 001w : 11 001 reg

memory by CL

1101 001w : mod 001 r/m

1100 000w : 11 001 reg : imm8 data

memory by immediate count

1100 000w : mod 001 r/m : imm8 data

RSM - Resume from System Management Mode

0000 1111 : 1010 1010

SAHF - Store AH into Flags

1001 1110

SAL - Shift Arithmetic Left

same instruction as SHL

SAR - Shift Arithmetic Right

1101 000w : 11 111 reg

memory by 1

1101 000w : mod 111 r/m

1101 001w : 11 111 reg

memory by CL

1101 001w : mod 111 r/m

1100 000w : 11 111 reg : imm8 data

memory by immediate count

1100 000w : mod 111 r/m : imm8 data

SBB - Integer Subtraction with Borrow

register1 to register2

0001 100w : 11 reg1 reg2

register2 to register1

0001 101w : 11 reg1 reg2

memory to register

0001 101w : mod reg r/m

0001 100w : mod reg r/m

immediate to register

1000 00sw : 11 011 reg : immediate data

immediate to AL, AX, or EAX

0001 110w : immediate data

immediate to memory

1000 00sw : mod 011 r/m : immediate data

SCAS/SCASB/SCASW/SCASD - Scan String

1010 111w

SETcc - Byte Set on Condition

0000 1111 : 1001 tttn : 11 000 reg

memory

0000 1111 : 1001 tttn : mod 000 r/m

SGDT - Store Global Descriptor Table Register

0000 1111 : 0000 0001 : mod^A 000 r/m

Vol. 2D B-15

INSTRUCTION FORMATS AND ENCODINGS

Table B-13. General Purpose Instruction Formats and Encodings for Non-64-Bit Modes (Contd.)

Instruction and Format

Encoding

SHL - Shift Left

1101 000w : 11 100 reg

memory by 1

1101 000w : mod 100 r/m

1101 001w : 11 100 reg

memory by CL

1101 001w : mod 100 r/m

1100 000w : 11 100 reg : imm8 data

memory by immediate count

1100 000w : mod 100 r/m : imm8 data

SHLD - Double Precision Shift Left

0000 1111 : 1010 0100 : 11 reg2 reg1 : imm8

memory by immediate count

0000 1111 : 1010 0100 : mod reg r/m : imm8

0000 1111 : 1010 0101 : 11 reg2 reg1

memory by CL

0000 1111 : 1010 0101 : mod reg r/m

SHR - Shift Right

1101 000w : 11 101 reg

memory by 1

1101 000w : mod 101 r/m

1101 001w : 11 101 reg

memory by CL

1101 001w : mod 101 r/m

1100 000w : 11 101 reg : imm8 data

memory by immediate count

1100 000w : mod 101 r/m : imm8 data

SHRD - Double Precision Shift Right

0000 1111 : 1010 1100 : 11 reg2 reg1 : imm8

memory by immediate count

0000 1111 : 1010 1100 : mod reg r/m : imm8

0000 1111 : 1010 1101 : 11 reg2 reg1

memory by CL

0000 1111 : 1010 1101 : mod reg r/m

SIDT - Store Interrupt Descriptor Table Register

0000 1111 : 0000 0001 : mod^A 001 r/m

SLDT - Store Local Descriptor Table Register

to register

0000 1111 : 0000 0000 : 11 000 reg

to memory

0000 1111 : 0000 0000 : mod 000 r/m

SMSW - Store Machine Status Word

to register

0000 1111 : 0000 0001 : 11 100 reg

to memory

0000 1111 : 0000 0001 : mod 100 r/m

STC - Set Carry Flag

1111 1001

STD - Set Direction Flag

1111 1101

STI - Set Interrupt Flag

1111 1011

STOS/STOSB/STOSW/STOSD - Store String Data

1010 101w

STR - Store Task Register

to register

0000 1111 : 0000 0000 : 11 001 reg

to memory

0000 1111 : 0000 0000 : mod 001 r/m

B-16

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Table B-13. General Purpose Instruction Formats and Encodings for Non-64-Bit Modes (Contd.)

Instruction and Format

Encoding

SUB - Integer Subtraction

register1 to register2

0010 100w : 11 reg1 reg2

register2 to register1

0010 101w : 11 reg1 reg2

memory to register

0010 101w : mod reg r/m

0010 100w : mod reg r/m

immediate to register

1000 00sw : 11 101 reg : immediate data

immediate to AL, AX, or EAX

0010 110w : immediate data

immediate to memory

1000 00sw : mod 101 r/m : immediate data

TEST - Logical Compare

register1 and register2

1000 010w : 11 reg1 reg2

memory and register

1000 010w : mod reg r/m

immediate and register

1111 011w : 11 000 reg : immediate data

immediate and AL, AX, or EAX

1010 100w : immediate data

immediate and memory

1111 011w : mod 000 r/m : immediate data

UD0 - Undefined instruction

0000 1111 : 1111 1111

UD1 - Undefined instruction

0000 1111 : 0000 1011

UD2 - Undefined instruction

0000 FFFF : 0000 1011

VERR - Verify a Segment for Reading

0000 1111 : 0000 0000 : 11 100 reg

memory

0000 1111 : 0000 0000 : mod 100 r/m

VERW - Verify a Segment for Writing

0000 1111 : 0000 0000 : 11 101 reg

memory

0000 1111 : 0000 0000 : mod 101 r/m

WAIT - Wait

1001 1011

WBINVD - Writeback and Invalidate Data Cache

0000 1111 : 0000 1001

WRMSR - Write to Model-Specific Register

0000 1111 : 0011 0000

XADD - Exchange and Add

register1, register2

0000 1111 : 1100 000w : 11 reg2 reg1

memory, reg

0000 1111 : 1100 000w : mod reg r/m

XCHG - Exchange Register/Memory with Register

register1 with register2

1000 011w : 11 reg1 reg2

AX or EAX with reg

1001 0 reg

memory with reg

1000 011w : mod reg r/m

XLAT/XLATB - Table Look-up Translation

1101 0111

XOR - Logical Exclusive OR

register1 to register2

0011 000w : 11 reg1 reg2

register2 to register1

0011 001w : 11 reg1 reg2

memory to register

0011 001w : mod reg r/m

Vol. 2D B-17

INSTRUCTION FORMATS AND ENCODINGS

Table B-13. General Purpose Instruction Formats and Encodings for Non-64-Bit Modes (Contd.)

Instruction and Format

Encoding

0011 000w : mod reg r/m

immediate to register

1000 00sw : 11 110 reg : immediate data

immediate to AL, AX, or EAX

0011 010w : immediate data

immediate to memory

1000 00sw : mod 110 r/m : immediate data

Prefix Bytes

address size

0110 0111

LOCK

1111 0000

operand size

0110 0110

CS segment override

0010 1110

DS segment override

0011 1110

ES segment override

0010 0110

FS segment override

0110 0100

GS segment override

0110 0101

SS segment override

0011 0110

NOTES:

1. The multi-byte NOP instruction does not alter the content of the register and will not issue a memory operation.

B.2.1

General Purpose Instruction Formats and Encodings for 64-Bit Mode

Table B-15 shows machine instruction formats and encodings for general purpose instructions in 64-bit mode.

Table B-14. Special Symbols

Symbol

Application

If the value of REX.W. is 1, it overrides the presence of 66H.

The value of bit W. in REX is has no effect.

Table B-15. General Purpose Instruction Formats and Encodings for 64-Bit Mode

Instruction and Format

Encoding

ADC - ADD with Carry

register1 to register2

0100 0R0B : 0001 000w : 11 reg1 reg2

qwordregister1 to qwordregister2

0100 1R0B : 0001 0001 : 11 qwordreg1 qwordreg2

register2 to register1

0100 0R0B : 0001 001w : 11 reg1 reg2

qwordregister1 to qwordregister2

0100 1R0B : 0001 0011 : 11 qwordreg1 qwordreg2

memory to register

0100 0RXB : 0001 001w : mod reg r/m

memory to qwordregister

0100 1RXB : 0001 0011 : mod qwordreg r/m

0100 0RXB : 0001 000w : mod reg r/m

qwordregister to memory

0100 1RXB : 0001 0001 : mod qwordreg r/m

immediate to register

0100 000B : 1000 00sw : 11 010 reg : immediate

immediate to qwordregister

0100 100B : 1000 0001 : 11 010 qwordreg : imm32

immediate to qwordregister

0100 1R0B : 1000 0011 : 11 010 qwordreg : imm8

B-18

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Table B-15. General Purpose Instruction Formats and Encodings for 64-Bit Mode (Contd.)

Instruction and Format

Encoding

immediate to AL, AX, or EAX

0001 010w : immediate data

immediate to RAX

0100 1000 : 0000 0101 : imm32

immediate to memory

0100 00XB : 1000 00sw : mod 010 r/m : immediate

immediate32 to memory64

0100 10XB : 1000 0001 : mod 010 r/m : imm32

immediate8 to memory64

0100 10XB : 1000 0031 : mod 010 r/m : imm8

ADD - Add

register1 to register2

0100 0R0B : 0000 000w : 11 reg1 reg2

qwordregister1 to qwordregister2

0100 1R0B 0000 0000 : 11 qwordreg1 qwordreg2

register2 to register1

0100 0R0B : 0000 001w : 11 reg1 reg2

qwordregister1 to qwordregister2

0100 1R0B 0000 0010 : 11 qwordreg1 qwordreg2

memory to register

0100 0RXB : 0000 001w : mod reg r/m

memory64 to qwordregister

0100 1RXB : 0000 0000 : mod qwordreg r/m

0100 0RXB : 0000 000w : mod reg r/m

qwordregister to memory64

0100 1RXB : 0000 0011 : mod qwordreg r/m

immediate to register

0100 0000B : 1000 00sw : 11 000 reg : immediate data

immediate32 to qwordregister

0100 100B : 1000 0001 : 11 010 qwordreg : imm

immediate to AL, AX, or EAX

0000 010w : immediate8

immediate to RAX

0100 1000 : 0000 0101 : imm32

immediate to memory

0100 00XB : 1000 00sw : mod 000 r/m : immediate

immediate32 to memory64

0100 10XB : 1000 0001 : mod 010 r/m : imm32

immediate8 to memory64

0100 10XB : 1000 0011 : mod 010 r/m : imm8

AND - Logical AND

register1 to register2

0100 0R0B 0010 000w : 11 reg1 reg2

qwordregister1 to qwordregister2

0100 1R0B 0010 0001 : 11 qwordreg1 qwordreg2

register2 to register1

0100 0R0B 0010 001w : 11 reg1 reg2

register1 to register2

0100 1R0B 0010 0011 : 11 qwordreg1 qwordreg2

memory to register

0100 0RXB 0010 001w : mod reg r/m

memory64 to qwordregister

0100 1RXB : 0010 0011 : mod qwordreg r/m

0100 0RXB : 0010 000w : mod reg r/m

qwordregister to memory64

0100 1RXB : 0010 0001 : mod qwordreg r/m

immediate to register

0100 000B : 1000 00sw : 11 100 reg : immediate

immediate32 to qwordregister

0100 100B 1000 0001 : 11 100 qwordreg : imm32

immediate to AL, AX, or EAX

0010 010w : immediate

immediate32 to RAX

0100 1000 0010 1001 : imm32

immediate to memory

0100 00XB : 1000 00sw : mod 100 r/m : immediate

immediate32 to memory64

0100 10XB : 1000 0001 : mod 100 r/m : immediate32

immediate8 to memory64

0100 10XB : 1000 0011 : mod 100 r/m : imm8

BSF - Bit Scan Forward

Vol. 2D B-19

INSTRUCTION FORMATS AND ENCODINGS

Table B-15. General Purpose Instruction Formats and Encodings for 64-Bit Mode (Contd.)

Instruction and Format

Encoding

register1, register2

0100 0R0B 0000 1111 : 1011 1100 : 11 reg1 reg2

qwordregister1, qwordregister2

0100 1R0B 0000 1111 : 1011 1100 : 11 qwordreg1

qwordreg2

memory, register

0100 0RXB 0000 1111 : 1011 1100 : mod reg r/m

memory64, qwordregister

0100 1RXB 0000 1111 : 1011 1100 : mod qwordreg r/m

BSR - Bit Scan Reverse

register1, register2

0100 0R0B 0000 1111 : 1011 1101 : 11 reg1 reg2

qwordregister1, qwordregister2

0100 1R0B 0000 1111 : 1011 1101 : 11 qwordreg1

qwordreg2

memory, register

0100 0RXB 0000 1111 : 1011 1101 : mod reg r/m

memory64, qwordregister

0100 1RXB 0000 1111 : 1011 1101 : mod qwordreg r/m

BSWAP - Byte Swap

0000 1111 : 1100 1 reg

BSWAP - Byte Swap

0100 100B 0000 1111 : 1100 1 qwordreg

BT - Bit Test

0100 000B 0000 1111 : 1011 1010 : 11 100 reg: imm8

qwordregister, immediate8

0100 100B 1111 : 1011 1010 : 11 100 qwordreg: imm8 data

memory, immediate

0100 00XB 0000 1111 : 1011 1010 : mod 100 r/m : imm8

memory64, immediate8

0100 10XB 0000 1111 : 1011 1010 : mod 100 r/m : imm8 data

register1, register2

0100 0R0B 0000 1111 : 1010 0011 : 11 reg2 reg1

qwordregister1, qwordregister2

0100 1R0B 0000 1111 : 1010 0011 : 11 qwordreg2

qwordreg1

memory, reg

0100 0RXB 0000 1111 : 1010 0011 : mod reg r/m

memory, qwordreg

0100 1RXB 0000 1111 : 1010 0011 : mod qwordreg r/m

BTC - Bit Test and Complement

0100 000B 0000 1111 : 1011 1010 : 11 111 reg: imm8

qwordregister, immediate8

0100 100B 0000 1111 : 1011 1010 : 11 111 qwordreg: imm8

memory, immediate

0100 00XB 0000 1111 : 1011 1010 : mod 111 r/m : imm8

memory64, immediate8

0100 10XB 0000 1111 : 1011 1010 : mod 111 r/m : imm8

register1, register2

0100 0R0B 0000 1111 : 1011 1011 : 11 reg2 reg1

qwordregister1, qwordregister2

0100 1R0B 0000 1111 : 1011 1011 : 11 qwordreg2

qwordreg1

memory, register

0100 0RXB 0000 1111 : 1011 1011 : mod reg r/m

memory, qwordreg

0100 1RXB 0000 1111 : 1011 1011 : mod qwordreg r/m

BTR - Bit Test and Reset

0100 000B 0000 1111 : 1011 1010 : 11 110 reg: imm8

qwordregister, immediate8

0100 100B 0000 1111 : 1011 1010 : 11 110 qwordreg: imm8

memory, immediate

0100 00XB 0000 1111 : 1011 1010 : mod 110 r/m : imm8

memory64, immediate8

0100 10XB 0000 1111 : 1011 1010 : mod 110 r/m : imm8

register1, register2

0100 0R0B 0000 1111 : 1011 0011 : 11 reg2 reg1

B-20

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Table B-15. General Purpose Instruction Formats and Encodings for 64-Bit Mode (Contd.)

Instruction and Format

Encoding

qwordregister1, qwordregister2

0100 1R0B 0000 1111 : 1011 0011 : 11 qwordreg2

qwordreg1

memory, register

0100 0RXB 0000 1111 : 1011 0011 : mod reg r/m

memory64, qwordreg

0100 1RXB 0000 1111 : 1011 0011 : mod qwordreg r/m

BTS - Bit Test and Set

0100 000B 0000 1111 : 1011 1010 : 11 101 reg: imm8

qwordregister, immediate8

0100 100B 0000 1111 : 1011 1010 : 11 101 qwordreg: imm8

memory, immediate

0100 00XB 0000 1111 : 1011 1010 : mod 101 r/m : imm8

memory64, immediate8

0100 10XB 0000 1111 : 1011 1010 : mod 101 r/m : imm8

register1, register2

0100 0R0B 0000 1111 : 1010 1011 : 11 reg2 reg1

qwordregister1, qwordregister2

0100 1R0B 0000 1111 : 1010 1011 : 11 qwordreg2

qwordreg1

memory, register

0100 0RXB 0000 1111 : 1010 1011 : mod reg r/m

memory64, qwordreg

0100 1RXB 0000 1111 : 1010 1011 : mod qwordreg r/m

CALL - Call Procedure (in same segment)

direct

1110 1000 : displacement32

0100 WR00^w 1111 1111 : 11 010 reg

memory indirect

0100 W0XB^w 1111 1111 : mod 010 r/m

CALL - Call Procedure (in other segment)

indirect

1111 1111 : mod 011 r/m

indirect

0100 10XB 0100 1000 1111 1111 : mod 011 r/m

CBW - Convert Byte to Word

1001 1000

CDQ - Convert Doubleword to Qword+

1001 1001

CDQE - RAX, Sign-Extend of EAX

0100 1000 1001 1001

CLC - Clear Carry Flag

1111 1000

CLD - Clear Direction Flag

1111 1100

CLI - Clear Interrupt Flag

1111 1010

CLTS - Clear Task-Switched Flag in CR0

0000 1111 : 0000 0110

CMC - Complement Carry Flag

1111 0101

CMP - Compare Two Operands

register1 with register2

0100 0R0B 0011 100w : 11 reg1 reg2

qwordregister1 with qwordregister2

0100 1R0B 0011 1001 : 11 qwordreg1 qwordreg2

register2 with register1

0100 0R0B 0011 101w : 11 reg1 reg2

qwordregister2 with qwordregister1

0100 1R0B 0011 101w : 11 qwordreg1 qwordreg2

memory with register

0100 0RXB 0011 100w : mod reg r/m

memory64 with qwordregister

0100 1RXB 0011 1001 : mod qwordreg r/m

0100 0RXB 0011 101w : mod reg r/m

qwordregister with memory64

0100 1RXB 0011 101w1 : mod qwordreg r/m

immediate with register

0100 000B 1000 00sw : 11 111 reg : imm

Vol. 2D B-21

INSTRUCTION FORMATS AND ENCODINGS

Table B-15. General Purpose Instruction Formats and Encodings for 64-Bit Mode (Contd.)

Instruction and Format

Encoding

immediate32 with qwordregister

0100 100B 1000 0001 : 11 111 qwordreg : imm64

immediate with AL, AX, or EAX

0011 110w : imm

immediate32 with RAX

0100 1000 0011 1101 : imm32

immediate with memory

0100 00XB 1000 00sw : mod 111 r/m : imm

immediate32 with memory64

0100 1RXB 1000 0001 : mod 111 r/m : imm64

immediate8 with memory64

0100 1RXB 1000 0011 : mod 111 r/m : imm8

CMPS/CMPSB/CMPSW/CMPSD/CMPSQ - Compare String Operands

compare string operands [ X at DS:(E)SI with Y at ES:(E)DI ]

1010 011w

qword at address RSI with qword at address RDI

0100 1000 1010 0111

CMPXCHG - Compare and Exchange

register1, register2

0000 1111 : 1011 000w : 11 reg2 reg1

byteregister1, byteregister2

0100 000B 0000 1111 : 1011 0000 : 11 bytereg2 reg1

qwordregister1, qwordregister2

0100 100B 0000 1111 : 1011 0001 : 11 qwordreg2 reg1

memory, register

0000 1111 : 1011 000w : mod reg r/m

memory8, byteregister

0100 00XB 0000 1111 : 1011 0000 : mod bytereg r/m

memory64, qwordregister

0100 10XB 0000 1111 : 1011 0001 : mod qwordreg r/m

CPUID - CPU Identification

0000 1111 : 1010 0010

CQO - Sign-Extend RAX

0100 1000 1001 1001

CWD - Convert Word to Doubleword

1001 1001

CWDE - Convert Word to Doubleword

1001 1000

DEC - Decrement by 1

0100 000B 1111 111w : 11 001 reg

qwordregister

0100 100B 1111 1111 : 11 001 qwordreg

memory

0100 00XB 1111 111w : mod 001 r/m

memory64

0100 10XB 1111 1111 : mod 001 r/m

DIV - Unsigned Divide

AL, AX, or EAX by register

0100 000B 1111 011w : 11 110 reg

Divide RDX:RAX by qwordregister

0100 100B 1111 0111 : 11 110 qwordreg

AL, AX, or EAX by memory

0100 00XB 1111 011w : mod 110 r/m

Divide RDX:RAX by memory64

0100 10XB 1111 0111 : mod 110 r/m

ENTER - Make Stack Frame for High Level Procedure

1100 1000 : 16-bit displacement : 8-bit level (L)

HLT - Halt

1111 0100

IDIV - Signed Divide

AL, AX, or EAX by register

0100 000B 1111 011w : 11 111 reg

RDX:RAX by qwordregister

0100 100B 1111 0111 : 11 111 qwordreg

AL, AX, or EAX by memory

0100 00XB 1111 011w : mod 111 r/m

RDX:RAX by memory64

0100 10XB 1111 0111 : mod 111 r/m

IMUL - Signed Multiply

B-22

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Table B-15. General Purpose Instruction Formats and Encodings for 64-Bit Mode (Contd.)

Instruction and Format

Encoding

AL, AX, or EAX with register

0100 000B 1111 011w : 11 101 reg

RDX:RAX := RAX with qwordregister

0100 100B 1111 0111 : 11 101 qwordreg

AL, AX, or EAX with memory

0100 00XB 1111 011w : mod 101 r/m

RDX:RAX := RAX with memory64

0100 10XB 1111 0111 : mod 101 r/m

register1 with register2

0000 1111 : 1010 1111 : 11 : reg1 reg2

qwordregister1 := qwordregister1 with qwordregister2

0100 1R0B 0000 1111 : 1010 1111 : 11 : qwordreg1

qwordreg2

0100 0RXB 0000 1111 : 1010 1111 : mod reg r/m

qwordregister := qwordregister with memory64

0100 1RXB 0000 1111 : 1010 1111 : mod qwordreg r/m

register1 with immediate to register2

0100 0R0B 0110 10s1 : 11 reg1 reg2 : imm

qwordregister1 := qwordregister2 with sign-extended

0100 1R0B 0110 1011 : 11 qwordreg1 qwordreg2 : imm8

immediate8

qwordregister1 := qwordregister2 with immediate32

0100 1R0B 0110 1001 : 11 qwordreg1 qwordreg2 : imm32

memory with immediate to register

0100 0RXB 0110 10s1 : mod reg r/m : imm

qwordregister := memory64 with sign-extended immediate8

0100 1RXB 0110 1011 : mod qwordreg r/m : imm8

qwordregister := memory64 with immediate32

0100 1RXB 0110 1001 : mod qwordreg r/m : imm32

IN - Input From Port

fixed port

1110 010w : port number

variable port

1110 110w

INC - Increment by 1

reg

0100 000B 1111 111w : 11 000 reg

qwordreg

0100 100B 1111 1111 : 11 000 qwordreg

memory

0100 00XB 1111 111w : mod 000 r/m

memory64

0100 10XB 1111 1111 : mod 000 r/m

INS - Input from DX Port

0110 110w

INT n - Interrupt Type n

1100 1101 : type

INT - Single-Step Interrupt 3

1100 1100

INTO - Interrupt 4 on Overflow

1100 1110

INVD - Invalidate Cache

0000 1111 : 0000 1000

INVLPG - Invalidate TLB Entry

0000 1111 : 0000 0001 : mod 111 r/m

INVPCID - Invalidate Process-Context Identifier

0110 0110:0000 1111:0011 1000:1000 0010: mod reg r/m

IRETO - Interrupt Return

1100 1111

Jcc - Jump if Condition is Met

8-bit displacement

0111 tttn : 8-bit displacement

displacements (excluding 16-bit relative offsets)

0000 1111 : 1000 tttn : displacement32

JCXZ/JECXZ - Jump on CX/ECX Zero

Address-size prefix differentiates JCXZ and JECXZ

1110 0011 : 8-bit displacement

JMP - Unconditional Jump (to same segment)

short

1110 1011 : 8-bit displacement

Vol. 2D B-23

INSTRUCTION FORMATS AND ENCODINGS

Table B-15. General Purpose Instruction Formats and Encodings for 64-Bit Mode (Contd.)

Instruction and Format

Encoding

direct

1110 1001 : displacement32

0100 W00B^w : 1111 1111 : 11 100 reg

memory indirect

0100 W0XB^w : 1111 1111 : mod 100 r/m

JMP - Unconditional Jump (to other segment)

indirect intersegment

0100 00XB : 1111 1111 : mod 101 r/m

64-bit indirect intersegment

0100 10XB : 1111 1111 : mod 101 r/m

LAR - Load Access Rights Byte

from register

0100 0R0B : 0000 1111 : 0000 0010 : 11 reg1 reg2

from dwordregister to qwordregister, masked by 00FxFF00H

0100 WR0B : 0000 1111 : 0000 0010 : 11 qwordreg1

dwordreg2

from memory

0100 0RXB : 0000 1111 : 0000 0010 : mod reg r/m

from memory32 to qwordregister, masked by 00FxFF00H

0100 WRXB 0000 1111 : 0000 0010 : mod r/m

LEA - Load Effective Address

in wordregister/dwordregister

0100 0RXB : 1000 1101 : mod^A reg r/m

in qwordregister

0100 1RXB : 1000 1101 : mod^A qwordreg r/m

LEAVE - High Level Procedure Exit

1100 1001

LFS - Load Pointer to FS

FS:r16/r32 with far pointer from memory

0100 0RXB : 0000 1111 : 1011 0100 : mod^A reg r/m

FS:r64 with far pointer from memory

0100 1RXB : 0000 1111 : 1011 0100 : mod^A qwordreg r/m

LGDT - Load Global Descriptor Table Register

0100 10XB : 0000 1111 : 0000 0001 : mod^A 010 r/m

LGS - Load Pointer to GS

GS:r16/r32 with far pointer from memory

0100 0RXB : 0000 1111 : 1011 0101 : mod^A reg r/m

GS:r64 with far pointer from memory

0100 1RXB : 0000 1111 : 1011 0101 : mod^A qwordreg r/m

LIDT - Load Interrupt Descriptor Table Register

0100 10XB : 0000 1111 : 0000 0001 : mod^A 011 r/m

LLDT - Load Local Descriptor Table Register

LDTR from register

0100 000B : 0000 1111 : 0000 0000 : 11 010 reg

LDTR from memory

0100 00XB :0000 1111 : 0000 0000 : mod 010 r/m

LMSW - Load Machine Status Word

from register

0100 000B : 0000 1111 : 0000 0001 : 11 110 reg

from memory

0100 00XB :0000 1111 : 0000 0001 : mod 110 r/m

LOCK - Assert LOCK# Signal Prefix

1111 0000

LODS/LODSB/LODSW/LODSD/LODSQ - Load String Operand

at DS:(E)SI to AL/EAX/EAX

1010 110w

at (R)SI to RAX

0100 1000 1010 1101

LOOP - Loop Count

if count ≠ 0, 8-bit displacement

1110 0010

if count ≠ 0, RIP + 8-bit displacement sign-extended to 64-bits

0100 1000 1110 0010

LOOPE - Loop Count while Zero/Equal

B-24

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Table B-15. General Purpose Instruction Formats and Encodings for 64-Bit Mode (Contd.)

Instruction and Format

Encoding

if count ≠ 0 & ZF =1, 8-bit displacement

1110 0001

if count ≠ 0 & ZF = 1, RIP + 8-bit displacement sign-extended to

0100 1000 1110 0001

64-bits

LOOPNE/LOOPNZ - Loop Count while not Zero/Equal

if count ≠ 0 & ZF = 0, 8-bit displacement

1110 0000

if count ≠ 0 & ZF = 0, RIP + 8-bit displacement sign-extended to

0100 1000 1110 0000

64-bits

LSL - Load Segment Limit

from register

0000 1111 : 0000 0011 : 11 reg1 reg2

from qwordregister

0100 1R00 0000 1111 : 0000 0011 : 11 qwordreg1 reg2

from memory16

0000 1111 : 0000 0011 : mod reg r/m

from memory64

0100 1RXB 0000 1111 : 0000 0011 : mod qwordreg r/m

LSS - Load Pointer to SS

SS:r16/r32 with far pointer from memory

0100 0RXB : 0000 1111 : 1011 0010 : mod^A reg r/m

SS:r64 with far pointer from memory

0100 1WXB : 0000 1111 : 1011 0010 : mod^A qwordreg r/m

LTR - Load Task Register

from register

0100 0R00 : 0000 1111 : 0000 0000 : 11 011 reg

from memory

0100 00XB : 0000 1111 : 0000 0000 : mod 011 r/m

MOV - Move Data

register1 to register2

0100 0R0B : 1000 100w : 11 reg1 reg2

qwordregister1 to qwordregister2

0100 1R0B 1000 1001 : 11 qwordeg1 qwordreg2

register2 to register1

0100 0R0B : 1000 101w : 11 reg1 reg2

qwordregister2 to qwordregister1

0100 1R0B 1000 1011 : 11 qwordreg1 qwordreg2

memory to reg

0100 0RXB : 1000 101w : mod reg r/m

memory64 to qwordregister

0100 1RXB 1000 1011 : mod qwordreg r/m

reg to memory

0100 0RXB : 1000 100w : mod reg r/m

qwordregister to memory64

0100 1RXB 1000 1001 : mod qwordreg r/m

immediate to register

0100 000B : 1100 011w : 11 000 reg : imm

immediate32 to qwordregister (zero extend)

0100 100B 1100 0111 : 11 000 qwordreg : imm32

immediate to register (alternate encoding)

0100 000B : 1011 w reg : imm

immediate64 to qwordregister (alternate encoding)

0100 100B 1011 1000 reg : imm64

immediate to memory

0100 00XB : 1100 011w : mod 000 r/m : imm

immediate32 to memory64 (zero extend)

0100 10XB 1100 0111 : mod 000 r/m : imm32

memory to AL, AX, or EAX

0100 0000 : 1010 000w : displacement

memory64 to RAX

0100 1000 1010 0001 : displacement64

AL, AX, or EAX to memory

0100 0000 : 1010 001w : displacement

RAX to memory64

0100 1000 1010 0011 : displacement64

MOV - Move to/from Control Registers

CR0-CR4 from register

0100 0R0B : 0000 1111 : 0010 0010 : 11 eee reg (eee = CR#)

Vol. 2D B-25

INSTRUCTION FORMATS AND ENCODINGS

Table B-15. General Purpose Instruction Formats and Encodings for 64-Bit Mode (Contd.)

Instruction and Format

Encoding

CRx from qwordregister

0100 1R0B : 0000 1111 : 0010 0010 : 11 eee qwordreg (Reee

= CR#)

0100 0R0B : 0000 1111 : 0010 0000 : 11 eee reg (eee = CR#)

qwordregister from CRx

0100 1R0B 0000 1111 : 0010 0000 : 11 eee qwordreg

(Reee = CR#)

MOV - Move to/from Debug Registers

DR0-DR7 from register

0000 1111 : 0010 0011 : 11 eee reg (eee = DR#)

DR0-DR7 from quadregister

0100 10OB 0000 1111 : 0010 0011 : 11 eee reg (eee = DR#)

0000 1111 : 0010 0001 : 11 eee reg (eee = DR#)

quadregister from DR0-DR7

0100 10OB 0000 1111 : 0010 0001 : 11 eee quadreg (eee =

DR#)

MOV - Move to/from Segment Registers

0100 W00B^w : 1000 1110 : 11 sreg reg

0100 000B : 1000 1110 : 11 sreg reg

memory to segment register

0100 00XB : 1000 1110 : mod sreg r/m

memory64 to segment register (lower 16 bits)

0100 10XB 1000 1110 : mod sreg r/m

memory to SS

0100 00XB : 1000 1110 : mod sreg r/m

segment register to register

0100 000B : 1000 1100 : 11 sreg reg

segment register to qwordregister (zero extended)

0100 100B 1000 1100 : 11 sreg qwordreg

segment register to memory

0100 00XB : 1000 1100 : mod sreg r/m

segment register to memory64 (zero extended)

0100 10XB 1000 1100 : mod sreg3 r/m

MOVBE - Move data after swapping bytes

memory to register

0100 0RXB : 0000 1111 : 0011 1000:1111 0000 : mod reg r/m

memory64 to qwordregister

0100 1RXB : 0000 1111 : 0011 1000:1111 0000 : mod reg r/m

0100 0RXB :0000 1111 : 0011 1000:1111 0001 : mod reg r/m

qwordregister to memory64

0100 1RXB :0000 1111 : 0011 1000:1111 0001 : mod reg r/m

MOVS/MOVSB/MOVSW/MOVSD/MOVSQ - Move Data from String to String

Move data from string to string

1010 010w

Move data from string to string (qword)

0100 1000 1010 0101

MOVSX/MOVSXD - Move with Sign-Extend

register2 to register1

0100 0R0B : 0000 1111 : 1011 111w : 11 reg1 reg2

byteregister2 to qwordregister1 (sign-extend)

0100 1R0B 0000 1111 : 1011 1110 : 11 quadreg1 bytereg2

wordregister2 to qwordregister1

0100 1R0B 0000 1111 : 1011 1111 : 11 quadreg1 wordreg2

dwordregister2 to qwordregister1

0100 1R0B 0110 0011 : 11 quadreg1 dwordreg2

memory to register

0100 0RXB : 0000 1111 : 1011 111w : mod reg r/m

memory8 to qwordregister (sign-extend)

0100 1RXB 0000 1111 : 1011 1110 : mod qwordreg r/m

memory16 to qwordregister

0100 1RXB 0000 1111 : 1011 1111 : mod qwordreg r/m

memory32 to qwordregister

0100 1RXB 0110 0011 : mod qwordreg r/m

MOVZX - Move with Zero-Extend

B-26

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Table B-15. General Purpose Instruction Formats and Encodings for 64-Bit Mode (Contd.)

Instruction and Format

Encoding

register2 to register1

0100 0R0B : 0000 1111 : 1011 011w : 11 reg1 reg2

dwordregister2 to qwordregister1

0100 1R0B 0000 1111 : 1011 0111 : 11 qwordreg1

dwordreg2

memory to register

0100 0RXB : 0000 1111 : 1011 011w : mod reg r/m

memory32 to qwordregister

0100 1RXB 0000 1111 : 1011 0111 : mod qwordreg r/m

MUL - Unsigned Multiply

AL, AX, or EAX with register

0100 000B : 1111 011w : 11 100 reg

RAX with qwordregister (to RDX:RAX)

0100 100B 1111 0111 : 11 100 qwordreg

AL, AX, or EAX with memory

0100 00XB 1111 011w : mod 100 r/m

RAX with memory64 (to RDX:RAX)

0100 10XB 1111 0111 : mod 100 r/m

NEG - Two's Complement Negation

0100 000B : 1111 011w : 11 011 reg

qwordregister

0100 100B 1111 0111 : 11 011 qwordreg

memory

0100 00XB : 1111 011w : mod 011 r/m

memory64

0100 10XB 1111 0111 : mod 011 r/m

NOP - No Operation

1001 0000

NOT - One's Complement Negation

0100 000B : 1111 011w : 11 010 reg

qwordregister

0100 000B 1111 0111 : 11 010 qwordreg

memory

0100 00XB : 1111 011w : mod 010 r/m

memory64

0100 1RXB 1111 0111 : mod 010 r/m

OR - Logical Inclusive OR

register1 to register2

0000 100w : 11 reg1 reg2

byteregister1 to byteregister2

0100 0R0B 0000 1000 : 11 bytereg1 bytereg2

qwordregister1 to qwordregister2

0100 1R0B 0000 1001 : 11 qwordreg1 qwordreg2

register2 to register1

0000 101w : 11 reg1 reg2

byteregister2 to byteregister1

0100 0R0B 0000 1010 : 11 bytereg1 bytereg2

qwordregister2 to qwordregister1

0100 0R0B 0000 1011 : 11 qwordreg1 qwordreg2

memory to register

0000 101w : mod reg r/m

memory8 to byteregister

0100 0RXB 0000 1010 : mod bytereg r/m

memory8 to qwordregister

0100 0RXB 0000 1011 : mod qwordreg r/m

0000 100w : mod reg r/m

byteregister to memory8

0100 0RXB 0000 1000 : mod bytereg r/m

qwordregister to memory64

0100 1RXB 0000 1001 : mod qwordreg r/m

immediate to register

1000 00sw : 11 001 reg : imm

immediate8 to byteregister

0100 000B 1000 0000 : 11 001 bytereg : imm8

immediate32 to qwordregister

0100 000B 1000 0001 : 11 001 qwordreg : imm32

immediate8 to qwordregister

0100 000B 1000 0011 : 11 001 qwordreg : imm8

immediate to AL, AX, or EAX

0000 110w : imm

Vol. 2D

B-27

INSTRUCTION FORMATS AND ENCODINGS

Table B-15. General Purpose Instruction Formats and Encodings for 64-Bit Mode (Contd.)

Instruction and Format

Encoding

immediate64 to RAX

0100 1000 0000 1101 : imm64

immediate to memory

1000 00sw : mod 001 r/m : imm

immediate8 to memory8

0100 00XB 1000 0000 : mod 001 r/m : imm8

immediate32 to memory64

0100 00XB 1000 0001 : mod 001 r/m : imm32

immediate8 to memory64

0100 00XB 1000 0011 : mod 001 r/m : imm8

OUT - Output to Port

fixed port

1110 011w : port number

variable port

1110 111w

OUTS - Output to DX Port

output to DX Port

0110 111w

POP - Pop a Value from the Stack

wordregister

0101 0101 : 0100 000B : 1000 1111 : 11 000 reg16

qwordregister

0100 W00B^S : 1000 1111 : 11 000 reg64

wordregister (alternate encoding)

0101 0101 : 0100 000B : 0101 1 reg16

qwordregister (alternate encoding)

0100 W00B : 0101 1 reg64

memory64

0100 W0XB^S : 1000 1111 : mod 000 r/m

memory16

0101 0101 : 0100 00XB 1000 1111 : mod 000 r/m

POP - Pop a Segment Register from the Stack

(Note: CS cannot be sreg2 in this usage.)

segment register FS, GS

0000 1111: 10 sreg3 001

POPF/POPFQ - Pop Stack into FLAGS/RFLAGS Register

pop stack to FLAGS register

0101 0101 : 1001 1101

pop Stack to RFLAGS register

0100 1000 1001 1101

PUSH - Push Operand onto the Stack

wordregister

0101 0101 : 0100 000B : 1111 1111 : 11 110 reg16

qwordregister

0100 W00B^S : 1111 1111 : 11 110 reg64

wordregister (alternate encoding)

0101 0101 : 0100 000B : 0101 0 reg16

qwordregister (alternate encoding)

0100 W00B^S : 0101 0 reg64

memory16

0101 0101 : 0100 000B : 1111 1111 : mod 110 r/m

memory64

0100 W00B^S : 1111 1111 : mod 110 r/m

immediate8

0110 1010 : imm8

immediate16

0101 0101 : 0110 1000 : imm16

immediate64

0110 1000 : imm64

PUSH - Push Segment Register onto the Stack

segment register FS,GS

0000 1111: 10 sreg3 000

PUSHF/PUSHFD - Push Flags Register onto the Stack

1001 1100

RCL - Rotate thru Carry Left

0100 000B : 1101 000w : 11 010 reg

qwordregister by 1

0100 100B 1101 0001 : 11 010 qwordreg

B-28

Vol. 2D
