INSTRUCTION FORMAT

2.3

INTEL® ADVANCED VECTOR EXTENSIONS (INTEL® AVX)

Intel AVX instructions are encoded using an encoding scheme that combines prefix bytes, opcode extension field,

operand encoding fields, and vector length encoding capability into a new prefix, referred to as VEX. In the VEX

encoding scheme, the VEX prefix may be two or three bytes long, depending on the instruction semantics. Despite

the two-byte or three-byte length of the VEX prefix, the VEX encoding format provides a more compact represen-

tation/packing of the components of encoding an instruction in Intel 64 architecture. The VEX encoding scheme

also allows more headroom for future growth of Intel 64 architecture.

2.3.1

Instruction Format

Instruction encoding using VEX prefix provides several advantages:

• Instruction syntax support for three operands and up-to four operands when necessary. For example, the third

source register used by VBLENDVPD is encoded using bits 7:4 of the immediate byte.

• Encoding support for vector length of 128 bits (using XMM registers) and 256 bits (using YMM registers).

• Encoding support for instruction syntax of non-destructive source operands.

• Elimination of escape opcode byte (0FH), SIMD prefix byte (66H, F2H, F3H) via a compact bit field represen-

tation within the VEX prefix.

• Elimination of the need to use REX prefix to encode the extended half of general-purpose register sets (R8-

R15) for direct register access, memory addressing, or accessing XMM8-XMM15 (including YMM8-YMM15).

• Flexible and more compact bit fields are provided in the VEX prefix to retain the full functionality provided by

REX prefix. REX.W, REX.X, REX.B functionalities are provided in the three-byte VEX prefix only because only a

subset of SIMD instructions need them.

• Extensibility for future instruction extensions without significant instruction length increase.

Figure 2-8 shows the Intel 64 instruction encoding format with VEX prefix support. Legacy instruction without a

VEX prefix is fully supported and unchanged. The use of VEX prefix in an Intel 64 instruction is optional, but a VEX

prefix is required for Intel 64 instructions that operate on YMM registers or support three and four operand syntax.

VEX prefix is not a constant-valued, “single-purpose” byte like 0FH, 66H, F2H, F3H in legacy SSE instructions. VEX

prefix provides substantially richer capability than the REX prefix.

# Bytes

2,3

0,1

0,1,2,4

0,1

[Prefixes]

[VEX]

OPCODE

ModR/M

[SIB]

[DISP]

[IMM]

Figure 2-8. Instruction Encoding Format with VEX Prefix

2.3.2

VEX and the LOCK prefix

Any VEX-encoded instruction with a LOCK prefix preceding VEX will #UD.

2.3.3

VEX and the 66H, F2H, and F3H prefixes

Any VEX-encoded instruction with a 66H, F2H, or F3H prefix preceding VEX will #UD.

2.3.4

VEX and the REX prefix

Any VEX-encoded instruction with a REX prefix proceeding VEX will #UD.

Vol. 2A

2-13

INSTRUCTION FORMAT

2.3.5

The VEX Prefix

The VEX prefix is encoded in either the two-byte form (the first byte must be C5H) or in the three-byte form (the

first byte must be C4H). The two-byte VEX is used mainly for 128-bit, scalar, and the most common 256-bit AVX

instructions; while the three-byte VEX provides a compact replacement of REX and 3-byte opcode instructions

(including AVX and FMA instructions). Beyond the first byte of the VEX prefix, it consists of a number of bit fields

providing specific capability, they are shown in Figure 2-9.

The bit fields of the VEX prefix can be summarized by its functional purposes:

•

Non-destructive source register encoding (applicable to three and four operand syntax): This is the first source

operand in the instruction syntax. It is represented by the notation, VEX.vvvv. This field is encoded using 1’s

complement form (inverted form), i.e., XMM0/YMM0/R0 is encoded as 1111B, XMM15/YMM15/R15 is encoded

as 0000B.

•

Vector length encoding: This 1-bit field represented by the notation VEX.L. L= 0 means vector length is 128 bits

wide, L=1 means 256 bit vector. The value of this field is written as VEX.128 or VEX.256 in this document to

distinguish encoded values of other VEX bit fields.

•

REX prefix functionality: Full REX prefix functionality is provided in the three-byte form of VEX prefix. However

the VEX bit fields providing REX functionality are encoded using 1’s complement form, i.e., XMM0/YMM0/R0 is

encoded as 1111B, XMM15/YMM15/R15 is encoded as 0000B.

— Two-byte form of the VEX prefix only provides the equivalent functionality of REX.R, using 1’s complement

encoding. This is represented as VEX.R.

— Three-byte form of the VEX prefix provides REX.R, REX.X, REX.B functionality using 1’s complement

encoding and three dedicated bit fields represented as VEX.R, VEX.X, VEX.B.

— Three-byte form of the VEX prefix provides the functionality of REX.W only to specific instructions that need

to override default 32-bit operand size for a general purpose register to 64-bit size in 64-bit mode. For

those applicable instructions, VEX.W field provides the same functionality as REX.W. VEX.W field can

provide completely different functionality for other instructions.

Consequently, the use of REX prefix with VEX encoded instructions is not allowed. However, the intent of the

REX prefix for expanding register set is reserved for future instruction set extensions using VEX prefix

encoding format.

•

Compaction of SIMD prefix: Legacy SSE instructions effectively use SIMD prefixes (66H, F2H, F3H) as an

opcode extension field. VEX prefix encoding allows the functional capability of such legacy SSE instructions

(operating on XMM registers, bits 255:128 of corresponding YMM unmodified) to be encoded using the VEX.pp

field without the presence of any SIMD prefix. The VEX-encoded 128-bit instruction will zero-out bits 255:128

of the destination register. VEX-encoded instruction may have 128 bit vector length or 256 bits length.

•

Compaction of two-byte and three-byte opcode: More recently introduced legacy SSE instructions employ two

and three-byte opcode. The one or two leading bytes are: 0FH, and 0FH 3AH/0FH 38H. The one-byte escape

(0FH) and two-byte escape (0FH 3AH, 0FH 38H) can also be interpreted as an opcode extension field. The

VEX.mmmmm field provides compaction to allow many legacy instruction to be encoded without the constant

byte sequence, 0FH, 0FH 3AH, 0FH 38H. These VEX-encoded instruction may have 128 bit vector length or 256

bits length.

The VEX prefix is required to be the last prefix and immediately precedes the opcode bytes. It must follow any other

prefixes. If VEX prefix is present a REX prefix is not supported.

The 3-byte VEX leaves room for future expansion with 3 reserved bits. REX and the 66h/F2h/F3h prefixes are

reclaimed for future use.

VEX prefix has a two-byte form and a three byte form. If an instruction syntax can be encoded using the two-byte

form, it can also be encoded using the three byte form of VEX. The latter increases the length of the instruction by

one byte. This may be helpful in some situations for code alignment.

The VEX prefix supports 256-bit versions of floating-point SSE, SSE2, SSE3, and SSE4 instructions. Note, certain

new instruction functionality can only be encoded with the VEX prefix.

The VEX prefix will #UD on any instruction containing MMX register sources or destinations.

2-14

Vol. 2A

INSTRUCTION FORMAT

Byte 0

Byte 1

Byte 2

(Bit Position) 7

3-byte VEX

11000100

R X B

m-mmmm

vvvv

2-byte VEX

11000101

vvvv

R: REX.R in 1’s complement (inverted) form

1: Same as REX.R=0 (must be 1 in 32-bit mode)

0: Same as REX.R=1 (64-bit mode only)

X: REX.X in 1’s complement (inverted) form

1: Same as REX.X=0 (must be 1 in 32-bit mode)

0: Same as REX.X=1 (64-bit mode only)

B: REX.B in 1’s complement (inverted) form

1: Same as REX.B=0 (Ignored in 32-bit mode).

0: Same as REX.B=1 (64-bit mode only)

W: opcode specific (use like REX.W, or used for opcode

extension, or ignored, depending on the opcode byte)

m-mmmm:

00000: Reserved for future use (will #UD)

00001: implied 0F leading opcode byte

00010: implied 0F 38 leading opcode bytes

00011: implied 0F 3A leading opcode bytes

00100-11111: Reserved for future use (will #UD)

vvvv: a register specifier (in 1’s complement form) or 1111 if unused.

L: Vector Length

0: scalar or 128-bit vector

1: 256-bit vector

pp: opcode extension providing equivalent functionality of a SIMD prefix

00: None

01: 66

10: F3

11: F2

Figure 2-9. VEX bit fields

The following subsections describe the various fields in two or three-byte VEX prefix.

2.3.5.1

VEX Byte 0, bits[7:0]

VEX Byte 0, bits [7:0] must contain the value 11000101b (C5h) or 11000100b (C4h). The 3-byte VEX uses the C4h

first byte, while the 2-byte VEX uses the C5h first byte.

2.3.5.2

VEX Byte 1, bit [7] - ‘R’

VEX Byte 1, bit [7] contains a bit analogous to a bit inverted REX.R. In protected and compatibility modes the bit

must be set to ‘1’ otherwise the instruction is LES or LDS.

Vol. 2A

2-15

INSTRUCTION FORMAT

This bit is present in both 2- and 3-byte VEX prefixes.

The usage of WRXB bits for legacy instructions is explained in detail section 2.2.1.2 of Intel 64 and IA-32 Architec-

tures Software developer’s manual, Volume 2A.

This bit is stored in bit inverted format.

2.3.5.3

3-byte VEX byte 1, bit[6] - ‘X’

Bit[6] of the 3-byte VEX byte 1 encodes a bit analogous to a bit inverted REX.X. It is an extension of the SIB Index

field in 64-bit modes. In 32-bit modes, this bit must be set to ‘1’ otherwise the instruction is LES or LDS.

This bit is available only in the 3-byte VEX prefix.

This bit is stored in bit inverted format.

2.3.5.4

3-byte VEX byte 1, bit[5] - ‘B’

Bit[5] of the 3-byte VEX byte 1 encodes a bit analogous to a bit inverted REX.B. In 64-bit modes, it is an extension

of the ModR/M r/m field, or the SIB base field. In 32-bit modes, this bit is ignored.

This bit is available only in the 3-byte VEX prefix.

This bit is stored in bit inverted format.

2.3.5.5

3-byte VEX byte 2, bit[7] - ‘W’

Bit[7] of the 3-byte VEX byte 2 is represented by the notation VEX.W. It can provide following functions, depending

on the specific opcode.

• For AVX instructions that have equivalent legacy SSE instructions (typically these SSE instructions have a

general-purpose register operand with its operand size attribute promotable by REX.W), if REX.W promotes

the operand size attribute of the general-purpose register operand in legacy SSE instruction, VEX.W has same

meaning in the corresponding AVX equivalent form. In 32-bit modes for these instructions, VEX.W is silently

ignored.

• For AVX instructions that have equivalent legacy SSE instructions (typically these SSE instructions have oper-

ands with their operand size attribute fixed and not promotable by REX.W), if REX.W is don’t care in legacy

SSE instruction, VEX.W is ignored in the corresponding AVX equivalent form irrespective of mode.

• For new AVX instructions where VEX.W has no defined function (typically these meant the combination of the

opcode byte and VEX.mmmmm did not have any equivalent SSE functions), VEX.W is reserved as zero and

setting to other than zero will cause instruction to #UD.

2.3.5.6

2-byte VEX Byte 1, bits[6:3] and 3-byte VEX Byte 2, bits [6:3]- ‘vvvv’ the Source or Dest

In 32-bit mode the VEX first byte C4 and C5 alias onto the LES and LDS instructions. To maintain compatibility with

existing programs the VEX 2nd byte, bits [7:6] must be 11b. To achieve this, the VEX payload bits are selected to

place only inverted, 64-bit valid fields (extended register selectors) in these upper bits.

The 2-byte VEX Byte 1, bits [6:3] and the 3-byte VEX, Byte 2, bits [6:3] encode a field (shorthand VEX.vvvv) that

for instructions with 2 or more source registers and an XMM or YMM or memory destination encodes the first source

VEX.vvvv is not used by the instructions with one source (except certain shifts, see below) or on instructions with

no XMM or YMM or memory destination. If an instruction does not use VEX.vvvv then it should be set to 1111b

otherwise instruction will #UD.

In 64-bit mode all 4 bits may be used. See Table 2-8 for the encoding of the XMM or YMM registers. In 32-bit and

16-bit modes bit 6 must be 1 (if bit 6 is not 1, the 2-byte VEX version will generate LDS instruction and the 3-byte

VEX version will ignore this bit).

2-16

Vol. 2A

INSTRUCTION FORMAT

Table 2-8. VEX.vvvv to register name mapping

General-Purpose Register

Valid in Legacy/Compatibility

VEX.vvvv

Dest Register

(If Applicable)¹

32-bit modes?²

1111B

XMM0/YMM0

RAX/EAX

Valid

1110B

XMM1/YMM1

RCX/ECX

Valid

1101B

XMM2/YMM2

RDX/EDX

Valid

1100B

XMM3/YMM3

RBX/EBX

Valid

1011B

XMM4/YMM4

RSP/ESP

Valid

1010B

XMM5/YMM5

RBP/EBP

Valid

1001B

XMM6/YMM6

RSI/ESI

Valid

1000B

XMM7/YMM7

RDI/EDI

Valid

0111B

XMM8/YMM8

R8/R8D

Invalid

0110B

XMM9/YMM9

R9/R9D

Invalid

0101B

XMM10/YMM10

R10/R10D

Invalid

0100B

XMM11/YMM11

R11/R11D

Invalid

0011B

XMM12/YMM12

R12/R12D

Invalid

0010B

XMM13/YMM13

R13/R13D

Invalid

0001B

XMM14/YMM14

R14/R14D

Invalid

0000B

XMM15/YMM15

R15/R15D

Invalid

NOTES:

1. See Section 2.6, “VEX Encoding Support for GPR Instructions” for additional details.

2. Only the first eight General-Purpose Registers are accessible/encodable in 16/32b modes.

The VEX.vvvv field is encoded in bit inverted format for accessing a register operand.

2.3.6

Instruction Operand Encoding and VEX.vvvv, ModR/M

VEX-encoded instructions support three-operand and four-operand instruction syntax. Some VEX-encoded

instructions have syntax with less than three operands, e.g., VEX-encoded pack shift instructions support one

source operand and one destination operand).

The roles of VEX.vvvv, reg field of ModR/M byte (ModR/M.reg), r/m field of ModR/M byte (ModR/M.r/m) with

respect to encoding destination and source operands vary with different type of instruction syntax.

The role of VEX.vvvv can be summarized to three situations:

• VEX.vvvv encodes the first source register operand, specified in inverted (1’s complement) form and is valid for

instructions with 2 or more source operands.

• VEX.vvvv encodes the destination register operand, specified in 1’s complement form for certain vector shifts.

The instructions where VEX.vvvv is used as a destination are listed in Table 2-9. The notation in the “Opcode”

column in Table 2-9 is described in detail in section 3.1.1.

• VEX.vvvv does not encode any operand, the field is reserved and should contain 1111b.

Table 2-9. Instructions with a VEX.vvvv destination

Opcode

Instruction mnemonic

VEX.128.66.0F 73 /7 ib

VPSLLDQ xmm1, xmm2, imm8

VEX.128.66.0F 73 /3 ib

VPSRLDQ xmm1, xmm2, imm8

VEX.128.66.0F 71 /2 ib

VPSRLW xmm1, xmm2, imm8

VEX.128.66.0F 72 /2 ib

VPSRLD xmm1, xmm2, imm8

VEX.128.66.0F 73 /2 ib

VPSRLQ xmm1, xmm2, imm8

VEX.128.66.0F 71 /4 ib

VPSRAW xmm1, xmm2, imm8

Vol. 2A

2-17

INSTRUCTION FORMAT

Opcode

Instruction mnemonic

VEX.128.66.0F 72 /4 ib

VPSRAD xmm1, xmm2, imm8

VEX.128.66.0F 71 /6 ib

VPSLLW xmm1, xmm2, imm8

VEX.128.66.0F 72 /6 ib

VPSLLD xmm1, xmm2, imm8

VEX.128.66.0F 73 /6 ib

VPSLLQ xmm1, xmm2, imm8

The role of ModR/M.r/m field can be summarized to two situations:

• ModR/M.r/m encodes the instruction operand that references a memory address.

• For some instructions that do not support memory addressing semantics, ModR/M.r/m encodes either the

destination register operand or a source register operand.

The role of ModR/M.reg field can be summarized to two situations:

• ModR/M.reg encodes either the destination register operand or a source register operand.

• For some instructions, ModR/M.reg is treated as an opcode extension and not used to encode any instruction

operand.

For instruction syntax that support four operands, VEX.vvvv, ModR/M.r/m, ModR/M.reg encodes three of the four

operands. The role of bits 7:4 of the immediate byte serves the following situation:

• Imm8[7:4] encodes the third source register operand.

2.3.6.1

3-byte VEX byte 1, bits[4:0] - “m-mmmm”

Bits[4:0] of the 3-byte VEX byte 1 encode an implied leading opcode byte (0F, 0F 38, or 0F 3A). Several bits are

reserved for future use and will #UD unless 0.

Table 2-10. VEX.m-mmmm interpretation

VEX.m-mmmm

Implied Leading Opcode Bytes

00000B

Reserved

00001B

00010B

0F 38

00011B

0F 3A

00100-11111B

Reserved

(2-byte VEX)

VEX.m-mmmm is only available on the 3-byte VEX. The 2-byte VEX implies a leading 0Fh opcode byte.

2.3.6.2

2-byte VEX byte 1, bit[2], and 3-byte VEX byte 2, bit [2]- “L”

The vector length field, VEX.L, is encoded in bit[2] of either the second byte of 2-byte VEX, or the third byte of 3-

byte VEX. If “VEX.L = 1”, it indicates 256-bit vector operation. “VEX.L = 0” indicates scalar and 128-bit vector

operations.

The instruction VZEROUPPER is a special case that is encoded with VEX.L = 0, although its operation zero’s bits

255:128 of all YMM registers accessible in the current operating mode.

See the following table.

2-18

Vol. 2A

INSTRUCTION FORMAT

Table 2-11. VEX.L interpretation

VEX.L

Vector Length

128-bit (or 32/64-bit scalar)

256-bit

2.3.6.3

2-byte VEX byte 1, bits[1:0], and 3-byte VEX byte 2, bits [1:0]- “pp”

Up to one implied prefix is encoded by bits[1:0] of either the 2-byte VEX byte 1 or the 3-byte VEX byte 2. The prefix

behaves as if it was encoded prior to VEX, but after all other encoded prefixes.

See the following table.

Table 2-12. VEX.pp interpretation

Implies this prefix after other prefixes but before VEX

00B

None

01B

10B

11B

2.3.7

The Opcode Byte

One (and only one) opcode byte follows the 2 or 3 byte VEX. Legal opcodes are specified in Appendix B, in color.

Any instruction that uses illegal opcode will #UD.

2.3.8

The ModR/M, SIB, and Displacement Bytes

The encodings are unchanged but the interpretation of reg_field or rm_field differs (see above).

2.3.9

The Third Source Operand (Immediate Byte)

VEX-encoded instructions can support instruction with a four operand syntax. VBLENDVPD, VBLENDVPS, and

PBLENDVB use imm8[7:4] to encode one of the source registers.

2.3.10 Intel® AVX Instructions and the Upper 128-bits of YMM registers

If an instruction with a destination XMM register is encoded with a VEX prefix, the processor zeroes the upper bits

(above bit 128) of the equivalent YMM register. Legacy SSE instructions without VEX preserve the upper bits.

2.3.10.1 Vector Length Transition and Programming Considerations

An instruction encoded with a VEX.128 prefix that loads a YMM register operand operates as follows:

• Data is loaded into bits 127:0 of the register

• Bits above bit 127 in the register are cleared.

Thus, such an instruction clears bits 255:128 of a destination YMM register on processors with a maximum vector-

instruction encoded with a VEX.128 or VEX.256 prefix will also clear any bits beyond bit 255. (This is in contrast

with legacy SSE instructions, which have no VEX prefix; these modify only bits 127:0 of any destination register

operand.)

Programmers should bear in mind that instructions encoded with VEX.128 and VEX.256 prefixes will clear any

future extensions to the vector registers. A calling function that uses such extensions should save their state before

calling legacy functions. This is not possible for involuntary calls (e.g., into an interrupt-service routine). It is

recommended that software handling involuntary calls accommodate this by not executing instructions encoded

Vol. 2A

2-19

INSTRUCTION FORMAT

with VEX.128 and VEX.256 prefixes. In the event that it is not possible or desirable to restrict these instructions,

then software must take special care to avoid actions that would, on future processors, zero the upper bits of vector

registers.

Processors that support further vector-register extensions (defining bits beyond bit 255) will also extend the

XSAVE and XRSTOR instructions to save and restore these extensions. To ensure forward compatibility, software

that handles involuntary calls and that uses instructions encoded with VEX.128 and VEX.256 prefixes should first

save and then restore the vector registers (with any extensions) using the XSAVE and XRSTOR instructions with

save/restore masks that set bits that correspond to all vector-register extensions. Ideally, software should rely on

a mechanism that is cognizant of which bits to set. (E.g., an OS mechanism that sets the save/restore mask bits

for all vector-register extensions that are enabled in XCR0.) Saving and restoring state with instructions other than

XSAVE and XRSTOR will, on future processors with wider vector registers, corrupt the extended state of the vector

registers - even if doing so functions correctly on processors supporting 256-bit vector registers. (The same is true

if XSAVE and XRSTOR are used with a save/restore mask that does not set bits corresponding to all supported

extensions to the vector registers.)

2.3.11 Intel® AVX Instruction Length

The Intel AVX instructions described in this document (including VEX and ignoring other prefixes) do not exceed 11

bytes in length, but may increase in the future. The maximum length of an Intel 64 and IA-32 instruction remains

15 bytes.

2.3.12 Vector SIB (VSIB) Memory Addressing

In Intel^® Advanced Vector Extensions 2 (Intel^® AVX2), an SIB byte that follows the ModR/M byte can support VSIB

memory addressing to an array of linear addresses. VSIB addressing is only supported in a subset of Intel AVX2

instructions. VSIB memory addressing requires 32-bit or 64-bit effective address. In 32-bit mode, VSIB addressing

is not supported when address size attribute is overridden to 16 bits. In 16-bit protected mode, VSIB memory

addressing is permitted if address size attribute is overridden to 32 bits. Additionally, VSIB memory addressing is

supported only with VEX prefix.

In VSIB memory addressing, the SIB byte consists of:

• The scale field (bit 7:6) specifies the scale factor.

• The index field (bits 5:3) specifies the register number of the vector index register, each element in the vector

• The base field (bits 2:0) specifies the register number of the base register.

Table 2-3 shows the 32-bit VSIB addressing form. It is organized to give 256 possible values of the SIB byte (in

hexadecimal). General purpose registers used as a base are indicated across the top of the table, along with corre-

sponding values for the SIB byte’s base field. The register names also include R8D-R15D applicable only in 64-bit

mode (when address size override prefix is used, but the value of VEX.B is not shown in Table 2-3). In 32-bit mode,

R8D-R15D does not apply.

Table rows in the body of the table indicate the vector index register used as the index field and each supported

scaling factor shown separately. Vector registers used in the index field can be XMM or YMM registers. The left-

most column includes vector registers VR8-VR15 (i.e., XMM8/YMM8-XMM15/YMM15), which are only available in

64-bit mode and does not apply if encoding in 32-bit mode.

2-20

Vol. 2A

INSTRUCTION FORMAT

Table 2-13. 32-Bit VSIB Addressing Forms of the SIB Byte

r32

EAX/

ECX/

EDX/

EBX/

ESP/

EBP/

ESI/

EDI/

R8D

R9D

R10D

R11D

R12D

R13D¹

R14D

R15D

(In decimal) Base =

(In binary) Base =

000

001

010

011

100

101

110

111

Scaled Index

Index

Value of SIB Byte (in Hexadecimal)

VR0/VR8

000

VR1/VR9

001

VR2/VR10

010

VR3/VR11

011

VR4/VR12

100

VR5/VR13

101

VR6/VR14

110

VR7/VR15

111

VR0/VR8

000

VR1/VR9

001

VR2/VR10

010

VR3/VR11

011

VR4/VR12

100

VR5/VR13

101

VR6/VR14

110

VR7/VR15

111

VR0/VR8

000

VR1/VR9

001

VR2/VR10

010

VR3/VR11

011

VR4/VR12

100

VR5/VR13

101

VR6/VR14

110

VR7/VR15

111

VR0/VR8

000

VR1/VR9

001

VR2/VR10

010

VR3/VR11

011

VR4/VR12

100

VR5/VR13

101

VR6/VR14

110

VR7/VR15

111

NOTES:

1. If ModR/M.mod = 00b, the base address is zero, then effective address is computed as [scaled vector index] + disp32. Otherwise the

base address is computed as [EBP/R13]+ disp, the displacement is either 8 bit or 32 bit depending on the value of ModR/M.mod:

MOD

Effective Address

00b

[Scaled Vector Register] + Disp32

01b

[Scaled Vector Register] + Disp8 + [EBP/R13]

10b

[Scaled Vector Register] + Disp32 + [EBP/R13]

2.3.12.1

64-bit Mode VSIB Memory Addressing

In 64-bit mode VSIB memory addressing uses the VEX.B field and the base field of the SIB byte to encode one of

the 16 general-purpose register as the base register. The VEX.X field and the index field of the SIB byte encode one

of the 16 vector registers as the vector index register.

In 64-bit mode the top row of Table 2-13 base register should be interpreted as the full 64-bit of each register.

2.4

INTEL® ADVANCED MATRIX EXTENSIONS (INTEL® AMX)

Intel^® AMX instructions follow the general documentation convention established in previous sections. Additionally,

Intel^® Advanced Matrix Extensions use notation conventions as described below.

In the instruction encoding boxes, sibmem is used to denote an encoding where a ModR/M byte and SIB byte are

used to indicate a memory operation where the base and displacement are used to point to memory, and the index

Vol. 2A

2-21

INSTRUCTION FORMAT

field as usual. The base register is added to the displacement, if present.

In the instruction encoding, the ModR/M byte is represented several ways depending on the role it plays. The

ModR/M byte has 3 fields: 2-bit ModR/M.mod field, a 3-bit ModR/M.reg field and a 3-bit ModR/M.r/m field. When all

bits of the ModR/M byte have fixed values for an instruction, the 2-hex nibble value of that byte is presented after

the opcode in the encoding boxes on the instruction description pages. When only some fields of the ModR/M byte

must contain fixed values, those values are specified as follows:

• If only the ModR/M.mod must be 0b11, and ModR/M.reg and ModR/M.r/m fields are unrestricted, this is

denoted as 11:rrr:bbb. The rrr correspond to the 3-bits of the ModR/M.reg field and the bbb correspond to the

3-bits of the ModR/M.r/m field.

• If the ModR/M.mod field is constrained to be a value other than 0b11, i.e., it must be one of 0b00, 0b01, or

0b10, then the notation !(11) is used.

• If the ModR/M.reg field had a specific required value, e.g., 0b101, that would be denoted as mm:101:bbb.

NOTE

Historically this document only specified the ModR/M.reg field restrictions with the notation /0 ... /7

and did not specify restrictions on the ModR/M.mod and ModR/M.r/m fields in the encoding boxes.

2.5

INTEL® AVX AND INTEL® SSE INSTRUCTION EXCEPTION SPECIFICATION

To look up the exceptions of legacy 128-bit SIMD instruction, 128-bit VEX-encoded instructions, and 256-bit VEX-

encoded instruction, Table 2-14 summarizes the exception behavior into separate classes, with detailed exception

conditions defined in sub-sections 2.5.1 through 2.6.1. For example, ADDPS contains the entry:

“See Exceptions Type 2”

In this entry, “Type2” can be looked up in Table 2-14.

The instruction’s corresponding CPUID feature flag can be identified in the fourth column of the Instruction

summary table.

Note: #UD on CPUID feature flags=0 is not guaranteed in a virtualized environment if the hardware supports the

feature flag.

NOTE

Instructions that operate only with MMX, X87, or general-purpose registers are not covered by the

exception classes defined in this section. For instructions that operate on MMX registers, see

Section 23.25.3, “Exception Conditions of Legacy SIMD Instructions Operating on MMX Registers”

in the Intel® 64 and IA-32 Architectures Software Developer’s Manual, Volume 3B.

2-22

Vol. 2A

INSTRUCTION FORMAT

Table 2-15. Instructions in each Exception Class

Exception Class

Instruction

Type 1

(V)MOVAPD, (V)MOVAPS, (V)MOVDQA, (V)MOVNTDQ, (V)MOVNTDQA, (V)MOVNTPD, (V)MOVNTPS

(V)ADDPD, (V)ADDPS, (V)ADDSUBPD, (V)ADDSUBPS, (V)CMPPD, (V)CMPPS, (V)CVTDQ2PS, (V)CVTPD2DQ,

(V)CVTPD2PS, (V)CVTPS2DQ, (V)CVTTPD2DQ, (V)CVTTPS2DQ, (V)DIVPD, (V)DIVPS, (V)DPPD*, (V)DPPS*,

VFMADD132PD, VFMADD213PD, VFMADD231PD, VFMADD132PS, VFMADD213PS, VFMADD231PS,

VFMADDSUB132PD, VFMADDSUB213PD, VFMADDSUB231PD, VFMADDSUB132PS, VFMADDSUB213PS,

VFMADDSUB231PS, VFMSUBADD132PD, VFMSUBADD213PD, VFMSUBADD231PD, VFMSUBADD132PS,

Type 2

VFMSUBADD213PS, VFMSUBADD231PS, VFMSUB132PD, VFMSUB213PD, VFMSUB231PD, VFMSUB132PS,

VFMSUB213PS, VFMSUB231PS, VFNMADD132PD, VFNMADD213PD, VFNMADD231PD, VFNMADD132PS,

VFNMADD213PS, VFNMADD231PS, VFNMSUB132PD, VFNMSUB213PD, VFNMSUB231PD, VFNMSUB132PS,

VFNMSUB213PS, VFNMSUB231PS, (V)HADDPD, (V)HADDPS, (V)HSUBPD, (V)HSUBPS, (V)MAXPD, (V)MAXPS,

(V)MINPD, (V)MINPS, (V)MULPD, (V)MULPS, (V)ROUNDPD, (V)ROUNDPS, (V)SQRTPD, (V)SQRTPS, (V)SUBPD,

(V)SUBPS

(V)ADDSD, (V)ADDSS, (V)CMPSD, (V)CMPSS, (V)COMISD, (V)COMISS, (V)CVTPS2PD, (V)CVTSD2SI, (V)CVTSD2SS,

(V)CVTSI2SD, (V)CVTSI2SS, (V)CVTSS2SD, (V)CVTSS2SI, (V)CVTTSD2SI, (V)CVTTSS2SI, (V)DIVSD, (V)DIVSS,

VFMADD132SD, VFMADD213SD, VFMADD231SD, VFMADD132SS, VFMADD213SS, VFMADD231SS,

VFMSUB132SD, VFMSUB213SD, VFMSUB231SD, VFMSUB132SS, VFMSUB213SS, VFMSUB231SS,

Type 3

VFNMADD132SD, VFNMADD213SD, VFNMADD231SD, VFNMADD132SS, VFNMADD213SS, VFNMADD231SS,

VFNMSUB132SD, VFNMSUB213SD, VFNMSUB231SD, VFNMSUB132SS, VFNMSUB213SS, VFNMSUB231SS,

(V)MAXSD, (V)MAXSS, (V)MINSD, (V)MINSS, (V)MULSD, (V)MULSS, (V)ROUNDSD, (V)ROUNDSS, (V)SQRTSD,

(V)SQRTSS, (V)SUBSD, (V)SUBSS, (V)UCOMISD, (V)UCOMISS

(V)AESDEC, (V)AESDECLAST, (V)AESENC, (V)AESENCLAST, (V)AESIMC, (V)AESKEYGENASSIST, (V)ANDPD,

(V)ANDPS, (V)ANDNPD, (V)ANDNPS, (V)BLENDPD, (V)BLENDPS, VBLENDVPD, VBLENDVPS, (V)LDDQU***,

(V)MASKMOVDQU, (V)PTEST, VTESTPS, VTESTPD, (V)MOVDQU*, (V)MOVSHDUP, (V)MOVSLDUP, (V)MOVUPD*,

(V)MOVUPS*, (V)MPSADBW, (V)ORPD, (V)ORPS, (V)PABSB, (V)PABSW, (V)PABSD, (V)PACKSSWB, (V)PACKSSDW,

(V)PACKUSWB, (V)PACKUSDW, (V)PADDB, (V)PADDW, (V)PADDD, (V)PADDQ, (V)PADDSB, (V)PADDSW,

(V)PADDUSB, (V)PADDUSW, (V)PALIGNR, (V)PAND, (V)PANDN, (V)PAVGB, (V)PAVGW, (V)PBLENDVB,

(V)PBLENDW, (V)PCMP(E/I)STRI/M***, (V)PCMPEQB, (V)PCMPEQW, (V)PCMPEQD, (V)PCMPEQQ, (V)PCMPGTB,

(V)PCMPGTW, (V)PCMPGTD, (V)PCMPGTQ, (V)PCLMULQDQ, (V)PHADDW, (V)PHADDD, (V)PHADDSW,

(V)PHMINPOSUW, (V)PHSUBD, (V)PHSUBW, (V)PHSUBSW, (V)PMADDWD, (V)PMADDUBSW, (V)PMAXSB,

Type 4

(V)PMAXSW, (V)PMAXSD, (V)PMAXUB, (V)PMAXUW, (V)PMAXUD, (V)PMINSB, (V)PMINSW, (V)PMINSD,

(V)PMINUB, (V)PMINUW, (V)PMINUD, (V)PMULHUW, (V)PMULHRSW, (V)PMULHW, (V)PMULLW, (V)PMULLD,

(V)PMULUDQ, (V)PMULDQ, (V)POR, (V)PSADBW, (V)PSHUFB, (V)PSHUFD, (V)PSHUFHW, (V)PSHUFLW, (V)PSIGNB,

(V)PSIGNW, (V)PSIGND, (V)PSLLW, (V)PSLLD, (V)PSLLQ, (V)PSRAW, (V)PSRAD, (V)PSRLW, (V)PSRLD, (V)PSRLQ,

(V)PSUBB, (V)PSUBW, (V)PSUBD, (V)PSUBQ, (V)PSUBSB, (V)PSUBSW, (V)PSUBUSB, (V)PSUBUSW,

(V)PUNPCKHBW, (V)PUNPCKHWD, (V)PUNPCKHDQ, (V)PUNPCKHQDQ, (V)PUNPCKLBW, (V)PUNPCKLWD,

(V)PUNPCKLDQ, (V)PUNPCKLQDQ, (V)PXOR, (V)RCPPS, (V)RSQRTPS, (V)SHUFPD, (V)SHUFPS, (V)UNPCKHPD,

(V)UNPCKHPS, (V)UNPCKLPD, (V)UNPCKLPS, (V)XORPD, (V)XORPS, VPBLENDD, VPERMD, VPERMPS, VPERMPD,

VPERMQ, VPSLLVD, VPSLLVQ, VPSRAVD, VPSRLVD, VPSRLVQ, VPERMILPD, VPERMILPS, VPERM2F128

(V)CVTDQ2PD, (V)EXTRACTPS, (V)INSERTPS, (V)MOVD, (V)MOVQ, (V)MOVDDUP, (V)MOVLPD, (V)MOVLPS,

(V)MOVHPD, (V)MOVHPS, (V)MOVSD, (V)MOVSS, (V)PEXTRB, (V)PEXTRD, (V)PEXTRW, (V)PEXTRQ, (V)PINSRB,

Type 5

(V)PINSRD, (V)PINSRW, (V)PINSRQ, PMOVSXBW, (V)RCPSS, (V)RSQRTSS, (V)PMOVSX/ZX, VLDMXCSR*,

VSTMXCSR

VEXTRACTF128/VEXTRACTFxxxx, VBROADCASTSS, VBROADCASTSD, VBROADCASTF128, VINSERTF128,

Type 6

VMASKMOVPS**, VMASKMOVPD**, VPMASKMOVD, VPMASKMOVQ, VBROADCASTI128, VPBROADCASTB,

VPBROADCASTD, VPBROADCASTW, VPBROADCASTQ, VEXTRACTI128, VINSERTI128, VPERM2I128

(V)MOVLHPS, (V)MOVHLPS, (V)MOVMSKPD, (V)MOVMSKPS, (V)PMOVMSKB, (V)PSLLDQ, (V)PSRLDQ, (V)PSLLW,

Type 7

(V)PSLLD, (V)PSLLQ, (V)PSRAW, (V)PSRAD, (V)PSRLW, (V)PSRLD, (V)PSRLQ

Type 8

VZEROALL, VZEROUPPER

Type 11

VCVTPH2PS, VCVTPS2PH

VGATHERDPS, VGATHERDPD, VGATHERQPS, VGATHERQPD, VPGATHERDD, VPGATHERDQ, VPGATHERQD,

Type 12

VPGATHERQQ

(*) - Additional exception restrictions are present - see the Instruction description for details

2-24

Vol. 2A

INSTRUCTION FORMAT

(**) - Instruction behavior on alignment check reporting with mask bits of less than all 1s are the same as with mask bits of all 1s, i.e., no

alignment checks are performed.

(***) - PCMPESTRI, PCMPESTRM, PCMPISTRI, PCMPISTRM, and LDDQU instructions do not cause #GP if the memory operand is not

aligned to 16-Byte boundary.

Table 2-15 classifies exception behaviors for AVX instructions. Within each class of exception conditions that are

listed in Table 2-18 through Table 2-27, certain subsets of AVX instructions may be subject to #UD exception

depending on the encoded value of the VEX.L field. Table 2-17 provides supplemental information of AVX instruc-

tions that may be subject to #UD exception if encoded with incorrect values in the VEX.W or VEX.L field.

Table 2-16. #UD Exception and VEX.W=1 Encoding

#UD If VEX.W = 1 in

Exception Class

#UD If VEX.W = 1 in all modes

non-64-bit modes

Type 1

Type 2

Type 3

VBLENDVPD, VBLENDVPS, VPBLENDVB, VTESTPD, VTESTPS, VPBLENDD, VPERMD,

Type 4

VPERMPS, VPERM2I128, VPSRAVD, VPERMILPD, VPERMILPS, VPERM2F128

Type 5

VEXTRACTF128, VBROADCASTSS, VBROADCASTSD, VBROADCASTF128,

Type 6

VINSERTF128, VMASKMOVPS, VMASKMOVPD, VBROADCASTI128,

VPBROADCASTB/W/D, VEXTRACTI128, VINSERTI128

Type 7

Type 8

Type 11

VCVTPH2PS, VCVTPS2PH

Type 12

Vol. 2A

2-25

INSTRUCTION FORMAT

Table 2-17. #UD Exception and VEX.L Field Encoding

Exception

#UD If (VEX.L = 1 && AVX2 not present && AVX

#UD If (VEX.L = 1 && AVX2

#UD If VEX.L = 0

Class

present)

Type 1

VMOVNTDQA

VDPPD

Type 2

Type 3

VMASKMOVDQU, VMPSADBW, VPABSB/W/D,

VPCMP(E/I)STRI/M,

VPACKSSWB/DW, VPACKUSWB/DW, VPADDB/W/D,

PHMINPOSUW

VPADDQ, VPADDSB/W, VPADDUSB/W, VPALIGNR, VPAND,

VPANDN, VPAVGB/W, VPBLENDVB, VPBLENDW,

VPCMP(E/I)STRI/M, VPCMPEQB/W/D/Q, VPCMPGTB/W/D/Q,

VPHADDW/D, VPHADDSW, VPHMINPOSUW, VPHSUBD/W,

VPHSUBSW, VPMADDWD, VPMADDUBSW, VPMAXSB/W/D,

Type 4

VPMAXUB/W/D, VPMINSB/W/D, VPMINUB/W/D,

VPMULHUW, VPMULHRSW, VPMULHW/LW, VPMULLD,

VPMULUDQ, VPMULDQ, VPOR, VPSADBW, VPSHUFB/D,

VPSHUFHW/LW, VPSIGNB/W/D, VPSLLW/D/Q, VPSRAW/D,

VPSRLW/D/Q, VPSUBB/W/D/Q, VPSUBSB/W,

VPUNPCKHBW/WD/DQ, VPUNPCKHQDQ,

VPUNPCKLBW/WD/DQ, VPUNPCKLQDQ, VPXOR

VEXTRACTPS, VINSERTPS, VMOVD, VMOVQ, VMOVLPD,

Same as column 3

VMOVLPS, VMOVHPD, VMOVHPS, VPEXTRB, VPEXTRD,

Type 5

VPEXTRW, VPEXTRQ, VPINSRB, VPINSRD, VPINSRW,

VPINSRQ, VPMOVSX/ZX, VLDMXCSR, VSTMXCSR

VEXTRACTF128,

VPERM2F128,

Type 6

VBROADCASTSD,

VBROADCASTF128,

VINSERTF128,

VMOVLHPS, VMOVHLPS, VPMOVMSKB, VPSLLDQ,

VMOVLHPS, VMOVHLPS

Type 7

VPSRLDQ, VPSLLW, VPSLLD, VPSLLQ, VPSRAW, VPSRAD,

VPSRLW, VPSRLD, VPSRLQ

Type 8

Type 11

Type 12

2-26

Vol. 2A

INSTRUCTION FORMAT

2.5.1

Exceptions Type 1 (Aligned Memory Reference)

Table 2-18. Type 1 Class Exception Conditions

Exception

Cause of Exception

VEX prefix.

VEX prefix:

If XCR0[2:1] ? ‘11b’.

If CR4.OSXSAVE[bit 18]=0.

Invalid Opcode,

Legacy SSE instruction:

#UD

If CR0.EM[bit 2] = 1.

If CR4.OSFXSR[bit 9] = 0.

If preceded by a LOCK prefix (F0H).

If any REX, F2, F3, or 66 prefixes precede a VEX prefix.

If any corresponding CPUID feature flag is ‘0’.

Device Not Avail-

If CR0.TS[bit 3]=1.

able, #NM

For an illegal address in the SS segment.

Stack, #SS(0)

If a memory address referencing the SS segment is in a non-canonical form.

VEX.256: Memory operand is not 32-byte aligned.

VEX.128: Memory operand is not 16-byte aligned.

Legacy SSE: Memory operand is not 16-byte aligned.

General Protec-

For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-

tion, #GP(0)

ments.

If the memory address is in a non-canonical form.

If any part of the operand lies outside the effective address space from 0 to FFFFH.

Page Fault

For a page fault.

#PF(fault-code)

Vol. 2A

2-27

INSTRUCTION FORMAT

2.5.2

Exceptions Type 2 (>=16 Byte Memory Reference, Unaligned)

Table 2-19. Type 2 Class Exception Conditions

Exception

Cause of Exception

VEX prefix.

If an unmasked SIMD floating-point exception and CR4.OSXMMEXCPT[bit 10] = 0.

VEX prefix:

If XCR0[2:1] ? ‘11b’.

If CR4.OSXSAVE[bit 18]=0.

Invalid Opcode,

Legacy SSE instruction:

#UD

If CR0.EM[bit 2] = 1.

If CR4.OSFXSR[bit 9] = 0.

If preceded by a LOCK prefix (F0H).

If any REX, F2, F3, or 66 prefixes precede a VEX prefix.

If any corresponding CPUID feature flag is ‘0’.

Device Not Avail-

If CR0.TS[bit 3]=1.

able, #NM

For an illegal address in the SS segment.

Stack, #SS(0)

If a memory address referencing the SS segment is in a non-canonical form.

Legacy SSE: Memory operand is not 16-byte aligned.

General Protec-

For an illegal memory operand effective address in the CS, DS, ES, FS or GS segments.

tion, #GP(0)

If the memory address is in a non-canonical form.

If any part of the operand lies outside the effective address space from 0 to FFFFH.

Page Fault

For a page fault.

#PF(fault-code)

SIMD Floating-

point Exception,

If an unmasked SIMD floating-point exception and CR4.OSXMMEXCPT[bit 10] = 1.

#XM

2-28

Vol. 2A

INSTRUCTION FORMAT

2.5.3

Exceptions Type 3 (<16 Byte Memory Argument)

Table 2-20. Type 3 Class Exception Conditions

Exception

Cause of Exception

VEX prefix.

If an unmasked SIMD floating-point exception and CR4.OSXMMEXCPT[bit 10] = 0.

VEX prefix:

If XCR0[2:1] ? ‘11b’.

If CR4.OSXSAVE[bit 18]=0.

Invalid Opcode, #UD

Legacy SSE instruction:

If CR0.EM[bit 2] = 1.

If CR4.OSFXSR[bit 9] = 0.

If preceded by a LOCK prefix (F0H).

If any REX, F2, F3, or 66 prefixes precede a VEX prefix.

If any corresponding CPUID feature flag is ‘0’.

Device Not Available,

If CR0.TS[bit 3]=1.

#NM

For an illegal address in the SS segment.

Stack, #SS(0)

If a memory address referencing the SS segment is in a non-canonical form.

For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-

ments.

General Protection,

If the memory address is in a non-canonical form.

#GP(0)

If any part of the operand lies outside the effective address space from 0 to

FFFFH.

Page Fault

For a page fault.

#PF(fault-code)

Alignment Check

For 2, 4, or 8 byte memory access if alignment checking is enabled and an

#AC(0)

unaligned memory access is made while the current privilege level is 3.

SIMD Floating-point

If an unmasked SIMD floating-point exception and CR4.OSXMMEXCPT[bit 10] = 1.

Exception, #XM

Vol. 2A

2-29

INSTRUCTION FORMAT

2.5.4

Exceptions Type 4 (>=16 Byte Mem Arg, No Alignment, No Floating-point Exceptions)

Table 2-21. Type 4 Class Exception Conditions

Exception

Cause of Exception

VEX prefix.

VEX prefix:

If XCR0[2:1] ? ‘11b’.

If CR4.OSXSAVE[bit 18]=0.

Legacy SSE instruction:

Invalid Opcode, #UD

If CR0.EM[bit 2] = 1.

If CR4.OSFXSR[bit 9] = 0.

If preceded by a LOCK prefix (F0H).

If any REX, F2, F3, or 66 prefixes precede a VEX prefix.

If any corresponding CPUID feature flag is ‘0’.

Device Not Available,

If CR0.TS[bit 3]=1.

#NM

For an illegal address in the SS segment.

Stack, #SS(0)

If a memory address referencing the SS segment is in a non-canonical form.

Legacy SSE: Memory operand is not 16-byte aligned.¹

For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-

General Protection,

ments.

#GP(0)

If the memory address is in a non-canonical form.

If any part of the operand lies outside the effective address space from 0 to

FFFFH.

Page Fault

For a page fault.

#PF(fault-code)

NOTES:

1. LDDQU, MOVUPD, MOVUPS, PCMPESTRI, PCMPESTRM, PCMPISTRI, and PCMPISTRM instructions do not cause #GP if the memory

operand is not aligned to 16-Byte boundary.

2-30

Vol. 2A

INSTRUCTION FORMAT

2.5.5

Exceptions Type 5 (<16 Byte Mem Arg and No FP Exceptions)

Table 2-22. Type 5 Class Exception Conditions

Exception

Cause of Exception

VEX prefix.

VEX prefix:

If XCR0[2:1] ? ‘11b’.

If CR4.OSXSAVE[bit 18]=0.

Legacy SSE instruction:

Invalid Opcode, #UD

If CR0.EM[bit 2] = 1.

If CR4.OSFXSR[bit 9] = 0.

If preceded by a LOCK prefix (F0H).

If any REX, F2, F3, or 66 prefixes precede a VEX prefix.

If any corresponding CPUID feature flag is ‘0’.

Device Not Available,

If CR0.TS[bit 3]=1.

#NM

For an illegal address in the SS segment.

Stack, #SS(0)

If a memory address referencing the SS segment is in a non-canonical form.

For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-

ments.

General Protection,

If the memory address is in a non-canonical form.

#GP(0)

If any part of the operand lies outside the effective address space from 0 to

FFFFH.

Page Fault

For a page fault.

#PF(fault-code)

Alignment Check

For 2, 4, or 8 byte memory access if alignment checking is enabled and an

#AC(0)

unaligned memory access is made while the current privilege level is 3.

Vol. 2A

2-31

INSTRUCTION FORMAT

2.5.6

Exceptions Type 6 (VEX-Encoded Instructions without Legacy SSE Analogues)

Note: At present, the AVX instructions in this category do not generate floating-point exceptions.

Table 2-23. Type 6 Class Exception Conditions

Exception

Cause of Exception

VEX prefix.

If XCR0[2:1] ? ‘11b’.

If CR4.OSXSAVE[bit 18]=0.

Invalid Opcode, #UD

If preceded by a LOCK prefix (F0H).

If any REX, F2, F3, or 66 prefixes precede a VEX prefix.

If any corresponding CPUID feature flag is ‘0’.

Device Not Available,

If CR0.TS[bit 3]=1.

#NM

For an illegal address in the SS segment.

Stack, #SS(0)

If a memory address referencing the SS segment is in a non-canonical form.

For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-

General Protection,

ments.

#GP(0)

If the memory address is in a non-canonical form.

Page Fault

For a page fault.

#PF(fault-code)

Alignment Check

For 2, 4, or 8 byte memory access if alignment checking is enabled and an

#AC(0)

unaligned memory access is made while the current privilege level is 3.

2-32

Vol. 2A

INSTRUCTION FORMAT

2.5.7

Exceptions Type 7 (No FP Exceptions, No Memory Arg)

Table 2-24. Type 7 Class Exception Conditions

Exception

Cause of Exception

VEX prefix.

VEX prefix:

If XCR0[2:1] ? ‘11b’.

If CR4.OSXSAVE[bit 18]=0.

Legacy SSE instruction:

Invalid Opcode, #UD

If CR0.EM[bit 2] = 1.

If CR4.OSFXSR[bit 9] = 0.

If preceded by a LOCK prefix (F0H).

If any REX, F2, F3, or 66 prefixes precede a VEX prefix.

If any corresponding CPUID feature flag is ‘0’.

Device Not Available,

If CR0.TS[bit 3]=1.

#NM

2.5.8

Exceptions Type 8 (AVX and No Memory Argument)

Table 2-25. Type 8 Class Exception Conditions

Exception

Cause of Exception

Invalid Opcode, #UD

Always in Real or Virtual-8086 mode.

If XCR0[2:1] ? ‘11b’.

If CR4.OSXSAVE[bit 18]=0.

If CPUID.01H.ECX.AVX[bit 28]=0.

If VEX.vvvv ? 1111B.

If proceeded by a LOCK prefix (F0H).

Device Not Available,

If CR0.TS[bit 3]=1.

#NM

Vol. 2A

2-33

INSTRUCTION FORMAT

2.5.9

Exceptions Type 11 (VEX-only, Mem Arg, No AC, Floating-point Exceptions)

Table 2-26. Type 11 Class Exception Conditions

Exception

Cause of Exception

Invalid Opcode, #UD

VEX prefix.

VEX prefix:

If XCR0[2:1] ? ‘11b’.

If CR4.OSXSAVE[bit 18]=0.

If preceded by a LOCK prefix (F0H).

If any REX, F2, F3, or 66 prefixes precede a VEX prefix.

If any corresponding CPUID feature flag is ‘0’.

Device Not Avail-

If CR0.TS[bit 3]=1.

able, #NM

Stack, #SS(0)

For an illegal address in the SS segment.

If a memory address referencing the SS segment is in a non-canonical form.

General Protection,

For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-

#GP(0)

ments.

If the memory address is in a non-canonical form.

If any part of the operand lies outside the effective address space from 0 to

FFFFH.

Page Fault #PF

For a page fault.

(fault-code)

SIMD Floating-Point

If an unmasked SIMD floating-point exception and CR4.OSXMMEXCPT[bit 10] = 1.

Exception, #XM

2-34

Vol. 2A

INSTRUCTION FORMAT

2.5.10 Exceptions Type 12 (VEX-only, VSIB Mem Arg, No AC, No Floating-point Exceptions)

Table 2-27. Type 12 Class Exception Conditions

Exception

Cause of Exception

Invalid Opcode, #UD

VEX prefix.

VEX prefix:

If XCR0[2:1] ? ‘11b’.

If CR4.OSXSAVE[bit 18]=0.

If preceded by a LOCK prefix (F0H).

If any REX, F2, F3, or 66 prefixes precede a VEX prefix.

If address size attribute is 16 bit.

If ModR/M.mod = ‘11b’.

If ModR/M.rm ? ‘100b’.

If any corresponding CPUID feature flag is ‘0’.

If any vector register is used more than once between the destination register,

mask register and the index register in VSIB addressing.

Device Not Available,

If CR0.TS[bit 3]=1.

#NM

Stack, #SS(0)

For an illegal address in the SS segment.

If a memory address referencing the SS segment is in a non-canonical form.

General Protection,

For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-

#GP(0)

ments.

If the memory address is in a non-canonical form.

If any part of the operand lies outside the effective address space from 0 to

FFFFH.

Page Fault #PF (fault-

For a page fault.

code)

2.6

VEX ENCODING SUPPORT FOR GPR INSTRUCTIONS

VEX prefix may be used to encode instructions that operate on neither YMM nor XMM registers. VEX-encoded

general-purpose-register instructions have the following properties:

• Instruction syntax support for three encodable operands.

• Encoding support for instruction syntax of non-destructive source operand, destination operand encoded via

VEX.vvvv, and destructive three-operand syntax.

• Elimination of escape opcode byte (0FH), two-byte escape via a compact bit field representation within the VEX

prefix.

• Elimination of the need to use REX prefix to encode the extended half of general-purpose register sets (R8-

R15) for direct register access or memory addressing.

• Flexible and more compact bit fields are provided in the VEX prefix to retain the full functionality provided by

REX prefix. REX.W, REX.X, REX.B functionalities are provided in the three-byte VEX prefix only.

• VEX-encoded GPR instructions are encoded with VEX.L=0.

Vol. 2A

2-35

INSTRUCTION FORMAT

Any VEX-encoded GPR instruction with a 66H, F2H, or F3H prefix preceding VEX will #UD.

Any VEX-encoded GPR instruction with a REX prefix proceeding VEX will #UD.

VEX-encoded GPR instructions are not supported in real and virtual 8086 modes.

2.6.1

Exceptions Type 13 (VEX-Encoded GPR Instructions)

The exception conditions applicable to VEX-encoded GPR instruction differs from those of legacy GPR instructions.

Table 2-28 lists VEX-encoded GPR instructions. The exception conditions for VEX-encoded GRP instructions are

found in Table 2-29 for those instructions which have a default operand size of 32 bits and 16-bit operand size is

not encodable.

Table 2-28. VEX-Encoded GPR Instructions

Exception Class

Instruction

Type 13

ANDN, BEXTR, BLSI, BLSMSK, BLSR, BZHI, MULX, PDEP, PEXT, RORX, SARX, SHLX, SHRX

(*) - Additional exception restrictions are present - see the Instruction description for details.

Table 2-29. Type 13 Class Exception Conditions

Exception

Cause of Exception

Invalid Opcode, #UD

If BMI1/BMI2 CPUID feature flag is ‘0’.

If a VEX prefix is present.

If VEX.L = 1.

If preceded by a LOCK prefix (F0H).

If any REX, F2, F3, or 66 prefixes precede a VEX prefix.

Stack, #SS(0)

For an illegal address in the SS segment.

If a memory address referencing the SS segment is in a non-canonical form.

General Protection,

For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-

#GP(0)

ments.

If the DS, ES, FS, or GS register is used to access memory and it contains a null

segment selector.

If the memory address is in a non-canonical form.

If any part of the operand lies outside the effective address space from 0 to

FFFFH.

Page Fault #PF(fault-

For a page fault.

code)

Alignment Check

For 2, 4, or 8 byte memory access if alignment checking is enabled and an

#AC(0)

unaligned memory access is made while the current privilege level is 3.

2.7

INTEL® AVX-512 ENCODING

The majority of the Intel AVX-512 family of instructions (operating on 512/256/128-bit vector register operands)

are encoded using a new prefix (called EVEX). Opmask instructions (operating on opmask register operands) are

encoded using the VEX prefix. The EVEX prefix has some parts resembling the instruction encoding scheme using

the VEX prefix, and many other capabilities not available with the VEX prefix.

2-36

Vol. 2A

INSTRUCTION FORMAT

The significant feature differences between EVEX and VEX are summarized below.

• EVEX is a 4-Byte prefix (the first byte must be 62H); VEX is either a 2-Byte (C5H is the first byte) or 3-Byte

(C4H is the first byte) prefix.

• EVEX prefix can encode 32 vector registers (XMM/YMM/ZMM) in 64-bit mode.

• EVEX prefix can encode an opmask register for conditional processing or selection control in EVEX-encoded

vector instructions. Opmask instructions, whose source/destination operands are opmask registers and treat

the content of an opmask register as a single value, are encoded using the VEX prefix.

• EVEX memory addressing with disp8 form uses a compressed disp8 encoding scheme to improve the encoding

density of the instruction byte stream.

• EVEX prefix can encode functionality that are specific to instruction classes (e.g., packed instruction with

“load+op” semantic can support embedded broadcast functionality, floating-point instruction with rounding

semantic can support static rounding functionality, floating-point instruction with non-rounding arithmetic

semantic can support “suppress all exceptions” functionality).

2.7.1

Instruction Format and EVEX

The placement of the EVEX prefix in an IA instruction is represented in Figure 2-10. Note that the values contained

within brackets are optional.

# of bytes:

2, 4

[Prefixes]

EVEX

Opcode

ModR/M

[SIB]

[Disp16,32]

[Immediate]

[Disp8*N]

Figure 2-10. AVX-512 Instruction Format and the EVEX Prefix

The EVEX prefix is a 4-byte prefix, with the first two bytes derived from unused encoding form of the 32-bit-mode-

only BOUND instruction. The layout of the EVEX prefix is shown in Figure 2-11. The first byte must be 62H, followed

by three payload bytes, denoted as P0, P1, and P2 individually or collectively as P[23:0] (see Figure 2-11).

EVEX

62H

R’

P[7:0]

P[15:8]

L’

V’

P[23:16]

Figure 2-11. Bit Field Layout of the EVEX Prefix¹

NOTES:

1. See Table 2-30 for additional details on bit fields.

Vol. 2A

2-37

INSTRUCTION FORMAT

Table 2-30. EVEX Prefix Bit Field Functional Grouping

Notation

Bit field Group

Position

Comment

Reserved

P[3 : 2]

Must be 0.

Fixed Value

P[10]

Must be 1.

EVEX.mm

Compressed legacy escape

P[1: 0]

Identical to low two bits of VEX.mmmmm.

EVEX.pp

Compressed legacy prefix

P[9 : 8]

Identical to VEX.pp.

EVEX.RXB

Next-8 register specifier modifier

P[7 : 5]

Combine with ModR/M.reg, ModR/M.rm (base, index/vidx). This

field is encoded in bit inverted format.

EVEX.R’

High-16 register specifier modifier

P[4]

Combine with EVEX.R and ModR/M.reg. This bit is stored in

inverted format.

EVEX.X

High-16 register specifier modifier

P[6]

Combine with EVEX.B and ModR/M.rm, when SIB/VSIB absent.

EVEX.vvvv

VVVV register specifier

P[14 : 11]

Same as VEX.vvvv. This field is encoded in bit inverted format.

EVEX.V’

High-16 VVVV/VIDX register specifier

P[19]

Combine with EVEX.vvvv or when VSIB present. This bit is

stored in inverted format.

EVEX.aaa

Embedded opmask register specifier

P[18 : 16]

EVEX.W

Osize promotion/Opcode extension

P[15]

EVEX.z

Zeroing/Merging

P[23]

EVEX.b

Broadcast/RC/SAE Context

P[20]

EVEX.L’L

Vector length/RC

P[22 : 21]

The bit fields in P[23:0] are divided into the following functional groups (Table 2-30 provides a tabular summary):

•

Reserved bits: P[3:2] must be 0, otherwise #UD.

•

Fixed-value bit: P[10] must be 1, otherwise #UD.

•

Compressed legacy prefix/escape bytes: P[1:0] is identical to the lowest 2 bits of VEX.mmmmm; P[9:8] is

identical to VEX.pp.

•

Operand specifier modifier bits for vector register, general purpose register, memory addressing: P[7:5] allows

access to the next set of 8 registers beyond the low 8 registers when combined with ModR/M register specifiers.

•

Operand specifier modifier bit for vector register: P[4] (or EVEX.R’) allows access to the high 16 vector register

set when combined with P[7] and ModR/M.reg specifier; P[6] can also provide access to a high 16 vector

•

Non-destructive source /vector index operand specifier: P[19] and P[14:11] encode the second source vector

vector register using P[19].

•

Op-mask register specifiers: P[18:16] encodes op-mask register set k0-k7 in instructions operating on vector

registers.

•

EVEX.W: P[15] is similar to VEX.W which serves either as opcode extension bit or operand size promotion to

64-bit in 64-bit mode.

•

Vector destination merging/zeroing: P[23] encodes the destination result behavior which either zeroes the

masked elements or leave masked element unchanged.

•

Broadcast/Static-rounding/SAE context bit: P[20] encodes multiple functionality, which differs across different

classes of instructions and can affect the meaning of the remaining field (EVEX.L’L). The functionality for the

following instruction classes are:

— Broadcasting a single element across the destination vector register: this applies to the instruction class

with Load+Op semantic where one of the source operand is from memory.

— Redirect L’L field (P[22:21]) as static rounding control for floating-point instructions with rounding

semantic. Static rounding control overrides MXCSR.RC field and implies “Suppress all exceptions” (SAE).

2-38

Vol. 2A

INSTRUCTION FORMAT

— Enable SAE for floating -point instructions with arithmetic semantic that is not rounding.

— For instruction classes outside of the afore-mentioned three classes, setting EVEX.b will cause #UD.

• Vector length/rounding control specifier: P[22:21] can serve one of three options.

— Vector length information for packed vector instructions.

— Ignored for instructions operating on vector register content as a single data element.

— Rounding control for floating-point instructions that have a rounding semantic and whose source and

destination operands are all vector registers.

2.7.2

EVEX-encoded instruction can access 8 opmask registers, 16 general-purpose registers and 32 vector registers in

64-bit mode (8 general-purpose registers and 8 vector registers in non-64-bit modes). EVEX-encoding can support

instruction syntax that access up to 4 instruction operands. Normal memory addressing modes and VSIB memory

addressing are supported with EVEX prefix encoding. The mapping of register operands used by various instruction

syntax and memory addressing in 64-bit mode are shown in Table 2-31. Opmask register encoding is described in

Section 2.7.3.

Table 2-31. 32-Register Support in 64-bit Mode Using EVEX with Embedded REX Bits

4¹

[2:0]

Reg. Type

Common Usages

REG

EVEX.R’

REX.R

modrm.reg

GPR, Vector

Destination or Source

VVVV

EVEX.V’

EVEX.vvvv

GPR, Vector

2ndSource or Destination

EVEX.X

EVEX.B

modrm.r/m

GPR, Vector

1st Source or Destination

BASE

EVEX.B

modrm.r/m

GPR

memory addressing

INDEX

EVEX.X

sib.index

GPR

memory addressing

VIDX

EVEX.V’

EVEX.X

sib.index

Vector

VSIB memory addressing

NOTES:

1. Not applicable for accessing general purpose registers.

The mapping of register operands used by various instruction syntax and memory addressing in 32-bit modes are

shown in Table 2-32.

Table 2-32. EVEX Encoding Register Specifiers in 32-bit Mode

[2:0]

Reg. Type

Common Usages

REG

modrm.reg

GPR, Vector

Destination or Source

VVVV

EVEX.vvv

GPR, Vector

2nd Source or Destination

modrm.r/m

GPR, Vector

1st Source or Destination

BASE

modrm.r/m

GPR

Memory Addressing

INDEX

sib.index

GPR

Memory Addressing

VIDX

sib.index

Vector

VSIB Memory Addressing

2.7.3

Opmask Register Encoding

There are eight opmask registers, k0-k7. Opmask register encoding falls into two categories:

• Opmask registers that are the source or destination operands of an instruction treating the content of opmask

Vol. 2A

2-39

INSTRUCTION FORMAT

standard modR/M byte’s reg field and rm field and VEX.vvvv. Such a scalar opmask instruction does not support

conditional update of the destination operand.

• An opmask register providing conditional processing and/or conditional update of the destination register of a

vector instruction is encoded using EVEX.aaa field (see Section 2.7.4).

• An opmask register serving as the destination or source operand of a vector instruction is encoded using

standard modR/M byte’s reg field and rm fields.

Table 2-33. Opmask Register Specifier Encoding

[2:0]

Common Usages

REG

modrm.reg

k0-k7

Source

VVVV

VEX.vvvv

k0-k7

2nd Source

modrm.r/m

k0-7

1st Source

{k1}

EVEX.aaa

k0¹-k7

Opmask

NOTES:

1. Instructions that overwrite the conditional mask in opmask do not permit using k0 as the embedded mask.

2.7.4

Masking Support in EVEX

EVEX can encode an opmask register to conditionally control per-element computational operation and updating of

result of an instruction to the destination operand. The predicate operand is known as the opmask register. The

EVEX.aaa field, P[18:16] of the EVEX prefix, is used to encode one out of a set of eight 64-bit architectural regis-

ters. Note that from this set of 8 architectural registers, only k1 through k7 can be addressed as predicate oper-

ands. k0 can be used as a regular source or destination but cannot be encoded as a predicate operand.

AVX-512 instructions support two types of masking with EVEX.z bit (P[23]) controlling the type of masking:

• Merging-masking, which is the default type of masking for EVEX-encoded vector instructions, preserves the old

value of each element of the destination where the corresponding mask bit has a 0. It corresponds to the case

of EVEX.z = 0.

• Zeroing-masking, is enabled by having the EVEX.z bit set to 1. In this case, an element of the destination is set

to 0 when the corresponding mask bit has a 0 value.

AVX-512 Foundation instructions can be divided into the following groups:

• Instructions which support “zeroing-masking”.

— Also allow merging-masking.

• Instructions which require aaa = 000.

— Do not allow any form of masking.

• Instructions which allow merging-masking but do not allow zeroing-masking.

— Require EVEX.z to be set to 0.

— This group is mostly composed of instructions that write to memory.

• Instructions which require aaa <> 000 do not allow EVEX.z to be set to 1.

— Allow merging-masking and do not allow zeroing-masking, e.g., gather instructions.

2.7.5

Compressed Displacement (disp8*N) Support in EVEX

For memory addressing using disp8 form, EVEX-encoded instructions always use a compressed displacement

scheme by multiplying disp8 in conjunction with a scaling factor N that is determined based on the vector length,

the value of EVEX.b bit (embedded broadcast) and the input element size of the instruction. In general, the factor

N corresponds to the number of bytes characterizing the internal memory operation of the input operand (e.g., 64

when the accessing a full 512-bit memory vector). The scale factor N is listed in Table 2-34 and Table 2-35 below,

2-40

Vol. 2A

INSTRUCTION FORMAT

where EVEX encoded instructions are classified using the tupletype attribute. The scale factor N of each tupletype

is listed based on the vector length (VL) and other factors affecting it.

Table 2-34 covers EVEX-encoded instructions which has a load semantic in conjunction with additional computa-

tional or data element movement operation, operating either on the full vector or half vector (due to conversion of

numerical precision from a wider format to narrower format). EVEX.b is supported for such instructions for data

element sizes which are either dword or qword (see Section 2.7.11).

EVEX-encoded instruction that are pure load/store, and “Load+op” instruction semantic that operate on data

element size less then dword do not support broadcasting using EVEX.b. These are listed in Table 2-35. Table 2-35

also includes many broadcast instructions which perform broadcast using a subset of data elements without using

EVEX.b. These instructions and a few data element size conversion instruction are covered in Table 2-35. Instruc-

tion classified in Table 2-35 do not use EVEX.b and EVEX.b must be 0, otherwise #UD will occur.

The tupletype will be referenced in the instruction operand encoding table in the reference page of each instruction,

providing the cross reference for the scaling factor N to encoding memory addressing operand.

Note that the disp8*N rules still apply when using 16b addressing.

Table 2-34. Compressed Displacement (DISP8*N) Affected by Embedded Broadcast

TupleType

EVEX.b

InputSize

EVEX.W

Broadcast

N (VL=128)

N (VL=256)

N (VL= 512)

Comment

32bit

none

32bit

{1tox}

Load+Op (Full Vector

Full

64bit

none

Dword/Qword)

64bit

{1tox}

32bit

none

Half

Load+Op (Half Vector)

32bit

{1tox}

Table 2-35. EVEX DISP8*N for Instructions Not Affected by Embedded Broadcast

TupleType

InputSize

EVEX.W

N (VL= 128)

N (VL= 256)

N (VL= 512)

Comment

Full Mem

N/A

Load/store or subDword full vector

8bit

N/A

16bit

N/A

Tuple1 Scalar

1Tuple

32bit

64bit

32bit

N/A

1 Tuple, memsize not affected by

Tuple1 Fixed

64bit

N/A

EVEX.W

32bit

Tuple2

Broadcast (2 elements)

64bit

32bit

Tuple4

Broadcast (4 elements)

64bit

Tuple8

32bit

Broadcast (8 elements)

Half Mem

N/A

SubQword Conversion

Quarter Mem

N/A

SubDword Conversion

Eighth Mem

N/A

SubWord Conversion

Mem128

N/A

Shift count from memory

MOVDDUP

N/A

VMOVDDUP

Vol. 2A

2-41

INSTRUCTION FORMAT

2.7.6

EVEX Encoding of Broadcast/Rounding/SAE Support

EVEX.b can provide three types of encoding context, depending on the instruction classes:

• Embedded broadcasting of one data element from a source memory operand to the destination for vector

instructions with “load+op” semantic.

• Static rounding control overriding MXCSR.RC for floating-point instructions with rounding semantic.

•

“Suppress All exceptions” (SAE) overriding MXCSR mask control for floating-point arithmetic instructions that

do not have rounding semantic.

2.7.7

Embedded Broadcast Support in EVEX

EVEX encodes an embedded broadcast functionality that is supported on many vector instructions with 32-bit

(double word or single precision floating-point) and 64-bit data elements, and when the source operand is from

memory. EVEX.b (P[20]) bit is used to enable broadcast on load-op instructions. When enabled, only one element

is loaded from memory and broadcasted to all other elements instead of loading the full memory size.

The following instruction classes do not support embedded broadcasting:

• Instructions with only one scalar result is written to the vector destination.

• Instructions with explicit broadcast functionality provided by its opcode.

• Instruction semantic is a pure load or a pure store operation.

2.7.8

Static Rounding Support in EVEX

Static rounding control embedded in the EVEX encoding system applies only to register-to-register flavor of

floating-point instructions with rounding semantic at two distinct vector lengths: (i) scalar, (ii) 512-bit. In both

cases, the field EVEX.L’L expresses rounding mode control overriding MXCSR.RC if EVEX.b is set. When EVEX.b is

set, “suppress all exceptions” is implied. The processor behaves as if all MXCSR masking controls are set.

2.7.9

SAE Support in EVEX

The EVEX encoding system allows arithmetic floating-point instructions without rounding semantic to be encoded

with the SAE attribute. This capability applies to scalar and 512-bit vector lengths, register-to-register only, by

setting EVEX.b. When EVEX.b is set, “suppress all exceptions” is implied. The processor behaves as if all MXCSR

masking controls are set.

2.7.10 Vector Length Orthogonality

The architecture of EVEX encoding scheme can support SIMD instructions operating at multiple vector lengths.

Many AVX-512 Foundation instructions operate at 512-bit vector length. The vector length of EVEX encoded vector

instructions are generally determined using the L’L field in EVEX prefix, except for 512-bit floating-point, reg-reg

instructions with rounding semantic. The table below shows the vector length corresponding to various values of

the L’L bits. When EVEX is used to encode scalar instructions, L’L is generally ignored.

When EVEX.b bit is set for a register-register instructions with floating-point rounding semantic, the same two bits

P2[6:5] specifies rounding mode for the instruction, with implied SAE behavior. The mapping of different instruc-

tion classes relative to the embedded broadcast/rounding/SAE control and the EVEX.L’L fields are summarized in

Table 2-36.

2-42

Vol. 2A

INSTRUCTION FORMAT

Table 2-36. EVEX Embedded Broadcast/Rounding/SAE and Vector Length on Vector Instructions

Position

P2[4]

P2[6:5]

Broadcast/Rounding/SAE Context

EVEX.b

EVEX.L’L

EVEX.RC

Reg-reg, FP Instructions w/ rounding semantic or SAE

Enable static rounding

Vector length Implied

00b: SAE + RNE

control (SAE implied)

(512 bit or scalar)

01b: SAE + RD

10b: SAE + RU

11b: SAE + RZ

Load+op Instructions w/ memory source

Broadcast Control

00b: 128-bit

01b: 256-bit

Other Instructions (

Must be 0 (otherwise

10b: 512-bit

Explicit Load/Store/Broadcast/Gather/Scatter)

#UD)

11b: Reserved (#UD)

2.7.11

#UD Equations for EVEX

Instructions encoded using EVEX can face three types of UD conditions: state dependent, opcode independent and

opcode dependent.

2.7.11.1 State Dependent #UD

In general, attempts of execute an instruction, which required OS support for incremental extended state compo-

nent, will #UD if required state components were not enabled by OS. Table 2-37 lists instruction categories with

respect to required processor state components. Attempts to execute a given category of instructions while

enabled states were less than the required bit vector in XCR0 shown in Table 2-37 will cause #UD.

Table 2-37. OS XSAVE Enabling Requirements of Instruction Categories

Instruction Categories

Vector Register State Access

Required XCR0 Bit Vector [7:0]

Legacy SIMD prefix encoded Instructions (e.g SSE)

XMM

xxxxxx11b

VEX-encoded instructions operating on YMM

YMM

xxxxx111b

EVEX-encoded 128-bit instructions

ZMM

111xx111b

EVEX-encoded 256-bit instructions

ZMM

111xx111b

EVEX-encoded 512-bit instructions

ZMM

111xx111b

VEX-encoded instructions operating on opmask

k-reg

111xxx11b

2.7.11.2 Opcode Independent #UD

A number of bit fields in EVEX encoded instruction must obey mode-specific but opcode-independent patterns

listed in Table 2-38.

Table 2-38. Opcode Independent, State Dependent EVEX Bit Fields

Position

Notation

64-bit #UD

Non-64-bit #UD

P[3 : 2]

if > 0

P[10]

if 0

P[1: 0]

EVEX.mm

if 00b

P[7 : 6]

EVEX.RX

None (valid)

None (BOUND if EVEX.RX != 11b)

Vol. 2A

2-43

INSTRUCTION FORMAT

2.7.11.3 Opcode Dependent #UD

This section describes legal values for the rest of the EVEX bit fields. Table 2-39 lists the #UD conditions of EVEX

prefix bit fields which encodes or modifies register operands.

Table 2-39. #UD Conditions of Operand-Encoding EVEX Prefix Bit Fields

Notation

Position

Operand Encoding

64-bit #UD

Non-64-bit #UD

EVEX.R

P[7]

ModRM.reg encodes k-reg

If EVEX.R = 0

None (BOUND if

EVEX.RX != 11b)

ModRM.reg is opcode extension

None (ignored)

ModRM.reg encodes all other registers

None (valid)

EVEX.X

P[6]

ModRM.r/m encodes ZMM/YMM/XMM

None (valid)

ModRM.r/m encodes k-reg or GPR

None (ignored)

ModRM.r/m without SIB/VSIB

None (ignored)

ModRM.r/m with SIB/VSIB

None (valid)

EVEX.B

P[5]

ModRM.r/m encodes k-reg

None (ignored)

ModRM.r/m encodes other registers

None (valid)

ModRM.r/m base present

None (valid)

ModRM.r/m base not present

None (ignored)

EVEX.R’

P[4]

ModRM.reg encodes k-reg or GPR

If 0

None (ignored)

ModRM.reg is opcode extension

None (ignored)

ModRM.reg encodes ZMM/YMM/XMM

None (valid)

EVEX.vvvv

P[14 : 11]

vvvv encodes ZMM/YMM/XMM

None (valid)

P[14] ignored

Otherwise

If != 1111b

EVEX.V’

P[19]

Encodes ZMM/YMM/XMM

None (valid)

If 0

Otherwise

If 0

Table 2-40 lists the #UD conditions of instruction encoding of opmask register using EVEX.aaa and EVEX.z

Table 2-40. #UD Conditions of Opmask Related Encoding Field

Notation

Position

Operand Encoding

64-bit #UD

Non-64-bit #UD

EVEX.aaa

P[18 : 16]

Instructions do not use opmask for conditional processing¹.

If aaa != 000b

Opmask used as conditional processing mask and updated

If aaa = 000b

If aaa = 000b;

at completion².

Opmask used as conditional processing.

None (valid³)

None (valid¹)

EVEX.z

P[23]

Vector instruction using opmask as source or destination⁴.

If EVEX.z != 0

Store instructions or gather/scatter instructions.

If EVEX.z != 0

Instructions with EVEX.aaa = 000b.

If EVEX.z != 0

VEX.vvvv

Varies

K-regs are instruction operands not mask control.

If vvvv = 0xxxb

None

NOTES:

1. E.g., VPBROADCASTMxxx, VPMOVM2x, VPMOVx2M.

2. E.g., Gather/Scatter family.

3. aaa can take any value. A value of 000 indicates that there is no masking on the instruction; in this case, all elements will be pro-

cessed as if there was a mask of ‘all ones’ regardless of the actual value in K0.

4. E.g., VFPCLASSPD/PS, VCMPB/D/Q/W family, VPMOVM2x, VPMOVx2M.

2-44

Vol. 2A

INSTRUCTION FORMAT

Table 2-41 lists the #UD conditions of EVEX bit fields that depends on the context of EVEX.b.

Table 2-41. #UD Conditions Dependent on EVEX.b Context

Notation

Position

Operand Encoding

64-bit #UD

Non-64-bit #UD

EVEX.L’Lb

P[22 : 20]

Reg-reg, FP instructions with rounding semantic.

None (valid¹)

Other reg-reg, FP instructions that can cause #XM.

None (valid²)

Other reg-mem instructions in Table 2-34.

None (valid³)

Other instruction classes⁴ in Table 2-35.

If EVEX.b = 1

NOTES:

1. L’L specifies rounding control, see Table 2-36, supports {er} syntax.

2. L’L is ignored.

3. L’L specifies vector length, see Table 2-36, supports embedded broadcast syntax

4. L’L specifies either vector length or ignored.

2.7.12 Device Not Available

EVEX-encoded instructions follow the same rules when it comes to generating #NM (Device Not Available) excep-

tion. In particular, it is generated when CR0.TS[bit 3]= 1.

2.7.13 Scalar Instructions

EVEX-encoded scalar SIMD instructions can access up to 32 registers in 64-bit mode. Scalar instructions support

masking (using the least significant bit of the opmask register), but broadcasting is not supported.

2.8

EXCEPTION CLASSIFICATIONS OF EVEX-ENCODED INSTRUCTIONS

The exception behavior of EVEX-encoded instructions can be classified into the classes shown in the rest of this

section. The classification of EVEX-encoded instructions follow a similar framework as those of AVX and AVX2

instructions using the VEX prefix. Exception types for EVEX-encoded instructions are named in the style of

“E##” or with a suffix “E##XX”. The “##” designation generally follows that of AVX/AVX2 instructions. The

majority of EVEX encoded instruction with “Load+op” semantic supports memory fault suppression, which is repre-

sented by E##. The instructions with “Load+op” semantic but do not support fault suppression are named

“E##NF”. A summary table of exception classes by class names are shown below.

Table 2-42. EVEX-Encoded Instruction Exception Class Summary

Exception Class

Instruction set

Mem arg

(#XM)

Type E1

Vector Moves/Load/Stores

Explicitly aligned, w/ fault suppression

None

Type E1NF

Vector Non-temporal Stores

Explicitly aligned, no fault suppression

None

Type E2

FP Vector Load+op

Support fault suppression

Yes

Type E2NF

FP Vector Load+op

No fault suppression

Yes

Type E3

FP Scalar/Partial Vector, Load+Op

Support fault suppression

Yes

Type E3NF

FP Scalar/Partial Vector, Load+Op

No fault suppression

Yes

Type E4

Integer Vector Load+op

Support fault suppression

Type E4NF

Integer Vector Load+op

No fault suppression

Type E5

Legacy-like Promotion

Varies, Support fault suppression

Type E5NF

Legacy-like Promotion

Varies, No fault suppression

Vol. 2A

2-45

INSTRUCTION FORMAT

Table 2-42. EVEX-Encoded Instruction Exception Class Summary

Exception Class

Instruction set

Mem arg

(#XM)

Type E6

Post AVX Promotion

Varies, w/ fault suppression

Type E6NF

Post AVX Promotion

Varies, no fault suppression

Type E7NM

None

Type E9NF

Miscellaneous 128-bit

Vector-length Specific, no fault suppression

None

Type E10

Non-XF Scalar

Vector Length ignored, w/ fault suppression

None

Type E10NF

Non-XF Scalar

Vector Length ignored, no fault suppression

None

Type E11

VCVTPH2PS, VCVTPS2PH

Half Vector Length, w/ fault suppression

Yes

Type E12

Gather and Scatter Family

VSIB addressing, w/ fault suppression

None

Type E12NP

Gather and Scatter Prefetch Family

VSIB addressing, w/o page fault

None

Table 2-43 lists EVEX-encoded instruction mnemonic by exception classes.

Table 2-43. EVEX Instructions in Each Exception Class

Exception Class

Instruction

Type E1

VMOVAPD, VMOVAPS, VMOVDQA32, VMOVDQA64

Type E1NF

VMOVNTDQ, VMOVNTDQA, VMOVNTPD, VMOVNTPS

VADDPD, VADDPH, VADDPS, VCMPPD, VCMPPH, VCMPPS, VCVTDQ2PH, VCVTDQ2PS, VCVTPD2DQ, VCVTPD2PH,

VCVTPD2PS, VCVTPD2QQ, VCVTPD2UQQ, VCVTPD2UDQ, VCVTPH2DQ, VCVTPH2PD, VCVTPH2QQ, VCVTPH2UDQ,

VCVTPH2UQQ, VCVTPH2UW, VCVTPH2W, VCVTPS2DQ, VCVTPS2UDQS, VCVTQQ2PD, VCVTQQ2PH, VCVTQQ2PS,

VCVTTPD2DQ, VCVTTPD2QQ, VCVTTPD2UDQ, VCVTTPD2UQQ, VCVTTPH2DQ, VCVTTPH2QQ, VCVTTPH2UDQ,

VCVTTPH2UQQ, VCVTTPH2UW, VCVTTPH2W, VCVTTPS2DQ, VCVTTPS2UDQ, VCVTUDQ2PH, VCVTUDQ2PS,

VCVTUQQ2PD, VCVTUQQ2PH, VCVTUQQ2PS, VCVTUW2PH, VCVTW2PH, VDIVPD, VDIVPH, VDIVPS, VEXP2PD,

VEXP2PS, VFIXUPIMMPD, VFIXUPIMMPS, VFMADDxxxPD, VFMADDxxxPH, VFMADDxxxPS, VFMADDSUBxxxPD,

Type E2

VFMADDSUBxxxPH, VFMADDSUBxxxPS, VFMSUBADDxxxPD, VFMSUBADDxxxPH, VFMSUBADDxxxPS,

VFMSUBxxxPD, VFMSUBxxxPH, VFMSUBxxxPS, VFNMADDxxxPD, VFNMADDxxxPH, VFNMADDxxxPS,

VFNMSUBxxxPD, VFNMSUBxxxPH, VFNMSUBxxxPS, VGETEXPPD, VGETEXPPH, VGETEXPPS, VGETMANTPD,

VGETMANTPH, VGETMANTPS, VGETMANTSH, VMAXPD, VMAXPH, VMAXPS, VMINPD, VMINPH, VMINPS, VMULPD,

VMULPH, VMULPS, VRANGEPD, VRANGEPS, VREDUCEPD, VREDUCEPH, VREDUCEPS, VRNDSCALEPD,

VRNDSCALEPH, VRNDSCALEPS, VRCP28PD, VRCP28PS, VRSQRT28PD, VRSQRT28PS, VSCALEFPD, VSCALEFPS,

VSQRTPD, VSQRTPH, VSQRTPS, VSUBPD, VSUBPH, VSUBPS

VADDSD, VADDSH, VADDSS, VCMPSD, VCMPSH, VCMPSS, VCVTPS2QQ, VCVTPS2UQQ, VCVTPS2PD, VCVTSD2SH,

VCVTSD2SS, VCVTSH2SD, VCVTSH2SS, VCVTSS2SD, VCVTSS2SH, VCVTTPS2QQ, VCVTTPS2UQQ, VDIVSD, VDIVSH,

VDIVSS, VFMADDxxxSD, VFMADDxxxSH, VFMADDxxxSS, VFMSUBxxxSD, VFMSUBxxxSH, VFMSUBxxxSS,

VFNMADDxxxSD, VFNMADDxxxSH, VFNMADDxxxSS, VFNMSUBxxxSD, VFNMSUBxxxSH, VFNMSUBxxxSS,

Type E3

VFIXUPIMMSD, VFIXUPIMMSS, VGETEXPSD, VGETEXPSH, VGETEXPSS, VGETMANTSD, VGETMANTSH,

VGETMANTSS, VMAXSD, VMAXSH, VMAXSS, VMINSD, VMINSH, VMINSS, VMULSD, VMULSH, VMULSS, VRANGESD,

VRANGESS, VREDUCESD, VREDUCESH, VREDUCESS, VRNDSCALESD, VRNDSCALESH, VRNDSCALESS, VSCALEFSD,

VSCALEFSH, VSCALEFSS, VRCP28SD, VRCP28SS, VRSQRT28SD, VRSQRT28SS, VSQRTSD, VSQRTSH, VSQRTSS,

VSUBSD, VSUBSH, VSUBSS

VCOMISD, VCOMISH, VCOMISS, VCVTSD2SI, VCVTSD2USI, VCVTSH2SI, VCVTSH2USI, VCVTSI2SD, VCVTSI2SH,

Type E3NF

VCVTSI2SS, VCVTSS2SI, VCVTSS2USI, VCVTTSD2SI, VCVTTSD2USI, VCVTTSH2SI, VCVTTSH2USI, VCVTTSS2SI,

VCVTTSS2USI, VCVTUSI2SD, VCVTUSI2SH, VCVTUSI2SS, VUCOMISD, VUCOMISH, VUCOMISS

2-46

Vol. 2A

INSTRUCTION FORMAT

Table 2-43. EVEX Instructions in Each Exception Class (Contd.)

Exception Class

Instruction

VANDPD, VANDPS, VANDNPD, VANDNPS, VBLENDMPD, VBLENDMPS, VFCMADDCPH, VFCMULCPH, VFMADDCPH,

VFMULCPH, VFPCLASSPD, VFPCLASSPH, VFPCLASSPS, VORPD, VORPS, VPABSD, VPABSQ, VPADDD, VPADDQ,

VPANDD, VPANDQ, VPANDND, VPANDNQ, VPBLENDMB, VPBLENDMD, VPBLENDMQ, VPBLENDMW, VPCMPD,

VPCMPEQD, VPCMPEQQ, VPCMPGTD, VPCMPGTQ, VPCMPQ, VPCMPUD, VPCMPUQ, VPLZCNTD, VPLZCNTQ,

VPMADD52LUQ, VPMADD52HUQ, VPMAXSD, VPMAXSQ, VPMAXUD, VPMAXUQ, VPMINSD, VPMINSQ, VPMINUD,

Type E4

VPMINUQ, VPMULLD, VPMULLQ, VPMULUDQ, VPMULDQ, VPORD, VPORQ, VPROLD, VPROLQ, VPROLVD, VPROLVQ,

VPRORD, VPRORQ, VPRORVD, VPRORVQ, (VPSLLD, VPSLLQ, VPSRAD, VPSRAQ, VPSRAVW, VPSRAVD, VPSRAVW,

VPSRAVQ, VPSRLD, VPSRLQ)¹, VPSUBD, VPSUBQ, VPSUBUSB, VPSUBUSW, VPTERNLOGD, VPTERNLOGQ,

VPTESTMD, VPTESTMQ, VPTESTNMD, VPTESTNMQ, VPXORD, VPXORQ, VPSLLVD, VPSLLVQ, VRCP14PD,

VRCP14PS, VRCPPH, VRSQRT14PD, VRSQRT14PS, VRSQRTPH, VXORPD, VXORPS

VCOMPRESSPD, VCOMPRESSPS, VEXPANDPD, VEXPANDPS, VMOVDQU8, VMOVDQU16, VMOVDQU32,

VMOVDQU64, VMOVUPD, VMOVUPS, VPABSB, VPABSW, VPADDB, VPADDW, VPADDSB, VPADDSW, VPADDUSB,

VPADDUSW, VPAVGB, VPAVGW, VPCMPB, VPCMPEQB, VPCMPEQW, VPCMPGTB, VPCMPGTW, VPCMPW, VPCMPUB,

E4.nb²

VPCMPUW, VPCOMPRESSD, VPCOMPRESSQ, VPEXPANDD, VPEXPANDQ, VPMAXSB, VPMAXSW, VPMAXUB,

VPMAXUW, VPMINSB, VPMINSW, VPMINUB, VPMINUW, VPMULHRSW, VPMULHUW, VPMULHW, VPMULLW,

VPSLLVW, VPSLLW, VPSRAW, VPSRLVW, VPSRLW, VPSUBB, VPSUBW, VPSUBSB, VPSUBSW, VPTESTMB,

VPTESTMW, VPTESTNMB, VPTESTNMW

VALIGND, VALIGNQ, VPACKSSDW, VPACKUSDW, VPCONFLICTD, VPCONFLICTQ, VPERMD, VPERMI2D, VPERMI2PS,

VPERMI2PD, VPERMI2Q, VPERMPD, VPERMPS, VPERMQ, VPERMT2D, VPERMT2PS, VPERMT2Q, VPERMT2PD,

Type E4NF

VPERMILPD, VPERMILPS, VPMULTISHIFTQB, VPSHUFD, VPUNPCKHDQ, VPUNPCKHQDQ, VPUNPCKLDQ,

VPUNPCKLQDQ, VSHUFF32X4, VSHUFF64X2, VSHUFI32X4, VSHUFI64X2, VSHUFPD, VSHUFPS, VUNPCKHPD,

VUNPCKHPS, VUNPCKLPD, VUNPCKLPS

VDBPSADBW, VPACKSSWB, VPACKUSWB, VPALIGNR, VPMADDWD, VPMADDUBSW, VMOVSHDUP, VMOVSLDUP,

VPSADBW, VPSHUFB, VPSHUFHW, VPSHUFLW, VPSLLDQ, VPSRLDQ, VPSLLW, VPSRAW, VPSRLW, (VPSLLD,

E4NF.nb²

VPSLLQ, VPSRAD, VPSRAQ, VPSRLD, VPSRLQ)³, VPUNPCKHBW, VPUNPCKHWD, VPUNPCKLBW, VPUNPCKLWD,

VPERMW, VPERMI2W, VPERMT2W

PMOVSXBW, PMOVSXBW, PMOVSXBD, PMOVSXBQ, PMOVSXWD, PMOVSXWQ, PMOVSXDQ, PMOVZXBW,

Type E5

PMOVZXBD, PMOVZXBQ, PMOVZXWD, PMOVZXWQ, PMOVZXDQ, VCVTDQ2PD, VCVTUDQ2PD, VMOVSH,

VPMOVSXxx, VPMOVZXxx,

Type E5NF

VMOVDDUP

VBROADCASTF32X2, VBROADCASTF32X4, VBROADCASTF64X2, VBROADCASTF32X8, VBROADCASTF64X4,

VBROADCASTI32X2, VBROADCASTI32X4, VBROADCASTI64X2, VBROADCASTI32X8, VBROADCASTI64X4,

VBROADCASTSD, VBROADCASTSS, VFPCLASSSD, VFPCLASSSS, VPBROADCASTB, VPBROADCASTD,

Type E6

VPBROADCASTW, VPBROADCASTQ, VPMOVQB, VPMOVSQB, VPMOVUSQB, VPMOVQW, VPMOVSQW, VPMOVUSQW,

VPMOVQD, VPMOVSQD, VPMOVUSQD, VPMOVDB, VPMOVSDB, VPMOVUSDB, VPMOVDW, VPMOVSDW,

VPMOVUSDW, VPMOVWB, VPMOVSWB, VPMOVUSWB

VEXTRACTF32X4, VEXTRACTF32X8, VEXTRACTF64X2, VEXTRACTF64X4, VEXTRACTI32X4, VEXTRACTI32X8,

Type E6NF

VEXTRACTI64X2, VEXTRACTI64X4, VINSERTF32X4, VINSERTF32X8, VINSERTF64X2, VINSERTF64X4,

VINSERTI32X4, VINSERTI32X8, VINSERTI64X2, VINSERTI64X4, VPBROADCASTMB2Q, VPBROADCASTMW2D

Type

VMOVHLPS, VMOVLHPS

E7NM.128⁴

(VPBROADCASTD, VPBROADCASTQ, VPBROADCASTB, VPBROADCASTW)⁵, VPMOVB2M, VPMOVD2M, VPMOVM2B,

Type E7NM.

VPMOVM2D, VPMOVM2Q, VPMOVM2W, VPMOVQ2M, VPMOVW2M

VEXTRACTPS, VINSERTPS, VMOVHPD, VMOVHPS, VMOVLPD, VMOVLPS, VMOVD, VMOVQ, VMOVW, VPEXTRB,

Type E9NF

VPEXTRD, VPEXTRW, VPEXTRQ, VPINSRB, VPINSRD, VPINSRW, VPINSRQ

VFCMADDCSH, VFMADDCSH, VFCMULCSH, VFMULCSH, VFPCLASSSH, VMOVSD, VMOVSS, VRCP14SD, VRCP14SS,

Type E10

VRCPSH, VRSQRT14SD, VRSQRT14SS, VRSQRTSH

Type E10NF

(VCVTSI2SD, VCVTUSI2SD)⁶

Type E11

VCVTPH2PS, VCVTPS2PH

Vol. 2A

2-47

INSTRUCTION FORMAT

Table 2-43. EVEX Instructions in Each Exception Class (Contd.)

Exception Class

Instruction

VGATHERDPS, VGATHERDPD, VGATHERQPS, VGATHERQPD, VPGATHERDD, VPGATHERDQ, VPGATHERQD,

Type E12

VPGATHERQQ, VPSCATTERDD, VPSCATTERDQ, VPSCATTERQD, VPSCATTERQQ, VSCATTERDPD, VSCATTERDPS,

VSCATTERQPD, VSCATTERQPS

VGATHERPF0DPD, VGATHERPF0DPS, VGATHERPF0QPD, VGATHERPF0QPS, VGATHERPF1DPD, VGATHERPF1DPS,

Type E12NP

VGATHERPF1QPD, VGATHERPF1QPS, VSCATTERPF0DPD, VSCATTERPF0DPS, VSCATTERPF0QPD,

VSCATTERPF0QPS, VSCATTERPF1DPD, VSCATTERPF1DPS, VSCATTERPF1QPD, VSCATTERPF1QPS

NOTES:

1. Operand encoding Full tupletype with immediate.

2. Embedded broadcast is not supported with the “.nb” suffix.

3. Operand encoding Mem128 tupletype.

4. #UD raised if EVEX.L’L !=00b (VL=128).

5. The source operand is a general purpose register.

6. W0 encoding only.

2.8.1

Exceptions Type E1 and E1NF of EVEX-Encoded Instructions

EVEX-encoded instructions with memory alignment restrictions, and supporting memory fault suppression follow

exception class E1.

Table 2-44. Type E1 Class Exception Conditions

Exception

Cause of Exception

If EVEX prefix present.

If CR4.OSXSAVE[bit 18]=0.

If any one of following conditions applies:

• State requirement, Table 2-37 not met.

• Opcode independent #UD condition in Table 2-38.

• Operand encoding #UD conditions in Table 2-39.

Invalid Opcode,

• Opmask encoding #UD condition of Table 2-40.

#UD

• EVEX.b encoding #UD condition of Table 2-41.

• Instruction specific EVEX.L'L restriction not met.

If preceded by a LOCK prefix (F0H).

If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.

If any corresponding CPUID feature flag is ‘0’.

2-48

Vol. 2A

INSTRUCTION FORMAT

Table 2-44. Type E1 Class Exception Conditions (Contd.)

Exception

Cause of Exception

Device Not Avail-

If CR0.TS[bit 3]=1.

able, #NM

If fault suppression not set, and an illegal address in the SS segment.

Stack, #SS(0)

If fault suppression not set, and a memory address referencing the SS segment is in

a non-canonical form.

EVEX.512: Memory operand is not 64-byte aligned.

EVEX.256: Memory operand is not 32-byte aligned.

EVEX.128: Memory operand is not 16-byte aligned.

General Protection,

If fault suppression not set, and an illegal memory operand effective address in the

#GP(0)

CS, DS, ES, FS or GS segments.

If fault suppression not set, and the memory address is in a non-canonical form.

If fault suppression not set, and any part of the operand lies outside the effective

address space from 0 to FFFFH.

Page Fault

If fault suppression not set, and a page fault.

#PF(fault-code)

Vol. 2A

2-49

INSTRUCTION FORMAT

EVEX-encoded instructions with memory alignment restrictions, but do not support memory fault suppression

follow exception class E1NF.

Table 2-45. Type E1NF Class Exception Conditions

Exception

Cause of Exception

If EVEX prefix present.

If CR4.OSXSAVE[bit 18]=0.

If any one of following conditions applies:

• State requirement, Table 2-37 not met.

• Opcode independent #UD condition in Table 2-38.

• Operand encoding #UD conditions in Table 2-39.

Invalid Opcode,

• Opmask encoding #UD condition of Table 2-40.

#UD

• EVEX.b encoding #UD condition of Table 2-41.

• Instruction specific EVEX.L'L restriction not met.

If preceded by a LOCK prefix (F0H).

If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.

If any corresponding CPUID feature flag is ‘0’.

Device Not Avail-

If CR0.TS[bit 3]=1.

able, #NM

For an illegal address in the SS segment.

Stack, #SS(0)

If a memory address referencing the SS segment is in a non-canonical form.

EVEX.512: Memory operand is not 64-byte aligned.

EVEX.256: Memory operand is not 32-byte aligned.

EVEX.128: Memory operand is not 16-byte aligned.

General Protection,

For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-

#GP(0)

ments.

If the memory address is in a non-canonical form.

If any part of the operand lies outside the effective address space from 0 to FFFFH.

Page Fault

For a page fault.

#PF(fault-code)

2-50

Vol. 2A

INSTRUCTION FORMAT

2.8.2

Exceptions Type E2 of EVEX-Encoded Instructions

EVEX-encoded vector instructions with arithmetic semantic follow exception class E2.

Table 2-46. Type E2 Class Exception Conditions

Exception

Cause of Exception

If EVEX prefix present.

If an unmasked SIMD floating-point exception and CR4.OSXMMEXCPT[bit 10] = 0.

If CR4.OSXSAVE[bit 18]=0.

If any one of following conditions applies:

• State requirement, Table 2-37 not met.

Invalid Opcode,

• Opcode independent #UD condition in Table 2-38.

#UD

• Operand encoding #UD conditions in Table 2-39.

• Opmask encoding #UD condition of Table 2-40.

• Instruction specific EVEX.L'L restriction not met.

If preceded by a LOCK prefix (F0H).

If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.

If any corresponding CPUID feature flag is ‘0’.

Device Not Avail-

If CR0.TS[bit 3]=1.

able, #NM

If fault suppression not set, and an illegal address in the SS segment.

Stack, #SS(0)

If fault suppression not set, and a memory address referencing the SS segment is in a

non-canonical form.

If fault suppression not set, and an illegal memory operand effective address in the CS,

DS, ES, FS or GS segments.

General Protec-

If fault suppression not set, and the memory address is in a non-canonical form.

tion, #GP(0)

If fault suppression not set, and any part of the operand lies outside the effective

address space from 0 to FFFFH.

Page Fault

If fault suppression not set, and a page fault.

#PF(fault-code)

Alignment Check

For 2, 4, or 8 byte memory access if alignment checking is enabled and an unaligned

#AC(0)

memory access is made while the current privilege level is 3.

SIMD Floating-

If an unmasked SIMD floating-point exception, {sae} or {er} not set, and CR4.OSXMMEX-

point Exception,

CPT[bit 10] = 1.

#XM

Vol. 2A

2-51

INSTRUCTION FORMAT

2.8.3

Exceptions Type E3 and E3NF of EVEX-Encoded Instructions

EVEX-encoded scalar instructions with arithmetic semantic that support memory fault suppression follow exception

class E3.

Table 2-47. Type E3 Class Exception Conditions

Exception

Cause of Exception

If EVEX prefix present.

If an unmasked SIMD floating-point exception and CR4.OSXMMEXCPT[bit 10] = 0.

If CR4.OSXSAVE[bit 18]=0.

If any one of following conditions applies:

• State requirement, Table 2-37 not met.

• Opcode independent #UD condition in Table 2-38.

Invalid Opcode, #UD

• Operand encoding #UD conditions in Table 2-39.

• Opmask encoding #UD condition of Table 2-40.

• EVEX.b encoding #UD condition of Table 2-41.

If preceded by a LOCK prefix (F0H).

If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.

If any corresponding CPUID feature flag is ‘0’.

Device Not Available,

If CR0.TS[bit 3]=1.

#NM

If fault suppression not set, and an illegal address in the SS segment.

Stack, #SS(0)

If fault suppression not set, and a memory address referencing the SS segment is

in a non-canonical form.

If fault suppression not set, and an illegal memory operand effective address in

the CS, DS, ES, FS or GS segments.

General Protection,

If fault suppression not set, and the memory address is in a non-canonical form.

#GP(0)

If fault suppression not set, and any part of the operand lies outside the effective

address space from 0 to FFFFH.

Page Fault #PF(fault-

If fault suppression not set, and a page fault.

code)

Alignment Check

For 2, 4, or 8 byte memory access if alignment checking is enabled and an

#AC(0)

unaligned memory access is made while the current privilege level is 3.

SIMD Floating-point

If an unmasked SIMD floating-point exception, {sae} or {er} not set, and CR4.OSX-

Exception, #XM

MMEXCPT[bit 10] = 1.

2-52

Vol. 2A

INSTRUCTION FORMAT

EVEX-encoded scalar instructions with arithmetic semantic that do not support memory fault suppression follow

exception class E3NF.

Table 2-48. Type E3NF Class Exception Conditions

Exception

Cause of Exception

EVEX prefix.

If an unmasked SIMD floating-point exception and CR4.OSXMMEXCPT[bit 10] = 0.

If CR4.OSXSAVE[bit 18]=0.

If any one of following conditions applies:

• State requirement, Table 2-37 not met.

• Opcode independent #UD condition in Table 2-38.

Invalid Opcode, #UD

• Operand encoding #UD conditions in Table 2-39.

• Opmask encoding #UD condition of Table 2-40.

• EVEX.b encoding #UD condition of Table 2-41.

If preceded by a LOCK prefix (F0H).

If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.

If any corresponding CPUID feature flag is ‘0’.

Device Not Available,

If CR0.TS[bit 3]=1.

#NM

For an illegal address in the SS segment.

Stack, #SS(0)

If a memory address referencing the SS segment is in a non-canonical form.

For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-

ments.

General Protection,

If the memory address is in a non-canonical form.

#GP(0)

If any part of the operand lies outside the effective address space from 0 to

FFFFH.

Page Fault #PF(fault-

For a page fault.

code)

Alignment Check

For 2, 4, or 8 byte memory access if alignment checking is enabled and an

#AC(0)

unaligned memory access is made while the current privilege level is 3.

SIMD Floating-point

If an unmasked SIMD floating-point exception, {sae} or {er} not set, and CR4.OSX-

Exception, #XM

MMEXCPT[bit 10] = 1.

Vol. 2A

2-53

INSTRUCTION FORMAT

2.8.4

Exceptions Type E4 and E4NF of EVEX-Encoded Instructions

EVEX-encoded vector instructions that cause no SIMD FP exception and support memory fault suppression follow

exception class E4.

Table 2-49. Type E4 Class Exception Conditions

Exception

Cause of Exception

If EVEX prefix present.

If CR4.OSXSAVE[bit 18]=0.

If any one of following conditions applies:

• State requirement, Table 2-37 not met.

• Opcode independent #UD condition in Table 2-38.

• Operand encoding #UD conditions in Table 2-39.

• Opmask encoding #UD condition of Table 2-40.

Invalid Opcode, #UD

• EVEX.b encoding #UD condition of Table 2-41 and in E4.nb subclass (see E4.nb

entries in Table 2-43).

• Instruction specific EVEX.L'L restriction not met.

If preceded by a LOCK prefix (F0H).

If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.

If any corresponding CPUID feature flag is ‘0’.

Device Not Available,

If CR0.TS[bit 3]=1.

#NM

If fault suppression not set, and an illegal address in the SS segment.

Stack, #SS(0)

If fault suppression not set, and a memory address referencing the SS segment is

in a non-canonical form.

If fault suppression not set, and an illegal memory operand effective address in

the CS, DS, ES, FS or GS segments.

General Protection,

#GP(0)

If fault suppression not set, and the memory address is in a non-canonical form.

If fault suppression not set, and any part of the operand lies outside the effective

address space from 0 to FFFFH.

Page Fault #PF(fault-

If fault suppression not set, and a page fault.

code)

Alignment Check

For 2, 4, or 8 byte memory access if alignment checking is enabled and an

#AC(0)

unaligned memory access is made while the current privilege level is 3.

2-54

Vol. 2A

INSTRUCTION FORMAT

EVEX-encoded vector instructions that do not cause SIMD FP exception nor support memory fault suppression

follow exception class E4NF.

Table 2-50. Type E4NF Class Exception Conditions

Exception

Cause of Exception

If EVEX prefix present.

If CR4.OSXSAVE[bit 18]=0.

If any one of following conditions applies:

• State requirement, Table 2-37 not met.

• Opcode independent #UD condition in Table 2-38.

• Operand encoding #UD conditions in Table 2-39.

• Opmask encoding #UD condition of Table 2-40.

Invalid Opcode, #UD

• EVEX.b encoding #UD condition of Table 2-41 and in E4NF.nb subclass (see

E4NF.nb entries in Table 2-43).

• Instruction specific EVEX.L'L restriction not met.

If preceded by a LOCK prefix (F0H).

If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.

If any corresponding CPUID feature flag is ‘0’.

Device Not Available,

If CR0.TS[bit 3]=1.

#NM

For an illegal address in the SS segment.

Stack, #SS(0)

If a memory address referencing the SS segment is in a non-canonical form.

For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-

ments.

General Protection,

#GP(0)

If the memory address is in a non-canonical form.

If any part of the operand lies outside the effective address space from 0 to

FFFFH.

Page Fault #PF(fault-

For a page fault.

code)

Vol. 2A

2-55

INSTRUCTION FORMAT

2.8.5

Exceptions Type E5 and E5NF

EVEX-encoded scalar/partial-vector instructions that cause no SIMD FP exception and support memory fault

suppression follow exception class E5.

Table 2-51. Type E5 Class Exception Conditions

Exception

Cause of Exception

If EVEX prefix present.

If CR4.OSXSAVE[bit 18]=0.

If any one of following conditions applies:

• State requirement, Table 2-37 not met.

• Opcode independent #UD condition in Table 2-38.

• Operand encoding #UD conditions in Table 2-39.

Invalid Opcode, #UD

• Opmask encoding #UD condition of Table 2-40.

• EVEX.b encoding #UD condition of Table 2-41.

• Instruction specific EVEX.L'L restriction not met.

If preceded by a LOCK prefix (F0H).

If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.

If any corresponding CPUID feature flag is ‘0’.

Device Not Available,

If CR0.TS[bit 3]=1.

#NM

If fault suppression not set, and an illegal address in the SS segment.

Stack, #SS(0)

If fault suppression not set, and a memory address referencing the SS segment is

in a non-canonical form.

If fault suppression not set, and an illegal memory operand effective address in the

CS, DS, ES, FS or GS segments.

General Protection,

If fault suppression not set, and the memory address is in a non-canonical form.

#GP(0)

If fault suppression not set, and any part of the operand lies outside the effective

address space from 0 to FFFFH.

Page Fault #PF(fault-

If fault suppression not set, and a page fault.

code)

Alignment Check

For 2, 4, or 8 byte memory access if alignment checking is enabled and an

#AC(0)

unaligned memory access is made while the current privilege level is 3.

EVEX-encoded scalar/partial vector instructions that do not cause SIMD FP exception nor support memory fault

suppression follow exception class E5NF.

2-56

Vol. 2A

INSTRUCTION FORMAT

Table 2-52. Type E5NF Class Exception Conditions

Exception

Cause of Exception

If EVEX prefix present.

If CR4.OSXSAVE[bit 18]=0.

If any one of following conditions applies:

• State requirement, Table 2-37 not met.

• Opcode independent #UD condition in Table 2-38.

• Operand encoding #UD conditions in Table 2-39.

Invalid Opcode, #UD

• Opmask encoding #UD condition of Table 2-40.

• EVEX.b encoding #UD condition of Table 2-41.

• Instruction specific EVEX.L'L restriction not met.

If preceded by a LOCK prefix (F0H).

If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.

If any corresponding CPUID feature flag is ‘0’.

Device Not Available,

If CR0.TS[bit 3]=1.

#NM

If an illegal address in the SS segment.

Stack, #SS(0)

If a memory address referencing the SS segment is in a non-canonical form.

If an illegal memory operand effective address in the CS, DS, ES, FS or GS segments.

General Protection,

If the memory address is in a non-canonical form.

#GP(0)

If any part of the operand lies outside the effective address space from 0 to

FFFFH.

Page Fault #PF(fault-

For a page fault.

code)

Alignment Check

For 2, 4, or 8 byte memory access if alignment checking is enabled and an

#AC(0)

unaligned memory access is made while the current privilege level is 3.

Vol. 2A

2-57

INSTRUCTION FORMAT

2.8.6

Exceptions Type E6 and E6NF

Table 2-53. Type E6 Class Exception Conditions

Exception

Cause of Exception

If EVEX prefix present.

If CR4.OSXSAVE[bit 18]=0.

If any one of following conditions applies:

• State requirement, Table 2-37 not met.

• Opcode independent #UD condition in Table 2-38.

• Operand encoding #UD conditions in Table 2-39.

Invalid Opcode, #UD

• Opmask encoding #UD condition of Table 2-40.

• EVEX.b encoding #UD condition of Table 2-41.

• Instruction specific EVEX.L'L restriction not met.

If preceded by a LOCK prefix (F0H).

If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.

If any corresponding CPUID feature flag is ‘0’.

Device Not Available,

If CR0.TS[bit 3]=1.

#NM

If fault suppression not set, and an illegal address in the SS segment.

Stack, #SS(0)

If fault suppression not set, and a memory address referencing the SS segment is

in a non-canonical form.

If fault suppression not set, and an illegal memory operand effective address in the

General Protection,

CS, DS, ES, FS or GS segments.

#GP(0)

If fault suppression not set, and the memory address is in a non-canonical form.

Page Fault #PF(fault-

If fault suppression not set, and a page fault.

code)

Alignment Check

For 2, 4, or 8 byte memory access if alignment checking is enabled and an

#AC(0)

unaligned memory access is made while the current privilege level is 3.

2-58

Vol. 2A

INSTRUCTION FORMAT

EVEX-encoded instructions that do not cause SIMD FP exception nor support memory fault suppression follow

exception class E6NF.

Table 2-54. Type E6NF Class Exception Conditions

Exception

Cause of Exception

Invalid Opcode, #UD

If EVEX prefix present.

If CR4.OSXSAVE[bit 18]=0.

If any one of following conditions applies:

• State requirement, Table 2-37 not met.

• Opcode independent #UD condition in Table 2-38.

• Operand encoding #UD conditions in Table 2-39.

• Opmask encoding #UD condition of Table 2-40.

• EVEX.b encoding #UD condition of Table 2-41.

• Instruction specific EVEX.L'L restriction not met.

If preceded by a LOCK prefix (F0H).

If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.

If any corresponding CPUID feature flag is ‘0’.

Device Not Available,

If CR0.TS[bit 3]=1.

#NM

For an illegal address in the SS segment.

Stack, #SS(0)

If a memory address referencing the SS segment is in a non-canonical form.

For an illegal memory operand effective address in the CS, DS, ES, FS or GS seg-

General Protection,

ments.

#GP(0)

If the memory address is in a non-canonical form.

Page Fault #PF(fault-

For a page fault.

code)

Alignment Check

For 2, 4, or 8 byte memory access if alignment checking is enabled and an

#AC(0)

unaligned memory access is made while the current privilege level is 3.

Vol. 2A

2-59

INSTRUCTION FORMAT

2.8.7

Exceptions Type E7NM

EVEX-encoded instructions that cause no SIMD FP exception and do not reference memory follow exception class

E7NM.

Table 2-55. Type E7NM Class Exception Conditions

Exception

Cause of Exception

If EVEX prefix present.

If CR4.OSXSAVE[bit 18]=0.

If any one of following conditions applies:

• State requirement, Table 2-37 not met.

• Opcode independent #UD condition in Table 2-38.

• Operand encoding #UD conditions in Table 2-39.

Invalid Opcode, #UD

• Opmask encoding #UD condition of Table 2-40.

• EVEX.b encoding #UD condition of Table 2-41.

• Instruction specific EVEX.L’L restriction not met.

If preceded by a LOCK prefix (F0H).

If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.

If any corresponding CPUID feature flag is ‘0’.

Device Not Available,

If CR0.TS[bit 3]=1.

#NM

2-60

Vol. 2A

INSTRUCTION FORMAT

2.8.8

Exceptions Type E9 and E9NF

EVEX-encoded vector or partial-vector instructions that do not cause no SIMD FP exception and support memory

fault suppression follow exception class E9.

Table 2-56. Type E9 Class Exception Conditions

Exception

Cause of Exception

If EVEX prefix present.

If CR4.OSXSAVE[bit 18]=0.

If any one of following conditions applies:

• State requirement, Table 2-37 not met.

• Opcode independent #UD condition in Table 2-38.

• Operand encoding #UD conditions in Table 2-39.

Invalid Opcode, #UD

• Opmask encoding #UD condition of Table 2-40.

• EVEX.b encoding #UD condition of Table 2-41.

• Instruction specific EVEX.L'L restriction not met.

If preceded by a LOCK prefix (F0H).

If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.

If any corresponding CPUID feature flag is ‘0’.

Device Not Available,

If CR0.TS[bit 3]=1.

#NM

If fault suppression not set, and an illegal address in the SS segment.

Stack, #SS(0)

If fault suppression not set, and a memory address referencing the SS segment is

in a non-canonical form.

If fault suppression not set, and an illegal memory operand effective address in the

CS, DS, ES, FS or GS segments.

General Protection,

If fault suppression not set, and the memory address is in a non-canonical form.

#GP(0)

If fault suppression not set, and any part of the operand lies outside the effective

address space from 0 to FFFFH.

Page Fault #PF(fault-

If fault suppression not set, and a page fault.

code)

Alignment Check

For 2, 4, or 8 byte memory access if alignment checking is enabled and an

#AC(0)

unaligned memory access is made while the current privilege level is 3.

Vol. 2A

2-61

INSTRUCTION FORMAT

EVEX-encoded vector or partial-vector instructions that must be encoded with VEX.L’L = 0, do not cause SIMD FP

exception nor support memory fault suppression follow exception class E9NF.

Table 2-57. Type E9NF Class Exception Conditions

Exception

Cause of Exception

If EVEX prefix present.

If CR4.OSXSAVE[bit 18]=0.

If any one of following conditions applies:

• State requirement, Table 2-37 not met.

• Opcode independent #UD condition in Table 2-38.

• Operand encoding #UD conditions in Table 2-39.

Invalid Opcode, #UD

• Opmask encoding #UD condition of Table 2-40.

• EVEX.b encoding #UD condition of Table 2-41.

• Instruction specific EVEX.L'L restriction not met.

If preceded by a LOCK prefix (F0H).

If any REX, F2, F3, or 66 prefixes precede a EVEX prefix.

If any corresponding CPUID feature flag is ‘0’.

Device Not Available,

If CR0.TS[bit 3]=1.

#NM

If an illegal address in the SS segment.

Stack, #SS(0)

If a memory address referencing the SS segment is in a non-canonical form.

If an illegal memory operand effective address in the CS, DS, ES, FS or GS segments.

General Protection,

If the memory address is in a non-canonical form.

#GP(0)

If any part of the operand lies outside the effective address space from 0 to

FFFFH.

Page Fault #PF(fault-

For a page fault.

code)

Alignment Check

For 2, 4, or 8 byte memory access if alignment checking is enabled and an

#AC(0)

unaligned memory access is made while the current privilege level is 3.

2-62

Vol. 2A

Intel 64 and IA-32 Architectures. Software Developer’s Manual (Collection, 2023) - page 63
